GENERAL ASSEMBLY
INSTRUCTIONS
TIG/INS48

BEFORE YOU GET STARTED
02 gersheds.com 0113 205 4189 sales@gersheds.com
PLEASE READ INSTRUCTIONS CAREFULLY
• Checkthepackandmakesureyouhaveallthepartslisted.
• Whenyouarereadytostart,makesureyouhavetherighttoolsathand(notsupplied).
• Ensurethereisplentyofspaceandacleandryareaforassembly.
TIMBER
Aswithallnaturalmaterials,mbercanbeaectedduringvariousweathercondions.Fortheduraonof
heavyorextendedperiodsofrain,swellingofthewoodlogsmayoccur.Warpingofthewoodmayalsooccur
duringexcessivedryspellsduetoaninteriormoistureloss.Unfortunately,theseprocessescannotbeavoided
butcanbemigated.Itissuggestedthattheoutdoorbuildingissprayedwithwaterduringextendedperiodsof
warmsunshineandshelteredasmuchaspossibleduringrainorsnow.
Pleasedonotpaintortreatyourcabinmbersbeforeassemblyastheymuststaydryforasnugtongueand
groovet.Tovalidateyourguaranteeandensurelongevityoftheproduct,itisESSENTIALthatyourbuildingis
treatedwithanappropriatehigh-qualityoilorsolventbasedpreservaveAFTERassembly,bothinternallyand
externally,thenannuallythereaer.
BUILDING A BASE
Caremustbetakentoensuretheproductisplacedonasuitablebase.Whenthinkingaboutwherethebuilding
andbaseisgoingtobeconstructed,ensurethattherewillbeaccesstoallsidesformaintenanceworkand
annualtreatment.
Ensurethebaseisrmandlevelandisbuiltonrmground,topreventdistoron.
Theconstructedbasemustbeatleastthesizeoftanalisedoorbearersasreferencedinsuppliedconstruct
diagram.Itisalsorecommendedthattheoorbeatleast25mmabovethesurroundinggroundleveltoavoid
ooding.
TYPES OF BASE
• Durableplascgrid*.
• Concrete75mmlaidontopof75mmhard-core.
• Slabslaidon50mmofsharpsand.
• Timberbase-Selfconstructed/Buypre-made.
*We recommend a Fastt EcoBase for your building. It is durable, lightweight, exible, and easy to put in place.
Please see gersheds.com for details.
WOOD WARPING
MAY OCCUR
WINTER
EXPANSION
SUMMER
CONTRACTION
PLASTIC BASE TIMBER BASE BROKEN SLABS BARE SOIL LOOSE GRAVELCONCRETE BASE SLAB BASE

Pleaseretaininstruconsforfuturereference
CAUTION:
Allbuildingsshouldbeerected
bytwocompetentadults.
CAUTION:
Itisadvisabletowearsafety
glovesduringbuildinginstallaon.
Whilst all products manufactured are made to the highest standards of safety, we cannot accept responsibility for your safety whilst erecng or
using this product.
GO WITH THE PRO!:
Weunderstandhowbusylifecanbe.OurPro-Installaonservicecantakethestressandstrainoutofassemblingyour
qualityTigerbuildingforyou.Werecommendusingprofessionalanddedicatedinstallerstoerectyourbuilding.Withtheir
knowledgeandexperience,theywillensurethatyourcabinisputproperlyinplacereadyforyoutoenjoyyourspacefor
yearstocome.
IfyouhavenotbookedourPro-Installaonserviceandwouldliketoarrangeaninstallaon,pleasecontactourfriendly
customersupportteamon0113 205 4189(Mon–Fri9am-5pm)oremailsales@gersheds.com.
•Thepro-installteamwillcontactyoutoarrangeasuitablemeanddatefortheng.
•Sitback,relaxandletourprofessionalhomeinstallaonservicedoallthehardworkforyou!
•PleaseviewourProInstallaonpageonourwebsiteforfulltermsandcondions.
MADE IN THE UK SINCE 1913.
Wehavebeenmakingourhighquality,
greatvaluegardenbuildingsherein
Britainfordecades.
03

