Timbery M120 Series Guide

Operation and Parts Manual
Sawmill
M120EH5
M120EH7
M120G9
M120G14

Table of Contents
2 110819 Timbery M100
SECTION 1 INTRODUCTION 1-1
1.2 Electric Sawmill Nomenclature ............................................................ 1-2
1.3 Gas Sawmill Nomenclature ................................................................... 1-2
SECTION 2 SPECIFICATIONS 2-1
2.1 Belt Sizes................................................................................................ 2-1
2.2 Blade Sizes............................................................................................. 2-1
2.3 Log Dimensions ..................................................................................... 2-2
2.4 Engine/Motor Specifications.................................................................. 2-2
2.5 Noise Level ............................................................................................ 2-3
2.6 Overall Dimensions................................................................................ 2-4
SECTION 3 SAWMILL ASSEMBLY 3-1
3.1 M120 Sawmill Mounting Parts.............................................................. 3-1
3.2 Unpacking the Sawmill.......................................................................... 3-6
3.3 Sawmill Bed Assembly.......................................................................... 3-8
3.4 Log Clamp and Side Support Installation............................................ 3-10
3.5 Bed Leveling........................................................................................3-12
3.6 Stop Bracket Installation...................................................................... 3-14
3.7 Saw Head Installation .......................................................................... 3-15
3.8 Clutch Lever Installation (Gas Sawmills)............................................ 3-25
3.9 Water Bottle Installation ......................................................................3-27
3.10 Sawdust Chute Installation................................................................... 3-29
3.11 Blade Height Scale Installation............................................................ 3-30
3.12 Catch Rail Installation.......................................................................... 3-31
3.13 Final Adjustments ................................................................................3-32
SECTION 4 OPERATION 4-1
4.1 Safety Instructions.................................................................................. 4-1
4.2 Set-Up .................................................................................................... 4-2
4.3 Replacing the Blade ............................................................................... 4-3
4.4 Tensioning the Blade ............................................................................. 4-4
4.5 Tracking the Blade ................................................................................. 4-5
4.6 Horizontal Adjustment of Idle-Side Blade Wheel ................................. 4-6
4.7 Horizontal Adjustment of Drive-Side Blade Wheel .............................. 4-7
4.8 Vertical Adjustment of Drive-Side Blade Wheel .................................. 4-8
4.9 Vertical Alignment of Idle-Side Blade Wheel..................................... 4-10
4.10 Saw Head Adjustment.......................................................................... 4-12
4.11 Blade Deflection .................................................................................. 4-13
4.12 Blade Guide Vertical Tilt Adjustment ................................................. 4-14
4.13 Blade Guide Spacing Adjustment ....................................................... 4-16
4.14 Blade Guide Horizontal Tilt................................................................. 4-17

Table of Contents
Timbery M100 110819 3
4.15 Blade Height Scale Adjustment ........................................................... 4-18
4.16 Engine/Motor Drive Belt Adjustment.................................................. 4-19
4.17 Starting the Engine/Motor.................................................................... 4-21
4.18 Loading, Turning and Clamping Logs................................................. 4-22
4.19 Up/Down Operation............................................................................. 4-25
4.20 Blade Drive Operation ......................................................................... 4-26
4.21 Gas Engine Operation (G9, G14)......................................................... 4-27
4.22 Feed Operation..................................................................................... 4-29
4.23 Cutting the Log ....................................................................................4-30
4.24 Edging .................................................................................................. 4-31
4.25 Blade Height Scale............................................................................... 4-32
4.26 Stop Bolt Adjustment........................................................................... 4-33
4.27 Water Lube System.............................................................................. 4-34
4.28 Transporting the Sawmill..................................................................... 4-35
SECTION 5 MAINTENANCE 5-1
5.3 Motor/Engine Maintenance.................................................................... 5-4

INTRODUCTION
1-1 110819 Timbery M100 INTRODUCTION
SECTION 1 INTRODUCTION
1.1 About this manual
Congratulations on your purchase of a TIMBERY M120 sawmill! When properly maintained
and operated, your M120 sawmill should give you many years of dependable service.
This manual does not cover every possible operation and safety issues that may occur while
using this sawmill. This manual covers some of the basic safety procedures relating to this
sawmill and all national and local laws/regulations take precedence over this manual. Operators
should follow those laws and regulations.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
CAUTION! Read this entire manual before operating the equipment. Take notice of all
safety warnings throughout this manual and those posted on the
equipment. Keep this manual with this equipment at
all times, regardless of ownership.
Read all additional manufacturer’s manuals and observe any
applicable safety instructions including dangers, warnings, and
cautions.
Only adults (18+ years) who have read and understood the entire
operator's manual should operate the sawmill. The sawmill is not intended for use by or around
children.
The TIMBERY M120 sawmill is intended for sawing wood only. The sawmill must not be used for
other purposes such as cutting ice, metal or any other materials.
CAUTION! It is always the owner's responsibility to comply with all applicable national
and local laws, rules and regulations regarding the ownership and operation of your
sawmill. All Timbery mill owners are encouraged to become thoroughly familiar with
these applicable laws and comply with them fully while using the mill.

