thomann MKR 61 User manual

MKR 61
roll-up keyboard
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
11.11.2015, ID: 353537 (V2)

Table of contents
1 General notes............................................................................................................................................... 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 7
2 Safety instructions..................................................................................................................................... 9
3 Features....................................................................................................................................................... 13
4 Installation.................................................................................................................................................. 14
4.1 Dealing with lithium batteries..................................................................................................... 15
5 Control panel and connections........................................................................................................ 17
6 Technical specifications....................................................................................................................... 26
7 Protecting the environment.............................................................................................................. 27
Table of contents
MKR 61
3

1 General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General notes
roll-up keyboard
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
General notes
MKR 61
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’, ‘OFF’.
References to other locations in this manual are identified by an arrow and the specified page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specified location.
Example: See
Ä ‘Cross-references’ on page 6.
Letterings
Displays
Cross-references
General notes
roll-up keyboard
6

1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General notes
MKR 61
7

Warning signs Type of danger
Warning – danger zone.
General notes
roll-up keyboard
8

2 Safety instructions
This device is intended to be used for electronic sound generation using a piano keyboard. Use
the device only as described in this user manual. Any other use or use under other operating
conditions is considered to be improper and may result in personal injury or property damage.
No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
MKR 61
9

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the following
section.
Safety
Safety instructions
roll-up keyboard
10

CAUTION!
Possible hearing damage
With loudspeakers or headphones connected, the device can produce volume
levels that may cause temporary or permanent hearing impairment.
Do not operate the device permanently at a high volume level. Decrease the
volume level immediately if you experience ringing in your ears or hearing
impairment.
NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
Safety instructions
MKR 61
11

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
roll-up keyboard
12

3 Features
The Roll-up keyboard is characterized by the following features:
n61 keys
n128 preprogrammed sounds
n128 preprogrammed styles
n45 demo songs
nRecord and playback function
nSingle-finger and multi-finger operation
nSustain
nVibrato
nDigital display
nBuilt-in speakers
nConnections: Headphones out, USB charger connection, MIDI out, audio in
Features
MKR 61
13

4 Installation
The device is powered by a rechargeable lithium-ion battery. Use only the included lithium-ion
battery or a spare battery with identical specifications (see
Ä Chapter 6 ‘Technical specifications’
on page 26).
Use the included USB charging cable for charging the inserted battery. Connect the device to
the USB port of a PC for charging via this cable.
After playing the Silicone keyboard, roll it up loosely and keep the unit in its original pack‐
aging. Do not kink the Silicone keyboard.
The unit automatically switches to standby mode when you don't press any key for about 5
minutes. To reactivate the device into normal operating mode press any key of the keyboard.
Installation
roll-up keyboard
14

4.1 Dealing with lithium batteries
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the following
section.
When handled correctly and appropriately lithium batteries pose no risk.
Store lithium batteries in a cool, dry place, ideally in the original packaging.
Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are
hermetically sealed. Never attempt to open a lithium battery.
If the battery housing is damaged small amounts of the electrolyte may leak out. If this should
happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte
using absorbent paper towels. You must wear protective rubber gloves when doing so. Clean
your hands and the affected surface thoroughly with cold water.
Installation
MKR 61
15

Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Installation
roll-up keyboard
16

5 Control panel and connections
Operating panel
Control panel and connections
MKR 61
17

1 Keyboard.
2 Speaker.
3 Display.
4[+]
Increases the displayed value by one.
5[Tone]
Button to select a preprogrammed sound.
Press the button to activate the selection. The display shows ‘tnE’. Use the buttons [+] and [–] to select a sound setting in
the range of ‘000’ … ‘127’.
6[OOP]
Button to activate the ‘OOP’ mode.
In this mode, you can record your own short drum sequences of up to 32 individual drum hits. Press the button to play
your recording. The sequence is repeated in a continuous loop until you press the button.
If you press the button [OOP] again and start a new recording, the previous sequence will be overwritten.
Control panel and connections
roll-up keyboard
18

7[Drum Kit]
Button to activate the ‘Drum Kit’ mode.
In this mode you create drum sounds using the various keys, (bass drum, snare, hi-hat, cymbals and effects).
Press the button once to activate the mode. The display briefly shows ‘On’.
Press the button again to exit the mode. The display briefly shows ‘OFF’.
8[Sustain]
Button to activate the Sustain effect.
Press the button once to activate the effect. The display shows ‘SUS’.
Press the button again to deactivate the effect. The display briefly shows ‘OFF’.
9[Vibrato]
Button to activate the Vibrato effect.
Press the button once to activate the effect. The display shows ‘Vib’.
Press the button again to deactivate the effect. The display briefly shows ‘OFF’.
Control panel and connections
MKR 61
19

10 [Vol]
Buttons for increasing / decreasing the volume.
Press the keys briefly to gradually adjust the setting. Keep the buttons pressed to adjust the setting quickly up and down.
11
Playback button. Starts and stops playback of user recordings in recording mode.
12
Play / Pause button.
Press the button once to start playback of styles and demo pieces.
Press the button again to stop playback of styles and demo pieces.
13 [Insert]
Button to insert a fill when playing styles. Press the button once to insert a fill at the end of the currently playing bar.
Control panel and connections
roll-up keyboard
20