BEFORE YOU GET STARTED
TOOLS REQUIRED
Werecommendusingthefollowingtools(notsupplied):
SCREWDRIVER +
Unpacking supplied cabin.
• Removeallwrappingfromdelivery.Fromtoptoboom,cutbandingholdingallcomponentstogetherand
 removethecabincomponents.
NOTE: PARTS MAY HAVE BECOME LOOSE OR MOVED DURING TRANSPORTATION.
•Laycomponentsonadry,horizontalsurface.
RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVELHAMMER
WOOD SAW
FIXING KIT CONTENTS:
SPANNER
04 gersheds.com 0113 205 4189 sales@gersheds.com
C20
CloutNails(20mm Galvanised - QTY 300)
N40
Nails(40mm Galvanised - QTY 30)
N65
Nails(65mm Galvanised - QTY 300)
S40
Screws(40mm - QTY 30)
S60
Screws(60mm - QTY 8)
S80
Screws(80mm - QTY 16)
CB40
M6CoachBolts(40mm - QTY 8)
BA40
Nails(40mm Bright Annular - QTY 400)

Pleaseretaininstruconsforfuturereference
ASSEMBLY
• Assemblyisstraighorwardifyoufollowthesestep-by-stepinstrucons.
• Werecommendgengeverythingalignedproperlybeforescrewingtogetherandthat
 screwholesshouldbepre-drilledtoavoidsplingthember.(Donotcomepre-drilled).
IMPORTANT
• Beforeassembly,pleasemakesureyouhaveasuitablebasereadytoerectyourbuildingon.
• YourbaseMUSTbermandleveltoensurethatthebuildingisassembledproperlyandissquare.
• Pleasecarefullyremovethepackagingandunpackthecomponentsinyourdelivery.
NOTE: ADDITIONAL TIMBER MAY BE INCLUDED AS PACKING MATERIALS.
• DO NOTstartyourbuildunlyouhavecheckedthatallthepartsofyourbuildingarepresentandinasuitablecondion.
• Ifyouareorganisingathirdpartytoinstallyourbuilding,itisbestpraccenottoschedulethisimmediatelyonreceiptof
 yourorder,togiveyoumetocheckyourdelivery.
BUILDING PACK CONTENTS:
ForfulldetailsofwhatshouldbeincludedpleaseseetheProductConstructDiagramanditemisedcunglist
thatissuppliedwiththedelivery.TheyarealsoavailableonrequestinpdfformfromourhelpfulCustomer
Supportteam–pleasecall0113 205 4189orusetheItemsDeliveredQueryformatgersheds.com/contact.
05

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
Step 1:
UNPACKING CABIN COMPONENTS:
• Unpackallcomponentsfromyoursuppliedcabinpack(s)andplaceeachindividualcomponentinthecorrect
 orderusingthesuppliedconstructdiagramandpartslistasaguide.Ensureallcomponentsarepresentandin
 thecorrectposionbeforebeginningassembly.
• Eachloginterlocksinastaggeredpaern.
NOTE: SOME LOGS FEATURE ADDITIONAL FULL NOTCHES & HALF NOTCHES.
• Beforesecuring,ensurethatthelogsareedproperlyintheirrespecvetongueandgrooves,gently
 tappingdownwithamallet.(Detail A1 & A2)
TOP TIP
Use packing materials to protect when
tapping logs into place.
A1 A2
06 gersheds.com 0113 205 4189 sales@gersheds.com

Pleaseretaininstruconsforfuturereference
Step 2:
DOUBLE DOOR ASSEMBLY
• Forcabinswithdoubledoors,buildupdoorframeusingthefourdoorcomponentsprovided.
 Removesuppliedkey.Thisisusuallystapledoverkeyhole.
• Arrangethedoorframingontoarmandlevelsurface,withhingestotheground.Slotthedoorsill(base)
 thenthedoorheadintoplace.Securethe4seconstogetherthroughthejointsusing1xS60percorner.
(Detail B)
NOTE: HOLES FOR FRAMING ARE PRE-DRILLED IN THE FACTORY.
NOTE: THIS IMAGE IS FOR ILLUSTRATIVE PURPOSES AND DOOR STYLE MAY DIFFER FROM YOUR
SUPPLIED PRODUCT.
B
DOOR HEAD
DOOR SILL (BASE)
S60
07

Step 3:
LAY DOWN TANALISED BEARERS
• Refertotheoorplanofyourconstructdiagram,posionthetanalisedbearersonpreparedbase.
• Spreadoutthetanalisedbearersequallyatapprox.400mmcentres.(Detail C For Orientaon)
NOTE: ON LARGER CABINS, TANALISED BEARERS MAY BE SUPPLIED IN MORE THAN 1 PIECE.
PLEASE REFER TO YOUR CONSTRUCT DIAGRAM FOR THIS.
• Setdeckpanelsatthefrontofyourcabin.Buupagainsttanalisedbearers.Useyoursuppliedconstruct
 diagramoorguideforreference.
TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
C
08 gersheds.com 0113 205 4189 sales@gersheds.com

