Timberk THU UL 04 User manual
ÀÂ71
Instruction manual
Outlook of devices, aslo colour scores can be revised without any special advance notices.
Electric
humidifier
THU UL 04
/Model
2
1. Important information
To improve product quality, its design, scope of delivery or
manufacturing process can be revised without advance notice.
The text and digital notations in this manual may have misprints.
Should you have any questions on the functioning and operation of the
device, please refer to the seller or a specialized service center to receive
clarification.
There is a label on the product, indicating all necessary technical data
and other useful information regarding the device.
Use the device only for purposes, stated in this manual.
The humidifier is intended to automatically maintain the preset level of
relative humidity indoors. Comfortable conditions are achieved at
relative humidity ranging from 40 to 60%. If the actual humidity goes
below the level you set then the humidifier will switch on automatically
and operate until the set relative humidity level is achieved, after that
the humidifier switches off automatically (for models with the automatic
operation mode).
Insufficient air humidity results in drying of mucous membranes, which
in its turn is the reason for decrease in immunity, headache, lip cracking,
sandpaper in the eyes, it also enables infection spreading and
respiratory tract diseases, causes fatigue, results in increased eye fatigue
and worsening of attention focusing, it has a negative effect on the
condition of pets and house plants, causes increase of dust generation
and, increase of electrostatic charge of synthetic fabrics, as well as
carpets and synthetic floor coatings, it causes damage of wooden
furniture and especially parquet floors, it negatively affects tuning of
musical instruments.
2. Safety measures
Prior to operation of the humidifier carefully read this operation manual
and save it for further use.
A number of safety measures should be followed upon operation of the
device. Improper operation due to ignoring precautions may result in
damaging of users and other peoples health, as well as damaging their
property.
The humidifier is intended for operation in living rooms subject to the
indicated operation conditions. The use of the humidifier for purposes
other than that intended may cause situations, hazardous for the life and
health of people.
The electric appliance must be kept watched during its operation,
especially if there are children in the vicinity. The unit is not intended to
be used by people (including children) with limited physical, sensory or
intellectual capabilities, having insufficient experience and knowledge,
unless they are supervised or received instructions on how to use the
unit from a person, responsible for their safety. It is necessary to be
careful that children do not play with the unit.
Do not use the unit for purposes, not specified by this operation manual.
It is forbidden to use the humidifier if the power cord or a plug are
damaged, as well as if the humidifier is broken, damaged as a result of
falling or under other circumstances. The humidifier must be operated
fully assembled only.
To prevent burns upon operation of the humidifier do not touch the
humidifiers membrane (for ultrasonic models). Due to high oscillations
frequency the membrane heats up very much.
Note:
High-frequency oscillations of the ultrasonic humidifier membrane are
not audible and completely safe for people and pets.
To prevent an electric shock, the damaged power cord must be replaced
only in authorized service centers by qualified specialists.
To prevent an electric shock, do not place the power cord next to
heating appliances and flammable or combustible substances.
DEAR CUSTOMER!
Thank you for a good choice and purchase of Timberk humidifier. It will
serve you for a long time.
Table of contents
1. Important information.............................................................................................
2. Safety measures..........................................................................................................
3. Technical characteristics..........................................................................................
4. Description of the unit.............................................................................................
5. Scope of delivery........................................................................................................
6. Filling tank with water..............................................................................................
7. Operation of the unit................................................................................................
8. Cartridge filter with ion exchange resin............................................................
9. Cleaning and maintenance of the unit..............................................................
10. Troubleshooting......................................................................................................
www.timberk.com electric humidifier
2
2
3
3
4
4
5
6
7
7
3
1
2
3
4
5
6
7
8
9
10
To prevent injuries and damage to property, do not try to repair the
humidifier on your own. Take out the plug from an outlet in the following cases:
prior to draining or filling the tank with water; prior to cleaning and maintenance;
prior to mantling/dismantling of humidifiers elements; prior to transportation of
the humidifier to another place.
Install the humidifier on to a smooth dry surface. The outgoing steam may damage
surfaces it contacts. Do not install the humidifier on the floor, as well as in the
vicinity of heating appliances, furniture and other objects.
