TimberPro HT 260 User manual

OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
GEBRUIKSAANWIJZING
MANUAL DEL PROPIETARIO
MANUALE D’ISTRUZIONI

DE 31-45
FR 16-30
GB 01-15
NL 46-60
ES 61-75
IT 76-90
HEDGE TRIMMER
TAILLE HAIE
HECKENSCHERE
DECESPUGLIATORE
CORTASETOS
HEGGENSCHAAR

12. Limited warranty ............................................ 15
7. Operation ...................................................... 9
4. Symbols on the machine ................................ 3
1. Parts location ...................................................2
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a
symbol concern critical points which must be taken
into consideration to prevent possible serious bodily injury, and
for this reason you are requested to read all such instructions
carefully and follow them without fail.
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in or-
der to prevent accidents, which could lead to serious bodily in-
jury or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
Contents
2. Specifications ................................................. 2
3. Warning labels on the machine ...................... 3
5. For safe operation........................................... 4
6. Fuel ................................................................. 7
8. Maintenance ................................................. 11
9. Storage ......................................................... 14
10. Disposal ........................................................ 14
11. Troubleshooting guide .................................. 14
GB 1

Dry weight............................................................................................................6,0 kg
Spark plug ............................................................................................... LD BM6A
Model .............................................................................................................1E34F
Blade length (from the tip of Gear Case)...........................................................600 mm
Model ..................................................................................................................HT260
19. Locking lever
1. Parts location
1. Front handle
2. Rear handle
3. Stop switch
4. Throttle trigger
5. Safety lock
6. Blades
7. Blade guard
Type ................................................................................................ double-action type
Engine
Displacement ........................................................................................... 25.4 cm3
Carburetor .................................................................................... Diaphragm type
Ignition system ..................................................... I.C.controlled flywheel magneto
Fuel ............................................................................. mixture (Gasoline 40 : Oil 1)
Fuel tank capacity ................................................................................................. 0,6 L
Starter ...................................................................................................... Recoil starter
Clutch .................................................................................................. Centrifugal type
Specifications are subject to change without notice.
2. Specification
8. Gear case
9. Starter knob
10. Fuel tank
11. Fuel cap
12. Choke lever
13. Air cleaner cover
14. Spark plug cap
15. Blade cover
16. Operator’s manual
17. Socket
18. Allen key
19
GB 2

G
B
3. Warning labels on the machine
If warning label peels off or becomes soiled and
impossible to read, you should contact the
dealer from which you purchased the product
to order new labels and affix them in the required
location(s).
Never modify your machine.
We won’t warrant the machine, if you use the
remodeled hedge trimmer or if you don’t ob-
serve the proper usage written in the manual.
(1)
(1)Read owner's manual before operat-
ing this machine.
(2)Wear head, eye and ear protection.
(3)Handling this machine improperly
could result in accidents causing se-
rious injury or death. Read this
manual carefully and practice using
the hedge-trimmer until you are fully
acquainted with all operations and
have learned to use it correctly.
(4)This is extremely sharp and can eas-
ily cause cuts.
4. Symbols on the machine
For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications,
please be careful not to make a mistake.
The port to refuel the “MIX GASOLINE”
Position: FUEL TANK CAP
The direction to close the choke
Position: AIR CLEANER COVER
The direction to open the choke
Position: AIR CLEANER COVER
GB 3

