Stealth Designer SC-24CC-UM User manual

QUICK-START GUIDE
NOTE: Ple se re d the complete owner’s m nu l
c refully before oper tion.
CEILING CASSETTE
AIR CONDITIONING & HEATING SYSTEM
Press to power the unit on or off.
Press to select and adjust each mode.
Press to lower settings including
temperature and time.
Press to raise settings including
temperature and time.
Press to select fan speed (Auto, Low, Medium
or High). Auto is default.
Press to control vertical angle of louvers
and to redirect airflow.
Press to display time of day.
Press to start the timer. (Adjust with “+” and “–”
buttons.) See Owner's Manual for more details.
Automatically runs fan after unit is turned off,
to remove moisture from coil.
Press to select temperature display: indoor, outdoor
or desired room temperature. (Adjust desired
temperature with “+” and “–” buttons.)
Press to stop the timer. (Adjust with “+” and “–”
buttons.) See Owner's Manual for more details.
Press to boost cooling or heating airflow.
Quickest way to reach preset temperature.
Press to select SLEEP mode, for comfort control while
sleeping. See Owner's Manual for more details.
Press to turn on lights on the unit’s Front Panel
Display. Press again to turn off.
: HEAT
: COOL
: DRY
:
FAN ONLY
: AUTO
Models:
SC-18CC-UM
SC-24CC-UM
SC-36CC-UM
SC-42CC-UM
SC-48CC-UM

KEY FEATURES & FUNCTIONS
MULTI FAN SPEEDS
Whether operating in either Cooling or Heating mode, the indoor fan can be set to your choice of speeds (Low, Medium,
High or Auto) to achieve maximum comfort.
X-FAN MODE
In humid areas, this function allows indoor fan to run for a pre-determined time after unit is turned off (in cooling or dry modes) to remove
additional moisture from coil.
CONDENSATE SENTRY
Overflow of the condensate pan is prevented. The system automatically shuts off when the condensate level is too high.
INTELLIGENT DEFROST
This increases room comfort and saves energy by sensing the need for defrosting and eliminating unnecessary defrost cycles.
POWER FAILURE MODE
Your settings and parameters are stored in non-volatile memory and are retained during a power failure.
SWING LOUVER
se the vertical swing louver button on wireless controller to select from five air discharge directions, including Continuous Sweep.
Maximize comfort by adjusting direction of airflow.
SLEEP MODE
You design a cycle to automatically adjust room temperatures during your sleep time, to maximize comfort and reduce utility bills.
TURBO MODE
When you wish to achieve the desired room temperature in the shortest possible time, Turbo Mode runs the unit at ultra high speeds for
quickest results.
INTELLIGENT PRE-HEATING
In heating mode, the system delays fan activation until the coil has warmed up, to prevent blowing uncomfortable cool air into the room.
SELF-DIAGNOSIS
The built-in computer uses real-time diagnostics to continuously scan for errors or malfunctions. Fault codes are shown on the unit display
to facilitate troubleshooting.
FAQs
Why does the f n continue to run even when the unit is not cooling or he ting?
To maintain consistent temperatures and minimize energy-loss from constant starts and stops, the fan keeps air flowing past the thermostat.
Wh t temper ture is displ yed on the remote controller?
The remote always displays your desired indoor temperature. (You may view current indoor and outdoor temperatures, as well as desired
temperature, on the indoor unit’s Front Panel Display.)
How often should I cle n the ir filters?
It is recommended that air filters be cleaned every three months to maintain peak performance and enhance the life of the unit.
Not all features available on all models. Your actual system and related devices may differ from the images shown in this manual.
For complete instructions on these and other functions,
as well as important safety information, see the Owners Manual.
Specifications are subject to change without notice. Manufacturer reserves the right to discontinue, or change at any time,
specifications or designs without notice or without incurring obligations. ©2015. All rights reserved.