The manufacturer and the seller do not bear any responsibility for damages,
inflicted due to improper position of the humidifier.
The humidifier should be installed on some kind of an elevation, for example, on
table, stand, etc.
It is not allowed to fill water into the humidifier through the atomizer.
Do not submerge the humidifier into water or other liquids.
Do not install the humidifier in places where it can be touched, tipped over, etc.
If the humidifier is not used, unplug it from electric mains.
Do not lay the power cord under a carpet or other objects. Position the humidifier
so that the power cord cannot be stumbled upon.
Do not use the humidifier in damp rooms.
Do not allow foreign object to get into the humidifier.
Do not block the air intake and humidifiers atomizer.
Do not sit, stand and put heavy objects on the humidifier.
To prevent damage of the humidifier, do not add essential oils, preservatives,
flavors and other foreign substances to humidification water. The manufacturer
and the seller do not bear any responsibility for damages of the humidifier,
inflicted due to failure to follow this requirement.
Do not pull the power cord and do not touch it by wet hands when you unplug the
humidifier from electric mains.
3. Technical characteristics
4. Description of the unit (fig. 1-4)
Nominal rated current, A
Nominal power consumption, W
Nominal power, V/Hz 220/50
85
IPX0
0,38
Water protection
3,5
Water tank, L
250
Capacity of humidity, ml/h
Table 1.
Electrical protection class
204185340
II
Device dimension, mm
Net weight, kg 2,2
1 Atomizer
2 Nozzle
3 Nozzle installation slot
4 Cartridge filter with ion
exchange resin
5 Temperature and
humidity sensor
6 Air vent in the base
7 Plug
8 Water tank
9 Water tank handle
10 LED display
Fig. 1
Atomizer rotates 360°, steam atomization direction can be adjusted
manually at users own discretion.
11 No water indicator
12 Digital humidity indicator
13 Warm steam mode indicator
14 Atomization frequency indicator: «L» -low, «M» -middle, «H»-hight.
15 Continuous operation mode indicator
16 Timer indicator
17 Night mode indicator
18 Automatic mode indicator
Fig. 2
11 12
13
14
15
16
17
18
www.timberk.com electric humidifier
The manufacturer reserves the right to change the set-list of the device (including liquid and powder
components) for different supplies without prior notice. The changes either in no way influence the
basic technical parameters of the device or may improve them, and also not violate the legislation or
quality standards of the countries of manufacture, transit and selling.
The changes in the set-list may result in changing of the weight and dimensions of the device, but not
more than by +\- 5-20% (depending on the product category)
ENGLISH
4
27 28
29
30
31
32
33
Fig. 3
19 Increase the humidity level (+)
20 Set the steam atomization frequency
21 Set the timer (+)
22 Set the warm steam mode
23 Decrease the humidity level ()
24 Select operation modes
25 Set the timer ()
26 Units on/off button
27 Base of device under the water tank
28 Ultrasonic membrane
29 Water level sensor (float)
30 Water valve axis
31 Water receiver
32 Air vent
33 Cleaning brush (not included in
the mandatory scope of delivery)
Fig. 4
5. Scope of delivery
1. Humidifier 1 pc.
2. Operation manual 1 pc.
3. Guarantee card 1 pc.
4. Packing 1 pc.
6. Filling tank with water (fig. 5-8)
Prior to filling the tank remove the atomizer from the tank. If you fail to do
so, then upon turning over the tank the atomizer will fall down. The device
must not be operated without the atomizer.
When moving the humidifier do not grab the water tank handle. You
should hold the humidifier by the base.
Fig. 5
1. Remove the atomizer and then the water tank from the device.
2. Grab the tank handle and pull it upwards.
3. Unscrew the tank cap
counterclockwise.
Fig. 6
4. Fill the tank with
water.
Fig. 7
5. Screw the tank cap clockwise.
Make sure the tank cap is securely tightened. Be
sure that the rubber gasket is installed to the tank
cap. Securely tighten the cap clockwise.
Incomplete fulfillment of the abovementioned
measures causes the air coming into the water tank
and, as a result, a failure.