gases contain dangerous carbon
monoxide.
2. Never use the product,
a. when the ground is slippery
or when you can’t maintain a
steady posture.
b. At night, at times of heavy fog,
or at any other times when
your field of vision might be
limited and it would be diffi-
cult to gain a clear view of the
working area.
c. During rain, during storms at
times of strong or gale-force
winds, or at any other times
when weather conditions
might make it unsafe to use
the product.
WORKING PLAN
1. You should never use the prod-
uct when under the influence of
alcohol, when suffering from ex-
haustion or lack of sleep, when
suffering from drowsiness as a re-
sult of having taken cold medicine
or at any other time when a pos-
sibility exists that your judgment
might be impaired or that you
might not be able to operate the
product properly and in a safe
manner.
2. When planning your work sched-
ule, allow plenty of time to rest.
Limit the amount of time over
which the product is to be used
continuously to somewhere
around 30 ~ 40 minutes per ses-
sion, and take 10 ~ 20 minutes of
rest between work sessions. Also
try to keep the total amount of
work performed in a single day
under 2 hours or less.
WARNING
1. If you don’t observe the working
time, or working manner (See
“USING THE PRODUCT”), Re-
petitive Stress Injury (RSI) could
occur.
If you feel discomfort, redness and
swelling of your fingers or any
other part of your body, see a doc-
tor before getting worse.
2. To avoid noise complaints, in gen-
eral, operate product between
8 a.m. and 5 p.m. on weekdays
and 9 a.m. to 5 p.m. on weekends.
1.THIS MACHINE CAN CAUSE
SERIOUS INJURIES. Read this
manual carefully until you com-
pletely understand and follow all
safety and operating instruc-
tions. Also, know how to stop the
machine quickly in an emer-
gency.
2. Keep this manual handy so that
you may refer to it later when-
ever any questions arise. Also
note, if you have any questions
which cannot be answered
herein, contact the dealer from
whom you purchased the prod-
uct.
3. Always be sure to include this
manual when selling, lending, or
otherwise transferring the own-
ership of this product.
4. Never allow children or anyone
unable to fully understand the
directions given in the manual
to use the machine.
WORKING CONDITION
1. When using the product, you
should wear proper clothing and
protective equipment.
(1) Helmet
(2) Ear protectors
(3) Protection goggles or face
protector
(4) Thick work gloves
(5) Non-slip-sole work boots
2. And you should carry with you.
(1) Attached tools
(2) Properly reserved fuel
(3) Spare blade
(4) Things to notify your working
area (rope, warning signs)
(5) Whistle (for collaboration or
emergency)
(6) Hatchet or saw (for removal of
obstacles)
(7) First-aid kit
3. Do not wear loose clothing, jew-
elry, short trousers, sandals, or go
barefoot. Do not wear anything
which might be caught by a mov-
ing part of the unit. Secure hair
so it is above shoulder length.
WORKING CIRCUMSTANCE
1. Never start the engine inside a
closed room or building. Exhaust
5. For safe operation
GB 4

G
B
BEFORE STARTING
THE ENGINE
1. The area within a perimeter of
15 m of the person using the
product should be considered a
hazardous area into which no one
should enter. If necessary, yellow
warning rope, warning signs
should be placed around the pe-
rimeter of the area. When work is
to be performed simultaneously
by two or more persons, care
should also be taken to constantly
look around or otherwise check
for the presence and locations of
other people working so as to
maintain a distance between
each person sufficient to ensure
safety.
2. Check the condition of working
area to avoid any accident by hit-
ting hidden obstacles such as
stumps, stones, cans, or broken
glass.
IMPORTANT
Remove any obstacle before begin-
ning work.
3. Inspect the entire unit for loose
fasteners and fuel leakage. Make
sure that the cutting attachment
is properly installed and securely
fastened.
STARTING THE ENGINE
1. Keep bystanders, especially chil-
dren, and animals at least 15 m
away from the operating point. If
you are approached, immediately
stop the engine.
2. The product is equipped with a
centrifugal clutch mechanism, so
the cutting attachment begins to
move as soon as the engine is
started by putting the throttle into
the start position. When starting
the engine, place the product
onto the ground in a flat clear area
and hold it firmly in place so as to
ensure that neither the cutting
part nor the throttle come into
contact with any obstacle when
the engine starts.
IMPORTANT
Check and follow the local regula-
tions as to sound level and hours of
operations for the product.
WARNING
• Never place the throttle into the
high-speed position when start-
ing the engine.
• Never start the engine at the cut-
ting attachment side.
3. After starting the engine, check
to make sure that the cutting at-
tachment stops moving when the
throttle is moved fully back to its
original position. If it continues to
move even after the throttle has
been moved fully back, turn off
the engine and take the unit to
your authorized Timberpro servi-
cing dealer for repair.
USING THE PRODUCT
IMPORTANT
Cut only materials recommended by
the manufacturer. And use only for
tasks explained in the manual.
1. Grip the handles firmly with both
hands using your whole hand.
Place your feet slightly apart
(slightly further apart than the
width of your shoulders) so that
your weight is distributed evenly
across both legs, and always be
sure to maintain a steady, even
posture while working.
2. Maintain the speed of the engine
at the level required to perform
cutting work, and never raise the
speed of the engine above the
level necessary.
3. If the unit starts to shake or vi-
brate, turn off the engine and
check the whole unit. Do not use
it until the trouble has been prop-
erly corrected.
4. Keep all parts of your body away
from moving cutting attachment
and hot surfaces.
5.
Never touch the muffler, spark plug,
or other metallic parts of the engine
while the engine is in operation or
immediately after shutting down the
engine. Doing so could result in
serious burns or electrical shock.
6. While operating the machine be
always sure of a safe and secure
operating position especially
when using steps or a ladder.
5. For safe operation
GB 5

