Thermocore Systems T1-PACH-14 User manual

Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just
a little preventative care on your part can save you a great deal of time and money over the life of
your air conditioner. Before operating this product, please read the instructions carefully and save this
manual for future use.
PORTABLE AIR CONDITIONERS
T1-PACH-14: 14000 BTU Cooling and Heating
www.thermospace.com

CONTENTS
SOCIABLE REMARK
Sociable remark..................................................................................................................................2
The rating data indicated on the energy label is based
on the testing condition of installing an un-extended
air exhaust duct without adaptor B (please refer to
the accessories chart on page 4.)
NOTE
1
SAFETY PRECAUTIONS
Safety rules .......................................................................................................................................3
Operating condition ...........................................................................................................................3
Electrical information .........................................................................................................................4
Accessories .......................................................................................................................................4
Names of parts...................................................................................................................................5
Electronic control operating instructions ...........................................................................................6
Operating instructions .......................................................................................................................7
Location ............................................................................................................................................9
Window kit installation ......................................................................................................................9
Exhaust hose installation ................................................................................................................12
Though-the-wall connection ..............................................................................................................12
Water drainage ................................................................................................................................13
Care and maintenance ....................................................................................................................14
Trouble shooting ..............................................................................................................................15
Replacing batteries ...........................................................................................................................16
Function buttons ...............................................................................................................................17
Indicators on LCD ............................................................................................................................18
Using the remote controller .............................................................................................................19
AIR CONDITIONER FEATURES
CARE AND MAINTENANCE
TROUBLESHOOTING TIPS
OPERATING INSTRUCTIONS
INSTALLATION INSTRUCTIONS
IDENTIFICATION OF PARTS
HANDLING THE REMOTE CONTROLLER
YOUR GUARANTEE

SOCIABLE REMARK
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste.
For disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can be
disposed of at least free of charge to the user.
B) The manufacture will take back the old appliance for disposal at least free of charge
to the user.
C) As old products contain valuable resources, they can be sold to scrap metal dealers.
Wild disposal of waste in forests and landscapes endangers your health when
hazardous substances leak into the ground-water and find their way into the food chain.
2
CAUTION:
This appliance is not intended for use by persons (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless
they are being supervised or been given instruction concerning the use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

3
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
SAFETY PRECAUTIONS
!
Always do this Never do this
Energy Save
The air conditioner must be operated within the temperature range indicated below:
Operating condition
Safety rules
Suggested tools for window kit installation
1. Screwdriver(medium size Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw(In the event that the window kit needs to be cut down in size because
the window is too narrow for direct installation)
MODE
ROOM TEMPERATURE
COOL
62°F~95°F (17°C~35°C)
DRY
55°F~95°F (13°C~35°C)
HEAT (heating models only)
41°F~88°F (5°C~30°C)
Your air conditioner should be used in such a way
that it is protected from moisture. e.g.
condensation, splashed water, etc. Do not place or
store your air conditioner where it can fall or be
pulled into water or any other liquid.
Always transport your air conditioner in a vertical
position and stand on a stable, level surface.
Turn off the product when not in use.
Always contact a qualified person to carry out
repairs. If the power cord is damaged, it must be
repaired by a qualified electrician.
Keep an clearance of at least 12 inches around the
unit for proper airflow (from walls, furniture and
curtains).
If the unit is knocked over during use, turn off
power immediately and unplug from power source.
Never leave the unit unsupervised when in
operation.
When unit is not in good order, please use
common sense to prevent further damage to
surroundings.
Do not operate your air conditioner in a wet/damp
room such as a bathroom or laundry room.
Do not touch the unit with wet or damp hands or
when barefoot.
Do not press the buttons on the control panel with
anything other than your fingers.
Do not remove any fixed covers. Never use this
appliance if it is not working properly, or if it has
been dropped or damaged.
Never use the plug to start and stop the unit.
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or allow
to come into contact with the unit.
Do not use the unit in the presence of flammable
substances or vapor such as alcohol, insecticides,
petrol, etc.
Do not allow children to operate the unit
unsupervised.
Do not use this product for functions other than
those described in this instruction manual.
Use the unit in the recommended room size.
Locate the unit where furniture cannot obstruct the air flow.
Keep blinds/curtains closed during the sunniest part of the day.
Keep the filters clean.
Keep doors and windows closed to keep cool air in and warm air out.
If a very hot day is expected, turn on the unit early to keep the room cool and keep the heat out.