6. Install the tank and the atomizer to the device. Fig. 8
20
21
22
23
24
25
26
19
www.timberk.com electric humidifier
5
www.timberk.com electric humidifier
7. Operation of the unit
7.1 Switching on the unit
Connect the unit to electric mains. Fill the tank with water in advance.
A musical signal will be given when the unit is connected to a power supply
source.
Press On/Off button (POWER), a musical signal will be given and the unit
will automatically start operating.
AUTO mode will be shown on the display screen and steam will start
coming out of the atomizer.
The display screen will show current air humidity and the warm atomizing
mode will be switched on automatically.
Ten seconds after switching of the device a light atomizing indicator
(preparation for operation) will be illuminated and then will go out.
At the very beginning of this operation the atomizing level could seem
unstable which is caused by the temperature difference and water quality.
It will take some time for water to transform into steam inside the
atomizers nozzle and this process to be stabilized. In 10-25 minutes of
operation the atomizing level will be gradually stabilized.
Heating of steam will take about 10-20 minutes.
Important!
1. To prevent an electric shock, prior to dismantling the device
(removing the tank), unplug the device from electric mains! 2. Do
not fill the tank with liquids other than tap water.
Other composition of liquids has an adverse effect on internal
parts and results in a failure.
3. Do not fill the device or the water tank with such additives as
essential oil, flavoring substance, detergent, chemical medical
products, warm water (over 40°), etc.
Otherwise the water tank and internal parts of the unit will be
damaged and be broken.
4. Do not fill water directly into the internal part of the unit or the
atomizer.
Water inside the unit may result in failure of the device.
5. Do not hit and do not throw the water tank. It can be damaged
which will result in water leakage. Do not use the unit in case the
tank is heavily hit.
Contact a maintenance service or maintenance and repair station
immediately.
6. Every day fill the tank with pure water and keep the unit clean.
Important!
At first or repeated use of the unit even with full tank the water lack
indicator, showing there is no water, will be illuminated on the display
screen. It happens due to the fact that it takes some time for water to flow
from the tank to a water groove.
The unit will automatically start operating in 2-5 minutes.
In case if all water in the tank is used, the unit will be switched off and a
sound signal will be given prior to it and the WATER indicator will be
illuminated.
Add water in accordance with the manual for further use of the unit.
7.2 Automatic operation mode
A temperature and humidity sensor is installed inside the humidifier, when
the unit is switched on or the automatic operation mode is selected it
allows the unit to independently achieve the most favorable
humidification level depending on room air temperature and humidity.
Table 2.
22-24°
20-21° 60%
50%
55%
>25°
65%
<19°
Setting of the automatic operation mode
(level of favorable humidity)
Room air temperature
In the automatic mode the atomizing level is set in accordance with the
difference between levels of measured and nominal humidity. The
atomizing level in automatic mode:
Table 3.
<3%
4-15% Middle level mode (normal power)
automatic switching off
Low mode (low power)
Current humidity level
exceeds the favorable one
Hight level (maximum power)
>16%
Atomizing frequency
(intensity atomizer level )
Difference between levels of
favorable and current humidity
ENGLISH
6www.timberk.com electric humidifier
Table 4.
<3%
4-15% Middle level (normal power)
automatic switching off
Low level (low power)
Current humidity level
exceeds the favorable one
Hight level(maximum power)
>16%
Atomizing frequency
(intensity level atomizer)
Difference between levels of
favorable and current humidity
7.3 Mode selection
Press Mode button (SETUP) and the unit will switch over to the Night
mode, Continuous (manual) mode or Automatic mode (AUTO).
7.4 Night mode
Press On/Off button (POWER), then in the auto mode press Mode button
once to switch over to the night mode.
ZZZ indicator on the display will show that the mode is on. The level of
favorable humidity in the night mode is set to 50%. Duration of the warm
atomizing operation (designated by the HEATING indicator) in the night
mode amounts to 6 hours and it will be over in 6 hours.
The atomizing level in the night mode
Additional night mode function
When the humidifier is operating, repeated pressing POWER button
decreases the display indicators brightness. This function is necessary when
the unit is used at night for a comfortable sleep. To make the indication as
bright as it was, it is necessary to press the same button twice again: at first the
unit will be switched off and then it will be switched on again in the mode of
bright indication.