servicing dealer for`
authori-
from the store nearest
is desi-
The engine of the product
•IF SOMEONE COMES
1. Guard against hazardous situa-
tions at all times. Warn adults to
keep pets and children away from
the area. Be careful if you are ap-
proached. Injury may result from
flying debris.
2. If someone calls out or otherwise
interrupts you while working, al-
ways be sure to turn off the en-
gine before turning around.
MAINTENANCE
1. In order to maintain your product
in proper working order, perform
the maintenance and checking
operations described in the
manual at regular intervals.
2. Always be sure to turn off the en-
gine and disconnect the spark
plug wire before performing any
maintenance, checking proce-
dures or working on the machine.
WARNING
The metallic parts reach high tem-
peratures immediately after stop-
ping the engine.
3. In the event that any part must be
replaced or any maintenance or
repair work not described in this
manual must be performed,
please contact a representative
assistance.
4. Under no circumstances should
you ever take apart the product
or alter it in any way. Doing so
5. For safe operation
might result in the product be-
coming damaged during opera-
tion or the product becoming un-
able to operate properly.
HANDLING FUEL
1.
uct is designed to run on a mixed
fuel, which contains highly flam-
mable gasoline. Never store cans
of fuel or refill the tank of the unit
in any place where there is a
boiler, stove, wood fire, electrical
sparks, welding sparks, or any
other source of heat or fire which
might ignite the fuel.
2. Never smoke while operating the
unit or refilling its fuel tank.
3. When refilling the tank, always
turn off the engine and allow it to
cool down. Take a careful look
around to make sure that there are
no sparks or open flames any-
where nearby before refueling.
4. Wipe spilled fuel completely us-
ing a dry rag if any fuel spillage
occurs during refueling.
5. After refueling, screw the fuel cap
back tightly onto the fuel tank and
then carry the unit to a spot 3 m
or more away from where it was
refueled before turning on the
engine.
6. Do not inhale fuel fumes as they
are toxic.
TRANSPORTATION
1. When hand-carrying the product,
cover over the cutting part if nec-
essary, lift up the product and
carry it paying attention to the
blade.
2. Never transport the product over
rough roads over long distances
by vehicle without removing all
fuel from the fuel tank. If doing so,
fuel might leak from the tank dur-
ing transport.
7. Check the cutting attachment.
Never use blades that are dull,
cracked or damaged.
8. To reduce the fire hazard, clean
dirt, leaves and surplus lubricant,
etc from the muffler and engine.
GB 6