Pleaseretaininstruconsforfuturereference
Step 4:
BEGIN BUILDING WALLS
• Place1stlayeroflogsontheedgesofthebearers.Ensurehalflogsareputdownrst.
 Seeconstructdiagramforbuildorder.
• Measurecornertocornerdiagonallytomakesurecabinoorissquare.Ifbothvaluesareequal,yourframeis
 square.Realigntheoorunlsquare.Donottrim.
• Screwlogsintotanalisedbearersusing3xS80perlog.(1xS80incentre,1xS80perendnotch)
• Forxingthroughnotches.(Detail D1)
• Forxingthroughhalflog.(Detail D2 & D3)
• Checkthatoorislevelusingaspiritlevel.
D1 D2 D3
S80 S80 S80
09
1 2
12

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
Step 5:
SECURING FLOOR
• Checkoorboardsarecorrectsize.Donotmixupwithroofboards.
• Lay5oorboardsinposionandtackinplace.Leaveapprox.2.5mmgapbetweentheedgeofthe
 oorboardsandtheinsideofexternalwalls.(Detail E)
NOTE: DO NOT FULLY SECURE AS THESE ARE ONLY TO KEEP THE FLOOR SQUARE WHILE BUILDING
THE LOG CABIN.*
• *Forcabinswithinternalparon,theoorboardswillneedtobefullyinstalledatthisstagetoallow
 paronbaselogstobeinstalled.PleasejumptoStep16fordetails.
10 gersheds.com 0113 205 4189 sales@gersheds.com
E

Pleaseretaininstruconsforfuturereference
11
Step 6:
CONTINUE TO BUILD WALLS
• Usingconstructdiagramasaguide,begintobuildupthewallsbyinterlockingthelogslayerbylayerunl
 3logshigh.
• Atthispoint,storeremainingoorboardsinsidethecabinreadyforinstallaon.Youmaynotbeabletot
 oorboardsthroughthedooroncecabinhasbeenbuilt.

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
12 gersheds.com 0113 205 4189 sales@gersheds.com
Step 7:
INSTALL DOORS & WINDOWS
• Taketheassembleddoorsandframeandslideoverthelogsunlfullyinserted.
• Posioncentrallywithinopening.Thiswillleaveagapeithersideforseling.(Detail F1)
• Fixsupplieddoorhandletoenableaccesstothecabin.(Detail F2)
• Repeatprocessforwindows.(Detail F3)
F2
F1

Pleaseretaininstruconsforfuturereference
13
F4
F3
• Posioncentrallywithinopening.Thiswillleaveagapeithersideforseling.
NOTE: DOORS AND WINDOWS ARE VERY HEAVY, PLEASE TAKE CARE
WHEN LIFTING INTO PLACE.
NOTE: IF YOUR BASE IS NOT FIRM AND LEVEL THEN
THIS CAN CAUSE THE DOORS AND WINDOWS TO
TWIST OR TO GO OUT OF SQUARE. USE A SPIRIT
LEVEL TO CHECK.
NOTE: DO NOT FIX THE DOORS OR
WINDOWS IN PLACE AT THIS STAGE
• Connuetobuildupyourcabinasshown..
(Detail F4)

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
14 gersheds.com 0113 205 4189 sales@gersheds.com
Step 8:
INSTALL SIGMA POSTS
• Slotoverbuiltdeckseconasshown.(Detail G1 & G2)
• SigmaPost1totheoutsideofdeckarea.
• SigmaPost2totheinsideofdeckarea.
NOTE: DO NOT FIX POSTS AT THIS STAGE.
• Connuetobuildupyourcabinastoeavesheigh.(Detail G3)
G1
G2
G3
SIGMA POST 1
SIGMA POST 1
SIGMA POST 2

Pleaseretaininstruconsforfuturereference
15
Step 9:
INSTALL GABLE TOPS
• Placeontopoftheeavesheightlogs.
NOTE: LARGER CABINS MAY HAVE ADDITIONAL TRUSSES TO SUPPORT ROOF.
PLEASE REFER TO YOUR CONSTRUCT DIAGRAM.
Step 10:
INSTALL PURLINS
• Posionthepurlinswiththeangledcutstotheboom.(Detail H1)
 Ensurenotchesinpurlinslineupwithgabletops.
• Securethepurlinsintothegabletopsusing2xN65perpurlinpergabletop.(Detail H2)
• Repeatforallpurlinandgabletopjoins.
STANDARD PURLIN
STANDARD PURLIN WITH EXTRA NOTCH(ES)
H1
H2
N65
N65