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-2
1.2 Electric Sawmill Nomenclature
1.3 Gas Sawmill Nomenclature
Symbol Version/Voltage 1/
Power Code
1 A-1x230V, B-3x230V, C-3x460V, H-3x400V
Safety Standard Code
S-CE Standard
U-UL Standard
M120EH7S
M120EH7
M120EH5S
M120EH5
M120EB5S
M120EB5
M120EB7
M120EB7S
M120EA5
M120EC5
M120EC7
M120EA5U
5.5kW, 400V, CE
5.5kW, 400V
4kW, 400V, CE
4kW, 400V
4kW, 230V, CE
4kW, 230V
5.5kW, 230V
5.5kW, 230V
4kW, 230V
4kW, 460V
5.5kW, 460V
4kW, 230V
S/U
UL
TABLE 1-1
Symbol Version/Power Code Safety Standard Code
S-CE Standard
U-UL Standard
M120G14S
M120G14
M120G9S
M120G9
14HP, CE
14HP
9.5HP, CE
9.5HP
S/U
TABLE 1-2

INTRODUCTION
1-3 110819 Timbery M100 INTRODUCTION
1.4 Safety
The symbol calls your attention to instructions concerning your personal safety.
Read and follow these instructions!
DANGER! indicates an imminently hazardous situation which, if not avoided,
will result in serious injury or death.
WARNING! suggests a potentially hazardous situation which, if not avoided,
may result in serious injury or death.
CAUTION! refers to potentially hazardous situations which, if not avoided, may result
in minor or moderate injury to persons or equipment damage.
NOTE: informs people of important installation, operation, or maintenance
information that is not hazard related.
Read all additional manufacturer’s manuals and observe any applicable safety instructions
including dangers, warnings, and cautions!
Wear protective clothing
WARNING! Secure all loose clothing and jewelry before operating the sawmill.
Failure to do so may result in serious injury or death.
WARNING! Always wear gloves and eye protection when handling bandsaw
blades. Changing blades is safest when done by one person! Keep all other
persons away from area when coiling, carrying or changing a blade. Failure to
do so may result in serious injury or death.
WARNING! Always wear eye, ear, respiration and foot protection as well as
protective clothing when operating or servicing the sawmill. Failure to do so
may result in serious injury or death.
Keep the sawmill and area around the machine clean
WARNING! Maintain a clean and clear path for all necessary movement around
the sawmill and lumber stacking areas. Failure to do so may result in serious
injury or death.

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-4
Handle fuel/lubricants safely
DANGER! Due to the flammable nature of fuel and oil, never smoke, weld, grind
or allow sparks near your engine or storage tanks, especially during times of
fueling. Doing so may result in serious injury or death.
DANGER! Never allow fuel to spill on a hot engine during fueling operations or
otherwise. The hot temperature of your engine could induce a fire or explosion.
Failure to do so will result in serious injury or death.
DANGER! Store gasoline away from sawdust and other flammable materials.
Failure to do so may result in serious injury or death.
Dispose of sawing by-products properly
CAUTION! Always properly dispose of all sawing by-products, including sawdust and
other debris, coolant, oil, fuel, oil filters and fuel filters. Failure to do so may result in
injury or equipment damage.
Safety for sawmill set-up
WARNING! Do not set up the sawmill on ground with more than a 10 degree
incline. If setup on an incline is necessary, put blocks under one side of the
machine or dig out areas for the legs to keep the sawmill level. Failure to do so
may result in serious injury or death.
Check sawmill before operation
DANGER! Make sure all guards and covers are in place and secured before
operating or towing the sawmill. Failure to do so may result in serious injury
or death.
WARNING! Release the blade tension when the sawmill is not in use
(for example at the end of a shift). Tension the blade again before starting the
engine/motor.
Keep all people away
DANGER! Keep all persons out of the path of moving equipment and logs when
operating the sawmill or loading and turning logs. Failure to do so may result in
serious injury or death.

