ThermoFisher Scientific HP RT2 Basic User manual

User Manual
Digital Hotplate
HP RT2 Basic
Operation Manual 9240-11-010

Thermo Scientific
MANUAL NUMBER 9240-11-010
0 -- 11/11/13 Original ccs
REV ECR/ECN DATE DESCRIPTION By
Preface
Digital Hotplate i
Important Before using this product, read this entire operation manual carefully. Users should
follow all of the operational guidelines contained in this manual and take all necessary safety
precautions while using this product. Failure to follow these guidelines could result in potentially
irreparable bodily harm and/or property damage. s
Caution All internal adjustments and maintenance must be performed by qualified service personnel. s
Material in this manual is for information purposes only. Thermo Fisher Scientific is committed to a continuing
program of product development and improvement, and reserves the right to change information, such as
specifications, appearance, and dimensions, described in this document without notice. Thermo makes no
representations or warranties with respect to this manual. In no event shall Thermo be held liable for any
damages, direct or incidental, arising out of or related to the use of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, including
photocopying, recording, or using information storage and retrieval systems, for any purpose other than the
purchaser's own use, without the express written permission of the manufacturer.
Any other product names and services identified in this manual are trademarks or registered trademarks of their
respective owners. No such use, or the use of any trade name, is intended to convey endorsement or other
affiliation with Thermo Fisher Scientific.
©2013 Thermo Fisher Scientific. All rights reserved.

Thermo Scientificii Digital Hotplate
Preface
This manual contains important safety and operation information. You must carefully read, understand, and
follow all the instructions in this manual prior to operating this instrument. Keep this manual in a safe place
nearby for reference and make it easily available to all users.
1) This manual highlights DANGER/WARNING/CAUTION/NOTICE alerts to prevent injury or property
damage and also to achieve optimum performance of your instrument.
(2) These alerts are classified into four types in this manual depending on the importance and the risk levels as
described below:
3) The claim which is out of the quality guarantee published by the Manufacturer is out of Manufacturer’s
responsibility.
4) The damage which is from unexpected fault or damage of user by Acts of God is out of Manufacturer’s
responsibility.
Symbols Meaning
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Ignoring this warning could cause serious injury or even death.
Ignoring this caution could cause injury or property damage.
Ignoring this notice could cause operational problems.

Thermo Scientific Digital Hotplate iii
Preface
Do You Need Information or Assistance on
Thermo Scientific Products?
If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:
1-740-373-4763 Direct
1-800-438-4851 Toll Free, U.S. and Canada
1-877-213-8051 FAX
http://www.thermoscientific.com Internet Worldwide Web Home Page
[e-mail] Tech Support Email Address
Certified Service Web Page
Thermo Fisher Scientific
401 Millcreek Road, Box 649
Marietta, OH 45750
Our staff can provide information on pricing and give you quotations. We can
take your order and provide delivery information on major equipment items or make
arrangements to have your local sales representative contact you. Our products are listed on the
Internet and we can be contacted through our Internet home page.
Our staff can supply technical information about proper setup, operation or
troubleshooting of your equipment. We can fill your needs for spare or replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended
Warranty for your Thermo Scientific products.
Whatever Thermo Scientific products you need or use, we will be happy to discuss your
applications. If you are experiencing technical problems, working together, we will help you
locate the problem and, chances are, correct it yourself...over the telephone without a service
call.
When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is
covered by the warranty, we will arrange for the unit to be repaired at our expense and to your
satisfaction.
Regardless of your needs, our professional telephone technicians are available to assist you
Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by
telephone or fax. If you wish to write, our mailing address is:
International customers, please contact your local Thermo Scientific distributor.
Sales Support
Service Support
www.unitylabservices.com

Digital Hotplate ivThermo Scientific
Table of Contents
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Convenience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Unpacking and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Installation Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Connecting to Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Location Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Connecting to Main Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Run/Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Check Power Status and Heating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Temperature Setting (t mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Temperature Setting (r mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
Timer Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Timer (continued) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Enter/Terminate Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
Lock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-7
Check Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-8
Selection of Heating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9
Temperature Unit Conversion (oC mpoF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
Temperature Offsetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
Selection of Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
Maximum Heating Rate Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-13
Change the High/Low Temperature Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-14
Temperature Control Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-15
Auto-tuning (PID Parameter Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-16
Escape Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Section 1
Section 2
Section 3
Section 4

v Digital Hotplate Thermo Scientific
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Cleaning Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Keeping Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Relocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Assembly of Support Rods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Assembly of Transparent Shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Disposing of the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Table of Contents
Section 6
Section 8
Section 7
Section 9
Section 5