16 gersheds.com 0113 205 4189 sales@gersheds.com
TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
I1 I2 I3
N65
N65
N65
Step 11:
INSTALL ROOF BOARDS
• Beforeinstallingtheroofboards,checkthatthecabinissquarebothvercally&horizontally.
 Adjustifrequired.
• Posionatongue&grooveroofboardushwithpurlinatoneendofroof.
 • Fixthroughapexpurlinusing2xN65perboard.(Detail I1)
 • Fixthroughoneaddionalpurlinusing2xN65perboard.(Detail I2)
 • Fixthroughsidetoplogsusing2xN65perboard.(Detail I3)
• Connueworkingacrossroof,repeangthestepsabove.
• Thenalroofboardmayneedtrimmingtositushwithpurlinatend.
CRITICAL!: ALL ROOF BOARDS MUST HAVE 2X N65 PER FIXING POINT AS OUTLINED ABOVE.
Step 12:
INSTALL ROOF BATTEN AND SKIRTING
• Fixroofbaenontotheundersideofroofboardsonlowsideusing6xN40,evenlyspacedalonglength.
 Finishwithapieceofskirng,aachedusing6xN40,evenlyspacedalonglength.(Detail J1 & J2)
NOTE: ROOF BATTENS AND SKIRTING MAY COME IN MORE THAN 1 SECTION.
J2J1
N40
N40

17
Pleaseretaininstruconsforfuturereference
Step 13:
SECURE SIGMA POSTS
• Securepostsintologsusing1xS40persideperpostathighlevel.(Detail K1)
• Securepostsintologsusing3xS40persideperpostatlowlevel.(Detail K2)
• Repeatforallotherposts.
S40
S40
S40
S40
S40
S40
S40
K1
K2

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
18 gersheds.com 0113 205 4189 sales@gersheds.com
Step 14:
FELT THE ROOF - MEASURE AND CUT BEFORE INSTALLING FELT
• Rollfeltoutontoacleanatsurface30minutesbeforeyouneeditsoithasachancetoaenout.
• Measurelengthofroofandallow75mmoverhangateachend.Cuteachstripoffelttosize.
 Useastraightedgetoguidecung.
• Rollcutfeltpiecealonglowsideofroof,Secon1,leavingsucientoverhangtofolddownontoroofedge.
 Donotfoldunderneathroof.(Detail L1 & L2)
• Oncefeltisrolledout,xtoroofusingCN20bothends,makingsurefeltisstraight.Securethroughskirng
 usingCN20atapprox.100mmintervals.(Detail L2)
 Ensurethefeltisght,securethetopsideoffeltusingCN20atapprox.100mmintervals.(Detail L3)
• Repeatforremainingfelt,workingfromthelowsideofrooftothehighside,overlappingthefeltby75mm
 unltheroofisfullycovered.(Detail L3)
• Foldtheoverhangingfeltatendsunderroofboardandtackinplace.
L1 L2 L3
INCORRECT FELT CORRECT FELT
CN20
CN20
CN20
ROOF BOARD
SECTION 1

Pleaseretaininstruconsforfuturereference
19
Step 15:
ATTACH ROOF FASCIA BOARDS (BARGEBOARDS) & FINIAL
• Aachrooffasciasusing4xN40perfasciaboard.Nailthroughtoppurlinandboomroofbaen.
 Completethelookwithnialsoverthejoinatapex.Secureusing2xN40pernial.
NOTE: THERE ARE NO BARGEBOARDS SUPPLIED FOR LOW SIDE OF ROOF AS THIS WILL PREVENT
EFFECTIVE WATER DRAINAGE.
Step 16:
LAY FLOORBOARDS
• Starttolaytheoorboards.Thereshouldbea2.5mmgapbetweentheedgeoftheoorboardsandtheouter
 logstoallowforexpansionandcontracon.
• Nailtheoorboardstothetanalisedbearersbelowwith2xBA40evenlyspacedperoorboardper
 tanalisedbearer.
• Thelastboardwillneedcungdowntosize.Ifinstallinganyparons,pleasereturntoStep6.
FASCIA FASCIA
FINIAL
CUT FLOORBOARD TO SIZE

TIGER SIGMA LOG CABIN GENERAL INSTRUCTIONS
20 gersheds.com 0113 205 4189 sales@gersheds.com
Step 17:
FIXING DOORS AND WINDOWS
• Checkthedoorsaresquareandscrewthefasciaboards,bothinternallyandexternally,intothelogsbehind
 with6xS40evenlyspacedasshown.(Detail M)
• Repeatprocessforallremainingdoorsandwindowsinyourcabin.
Timber is a natural product; any log or board can expand and contract. This may cause slight gapping in the
log cabin which can be reced by un-screwing and re-screwing fascia boards over the course of the year.
S40 S40
S40 S40
S40 S40
M