6. Fuel
GB 7
■ FUEL
WARNING
• Gasoline is very flammable. Avoid smoking or
bringing any flame or sparks near fuel. Make sure
to stop the engine and allow it cool before refuel-
ing the unit. Select outdoor bare ground for fueling
and move at least 3 m (10 ft) away from the fueling
point before starting the engine.
40
- ONLY USE UNLEADED 95 FUEL (STANDARD) AND
SYNTHETIC 2-STROKE OIL FOR THE MIXTURE.
MIX 25:1 40:1
Gasoline Oil in ml Oil in ml
1,0 Liter 40 25
1,5 Liter 60 38
2,0 Liter 80 50
2,5 Liter 100 63
3,0 Liter 120 75
3,5 Liter 140 88
4,0 Liter 160 100
4,5 Liter 180 113
5,0 Liter 200 125
5,5 Liter 220 138
6,0 Liter 240 150
6,5 Liter 260 163
7,0 Liter 280 175
7,5 Liter 300 188
8,0 Liter 320 200
8,5 Liter 340 213
9,0 Liter 360 225
9,5 Liter 380 238
10,0 Liter 400 250
10,5 Liter 420 263
11,0 Liter 440 275
11,5 Liter 460 288
12,0 Liter 480 300
12,5 Liter 500 313
13,0 Liter 520 325
13,5 Liter 540 338
14,0 Liter 560 350
14,5 Liter 580 363
15,0 Liter 600 375
15,5 Liter 620 388
16,0 Liter 640 400
16,5 Liter 660 413
17,0 Liter 680 425
■RECOMMENDED MIXING RATIO
GASOLINE 40 : OIL 1
√
■ FUEL
WARNING
• Gasoline is very flammable. Avoid smoking or
bringing any flame or sparks near fuel. Make sure
to stop the engine and allow it cool before refuel-
ing the unit. Select outdoor bare ground for fueling
and move at least 3 m (10 ft) away from the fueling
point before starting the engine.
40
- ONLY USE UNLEADED 95 FUEL (STANDARD) AND
SYNTHETIC 2-STROKE OIL FOR THE MIXTURE.
MIX 25:1 40:1
Gasoline Oil in ml Oil in ml
1,0 Liter 40 25
1,5 Liter 60 38
2,0 Liter 80 50
2,5 Liter 100 63
3,0 Liter 120 75
3,5 Liter 140 88
4,0 Liter 160 100
4,5 Liter 180 113
5,0 Liter 200 125
5,5 Liter 220 138
6,0 Liter 240 150
6,5 Liter 260 163
7,0 Liter 280 175
7,5 Liter 300 188
8,0 Liter 320 200
8,5 Liter 340 213
9,0 Liter 360 225
9,5 Liter 380 238
10,0 Liter 400 250
10,5 Liter 420 263
11,0 Liter 440 275
11,5 Liter 460 288
12,0 Liter 480 300
12,5 Liter 500 313
13,0 Liter 520 325
13,5 Liter 540 338
14,0 Liter 560 350
14,5 Liter 580 363
15,0 Liter 600 375
15,5 Liter 620 388
16,0 Liter 640 400
16,5 Liter 660 413
17,0 Liter 680 425
■RECOMMENDED MIXING RATIO
GASOLINE 40 : OIL 1
√

GB 8
6. Fuel
3. DO NOT USE READY-TO-USE ALKYLATE PETROL, THESE
2. DO NOT USE FUEL TYPE SP95-E10 (10% ETHANOL) TO
•Exhaust emission are controlled by the funda-
mental engine parameters and components (eq.,
carburation, ignition timing and port timing) with-
out addition of any major hardware or the introduc-
tion of an inert material during combustion.
• These engines are certified to operate on unleaded
gasoline.
• If you use a gasoline of a lower octane value than pre-
scribed, there is a danger that the engine tempera-
ture may rise and an engine problem such as piston
seizing may consequently occur.
• Unleaded gasoline is recommended to reduce the
contamination of the air for the sake of your health and
the environment.
• Poor quality gasolines or oils may damage sealing
rings, fuel lines or fuel tank of the engine.
■ HOW TO MIX FUEL
WARNING
•Pay attention to agitation.
1. Measure out the quantities of gasoline and oil to be
mixed.
2. Put some of the gasoline into a clean, approved fuel
container.
3. Pour in all of the oil and agitate well.
4. Pour in the rest of gasoline and agitate again for at
least one minute. As some oils may be difficult to
agitate depending on oil ingredients, sufficient agi-
tation is necessary for the engine to last long. Be
careful that, if the agitation is insufficient, there is an
increased danger of early piston seizing due to ab-
normally lean mixture.
5.
Put a clear indication on the outside of the container
to avoid mixing up with gasoline or other containers.
6. Indicate the contents on outside of container for easy
identification.
■ FUELING THE UNIT
1. Untwist and remove the fuel cap. Rest the cap on a
dustless place.
2. Put fuel into the fuel tank to 80% of the full capacity.
3. Fasten the fuel cap securely and wipe up any fuel
spillage around the unit.
WARNING
1. Select flat and bare ground for fueling.
2. Move at least 10 feet (3 meters) away from the fu-
eling point before starting the engine.
3. Stop the engine before refueling the unit. At that
time, be sure to sufficiently agitate the mixed gaso-
line in the container.
■ FOR YOUR ENGINE LIFE, AVOID:
1. FUEL WITH NO OIL (RAW GASOLINE) – It will cause
severe damage to the internal engine parts very quickly.
4. OIL FOR 4-CYCLE ENGINE USE – It can cause spark
plug fouling, exhaust port blocking, or piston ring stick-
ing.
5. Mixed fuels which have been left unused for a pe-
riod of one month or more may clog the carburetor
and result in the engine failing to operate properly.
6. In the case of storing the product for a long period of
time, clean the fuel tank after rendering it empty. Next,
activate the engine and empty the carburetor of the
composite fuel.
7. In the case of scrapping the used mixed oil container,
scrap it only at an authorized repository site.

