Tholin-Audio PT10 Dimensions and installation guide

PT10 / PT40 Stereo Audio
Tube Amplifier
User Manual and
Warranty Information
Thank you for purchasing a Tholin-Audio product!
Tholin-Audio and the Tholin-Audio logo are registered trademarks of Tholin Limited. ©2022 Tholin Limited, 1512,
15F Lucky CTR, 165-171 Wan Chai Rd, Wan Chai, Hong Kong, 999077
Tholin-Audio®
2
Important Safety Instructions
1. Read and follow these instructions and keep them.
2. Operate the device only with connected speakers (with at least 4Ohm impedance)
3. Never cover the device.
4. Keep children and animals away because the device can get extremely hot during operation.
5. Do not use this device near water.
6. Clean only with a dry cloth.
7. Make sure that the ventilation openings are not blocked.
8. Do not operate the device in the immediate vicinity of heat sources such as radiators, heat flaps, stoves
that generate heat.
9. Do not bypass the polarized or grounded plugs attached for safety reasons. A polarized plug has two
contact pins, one of which is wider than the other. A grounded plug has two contact pins and a third
grounded ground contact. The wider contact pin or Mass contact is for your safety. If the enclosed plug
does not fit into your socket, please contact an electrician to replace your socket.
10. Route the power cord so that no one runs over it and it cannot be bent by heavy objects. Pay particular
attention to power plugs, extension sockets and the cable connection on the device.
11. In case of thunderstorms or prolonged non-use, unplug the device from the socket.
12. All maintenance work must be carried out by qualified specialists. Maintenance is necessary in the
following cases: if the device has been damaged, if an electrical cable or plug has been damaged, if
liquids have been spilled or an object has fallen into the device, if the device has stood in the rain or was
exposed to moisture, does not function normally or has been dropped.
13. Use the power plug to disconnect the device from the mains.
14. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, NEVER EXPOSE THE DEVICE
TO RAIN OR MOISTURE!
15. DO NOT EXPOSE THE DEVICE TO DRIPPING WATER OR SPLASHING WATER AND MAKE SURE
THAT NO LIQUID-FILLED OBJECTS SUCH AS VASES ARE PLACED ON THE DEVICE.
16. THE POWER PLUG OF THE POWER CORD MUST BE ACCESSIBLE AT ALL TIMES.
DO NOT OPEN THE HOUSING OF THE DEVICE: RISK OF ELECTRIC SHOCK! THE COMPONENTS INSIDE
THE DEVICE CANNOT BE MAINTAINED BY THE USER. ALL MAINTENANCE WORK MUST BE CARRIED
OUT BY QUALIFIED SPECIALISTS.
TO COMPLETELY DISCONNECT THIS DEVICE FROM THE MAINS, UNPLUG THE POWER CORD FROM
THE POWER OUTLET. THE POWER PLUG OF THE POWER CORD MUST BE ACCESSIBLE AT ALL TIMES.
Tholin-Audio®
3
Index
Index ....................................................................................................................................... 3
Welcome ................................................................................................................................ 4
Front buttons ........................................................................................................................ 5
Connections on the back ................................................................................................... 5
Commissioning and usage ............................................................................................... 6
Customer Service (Germany) ........................................................................................... 7
Warranty and Disclaimer ................................................................................................... 7
Tholin-Audio®
4
Welcome
Thank you for purchasing the PT10 / PT40 stereo tube amplifier!
Features
• High-End class-A tube amplifier wit 2 x 10 Watt (PT10) / class-A/B tube amplifier with 2 x 40 Watt
(PT40)
• Pre-amp and power-amp stages are both tube-powered (no hidden digital pre-amps like in so many
other devices)
• Bluetooth 5.0 input – works with mobile phones, computers, High-Definition music players, etc.
• Golden RCA inputs for the traditional cable connected CD player, phono amplifier, etc.
• Golden Loudspeaker connectors (also accepts banana plugs)
• Top grade, heavy and solid design in aluminum
• Discrete signal path
Technical Data
• Output power: 2 x 10 Watt on 8 Ohm (PT10) / 2 x 40 Watt on 8 Ohm (PT40)
• Total harmonic distortion: <0,06%
• Frequency response: 20 Hz - 20 kHz
• Input impedance: 50 kOhm
• Loud impedance: 4 – 8 Ohm
• Power consumption: 115 Watt (PT10) / 90 Watt (PT40)
• Input voltage: AC 220/230 V
• Net weight: 7.3 kg (PT10) / 12.1 kg (PT40)
• Dimensions: 200 x 180 x 292 mm (PT10) / 214 x 200 x 310 mm (PT40)
Tholin-Audio®
5
Front buttons
Left: On/Off toggle. Red LED lights up when turned On
Middle: Volume knob
Right: Input selector
Down: Chinch / RCA input selected
Up: Bluetooth input selected
Connections on the back
Left to right:
1) Chinch / RCA input for CD-player or other audio sources. Located above is the Bluetooth antenna
2) Loudspeaker terminals
3) Power cord connector
Tholin-Audio®
6
Commissioning and usage
Please visit us at www.tholin-audio.com or contact us by Email to support@tholin-audio.com for more information, help
with your questions and setting up.
Note: To ensure the amplifier vacuum tubes are not damaged during transport, they must be installed and connected after
receipt of the amplifier by the customer.
How do I set up the amplifier after receiving it?
1) Unpack the device and place it on a flat surface
2) Install the vacuum tubes in their sockets
• Small tubes at the front, large tubes in the rear sockets.
• The sockets only allow installation in a certain direction. Please make sure that the direction of
the tubes matches that of the socket and make sure that the connectors of the tubes are not
damaged when they are inserted into the sockets.
• Please proceed carefully and ideally wear gloves during installation to avoid dirt or oil/fat swab
on the tubes.
3) Connect the head-plugs onto the large rear tubes
• Please make sure that the connectors are placed in the middle of the contact, snap them into
place correctly. Ensure they are properly stuck after connection and cannot be removed easily.
4) Connect the speakers to the speaker terminals on the back of the device
5) Connect the power cord to the back of the device
6) Turn down the volume knob
7) Turn on the amplifier (power switch on the left front)
8) Connect the audio source via Bluetooth (see below) or RCA (e.g. CD player, smartphone, phono