4
Be sure the electrical service is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding is
important. The power cord is equipped with a three-prong grounding plug for protection against shock
hazards.
Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend
to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified
electrician install the proper receptacle.
Ensure the receptacle is accessible after the unit installation.
WARNING For your safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove
any prong from the power cord.
WARNING Electrical Infor mation
IDENTIFICATION OF PARTS
Accessories
* Check to ensure all accessories are included in the package. Please refer to the installation instructions for
their usage.
PARTS :
PARTS NAME : QUANTITY :
1 set
Adaptor A (connects unit to hose)
Adaptor B (connects hose to slider kit)
Exhaust Hose
Window Slider Kit and bolt
Foam seal
3/pcs
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
FOLLOW
ME LED
DISPLAY
ION
TURBO
Remote Controller
(Requires 2 AAA batteries, not included)
1pc
Drain hose and drain hose adaptor
1pc
All the illustrations in this manual are for explanation purpose only. Your air conditioner
may be slightly different. The actual shape shall prevail.
NOTE:
Wall adaptor for through-the-wall installation
(not included, option to purchase)
Please refer to page 12 for installation instructions

IDENTIFICATION OF PARTS
5
NAMES OF PARTS
Front
Rear
Control panel
Horizontal louver blade
(swings automatically)
Caster
Carrying handle
(both sides)
3
1
2
3
4
6
7
8
9
10
11
Upper air intake
12
Fig.1
13
1
2
4
Fig.2
5
7
9
8
15
14
13
12
5Upper air filter
(Behind the grille)
6
10
11
Air outlet
Drain outlet
(Heating models only)
Power cord outlet
Power cord bracket
(for storage purposes only)
Bottom tray drain outlet
Power plug socket
(for storage purposes only)
Lower air filter
(Behind the grille)
14
Lower air intake
15
Drain outlet

6
AIR CONDITIONER FEATURES
Before you begin, thoroughly familiarize yourself with the functions of the control panel and
remote controller, then follow the symbol for the functions you desire.
The unit can be controlled by the unit control panel alone or with the remote controller .
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Fig.3
OPERATION PANEL OF THE AIR CONDITIONER
15
3
4
Used to initiate the SLEEP operation.
SLEEP button
Controls the fan speed. Press to select the fan
speed in four steps: LOW, MED, HI and AUTO.
The corresponding speed indicator light will illuminate,
except for AUTO speed. When AUTO speed is selected,
all fan indicators are dark.
FAN button
1
2344567
8
Selects the appropriate operating mode.
Each press of the button will select mode
in the following sequence: AUTO, COOL,
DRY, FAN and HEAT(heating models only).
The corresponding mode indicator light
will illuminate.
MODE select button
Power switch, press to turn on/off.
POWER button
2
UP( ) and DOWN( ) button
+-
6TIMER button
Used to initiate the AUTO ON (start time) and
AUTO OFF (stop time) programs. Used in
conjunction with the + and - buttons. The
corresponding timer indicator light will illuminate.
7SWING button
Used to initiate the Auto swing feature. If
auto-swing is in function, press the button
again to stop the louver at desired angle.
Displays set temperature, in either °C or °F.
Displays auto-timer settings (if any)
When unit is in DRY or FAN modes, displays
current room temperature.
LED Display
8
FAN
Used to increase or decrease temperature
setting in 1°C or 2°F increments.
Adjustable range: 62°F-88°F (17°C-30°C)
Also used to set timer between 0-24 hours
NOTE: The control is capable of displaying
temperature in Fahrenheit or Celsius. To
convert from one to the other, press and
hold the UP and DOWN buttons
simultaneously for 3 seconds.