17,5 Liter 700 438
18,0 Liter 720 450
18,5 Liter 740 463
19,0 Liter 760 475
19,5 Liter 780 488
20,0 Liter 800 500
MAKE THE 2-STROKE MIXTURE.
TYPES OF FUELS ARE DIFFERENT IN COMPOSITION AND
NOT COMPATIBLE WITH OUR MACHINES AND CAN RESULT
IN EARLY DAMAGE OF THE ENGINE AND / OR CARBURETOR.
NOTE
As for details of quality assurance, read the description
in the section Limited Warranty carefully. Moreover, nor-
mal wear and change in product with no functional in-
fluence are not covered by the warranty. Also, be care-
ful that, if the usage in the instruction manual is not ob-
served as to the mixed gasoline, etc. described therein,
it may not be covered by the warranty.

STARTING ENGINE
1. Feed fuel into the fuel tank and tighten the cap se-
curely.
2. Rest the unit on a flat, firm place. Keep the cutting
head off the ground and clear of surrounding objects
as it will start moving upon starting of the engine.
3. Push the primer several times until overflown fuel flows
out in the clear tube.
(a) Primer (b) Clear tube
4. When the engine is cool, move the choke lever to the
closed position.
(a) Choke lever (b) Open (c) Close
5. Set the ignition switch to the “RUN” position.
Release the throttle trigger and make sure it is fully back.
6. While holding the unit firmly, pull out the starter rope
quickly until engine fires.
IMPORTANT
• Avoid pulling the rope to its end or returning it by re-
leasing the knob. Such actions can cause starter fail-
ures.
7. Move the choke lever downward to open the choke.
and restart engine.
8. Allow the engine to warm up for a several minutes
before starting opertion.
NOTE
1. When restarting the engine immediately after stop-
ping it, leave the choke open.
2. Overchoking can make the engine hard to start due
to excess fuel. When the engine failed to start after
several attempts, open the choke and repeat pulling
the rope, or remove the spark plug and dry it.
STOPPING ENGINE
1. Release the throttle trigger and run the engine for half
a minute.
2. Shift the stop switch to the “STOP” position.
IMPORTANT
• Except for an emergency, avoid stopping the engine
while pulling the throttle trigger.
NOTE
If the engine won't stop when setting the stop switch to
the stop position, close the choke lever and stop the
engine.
In this case, please repair the machine at your nearest
servicing dealer.
7. Operation
(a) Throttle trigger (b) Stop switch (c) RUN (d) STOP
a
b
(c)
d
a
b
(c)
d
GB 9

ith the 2-sided blade model HT 260 use an arc-
HOW TO USE : HANDLE
CUTTING WORK
WARNING
•Weather conditions and altitude may effect
carburation.
•Do not allow anyone to stay close to the hedge-
trimmer while working or while adjusting the car-
buretor.
•To reduce fatigue when trimming hedges, the handle
can be swivelled through 90° to the left or right.
•Do not press the throttle during this operation!
Proceed as follows:
1. Free the handle by pressing the locking lever.
2. Turn the handle until the locking lever clicks into place.
3. When the handle is locked in its new position, you can
apply the throttle again.
7. Operation
(1) handle
(2) locking lever
•You can swivel the handle even with the engine
idling because the hedge-trimmer is equipped with
a blade brake that maintains the blades at a
standstill.
■HEDGE TRIMMING TECHNIQUES
Trim sides of a hedge first, and then the top.
Vertical cut:
Horizontal cut:
• In order to get the best cutting results, slightly tilt the
blade (5÷10°) towards the cutting direction.
Cut slowly, specially with thick hedges.
WARNING
Always follow the safety precautions.
The hedge-trimmer must only be used to trim hedges
or small bushes. It is forbidden to cut other types of
material. Do not use the hedge-trimmer as a lever to
lift, move or break objects, nor lock it on fixed sup-
ports. It is forbidden to apply tools or applications
that are not the ones indicated by the manufacturer
onto the hedge-trimmer’s power take-off. Do not use
it for pruning trees or cutting grass.
•W
ing cut from the bottom upwards, then downwards to
use both sides of the blades. GB 10