Digital Hotplate 1-1Thermo Scientific
Section 1 Warnings and Cautions
Ignoring the following warnings could cause serious injuries or even
fatal accidents.
Understand all alert labels prior to operating this equipment. Never remove or
damage the alert labels.
Never move this equipment while under operation.
Never install or use this equipment in explosive or flammable atmospheres.
Never use or store flammable or hazardous substances near to this equipment.
Never use the equipment to heat flammable or hazardous substances.
Always wear proper protective gear (such as goggles, gloves, masks or an
apron) when using this equipment.
Never allow water, organic solvents, dust, or corrosive gases to get inside the
equipment.
Never immerse this equipment in water or operate it under water. Never reach
for this equipment if it has fallen into water.
Check electrical requirements described in this operation manual or on the ID
plate of this equipment before use. Connect this equipment to a dedicated
power outlet nearby.
Connect this equipment only to properly grounded power outlets to protect you
and your instrument. Do not ground to gas pipes or water pipes.
Never install this equipment closer than 30 cm (12 inches) to a wall of
combustible material. Observe minimum distances (in general, 30 cm) from
other devices.
If you observe strange smoke, odor or noise from the instrument, unplug the
power cord immediately and turn off the main power switch. After the smoke or
odor disappears, contact your dealer or Thermo Scientific if any repair is
required.
Never disassemble, repair, or modify this equipment on your own. Doing so will
void your warranty and may result in injuries or product damages.

1-2 Digital Hotplate Thermo Scientific
Section 1
Warnings and Cautions
Ignoring the following cautions could cause injuries or property
damages.
Do not touch the top plate or any object near it even when the heater is turned
off. You may get burned due to residual heat.
After using this equipment, make sure to turn off the main power switch and
also to disconnect the power cord from the power outlet for the safety of other
users.
Do not place heavy objects, including this equipment, on top of the power cord
and do not strip, scratch, bend, twist, pull, or heat the power cord. A damaged
power cord is a fire and electrical shock hazard.
Make sure to set up this equipment on a flat, stable, clean, non-slip, dry, and
fireproof surface inside a lab with proper safety measures.
Do not place any device which can be affected by the motor vibrations near
this equipment.
Do not touch the power outlet, power socket, or power cord with wet hands.
And make sure to connect the power cord directly and firmly to the power
outlet and power socket.
Do not put or insert any objects (especially if conductive or flammable) inside
this equipment.
Do not expose this equipment to any heat sources including direct sunlight.
Mechanical shock or vibration can damage this equipment. Pay extra attention
while moving it. Damages caused by mechanical shock or vibration may result
in injury or fire.
Do not impact the top plate or heat sink. You can damage the equipment or get
injured.
Do not install this equipment near any device that generates high frequency
noise such as high frequency welding machines, high frequency sewing
machines, or SCR power controllers.
Before cleaning, make sure to unplug the power cord to avoid electric shock or
fire.
Do not use chlorine bleach, ammonia-based cleaners, abrasives, ammonia, or
metal scouring pads. Wipe with a soft damped cloth or a sponge soaked in
water or diluted neutral detergent.

Digital Hotplate 2-1Thermo Scientific
Section 2 General Description
Congratulations of your purchase of a Thermo Scientific hotplate which is
specially designed to provide maximum benefit for your investment with
respect to performance, safety, ease of use, and durability.
HP RT2 Basic boasts quick heat-up time thanks to ample heating capacity
(600W) as well as the superb heat transfer rate enabled by the tightly
integrated structure of the heater and the ceramic-coated aluminum alloy
top plate.
Item/Model HP RT2 Basic
Dimension (W x D x H, mm) 161 x 290 x 100
Top plate dimension (Ø) 140 mm (5.5”)
Maximum heating capacity 600W
Current consumption (230V) 3A
Current consumption (120V) 5A

2-2 Digital Hotplate Thermo Scientific
Section 2
General Description
Features Performance
• Microprocessor PID Feedback Control
Fast and precise temperature control is provided by the microprocessor
PID controller
• Quick Heat Up Time
Ample heating capacity and superb heat transfer rate of the tightly inte-
grated structure of heater and ceramic-coated aluminum alloy top plate
allow quick heat up time (up to 350°C).
• Selection of the Temperature Control Modes
Three user-selectable temperature control modes are provided for your
convenience:
• Adjustment of the Heating Rate
If needed, you can adjust the heating rate ranging from 0 to 100% at 1%
interval. (Refer to 4.2.4 Temperature Setting under Heating Rate Priority
Mode (r mode))
• Selection of the Timer Mode
Immediate Activation -
The timer starts immediately after setting the timer.
Delayed Activation -
The timer is activated only when the set temperature is reached.
• Auto-tuning (Calibration)
Automatic tuning of the PID parameters provides more accurate temper-
ature control. (Refer to 4.3.10 Auto-tuning (PID Parameter Calibration))
• Temperature Offsetting
In case your own thermometer is to be used for temperature control for
specific applications, there can be some differences between the tempera-
ture of your thermometer and the displayed temperature of this unit. If
needed, such temperature differences ranging from -10°C to ase°C at
0.1°C interval can be offset. Refer to section Temperature Offsetting.
Optimal Mode
Providing optimal balance between the heat-up time to reach the target
temperature and the allowed fluctuation range of temperature overshoot
and undershoot (factory default)
Fast Mode Providing the fastest heat up time but wide fluctuation range of tempera-
ture overshoot and undershoot
Slow Mode Providing the slowest heat up time but the narrowest fluctuation range of
temperature overshoot and undershoot
Point Mode
Allowing linear heating up to the target temperature using the maximum
heating rate and switching on and off the heater based on the target tem-
perature. Note that this mode shows the widest fluctuation range of temper-
ature overshoot and undershoot.
User Mode Allowing the auto-tuned parameters to be used for temperature control