7
OPERATING INSTRUCTIONS
Operating Instructions
- Press the MODE button until the "COOL"
indicator light comes on.
- Press the + or - buttons to set desired room
temperature. The temperature range is between
62°F-88°F (17°C-30°C).
- Press the FAN button to choose the
desired fan speed.
- Press the MODE button until the "DRY"
indicator light comes on.
- Under this mode, you cannot select a fan
speed or adjust the temperature. The fan
motor operates at LOW speed.
- Keep windows and doors closed for the
best dehumidifying effect.
- Do not connect exhaust hose fixture to window.
COOL operation
- Press the MODE button until the "FAN "
indicator light comes on.
- Press the FAN SPEED button to
select desired fan speed. The temperature
cannot be adjusted.
- Do not connect exhaust hose fixture to window.
FAN operation
TIMER operation
- Press the MODE button until the "HEAT"
indicator light comes on.
- Press the + or - buttons to set desired room
temperature. The temperature range is between
62°F-88°F (17°C-30°C).
- Press the FAN button to choose the desired
fan speed.
HEAT operation (heating models only)
AUTO operation
- When you set the air conditioner in AUTO
mode, it will automatically select cooling,
heating (for heating models only), or
fan mode, depending on set temperature
and ambient room temperature.
- The air conditioner will operate in the
appropriate mode based on the set
temperature.
- Under AUTO mode, you can not
select the fan speed.
- When the unit is on, pressing the
TIMER button will initiate the auto-stop
program, the TIMER OFF indicator light
will illuminate. Press the + or - buttons to
set the time for unit to turn off.
Press the TIMER button again within 5
seconds will initiate the auto-start
program, the TIMER ON indicator light
will illuminate. Press the + or - buttons to
set the time for unit to turn on.
- When the unit is off, pressing the
TIMER button will initiate the auto-start
program; press again within 5 seconds to
initiate auto-stop program.
- Press or hold the +/- button to change time
in 0.5 hour increments, up to 10 hours;
then in 1 hour increments, up to 24 hours.
The control panel will count down the
remaining time until program begins.
- The display will automatically revert
back to displaying the previous
temperature setting if there is no activity
within a 5 second period.
- After timer has been programmed, if unit
is manually turned ON or OFF; or if the
timer setting is adjusted to 0.0, any timer
programmed will be cancelled.
- When unit malfunctions and error codes
E1, E2, E3 or E4 is displayed, timer
programs will also be cancelled.
Error codes and protection code:
E1- Room temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
E2- Evaporator temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call for service.
E3- Condenser temperature sensor error-
Unplug the unit and plug it back in. If error
repeats, call for service.
E4- Display panel communication error-
Unplug the unit and plug it back in.
If error repeats, call for service.
P1- Bottom tray is full - Connect the drain
hose to drain and empty the bottom tray.
If protection repeats, call for service.
DRY (dehumidify) operation

8
OPERATING INSTRUCTIONS
Fig.4
Other features
After the unit has stopped (or powered off), there
will be a 3-minute delay before unit will start up
again. This is to protect the compressor. Operation
will automatically resume after 3 minutes.
Wait 3 minutes before resuming operation
SLEEP operation
If the unit breaks off unexpectedly due to
power cut, it will restart at previous function
when the power resumes.
Auto-Restart
The louver can be adjusted automatically (Fig. 4):
- When unit powers ON, the louver opens fully.
- Press the SWING button on the panel or
remote controller to initiate the Auto swing
feature. The louver will automatically swing
up and down.
- Press SWING button again at desired angle
for set air flow.
- Please do not adjust the louver manually.
Air flow direction adjustment
Swing automatically
- If unit is running in COOL mode when SLEEP
function is activated, unit will automatically
increase set temperature by 1°C/2°F after 30
minutes. After another 30 minutes, unit will
again increase temperature by 1°C/2°F.
- If unit is running in HEAT mode (heating
models only) when SLEEP function is
activated, unit will automatically decrease set
temperature by 1°C/2°F after 30 minutes. After
another 30 minutes, unit will again decrease
temperature by 1°C/2°F.
- Unit will maintain the new temperature for 7
hours, then returns to original set temperature.
This ends the Sleep function and unit will
continue to operate as originally programmed.
Note: This feature is unavailable under FAN or
DRY mode