8. Maintenance
Every Every Every
25 50 100
System/components Procedure Before hours hours hours Note
use after after after
fuel leaks, fuel spillage wipe out ✔
fuel tank, air filter, fuel filter inspect/clean ✔✔ replace, if necessary
see adjusting replace carburetor
idle adjusting screw ✔
idling speed if necessary
clean and readjust GAP: 0.6 ~ 0.7 mm
spark plug ✔
plug gap replace, if necessary
intake air cooling vent clean ✔
throttle trigger, stop switch check operation ✔
clean take it to a service dealer
cutting parts ✔if somethings wrong
gear case grease ✔
screws/nuts/bolts tighten/replace ✔✔not adjusting screws
plate receive make sure to attach ✔
ENGINETRIMMER
WARNING
•Make sure that the engine has stopped and is cool
before performing any service to the machine. Con-
tact with moving cutting head or hot muffler may
result in a personal injury.
BLADE
• Clean any resin and plant reside from the blade be-
fore and after using the machine.
• Check the cutting edges and reform with a flat file.
WARNING
•Make sure that the blade bolts are well tightened.
• The blade assembly is designed to automatically
compensate for any play between the blades.
Point :
1. Keep the end corner sharp.
2. Round the root of the edge.
3. Do not use water when using a grinder.
IMPORTANT
When mounting the blade, make sure to fasten the
spacer, washer and bolt, then fasten the nut.
■SHARPENING
Always keep the file or sharpener at an angle of 45° to
the blade, and:
• Always grind in the direction of the cutting edge;
• Note: files cut only in one direction; lift the file from
the blade when returning to start a new pass;
• Remove all burr from the edge of the blade with a slip
stone;
• Remove as little material as possible;
• Before refitting the sharpened blades, remove filings
and then apply grease.
Do not try to sharpen a damaged blade: change it or
take it to a Service dealer.
GB 11

Check periodically if the springs are not
Check periodically if the rubber cushions
G
B
8. Maintenance
ANTI-VIBRATION SYSTEM
WARNING
The deformed or damaged anti-vibration system may
cause of the breakages like getting rickety or falling
off of engine and/or blade .
•
are not deformed or damaged.
•
deformed or damaged.
AIR FILTER
• The air filter, if clogged, will reduce the engine perfor-
mance. Check and clean the filter element in warm,
soapy water as required. Dry completely before in-
stalling. If the element is broken or shrunk, replace
with a new one.
FUEL FILTER
• When the engine runs short of fuel supply, check the
fuel cap and the fuel filter for blockage.
SAFETY LOCK
WARNING
•Stop operation when the safety lock is defective.
• Safety lock is the device not to accelerate the throttle
trigger without intention. While pushing the safety lock,
you can accelerate the throttle trigger.
1. Check if the throttle trigger does not move when
you do not push the safety lock.
2. Check if the throttle trigger moves when you grasp
or release it while pushing the safety lock.
3. Check if the safety lock returns to its original po-
sition when you release your hand from safety lock.
• If you find any defects at the checks above, contact
your nearest servicing dealer for repair.
(1) Safety lock
GB 12