preamplifier, ...)
9) Start playback on your audio source and slowly turn up the volume
Tholin-Audio®
7
How do I connect a Bluetooth device to the amplifier?
10) Turn down the volume control
11) Turn on the amplifier (power switch on the left front)
12) Stay in the range of ~10 meters and look for a new Bluetooth device "QCC3003" on your
phone/computer/device and connect (note: the Bluetooth device name may vary from product to
product)
13) Turn on Bluetooth on the amplifier (Bluetooth switch front right; RCA inputs are automatically
deactivated)
14) Start playback and turn the volume control up
Notes:
• Turn off Bluetooth first before turning off the amplifier, otherwise there may be unwanted noise
• Ideally, keep the volume of the audio device from which you playback music at the maximum level and
adjust the volume exclusively on the amplifier
• To connect another device via Bluetooth, the currently connected device must first terminate its
connection to the amplifier and thus "free up" the connection.
Customer Service (Germany)
In case of error or problems, please first contact Tholin Limited by e-mail (support@tholin-audio.com)
Tholin Limited / Service
Werdener Str. 51
42551 Velbert, Germany
Warranty and Disclaimer
SUMMARY OF WARRANTY*
Tholin Limited warrants to you, the ORIGINAL PURCHASER and ANY SUBSEQUENT OWNER of each NEW
Tholin-Audio product, for a period of one (1) year from the date of purchase by the original purchaser (the
“warranty period”) that the new Tholin-Audio product is free of defects in materials and workmanship. We further
warrant the new Tholin-Audio product regardless of the reason for failure, except as excluded in this Warranty.
ITEMS EXCLUDED FROM THIS Tholin-Audio WARRANTY
This Tholin-Audio Warranty is in effect only for failure of a new Tholin-Audio product which occurred within the
Warranty Period. It does not cover any product which has been damaged because of any intentional misuse,
accident, negligence, or loss which is covered under any of your insurance contracts. This Tholin-Audio Warranty
also does not extend to the new Tholin-Audio product if the serial number has been defaced, altered, or removed.
WHAT THE WARRANTOR WILL DO
We will remedy any defect, regardless of the reason for failure (except as excluded), by repair, replacement, or
refund. We may not elect refund unless you agree, or unless we are unable to provide replacement, and repair is
not practical or cannot be timely made. If a refund is elected, then you must make the defective or malfunctioning
Tholin-Audio®
8
product available to us free and clear of all liens or other encumbrances. The refund will be equal to the actual
purchase price, not including interest, insurance, closing costs, and other finance charges less a reasonable
depreciation on the product from the date of original purchase. Warranty work can only be performed at our
authorized service centers or at the factory. We will remedy the defect and ship the product from the service
center or our factory within a reasonable time after receipt of the defective product at our authorized service
center or our factory. All expenses in remedying the defect, including surface shipping costs in Germany, will be
borne by us. (You must bear the expense of shipping the product between any foreign country and the port of
entry in Germany including the return shipment, and all taxes, duties, and other customs fees for such foreign
shipments.)
HOW TO OBTAIN WARRANTY SERVICE
You must notify us of your need for warranty service within the warranty period. All components must be shipped
in a factory pack, which, if needed, may be obtained from us free of charge. Corrective action will be taken within
a reasonable time of the date of receipt of the defective product by us or our authorized service center. If the
repairs made by us or our authorized service center are not satisfactory, notify us or our authorized service
center immediately.
DISCLAIMER OF CONSEQUENTIAL AND INCIDENTAL DAMAGES
YOU ARE NOT ENTITLED TO RECOVER FROM US ANY INCIDENTAL DAMAGES RESULTING FROM ANY
DEFECT IN THE NEW THOLIN-AUDIO PRODUCT. THIS INCLUDES ANY DAMAGE TO ANOTHER PRODUCT
OR PRODUCTS RESULTING FROM SUCH A DEFECT. SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
WARRANTY ALTERATIONS
No person has the authority to enlarge, amend, or modify this Tholin-Audio Warranty. This Tholin-Audio Warranty
is not extended by the length of time which you are deprived of the use of the new Tholin-Audio product. Repairs
and replacement parts provided under the terms of this Tholin-Audio Warranty shall carry only the unexpired
portion of this Tholin-Audio Warranty.
DESIGN CHANGES
We reserve the right to change the design of any product from time to time without notice and with no obligation
to make corresponding changes in products previously manufactured.
LEGAL REMEDIES OF PURCHASER
THIS THOLIN-AUDIO WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE. No action to enforce this Tholin-Audio Warranty shall be
commenced after expiration of the warranty period.
THIS STATEMENT OF WARRANTY SUPERSEDES ANY OTHERS CONTAINED IN THIS MANUAL FOR
THOLIN-AUDIO PRODUCTS
*The warranty period for amplifier vacuum tubes is limited to three (3) months upon the date of purchase.
DISCLAIMER OF LIABILITY
WITH THE PURCHASE OF THOLIN LIMITED’S PRODUCT OR SERVICE YOU ARE ACCEPTING THE HERE
OUTLINED DISCLAIMER OF LIABILITY.
TO THE EXTENT NOT PROHIBITED BY APPLICABLE LAW, IN NO EVENT WILL THOLIN LIMITED
(RESPECTIVELY THE REGISTERED BRAND THOLIN-AUDIO) BE LIABLE FOR PERSONAL INJURY, OR
ANY INCIDENTAL, SPECIAL, INDIRECT, CONSEQUENTIAL OR PUNITIVE DAMAGES WHATSOEVER,
INCLUDING, WITHOUT LIMITATION, DAMAGES RESULTING FROM WRONG USAGE, DELAY OF
DELIVERY, FOR LOSS OF PROFITS, BUSINESS OR GOODWILL, FOR BUSINESS INTERRUPTION OR ANY
OTHER COMMERCIAL DAMAGES OR LOSSES, ARISING OUT OF OR RELATED TO THIS AGREEMENT OR
Tholin-Audio®
9
YOUR USE OR INABILITY TO USE THE PRODUCT OR SERVICE PURCHASED FROM THOLIN LIMITED OR
ITS AFFILIATES, HOWEVER CAUSED, WHETHER UNDER A THEORY OF CONTRACT, WARRANTY, TORT
(ALSO NEGLIGENCE), PRODUCTS LIABILITY, OR OTHERWISE, EVEN IF THOLIN LIMITED HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND NOTWITHSTANDING THE FAILURE OF
ESSENTIAL PURPOSE OF ANY REMEDY. IN NO EVENT SHALL THOLIN LIMITED’S TOTAL LIABILITY TO
YOU UNDER THIS AGREEMENT FOR ALL DAMAGES (OTHER THAN AS MAY BE REQUIRED BY
APPLICABLE LAW) EXCEED THE AMOUNT OF FIFTY EUROS (EUR 50.00).