7.5 Continuous (manual) mode
Press POWER button and the unit will start operating, press SET UP button and
switch to the manual operation mode (the corresponding indicator will be
illuminated on the display). In the manual setting mode you can freely adjust
the frequency of steam atomizing, activate/deactivate humidification by
warm steam, set the most suitable humidity level and timer operation.
Press the STEAM button once to adjust settings light-moderate-intensive,
respectively. The display will show the corresponding settings.
The time, required to achieve the necessary room humidity level, depends on
the atomizing frequency. When the humidity level, set by the user, is achieved
the unit stops the operation.
At a light atomizing frequency the unit operates for about 60 hours; at a
moderate frequency about 30 hours; at an intensive frequency about 20
hours. At the intensive frequency of warm steam atomizing the unit operates
for about 11 hours.
The most suitable for the user humidity level is set by means of the lower and
upper buttons humidity level adjustment (up-down).
The setting range is within 40-80% with the adjustment of each set value by 5%.
8. Cartridge filter with an ion exchange resin
The set of the unit includes a cartridge filter with an ion exchange resin. Upon
long use of the humidifier without replacement of resin a white residue may
appear on the unit and objects next to it.
The white residue is calcium and magnesium comprised in the composition of
ordinary tap water. When the ion exchange resin in the filter expires, they are
released along with steam and settle on the surrounding objects and surfaces.
Though these substances are safe for people, in large amounts they may have
hazardous effect on furniture. By means of an ion exchange filter, installed at the
bottom of the tank, calcium and magnesium are removed from tap water. At the
beginning of operation the ion exchange filter can make water tea-colored. This
doesnt affect safety or operation of the unit.
The ion exchange filter is
installed at the cap of the water
tank. To replace the filter it is
necessary to remove a cap by
turning it counterclockwise and
then remove the filter also by
turning it counterclockwise. The
new filter is installed in the
reverse order. To purchase an ion
exchange filter, please, contact
the seller.
Note:
Sometimes at high content of calcium and magnesium in water, the ion-
exchange resin cartridge may not completely eliminate these substances from
water being used, in such a case it is necessary to use filtered water.
Important!
Useful capacity of an ion exchange filter is about 400 liters. Continuous
use after expiration reduces the capability to filter hard components
(calcium and magnesium) of tap water. As a result, the level of white
residue formation increases.
Standard filter replacement period is about 180 days given the automatic
operation mode (duration of humidification with heating about 6 hours
every day). Filter replacement period can be decreased depending on
different frequency of operation and water quality. Pay attention to the
formation of a white powder.
Fig. 9
Filter with an ion
exchange resin
Cap of water tank
9. Cleaning and maintenance of the unit
Prior to cleaning make sure that the plug is disconnected from an outlet.
Otherwise it may result in an electric shock.
Before cleaning, wait until water in the base device is completely cooled
down in order not to burn hands.
Clean the unit once or twice a week.
9.1 To wipe the external surface of the unit use a damp and soft cloth.
To prevent an electric shock do not scratch and do not damage units
elements upon cleaning.
When cleaning the unit, do not use solvents, benzine, dimethylbenzene, hard
brush, talc powder and other substances other than water.
9.2 Wipe water remains inside the base device under the tank by a damp
and soft cloth.
To remove water remains on small parts you can use the brush, and then wipe
them again with a soft cloth.
9.3 If there is dirt on the membrane, clean it by means of a brush.
9.4 Use a brush to remove water remains on the surface of the nozzle
and then wipe it again by a soft cloth.
9.5 Clean the water tank and the atomizer by pure water. Clean the cap
carefully, without applying much effort, otherwise it may result in water
leakage through the cap.
Once water remains are removed from the surface of the atomizer, wipe it
by a soft cloth.
Clean the external surface of the unit by a damp and soft cloth.
10. Troubleshooting
In case of emergencies resort to troubleshooting methods, given in table 5.
Poor atomizing
(insufficient
performance)
Remedy
Defect Possible cause
The unit is operating in
a light mode (low
atomizing frequency)
No defect. If necessary to switch to the intensive
mode, press «STEAM» button in
the manual setting mode and switch the unit
to the intensive operation mode.