Digital Hotplate 2-3Thermo Scientific
Section 2
General Description
Safety • High and Low Temperature Limits
The high temperature limit of the top plate is set to 350°C to protect
you and your media. However, you can set your own high and low tem-
perature limits to reduce operation time and also to avoid inadvertent
mistakes.
If the temperature of the top plate exceeds the set temperature range, the
heater will be automatically turned on and off and the Heater LED will
be turned on and off accordingly.
• Multiple Overheat Prevention Measures
Built-in overheat prevention circuit will turn off the heater if the plate
temperature reaches 450°Cfor any reason. In addition, if the temperature
of the main body exceeds 85°C the overheat prevention circuit also stops
heating to protect the motor and the PCB. You will be alerted by both
audible and visible signals will be activated.
In such cases, turn off the power switch and disconnect the power cord
first. Allow your unit to cool down completely before operating it again.
• Hot Top Warning Indicator
The top plate temperature can remain very hot for some time even after
the heater is turned off. To prevent injury or fire under such circum-
stances, this equipment has a hot top warning indicator on the control
panel. This indicator will illuminate if the top plate temperature is over
50°C. Even so, do not rely on this indicator alone for your safety.
• Heating Bath (Patent Pending)
A specially designed non-slip heating bath shown above is available as an
option. To prevent unintentional slips of the bath during operation, this
bath has concavo-convex bottom so that it fits snugly on top of the heat-
ing plate.
HOT TOP
Figure 2-1. Heating Bath

• Lock Button
Inadvertent or accidental changes during operation can be prevented by
using this feature.
• Transparent Shield
An optional transparent shield is available to allow you to monitor your
operations more safely by shielding you against liquid splashes.
• Spill-proof Body Design
Spill-proof design of the main body protects the inner parts of the equip-
ment and the elevated control panel reduces the chances of contact with
liquid spills or leakage.
• Two large digital displays on the control panel clearly show both set
and actual temperatures of the top plate side by side.
• You can easily set your own temperature limit at any value between 0
and 350°C.
• Heating rate can be set from 0 to 100% at 1% interval for delicate
temperature control.
• Up to two support rods (optional) can be attached to hold various
kinds of devices such as temperature sensors, thermometers, laboratory
glassware, and so on.
• The ceramic-coated top plate is highly resistant to heat and corrosion.
In addition, its white color is optimal for monitoring color changes of
the media during operation.
(1) Ceramic-coated Top Plate
(2) Heat Sink
(3) Control Panel (see Control Panel section)
(4) Heater Knob
(5) Control Knob
(6) Threaded Holes for Support Rods
(7) Main Power Switch
2-4 Digital Hotplate Thermo Scientific
Section 2
General Description
Safety (continued)
Convenience
Construction
Figure 2-2. Front Components

(8) Transparent Shield (optional)
(9) Support Rod (optional)
(10) Heating Bath (optional)
(11) Power Socket
Digital Hotplate 2-5Thermo Scientific
Section 2
General Description
Construction
(continued)
Figure 2-3. Back Components

Digital Hotplate 3-1Thermo Scientific
Section 3 Unpacking and Installation
Upon receiving the instrument, check to ensure that no damage has
occurred during shipment. It is important that any damage that occurred
during shipment must be detected before unpacking. If such damage is
found, notify the carrier immediately.
After unpacking, check to ensure that all the following parts and
accessories are included in the package. If not, contact your dealer or
Thermo Scientific immediately.
It should be installed in suitable environment as described below.
Item Quantity
Main Body 1
Operation Manual 1
Power Cord 1
Transparent Shield (Option) 1
Heating Bath (Option) 1
Support Rods (Option) 2
Installation
Environment
Avoid direct sunlight.
Room temperature should be 5°C ~ 40°C
Relative Humidity (RH%) should be less 80%.
Altitude should be less than 2,000m.