INTRODUCTION
1-5 110819 Timbery M100 INTRODUCTION
DANGER! Always be sure the blade is disengaged and all persons are out of the
path of the blade before starting the engine or motor. Failure to do so may
result in serious injury or death.
Keep hands away
DANGER! Always disengage the blade and shut off the sawmill motor/engine
before changing the blade. Failure to do so may result in serious injury
or death.
DANGER! Always keep hands away from moving bandsaw blade. Failure to do
so may result in serious injury or death.
DANGER! Always be aware of and take proper protective measures against
rotating shafts, pulleys, fans, etc. Always stay a safe distance from rotating
members and make sure that loose clothing or long hair does not engage
rotating members. Failure to do so may result in serious injury or death.
WARNING! Do not spin the blade wheels by hand. Failure to do so may result in
serious injury or death.
WARNING! Always keep clear of exiting sawdust. Keep hands, feet, and any
other objects away from the sawdust chute when operating the sawmill. Failure
to do so may result in serious injury or death.
WARNING! Never clean the blade or the blade wheels with a brush or a scraper
during sawmill operation.
WARNING! Before installation of the blade, inspect it for damage and cracks.
Use only properly sharpened blades. Always handle the blade with extreme
caution. Use suitable carrier equipment for transporting the blades.
Cautions for gas engine operation
DANGER! The exhaust gases of your engine are poison gases. Operate your
engine/machine in well ventilated areas only. Failure to do so may result in
serious injury or death.
DANGER! Leaking fuel or oil can contact hot surfaces and ignite into flames.
Never operate an engine with a fuel or oil leak. Failure to do so may result in
serious injury or death.

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-6
WARNING! Engine components can become very hot during operation. Avoid
contact with any part of a hot engine especially during and following operation.
Contact with hot engine components can cause serious burns. Never touch
or perform service functions on a hot engine. Allow the engine to cool
sufficiently before beginning any service function. Failure to do so will result in
serious injury or death.
WARNING! Do not operate the engine without proper and operational spark
arrester/muffler. Sparks from the engine can cause a fire or explosion. Failure
to do so may result in serious injury or death.
Use extreme care when turning heavy logs
WARNING! Before sawing, always make sure the log is securely clamped
against the side supports. Failure to do so may result in serious injury or death.
Keep safety labels in good condition
WARNING! Always be sure that all safety decals placed on the machine are
clean and readable. Replace all damaged safety decals to prevent personal
injury or damage to the equipment. Contact your local distributor, or call
Timbery Customer Service to order decals.
WARNING! When replacing any component having a safety decal affixed,
be sure to place an identical safety decal on the new component.

INTRODUCTION
1-7 110819 Timbery M100 INTRODUCTION
See Table 1-3. See the table below for descriptions of the pictographic warning
and informational decals placed on the M120 sawmill.
TABLE 1-4
Decal View Decal No. Description
096317 CAUTION! Read thoroughly the operator’s
manual before operating the sawmill.
Observe all safety instructions and rules
when operating the machine.
099220 CAUTION! Close all guards and covers
before starting the machine.
099219 Blade tension. Turning the bolt clockwise
will increase the blade tension, and turning
the bolt counterclockwise will decrease the
tension.
099220
099219
+

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-8
099221 CAUTION! Keep all persons away from
work area when operating the machine.
096316 CAUTION! Do not open or close the
electric box when the switch is not in the
”0” position.
096319 CAUTION! Disconnect power supply
before opening the box.
096321 Blade movement direction
TABLE 1-4
099221

INTRODUCTION
1-9 110819 Timbery M100 INTRODUCTION
086099 CAUTION! Hot parts - keep a safe
distance!
S12004G CAUTION! Always wear safety goggles
when operating the sawmill!
S12005G CAUTION! Always wear protective ear
muffs when operating the sawmill!
501465 CAUTION! Always wear safety boots when
operating the sawmill!
TABLE 1-4
086099

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-10
P11789 Tracking the blade on the blade wheels
527864 Setting the blade tension indicator
P85070 CE certification marking
S20097 Direction of motor revolutions
501477 Safety handle - the blade stops after
releasing the handle.
TABLE 1-4
S20097