Atomizer is clogged Clean the atomizer
Tank water temperature
is too low Set the maximum performance. Humidifiers
performance will be increased in 10 minutes
No atomizing The plug is poorly
inserted into an outlet Connect the plug into an outlet carefully
Red light on the water
indicator has illuminated
and went out (water
tank is completely empty)
Add water to the tank
A white residue appeared
on objects around the
humidifier (salts,
separating from water)
Lime deposits are formed
on the membrane Clean the humidifiers membrane by a special brush
Water demineralization
cartridge is worn down
(ion exchange resin).
Inused water contains
a large amount a caleium
or magnesium.
Replace the cartridge.
No warm atomizing Use of warm steam is
not selected Press «HEART» button in the manual setting
mode and switch the unit to a warm steam
humidification mode
Operation has just started No defect. It will take about 10-20 minutes
for warm steam to be atomized (time, required
for water heating by the heater after
its switched on)
Difference between the
level of current humidity
and readings of a
humidity recorder
is too big
Dirt accumulation
inside an air vent Clean the air vent. Even in one room humidity
can be different depending on the location
The unit is operated in
places, where it is affected
by the environment,
for example, by a window
Install the unit in places, where it cannot be
affected by the environment
Steam has an
unpleasant odor
Signal 1 is given
Signal 2 is given
Not fresh water in use
Tank full sound signal
Fan operation
sound signal
There are remains of
not fresh water or litter
in the water groove
Clean the unit in accordance with the cleaning
and maintenance manual and fill it with fresh
water
No defect in the unit, keep on its operation
Table 5.
ENGLISH
Fig. 10
Fig. 11
11. Utilization
If you are unable to solve issues by means of mentioned methods,
contact a service center.Life of the humidifier is 2 years.
Upon expiration of the humidifier it must be disposed in accordance with
regulations, rules and by means, currently in force at a disposal station.
The base of the device
Membrane
Use a filtred water.
8
1.
,
.
.
,
.
,
.
,
.
.
40 60%.
,
,
(
).
,
, , ,
,
, ,
,
,
,
,
,
,
.
2.
.
,
.
,
.
.
,
.
, ,
.
( )
, ,
,
,
. ,
.
, ,
.
!
Timberk. .
, !
www.timberk.com
1. ..............................................................................................
2. ...................................................................................
3. ............................................................................
4. .................................................................................................
5. .........................................................................................................
6. .......................................................................
7. ........................................................................................
8. - ..............................................
9. ...................................................................
10. ........................................................
11. ............................................................................................................
12. .......................................................................
8
8
9
9
10
10
11
13
14
14
15
16
9
.
. -
.
:
.
,
.
.
.
: ;
; /
; .
.
, .
,
, , .
, -
, .
- , ,
, ..
.
.
,
, ..
, .
.
, .
.
.
.
, .
, ,
.
3.
,
,
, / 220/50
85
IPX0
0,38
3,5
,
250
, /
1.
4.
(. 1-4)
1
2
3
4 -
5
6
7
8
9
10 LED-
204185340
II
,
, 2,2
. 1
1
2
3
4
5
6
7
8
9
10
360°,
.
( \
),
, \
\ .
, +\- 5-20%
( ).
www.timberk.com
60 ;
30 ; 20 . «»
11 .
, -
, .
.
.
27 28
29
30
31
32
33
10
11
12
13
14 («L» - , «M» - ,
«H» - )
15
16
17
18
. 3
. 2
19 (+)
20
21 (+)
22
23 ()
24
25 ()
26 ./.
27
28
29 ()
30
31
32
33 (
)
5.
1. 1 .
2. 1 .
3. 1 .
4. 1 .
6.
(. 5-8)
.
, ,
.
.
.
.
. 5
. 4
1. , .
2. .
11 12
13
14
15
16
17
18
20
21
22
23
24
25
26
19
www.timberk.com
11
3.
. 6
4.
.
. 7
5.
.
. ,
.
.
.
6.
.
. 8
7. .
7.1 .
,
.
.
«./.» («POWER»),
, .
«AUTO»
.
.
!
1. , ,
( ),
!
2. ,
.
.
3.
, ,
, ,
( 40°) . .
.
4.
.
