Thermaltake Toughpower Ultra Slim 65W User manual

ToughpowerTM
Ultra Slim 65W / 90W
Universal Laptop AC Power Adapter
Setup GuideSetup Guide
P/N:ADP65W0004 / ADP90W005
www.thermaltake.com

ToughpowerTM
Ultra Slim 65W / 90W
P/N:ADP65W0004 / ADP90W0005
1
2
3
Check your original adapter spec
Select your Tips
Connect the tip to Terminal B
www.thermaltake.com
It showed the output voltage is DC
19V, output current is 4.74A, 65W &
90W adapter supports the output
range from 18V~20V
Original DC tip
Choose a tip which is the same
as the original DC tip.
Terminal B
(fool-proof built in)

Terminal B connected
4
5
Connect the tip with your laptop.
The system will display on screen from battery mode change to AC mode
ToughpowerTM
Ultra Slim 65W / 90W
P/N:ADP65W0004 / ADP90W0005
www.thermaltake.com

Charge USB device by 65W or 90W adapter
6
You can charge any electrical device such as mobile phone, MP3, USB
mobile power bank, PDA, etc. Please make sure your electrical device
consumes 5V input, some devices may need additional power charging
connectors.
When applying the USB
charger, please connect the
power charge cable of your
electrical device to the USB
port of your adapter.