8. Maintenance
ADJUSTING CARBURETOR
The carburetor has been adjusted at the factory. Should
your unit need readjustment due to the changes in alti-
tude or operating conditions, please let your skillful dealer
make the adjustment. A wrong adjustment may cause
damage to your unit.
(1) Idle adjusting screw
(2) Up
(3) Down
(4) Fuel adjusting screw
(Opening 1 ± 1/4)
(5) Decrease
(6) Increase
WAY OF THE COOLING AIR
• This engine is air-cooled. Dust clogging between the
inlet port of the cooling air and cylinder fins will cause
overheating of the engine. Periodically check and
clean the cylinder fins after removing the air cleaner
and the cylinder cover.
0.6~0.7 mm
TIGHTENING TORQUE: 14.7–21.5 N·m
SPARK PLUG
• Starting failure and misfiring are often caused by a
fouled spark plug. Clean the spark plug and check
that the plug gap is in the correct range. For a re-
placement plug, use the correct type.
IMPORTANT
•Note that using any spark plug other than those des-
ignated may result in the engine failing to operate prop-
erly or in the engine becoming overheated and dam-
aged.
•To install the spark plug, first turn the plug until it is
finger tight, then tighten it a quarter turn more with a
socket wrench.
GEAR CASE
• Supply multi-purpose grease at every 50 hours of use.
1. Use a grease pump.
2. Feed grease until it comes out of the base of blades.
(a) Grease nipple: A type
ADJUSTING THROTTLE CABLE
•The normal play is 1 or 2 mm when measured at the
carburetor side end. Readjust with the cable adjuster
as required and tighten the screw up.
(1)
(3)
(2)
(1) Cable adjuster
(2) 0.04in (1~2mm)
(3) Screw
GB 13

When your unit seems to need further service, please consult with our service shop in your area.
G
B
9. Storage
1. Oil the blade to prevent rust.
2. Empty the fuel tank and put the cap back on.
3. Remove the spark plug, pour a small amount of oil
into the cylinder.
4. Rotate the crankshaft several times using the start-
ing rope in order to distribute the oil. Put the spark
plug back in.
5. Wrap the engine with a plastic sheet.
6. Store the trimmer indoors in a dry place, dust free
place, out of the reach of children, preferably not in
direct contact with the floor and away from heat
sources.
10. Disposal
• When you dispose of the machine, do not disassemble
the machine.
•When you dispose of the machine fuel oil, be sure to
follow your local regulations.
11. Troubleshooting guide
Case 1. Starting failure
CHECK PROBABLE CAUSES ACTION
fuel tank Aincorrect fuel Adrain it and use correct fuel
fuel filter Afuel filter is clogged Aclean
carburetor adjustment screw Aout of normal range Aadjust to normal range
sparking (no spark) Aspark plug is fouled/wet Aclean/dry
Aplug gap is incorrect Acorrect (GAP: 0.6 ~ 0.7 mm)
spark plug Adisconnected Aretighten
Case 2. Engine starts but does not keep running/hard re-starting
CHECK PROBABLE CAUSES ACTION
fuel tank Aincorrect fuel or staled fuel Adrain it and use correct fuel
carburetor adjustment screw Aout of normal range Aadjust to normal range
muffler, cylinder (exhaust port) Acarbon is built-up Aconsult with the repair specialty store
air cleaner Aclogged with dust Awash
cylinder fin, fan cover Aclogged with dust Aconsult with the repair specialty store
GB 14