.
5. .
, .
.
.
6.
.
(
).
,
. ,
. 1025
.
1020 .
www.timberk.com
12 www.timberk.com
!
, , . -
,
.
25 .
,
«WATER». ,
. 6 («
»).
2.
22-24°
20-21° 60%
50%
55%
>25°
65%
<19°
( )
7.2
,
.
. :
3.
<3 %
4-15 % ( )
( )
( )
>16 %
( )
7.3
« » (SET UP)
« », « () »
« » (AUTO).
7.4
«./.» (POWER), ,
, « »
.
«ZZZ» .
50%.
( «HEATING»)
6 6 .
:
4.
<3
4-15 % ( )
( )
( )
>16 %
( )
!
, ,
.
.
.
,
«POWER» .
.
,
: ,
.
7.5 ()
«POWER» ,
«SET UP» (
).
,
/ ,
.
«STEAM» .
8. -
-
.
.
,
.
.
,
.
,
.
.
.
13
,
, ,
,
«L» - , «M» - , «H» - .
.
.
.
60 ;
30 ; 20 .
«»
11 .
«
» (-).
40% 80%
5%.
. 9
!
400
.
( ) .
.
180
( 6
).
.
.
, ,
, .
.
.
www.timberk.com
:
,
, -
.
14 www.timberk.com
9.
,
. ,
.
, .
.
9.1
.
.
, ,
, , ,
.
9.2
.
, .
. 10
9.3 ,
.
. 11
9.4
, .
9.5 .
,
.
.
.
!
,
,
,
.
.
.
.
,
.
,
, .
.
.
10.
, 5.
.
15
www.timberk.com
(
)
5
(
)
.
«STEAM»
.
10
(
)
(,
)
-
( )
«HEAT»
.
-
(
)
,
,
,
,
«1»
«2»
,
11.
2 .
, ,
.
16 www.timberk.com
12.
:
. RU.0001.11AB71.
"". : 123308. . , .
, .3, . 1, . 323;
: 115162, . , . 28, 4, .
+7 495 6044266, +7 495 6044266.
:
52161.2.30-2007,
51318.14.1-2006 .4,
51318.14.2-2006 .5,7,
51317.3.3-2008,
51317.3.2-2006 .6,7
: RU C-IL.AB71.B.00081
: 5.07.2012 4.07.2015
*:
« » , 10, ,
88000
/ +972-8-637-88-311
*:
OOO «»
: . , . , 1, .1, 606
/ (499) 638-26-77
:
+ 7 (495) 6275285
* , ,
\ \ .
, ,
.
EEC 89/336,
,
.
.
Timberk ,
Timberk , ,
,
, ,
.
17
www.timberk.com
18 www.timberk.com electric humidifier
19
www.timberk.com
Timberk
.
Timberk,
,
:
1.
2.
3.
(
)
:
1.
2.
3. ,
c 10%,
4.
.
RU
BY
KG
KZ
UA
AK
TJ
()
.
OS
CIS
www.timberk.com
ÀÂ71
www.timberk.ru
Table of contents
Other Timberk Humidifier manuals
Timberk
Timberk THU 14 E User manual
Timberk
Timberk H2O Series User manual
Timberk
Timberk THU UL 07 User manual
Timberk
Timberk THU UL 37 E User manual
Timberk
Timberk T-HU3.5-A15E-W User manual
Timberk
Timberk THU UL 26 (PW) User manual
Timberk
Timberk THU UL 03 (GN) User manual
Timberk
Timberk THU UL 16M User manual
Timberk
Timberk T-HU6-A19E-W User manual
Timberk
Timberk THU UL 18 YE User manual
Timberk
Timberk T-HU4-A16M-W User manual
Timberk
Timberk THU UL 42 E User manual
Timberk
Timberk THU UL 06 User manual
Timberk
Timberk Harmony Series User manual
Timberk
Timberk THU UL 30 E User manual
Timberk
Timberk THU MINI 01 (W) User manual
Timberk
Timberk THU UL 05 User manual
Timberk
Timberk THU UL 03 W User manual
Timberk
Timberk T-HU5.2-A21E-W User manual
Timberk
Timberk THU UL 03 (P) User manual