INSTALLATION INSTRUCTIONS
Horizontal
window
Window Slider Kit
Minimum: 26.57”
Maxmum: 48.43”
Horizontal
window
Fig.6
Fig.7
Fig.5
Location
The air conditioner should be placed on a firm
foundation to minimize noise and virbration. For
safe and secure positioning, place the unit on a
smooth, level floor strong enough to support the unit.
The unit has casters to aid placement, but it should
only be rolled on smooth, flat surfaces. Use caution
when rolling on carpet. Do not attempt to roll the
unit over objects.
The unit must be placed within reach of a properly
grounded socket.
Never place any obstacles around the air inlet or
outlet of the unit.
Allow 12 to 40 inches of space between the back
of the unit and the wall for efficient air-conditioning.
Your window slider kit has been designed to fit most
standard vertical and horizontal window applications.
However, it may be necessary for you to improvise or
modify some aspects of the installation procedures
for certain types of windows. Please refer to Fig. 6
and Fig.7 for minimum and maximum window
opening requirements.
Window slider kit can be fixed with a bolt (Fig.7a).
Window slider kit Installation
B
A
INSTALLATION INSTRUCTIONS
9
bolt
Window slider kit
Fig.7a
A: 12-40 inches. B: 12 inches
Note: If the window opening is less than the
minimum required length and the slider kit needs to
be cut down to size, cut the piece with the hole in it,
but cut the end without the hole.
Do Not cut out the hole in the slider kit.
Slider kit length: 26.5 to 48 inches.
Window opening requirements:
Minimum = 26.57 inches
Maximum = 48.43 inches
Window Slider Kit
Minimum: 26.57”
Maxmum: 48.43”

INSTALLATION INSTRUCTIONS
10
Installation for a double-hung sash window
1. Trim foam seal (with adhesive) to the proper length and
attach to window stool (Fig.8)
2. Adjust the length of the slider kit according to the width
of the window. Place slider kit to window stool, on top of
foam seal (Fig.9)
3. Trim another foam seal (with adhesive) to the proper
length and place on top of the slider kit (Fig.10).
4. Close the window sash securely against the kit.
5. Trim the last foam seal to the proper length to seal
the open gap between the top window sash and
outer window sash (Fig.11)
Foam seal A
(adhesive type)
Foam seal
Fig.8
Fig.9
Fig.10
Fig.11
Window kit
Window stool
Window kit
Window stool
C

INSTALLATION INSTRUCTIONS
11
Installation for sliding sash window
1. Trim foam seal (with adhesive) to the proper length
and attach to window frame (Fig.12).
2. Adjust the length of the slider kit according to the height
of the window. Place window slider kit against foam
seal (Fig.13).
3. Trim another foam seal (with adhesive) to the proper length
and attach it to the open side of slider kit (Fig.14).
4. Slide window close against the slider kit.
5. Trim the last foam seal to the proper length to seal the
open gap between the two window sashes (Fig.15).
Foam seal
Foam seal A
(adhesive type)
Fig.12
Fig.13
Fig.14
Fig.15
Window
panel
C
NOTE: All illustrations in this manual are for explanation
purposes only. Your unit may differ slightly. The
actual shape shall prevail.

INSTALLATION INSTRUCTIONS
Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed
in accordance with the usage mode.
1. Attach both adaptors A and B to exhaust hose. Extend each
end of the hose by couple inches and turn the adaptors
as shown in Fig.16. Do not over-tighten. Refer to previous
pages for window kit installation.
2. Align the hooks on adaptor A to the openings of the air
outlet. Insert and slide downwards to install. (Fig. 17)
12
Fig.16
Fig.17
Fig.19
Through-the wall connection
NOTE: It is necessary to purchase the following parts for
through-the-wall installation:
1. Prepare a hole in the wall and install the Wall Adaptor to the
opening (from outside). Secure with 4 expansion plugs and
screws. (Fig.18)
2. Attach exhaust hose to the Wall Adaptor.
Note: The wall adaptor does NOT have threading to fit onto
the hose. Its circumference is smaller than the hose and is
designed to fit inside the hose. You may want to use foil tape
(not included) on the inside wall to affix the hose and seal
off any openings.
Cover the hole using the adaptor cap when not in use.
IMPORTANT:
DO NOT OVER BEND THE EXHAUST HOSE (SEE Fig.19)
The exhaust hose can be compressed or extended moderately
according to the installation requirement, but it is desirable to
keep the hose length to a minimum.
Fig.18
max 47 inches
min 12 inches
Wall Adaptor
Expansion plug
position
Cap
COOL, HEAT (heating models only)
or AUTO mode
FAN or DEHUMIDIFY mode
Install
Remove
CAUTION:
Make sure there are no obstacles blocking the air outlet of
the exhaust hose (in the range of 20 inches), for the exhaust
system to work properly.
Opening
Hook
Wall Adaptor
(sold separately, please contact
Sunpentown at 1-800-330-0388 or visit
www.sunpentown.com)
Screws & expansion plugs
(can be purchased at any hardware store)