12. Limited warranty
Should any failure occur on the product under normal
operating conditions within the applicable warranty pe-
riod, the failed part will be replaced or repaired free of
charge by a TIMBERPRO authorized dealer.
WARRANTY PERIOD: 2 years (6 months if used profes-
sionally, and 30 days if used for rental purpose) from the
date of initial purchase.
THE PURCHASER SHALL BEAR COSTS OF TRANS-
PORTING THE UNIT TO / FROM TIMBWERPRO
DEALER.
THE PURCHASER SHALL NOT BE CHARGED FOR DI-
AGNOSTIC LABOR WHICH LEADS TO THE DETERMI-
NATION THAT A WARRANTED PART IS DEFECTIVE, IF
THE DIAGNOSTIC WORK IS PERFORMED AT THE
DEALER.
THE PURCHASER OR OWNER IS RESPONSIBLE FOR
THE PERFORMANCE OF THE REQUIRED MAINTE-
NANCE AS DEFINED BY THE MANUFACTURER IN THE
OWNER/OPERATOR MANUAL.
ANY WARRANTED PART WHICH IS NOT SCHEDULED
FOR REPLACEMENT AS REQUIRED MAINTENANCE,
OR WHICH IS SCHEDULED ONLY FOR REGULAR IN-
SPECTION TO THE EFFECT OF REPAIR OR “REPLACE
AS NECESSARY” SHALL BE WARRANTED FOR THE
WARRANTY PERIOD. ANY WARRANTED PART WHICH
IS SCHEDULED FOR REPLACEMENT AS REQUIRED
MAINTENANCE SHALL BE WARRANTED FOR THE PE-
RIOD OF TIME UP TO THE FIRST SCHEDULED
REPLACEMENT POINT FOR THE PART.
ANY REPLACEMENT PART THAT IS EQUIVALENT IN
PERFORMANCE AND DULABILITY MAY BE USED IN
NON-WARRANTY MAINTENANCE OR REPAIRS, AND
SHALL NOT REDUCE THE WARRANTY OBLIGATION
OF THE COMPANY.
THE COMPANY IS LIABLE FOR DAMAGES TO OTHER
ENGINE COMPONENTS CAUSED BY THE FAILURE OF
A WARRANTED PART STILL UNDER WARRANTY.
THE WARRANTY DOES NOT APPLY TO THOSE UNITS
WHICH HAVE BEEN DAMAGED BY NEGLIGENCE OF
INSTRUCTION LISTED IN THE OWNER/OPERATOR
MANUAL FOR PROPER USE AND MAINTENANCE OF
THE UNITS ACCIDENT MISHANDLING, ALTERATION,
ABUSE, IMPROPER LUBRICATION, USE OF ANY PARTS
OR ACCESSORIES OTHER THAN THOSE SPECIFIED
BY THE COMPANY, OR OTHER CAUSES BEYOND THE
COMPANY’S CONTROL.
THIS WARRANTY DOES NOT COVER THOSE PARTS
REPLACED BY NORMAL WEAR OR HARMLESS
CHANGES IN THEIR APPEARANCE.
THERE ARE NO OTHER EXPRESS WARRANTIES.
IMPLIED WARRANTIES INCLUDING THOSE OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE LIMITED TO TWO (2) YEARS OF HOME
USE [ONE (1) YEAR FOR ANY OTHER USE] FROM THE
ORIGINAL DELIVERY DATE.
LIABILITIES FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGE UNDER ANY AND ALL WARRANTIES ARE
EXCLUDED.
IF YOU NEED TO OBTAIN MORE INFORMATION,
PLEASE CALL YOUR NEAREST SERVICE CENTER,
OR PLEASE CHECK TIMBERPRO WEB SITE
http://www.techandtrade.com/
IN CASE OF FAILURE THE PREFERENCE IS GIVEN
TO A REPLACEMENT OR REPARATION OF THE FA-
ULTY PART IN THE FIRST PLACE. ONLY THE COM-
PANY OR AN AUTHORIZED DEALER CAN DECIDE
IF AN ITEM SHOULD BE REPLACED ENTIRELY. TH-
IS IS NOT THE PURCHASER’S CHOICE.
GB 15

7102 June ht19
____________________
EC Declaration of Conformity
We, BVBA Tech and Trade
Paalstraat 29 BE-2223 Schriek (Heist-Op-Den-Berg) - Belgium,
Herewith declare under our sole responsibility that the GASOLINE HEDGE TRIMMER
Model ................................: HT 260
Produced under the registered trademark of
Meets all relevant requirements of the above mentioned directives
2006/42/EC Machinery Directive (MD)
2014/30/EU Electromagnetic Compatibility Directive (EMC)
97/68/EC amended by 2010/26/EC Directive of Emission
2000/14 EC & 2005 /88 EC Directive of EU Noise
Using the following draft and transposed standards
EN ISO 10517:2009
EN ISO 14982:2009
Having been type examined to the requirements of the directives by:
TÜV Rheinland LGA Products GmbH Notified Body number: 0197
Tillystraße 2 Certificate Number: AM 503495602 0001
AE 50344469 000190431 Nürnberg
Country : Germany
Conformity assessment procedure: 2000/14/EC-Appendix V
Measured level of the acoustic output LWA 107,4 dB (A).
Guaranteed level of the acoustic output LWA 110 dB (A).
EC type-approval No.: e11*97/68SA*2010/26*2710*00 ( )(EUII Emission)
etaDdengiS
Ⅱ
