Thermon E4X-1 Reference guide

E4X-1
Pipe Mounted Thermostat Kit
INSTALLATION PROCEDURES
Picture Of Completed Product
WARNING:Disconnect Circuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac,15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
foruse in NEM A 4X Ordinary Locations
PN27085-0707

2
Order Separately . . .
PETK Power and End Termination Kits (per cable)
PETK-1D for BSX, RSX, VSX
PETK-2D for KSX, HTSX
PETK-3D for HPT, FP
Tools Required . . .
E4X-1 INSTALLATION PROCEDURES
The following installation procedures are suggested guidelines
for the installation of termination and connection systems.
Receiving, Storing and Handling . . .
1. Inspect materials for possible damage incurred during
shipping.
2. Report any damages to the carrier for settlement.
3. Identify parts against the packing list to ensure the proper
type and quantity has been received.
4. Store in dry location prior to installation.
Kit Contents . . .
Item Quantity Description
1 1 E4X-1 Kit Assembly
2 1 Junction Box Cover
3 2 Stainless Steel Pipe Band
4 1 Thermostat Sensor
2
4
3
1
Installation Precautions . . .
• To minimize the potential for arcing and fire caused by product
damage or improper installation use ground-fault protection.
The National Electrical Code (NEC) and Canadian Electrical
Code (CEC) require ground-fault protection of equipment for
each branch circuit supplying electric heat tracing.
• Installation must comply with Thermon requirements and
be installed in accordance with the NEC, CEC, or any other
applicable national and local codes.
• Component approvals and performance ratings are based on
the use of Thermon specified parts only.
• De-energize all power sources before opening enclosure.
• Keep ends of heating cable and kit components dry before
and during installation.
• Individuals installing these products are responsible for
complying with all applicable safety and health guidelines.
Proper personal protective equipment, or PPE, should be
utilized during installation. Contact Thermon if you have
any additional questions.
Item Quantity Description
1 1 RTV Tube
2 1 Power Connection Boot
3 1 End Cap
4 1 Tape Strip Teflon 6" (PETK-3D only)
5 1 End Termination Caution Label
61
GRW-G Grommet (PETK-3D only) (Not used with
E4X-1)
1
2 64
3 5
WARNING: DisconnectCircuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac,15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac,15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac,15A/480 Vac
foruse in NEMA 4X Ordinar y Locations
PN27085-0707

3
Wiring Schematic
2Insert cable into expediter piercing grommet.
Slide expediter toward pipe.
min.
300 mm
(12")
Screwdriver
E4X-1 INSTALLATION PROCEDURES
Heating Cable
Overjacket
3Mount expediter to pipe using banding.
1 Cut end of cable at angle to aid in piercing
grommet.
45°
4Secure thermostat sensor to pipe using
attachment tape. Position thermostat sensor
parallel to heating cable approximately 90° away
from cable. See illustration showing heating
cable vs. sensor location.
6Connect incoming power (by others) and complete
system wiring. See wiring schematic.
Incoming Power
(by others)
8Install junction box cover and tighten.
5Terminate cable with appropriate PETK
termination kit. Refer to PETK installation
instructions.
L1
L2/N
G
Do not band over cable.
TBX Boot
Ground Braid
WARNING: DisconnectCircuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac,15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac,15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac,15A/480 Vac
foruse in NEMA 4X Ordinar y Locations
PN27085-0707
Thermostat
Sensor
Attachment Tape
45
Heating
Cable
Sensor
90
Heating Cable vs. Sensor Location
40
35
60
80
200
120
160
235
140
100
180
220
150
Increase
Temperature
Decrease
Temperature
7Turn thermostat dial clockwise to increase
setpoint, and counter clockwise to decrease
setpoint.
Setpoint
Indicator