INSTALLATION INSTRUCTIONS
13
Water drainage:
Fig.22
Continuous Drainage (optional) - COOL/DRY modes
Remove the upper drain plug from back of unit.
Attach drain connector (5/8” universal female
mender) to a 3/4” hose (not included, purchase
from any hardware store). Connect to spout.
Position the open end directly over drain area.
(Fig.20a)
Continuous Drainage (required) - HEAT mode
(heating models only)
Remove the lower drain plug from back of the
unit.
Attach drain connector (5/8” universal female
mender) to a 3/4” hose (not included, purchase
from any hardware store). Connect to spout.
Position the open end directly over drain area.
(Fig.20b)
 The continuous drain for Heat mode has a built-in
pump, maximum height for drain hose is 5 feet.
NOTE: Make sure connections are secure to prevent
leakage. Make sure there are no kinks that may
stop the water ow. Do not direct the hose more
than 5 feet upwards as in Fig. 21a and 21b.
Emptying the Water Tank
When the water in the bottom tray reaches its
maximum capacity, the unit will beep 8 times and
display will show “P1”. At this time, the
compressor will immediately stop (AC, Dry or
Heat) but fan will continue to operate.
Place a collection pan underneath the drain spout
or carefully move the unit to a drain location.
Remove the bottom drain plug and water will
begin to drain out. Fig.22
Replace the drain plug and restart unit. P1
indication should disappear.
Note: Be sure to replace the drain plug before
restarting the unit.
up to 5’ more than 5’

CARE AND MAINTENANCE
CARE AND MAINTENANCE
14
1) Be sure to unplug the unit before cleaning or servicing.
2) Do not use gasoline, thinner or other chemicals to clean
the unit.
3) Do not wash the unit directly under a tap or spray with
water hose. It may cause electrical danger.
4) If the power cord is damaged, it should be repaired by
manufacture or its certified electrician.
1. Air filter
- Clean the air filter at least once every two weeks to prevent
inferior fan operation due to dust accumulation.
- Removal (This unit has two filters)
Upper Filter: Pull and remove according to arrow direction
in Fig. 23.
Lower Filter: First remove the screw as indicated in Fig.23,
remove filter.
- Cleaning
Wash the air filters by immersing gently in warm water
O O
(about 40 C/104 F) with a neutral detergent. Rinse the filters
and allow to dry completely in a shady area - do not place
under direct sunlight.
- Mounting
Replace upper filter according to arrow direction in Fig.24
Replace lower filter and reinsert the screw. (Fig.24)
2. Housing
- Use a lint-free cloth soaked with neutral detergent to clean
the unit’s housing. Finished by a dry clean cloth.
3. Storage
- Remove the rubber plug at the back of the unit and attach
a hose to drain outlet. Place the open end of the hose
directly over the drain area (See Fig.20 & 21).
- Drain water from the bottom tray by removing the plug from
the bottom drain outlet (See Fig.22).
- Turn unit on and run in FAN for half a day in a warm room.
This will dry the inside of the unit and prevent mold and
mildew growth.
- Power off the unit and unplug from power source. Wrap the
cord around the bracket and insert plug into the storage
socket. (Fig.25)
- Clean both filters and reinstall.
- Remove batteries from the remote and store with unit.
- Cover with a plastic bag and store in a cool, dry place.