3-2 Digital Hotplate Thermo Scientific
Section 3
Unpacking and Installation
Location Conditions
• Never install or use this equipment in explosive atmospheres.
• Never install or use this equipment with or near to hazardous or flammable
substances.
• Never expose this equipment to any heat sources including direct sunlight.
• Never install this equipment closer than 20 cm (8 inches) to a wall of
combustible material.
• Never install this equipment near any device that generates high frequency
noises.
• Set up this equipment on a flat, stable, clean, non-slip, dry, and fireproof
surface inside a lab with proper safety measures.
• Observe the minimum distances (in general, 30 cm or 12 inches) from other
devices. In addition, any device which can be affected by the motor
vibrations should not be placed near this equipment.
When connecting power, use only the power cord that came with your
instrument. The power connection procedures are as follows:
(1) Before connecting the power cord, make sure that the main power
switch is turned off.
(2) Plug the power cord into the power socket at the back of this
equipment as shown in Figure 3-1.
(3) Plug the other end into a properly grounded and dedicated power
outlet nearby.
Connecting to Power
Supply
Figure 3-1. Connect Power Cord
Main power switch
Power socket

Digital Hotplate 3-3Thermo Scientific
Section 3
Unpacking and Installation
• Check electrical requirements in the operation manual or on the ID plate
attached to the bottom of this equipment before use.
• Make sure to connect this equipment only to properly grounded as well as
dedicated power outlets to protect you and your equipment.
• In order to prevent fire or power cord damage due to overloading, do not
use power strips or improper extension cords.
Connecting to Main
Power

Digital Hotplate 4-1Thermo Scientific
Section 4 Operation
A. Hot Top Warning Indicator
B. Operational Status LEDs
C. Actual Temperature Display
D. RUN/STOP Button
E. Temperature Setting Button
F. Timer Setting Button
G. Lock Button
H. Configuration Button (see Configuration Mode)
I. Set Temperature Display
J. Heater Knob
K. Control Knob
Figure 4-1. Control Panel

(1) The following displays will appear in sequence together with a beep
sound when the power cord is connected:
(2) Note that the following display will also appear momentarily if the
main power switch is off:
(3) If you turn on the main power switch, the following display will appear
in sequence:
(4) You can easily check the selected heating mode by checking the LED.
The T. CTRL LED illuminates under the temperature priority mode:
The R. CTRL LED illuminates under the heating rate priority mode:
Even if the main power switch is turned on, you have to press the
RUN/STOP Button to start or to finish the operation.
The RUN LED illuminates only when the unit is operating and the HEAT
LED blinks only when the heater is activated.
4-2 Digital Hotplate Thermo Scientific
Section 4
Operation
Check Power Status
and Heating Mode
Run/Stop Button

Digital Hotplate 4-3Thermo Scientific
Section 4
Operation
If you press the RUN/STOP Button to start the operation and the current
temperature is below the set temperature, both the HEAT and the RUN
LEDs will light up as shown below:
Note, however, that the HEATER LED will be turned on and off during
the operation because the heater is automatically activated or deactivated
to maintain the set temperature.
• Hot Top Warning Indicator will illuminate if the top plate temperature is
over 50°C.
• Surface temperature may be hot!
• Even if the instrument is turned off, the surface of the top plate and the
vessel on top of it will remain very hot for some time. Never leave your
instrument accessible to others while it is hot and never touch it unless you
are absolutely sure.
The temperature setting procedures under temperature priority mode (t
mode) are as follows:
(1) Press the Temperature Setting Button and check the display showing
the current temperature setting:
(2) If you want to change the temperature setting, select the desired
temperature by turning the Control Knob:
Run/Stop Button
(continued)
Temperature Setting
(t mode)

(3) Push the Control Knob to save the desired temperature setting. The
following displays will appear in sequence:
• You can change the temperature setting even during operation.
• You can cancel the temperature setting any time before pushing the control
knob.
• Changing the temperature setting is allowed only within the low and high
temperature limits. If changing the temperature setting cannot be done prop-
erly, check the low and high limits first. See Changing the High and Low
Temperature Limits.
• You can set the low and high temperature limits at any value between 0°C
and 350°C.
The temperature setting procedures under heating rate priority mode (r
mode) are as follows:
(1) Select the desired heating rate by turning the Heater Knob:
(2) Select the desired temperature as described in ‘r mode’ above.
• You can change the heating rate even during operation.
• Note that wide temperature fluctuation (overshoot and undershoot) may hap-
pen if the heating rate is high.
• You can adjust the heating rate ranging from 0 to 100% at 1% interval.
4-4 Digital Hotplate Thermo Scientific
Section 4
Operation
Temperature Setting
(t mode) continued
Temperature Setting
(r mode)