This manual suits for next models

1

Other Tholin-Audio Amplifier manuals

Tholin-Audio PR-1 Dimensions and installation guide

Tholin-Audio

Tholin-Audio PR-1 Dimensions and installation guide

Tholin-Audio PA-1 Instruction Manual

Tholin-Audio

Tholin-Audio PA-1 Instruction Manual

Popular Amplifier manuals by other brands

Alpine MRP-M850 owner's manual

Alpine

Alpine MRP-M850 owner's manual

Rotel RA-02 owner's manual

Rotel

Rotel RA-02 owner's manual

LY ED-35M manual

LY

LY ED-35M manual

Eden World Tour WT800C Operation manual

Eden

Eden World Tour WT800C Operation manual

Sherbourn PRE-1 user manual

Sherbourn

Sherbourn PRE-1 user manual

Texas Instruments LM4910 Boomer manual

Texas Instruments

Texas Instruments LM4910 Boomer manual

Oldfield 6750 user guide

Oldfield

Oldfield 6750 user guide

Advance acoustic BX2 quick start

Advance acoustic

Advance acoustic BX2 quick start

Grace m108 owner's manual

Grace

Grace m108 owner's manual

Behringer Bass V-Amp Pro quick start guide

Behringer

Behringer Bass V-Amp Pro quick start guide

Hartke HD 75 owner's manual

Hartke

Hartke HD 75 owner's manual

Vivanco MA 225 operating instructions

Vivanco

Vivanco MA 225 operating instructions

Minebea DAS-406C instruction manual

Minebea

Minebea DAS-406C instruction manual

Philips DFA 888 manual

Philips

Philips DFA 888 manual

CASTONE ELECTRONIC CPA-60C user manual

CASTONE ELECTRONIC

CASTONE ELECTRONIC CPA-60C user manual

Metro DataVac PA16-120 manual

Metro DataVac

Metro DataVac PA16-120 manual

SubDude Audio PINWOOFER manual

SubDude Audio

SubDude Audio PINWOOFER manual

PARK AUDIO DF-SERIES WITH DSP owner's manual

PARK AUDIO

PARK AUDIO DF-SERIES WITH DSP owner's manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