INTRODUCTION
1-11 110819 Timbery M100 INTRODUCTION
1.5 Major Components
The major components of the Timbery M120 are shown in the figures below. These component
names will be used throughout the manual.
Motor Water Bottle Scale
Electric Box
RIGHT SIDE
Sawdust Chute
Log Side Support
Log Clamp
Bed Rail Bed Frame Saw Head
Mast
LEFT SIDE
FIG. 1-1 MAJOR COMPONENTS OF ELECTRIC TIMBERY M120 SAWMILLS

INTRODUCTION
INTRODUCTION Timbery M100 110819 1-12
Bed Rail Bed Frame
Log Clamp
SAW HEAD
Gas Engine
Scale
Mast
Operator’s
Handle
Log Side Support
LEFT SIDE
RIGHT SIDE
Sawdust Chute
FIG. 1-2 MAJOR COMPONENTS OF TIMBERY M120 SAWMILLS W/GAS ENGINE

Specifications
2
2-1 doc110819 Specifications
SECTION 2 SPECIFICATIONS
2.1 Belt Sizes
See Table 2-1. Belt sizes for the M120 sawmill are shown below.
2.2 Blade Sizes
See Table 2-2. See the table below for blade specifications for the M120 sawmills.
Description Belt Size Timbery
Part No.
Drive-Side Wheel Belt B69 CARLISLE
SUPER II
X100-905
Idle-Side Wheel Belt B47.5 M120 1
1 To insure proper blade tracking, use Goodyear, Dayco Super II, or
Browning belts only.
X100-900
TABLE 2-1
Description Thickness Length
M120 0.90 mm (0.035")
1 mm (0.039")
1.07 mm (0.042")
1.14 mm (0.045")
3340-3360 mm
(131.5"-132")
TABLE 2-2

Specifications
Specifications doc110819 2-2
2
2.3 Log Dimensions
See Table 2-3. The maximum dimensions of logs that can be cut on the standard M120 sawmill are
listed below.
2.4 Engine/Motor Specifications
See Table 2-4. See the table below for data on the engines/motors used on the M120 sawmills.
See Table 2-5. Power supply specifications for the M120 sawmill are given below.
Maximum Log
Diameter
Log Length
M120 66 cm 3.8 m
TABLE 2-3
Engine/Motor Type Manufacturer Model No. Other Specifications
EH5 Electric Motor (4.0 kW) Siemens, Germany 1LE1002 1CA13-4AA4-Z
F01+F12
3 x 400V, 50 Hz
EH7 Electric Motor (5.5 kW) Indukta, Poland PSg-132 S2 - HM 3 x 400V, 50 Hz
EA5 Electric Motor (4.0 kW) LEESON 131638.00 1x230V, 50 Hz
EA5U Electric Motor (4.0 kW) - - 1x230V, 60 Hz
EC5 Electric Motor (4.0 kW) - - 3x460V, 60 Hz
EC7 Electric Motor (5.5 kW) - - 3x460V, 60 Hz
G9 Gas Engine (9.5 HP) KOHLER CH395-3149
G14 Gas Engine (14 HP) KOHLER CH440-3149
TABLE 2-4
Fused
Disconnect
Switch
Recommended
Wire Size
M120EH5 - 10A 1.5 mm
M120EH7 - 13A 1.5 mm
M120EB5 - 16A 2.5 mm
M120EB7 - 20A 2.5 mm
M120EA5 2.5 mm
M120EA5U -
M120EC5 -
M120EC7 -
TABLE 2-5

Specifications
2
2-3 doc110819 Specifications
2.5 Noise Level
See Table 2-6. See the table below for the average levels of noise generated by various M120
sawmill models12.
Sawmill Noise Level
M120EH5, M120EH7 LEX8 = 99 dB (A)
M120G9, M120G14 LEX8 = 106 dB (A)
TABLE 2-6
1.The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard. The noise exposure level given
above concerns an 8-hour work day. Value for associated uncertainty: K=4dB
2. The measured values refer to emission levels, not necessarily to noise levels in the workplace. Although there is a
relation between emission levels and exposure levels, it is not possible to determine with certainty if preventives are
needed or are not needed. The factors affecting a current level of noise exposure during work are inter alia room
characteristics and characteristics of other noise sources, e.g. number of machines and machining operations nearby. Also
the permissible exposure level can vary from country to country. This information, however, will enable the user of the
machine to make a better evaluation of the hazard and risk.

Specifications
Specifications doc110819 2-4
2
2.6 Overall Dimensions
See Figure 2-1. The overall dimensions of the M120 sawmills are shown below.
FIG. 2-1

Specifications
2
2-5 doc110819 Specifications
See Figure 2-2. See the figure below for the operator’s work-place.
FIG. 2-2