TROUBLESHOOTING TIPS
TROUBLE SHOOTING
1. Unit will not start
- P1 appears in the display window
Drain the water in the bottom tray.
TROUBLES
POSSIBLE CAUSES
SUGGEST REMEDIES
Adjust the set temperature.
Make sure all the windows and
doors are closed.
Remove the heat sources if possible.
Connect the duct and make
sure it can function properly.
Decrease the set temperature.
Clean the air filters.
- Room temperature is lower than
the set temperature.(Cooling mode)
- The windows or doors in the room
are not closed.
- There are heat sources inside the
room.
- Exhaust air duct is not connected or
blocked.
- Temperature setting is too high.
- Air filters are dirty.
2. Not cool enough
Place the unit on a flat, level
ground if possible.
This is normal.
- The ground is not level or not flat
enough.
- This is the sound of refrigerant
flowing inside the unit.
4. Noisy or vibration
5. Gurgling sound
15
Switch on again after the unit
has cooled down.
- Overheat protection. When the
temperature at the air outlet
O O
exceeds 70 C/158 F, the unit
will automatically shut off as a
protection feature.
6. Power shuts off in
Heat mode
(heating models only)

Use the remote controller within a distance of 26 feet
from the appliance, pointing it towards the receiver.
Reception is confirmed by a beep.
Location of the remote controller.
26’
CAUTIONS
The air conditioner will not respond if curtains, doors or other barriers
block the signal from the remote controller to the unit.
Prevent any liquid from coming in contact with the remote controller.
Do not expose the remote controller to direct sunlight or heat.
If the infrared signal receiver on the unit is exposed to direct sunlight,
the air conditioner may not respond. Close curtains/blinds to block
sunlight from falling on the receiver.
If other electrical appliances react to the remote controller, move
those appliances if possible.
The remote controller is powered by two AAA batteries (not included).
The batteries are housed in the back of remote, protected by a cover.
(1) Remove the cover by pressing down and sliding off.
(2) Remove the old batteries and insert new batteries, placing the
(+) and (-) ends correctly.
(3) Replace cover by sliding it back into position.
NOTE: When the batteries are removed, any programming
will be erased. After inserting the new batteries, the remote controller
can be reprogrammed.
Replacing batteries
.
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
FOLLOW
ME LED
DISPLAY
ION
TURBO
HANDLING THE REMOTE CONTROLLER
16
CAUTIONS
Do not mix old and new batteries or batteries of a different type.
Do not leave the batteries in the remote controller if it is not going to be used for extended period
of time (2 months or more).
Dispose old batteries at recycling centers - contact your local government for disposal practices
in your area.
1. Operating Mode: AUTO, COOL, DRY, HEAT (Heating models only) and FAN.
2. Timer Setting Function in 24 hours.
3. Indoor Setting Temperature Range: 62°F to 88°F (17°C to 30°C)
4. Full function of LCD (Liquid Crystal Display)
(Operating temperature: -41°F to 140°F (-5°C to 60°C)
Performance Feature
All illustrations in this manual are for explanation purpose only. Your air conditioner
may be differ slightly. The actual shape shall prevail.
NOTE:

Function buttons
1
TEMP DOWN Button
Push this button to decrease set temperature, in
increments of 2°F (1°C). Lowest is 62°F (17°C°)
2
TEMP UP Button
Push this button to increase set temperature, in
increments of 2°F (1°C). Highest 88°F (30°C°)
Each time the button is pressed, the operation
mode is selected in the following sequence:
3
MODE Button
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
12
4
3
6
5
7
8
9
10
11
SET TEMPERATURE( C)
LED
DISPLAY
4
SWING Button
Press to start/stop auto swing feature. Or to set
desired angle for directional airflow.
5
6
RESET Button
If the recessed RESET button is pressed, all
current settings will be cancelled and the
controller will return to the default settings.
7
ON/OFF Button
Power button, press to turn unit ON/OFF.
NOTE: Heat mode is for Cooling & Heating models only.
AUTO COOL
DRY HEAT FAN
Press to select the fan speed in four steps:
Auto Low Med High
FAN SPEED Button
12
TIMER ON Button
8
Press to activate Auto-on timer. Each press
increases the timer setting by 30-minutes, up
to 10 hours. Then at 1-hour increments, up
to 24 hours. To cancel the Auto-on timer, press
the button until time setting is 0.0.
9
ECONOMY(SLEEP) Button
Press to engage Sleep mode. Select this
function for the sleeping hours to maintain the
most comfortable temperature and save energy.
This function is only available under AUTO,
COOL and HEAT (heating models) modes.
NOTE: SLEEP function would be cancelled if
ON/OFF, FAN SPEED, SLEEP or MODE button
is pressed.
HANDLING THE REMOTE CONTROLLER
17
TIMRT OFF Button
LOCK Button
10
11
Press this recessed button to lock all current
settings (a lock symbol will appear on the LCD).
When the remote is locked, it will not respond
to any actions except LOCK. Use the LOCK
mode when you want to prevent any accidental
setting changes. Press again to unlock
Press this button to turn off the display on the
unit, press it again to light the display .
LED Display Button
12
Press to activate Auto-off timer. Each press
increases the timer setting by 30-minutes, up
to 10 hours. Then at 1-hour increments, up
to 24 hours. To cancel the Auto-off timer, press
the button until time setting is 0.0.

TIMER ON OFF
SET TEMPERATURE
Transmission Indicator
Temp./Timer display
FAN SPEED display
MODE display
ON/OFF display
This transmission indicator lights up whenever remote controller
is transmitting signals to the AC unit.
Indicates the current selected mode: AUTO, COOL,
DRY or HEAT (heating models only).
Displays the set temperature (62°F to 88°F / 17°C to 30°C) or
timer setting (0~24h).
If FAN mode is selected, there will be no display.
This indicator will be displayed when the unit is operating.
Indicates the selected fan speed: AUTO, HIGH, MED or LOW.
AUTO fan speed will have no indicator displayed.
When unit is operating in AUTO or DRY Mode, there will be no signals.
This display area indicates if Timer ON and/or Timer OFF has been set:
- TIMER ON: auto-on function is set
- TIMER OFF: auto-off function is set
- TIMER ON OFF: both auto-on and auto-off are set
Indicates the remote is locked and will not respond to any changes
(except LOCK button).
MODE display (FAN mode)
TIMER display
LOCK Indicator
Indicators on LCD
HANDLING THE REMOTE CONTROLLER
18

HANDLING THE REMOTE CONTROLLER
19
Cooling /Heating/Fan operation
Ensure the unit is plugged in and power is available.
1. Press the MODE button to select COOL, HEAT (heating models
only) or FAN mode.
2. Press the TEMP up/down button to set desired temperature,
between 62°F to 88°F (17°C to 30°C). Each press is in
increments of 2°F or 1°C.
3. Press the FAN SPEED button to select fan speed: Auto, Low,
Med or High.
4. Press the ON/OFF button to start the AC unit.
NOTE:
In FAN mode, temperature setting is not applicable. There will be no
temperature displayed on the LCD. Only steps 1, 3 and 4 may be
performed.
Using the remote controller
Auto operation
Ensure the unit is plugged in and power is available.
1. Press the MODE button to select Auto.
2. Press the TEMP up/down button to set desired temperature,
between 62°F to 88°F (17°C to 30°C). Each press is in
increments of 2°F or 1°C.
3. Press the ON/OFFbutton to start the air conditioner.
NOTE:
3
1
2
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
LED
DISPLAY
3
1
2
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
LED
DISPLAY
4
Under Auto mode, the unit will sense the difference between
ambient temperature and set temperature to determine the
operating mode: COOL, FAN or HEAT (heating models only).
Fan speed cannot be controlled in Auto mode. Unit automatically
selects the most appropriate speed.
If Auto mode is not comfortable for you, the desired mode can be
selected manually.
Dry (Dehumidifying) operation
Ensure the unit is plugged in and power is available.
1. Press the MODE button to select DRY mode.
2. Press the TEMP up/down button to set desired temperature,
between 62°F to 88°F (17°C to 30°C). Each press is in
increments of 2°F or 1°C.
3. Press the ON/OFF button to start the AC unit.
NOTE:
In DRY mode, fan speed is automatically controlled.
3
1
2
TEMP
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
MODE
FAN SPEED
SWING
TIMER ON
ECONOMY
ON/OFF
TIMER OFF
RESET LOCK
SET TEMPERATURE( C)
LED
DISPLAY
