Sealey SA348 User manual

RECIPROCATING AIR SAW SLIM BODY
MODEL NO: SA348
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
WARNING! Disconnect from air supply before changing the blade or file, servicing or performing maintenance.
9Maintain the tool in good condition.
9Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Use in suitable, clean and tidy work area, free from unrelated materials. Ensure that there is adequate lighting.
WARNING! Always wear approved eye or face and hand protection when operating the saw.
9Remove ill fitting clothing. Remove ties, loose jewellery and contain and/or tie back long hair.
9Wear appropriate protective clothing and keep hands and body clear of working parts.
9Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9Keep children and unauthorised persons away from work area.
8DO NOT use blades that are cracked or deformed.
8DO NOT use hacksaw blade segments.
9Ensure that blades and files are clamped tightly to the airtool.
9Check moving parts alignment on a regular basis.
9Ensure workpiece is secure before operating the saw. Never hold a workpiece by hand. Use a vice or clamps.
WARNING! Ensure correct air pressure is maintained and not exceeded. Recommended pressure is 90psi.
9Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and ensure that all connections are secure.
9Prolonged exposure to vibration from this tool poses a health risk. It is the employer’s/owner’s responsibility to correctly assess the
hazard and issue guidelines for safe periods of use and offer suitable protective equipment.
8DO NOT use any power source except an air compressor.
8DO NOT operate the tool near any inflammable substance or on any container that has held an inflammable substance.
8DO NOT use tool for a task it is not designed to perform.
8DO NOT operate tool if any parts are damaged or missing as this may cause failure and/or personal injury.
8DO NOT carry the tool by the hose, or yank the hose from the air supply.
8DO NOT operate tool when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8DO NOT carry the tool with your finger on the trigger.
8DO NOT direct air from the air hose at yourself or others.
9When not in use disconnect from air supply and store in a safe, dry, childproof location.
2. INTRODUCTION
Suitable for a variety of bodyshop applications such as cutting through panels, sills and chassis members. Excellent for initial crash-
repair preparation when quick removal of damaged panels is required. Fitted with safety trigger device. Supplied with a starter pack of
blades.
3. SPECIFICATION
Model No.:.................................................................. SA348
Free Speed: ............................................................ 9000bpm
Stroke: ......................................................................... 10mm
Maximum Cutting Capacity: ............. 2mm Steel, 3mm Aluminium
Air Consumption: ........................................................... 3cfm
Operating Pressure:...................................................... 90psi
Air Inlet Size:.............................................................1/4”BSP
Weight:...................................................................... 0.425kg
Noise Power:.............................................................99dB(A)
Noise Pressure: ........................................................ 88dB(A)
Vibration/Uncertainty.......................................11.985/1.5m/s2
CONSUMABLES:
14 TPI Air Saw Blade ............................................. SA34/B14
24 TPI Air Saw Blade ............................................. SA34/B24
32 TPI Air Saw Blade ............................................. SA34/B32
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves
Wear eye
protection
Wear ear
protection
SA348 Issue 1 12/02/19

4. AIR SUPPLY
4.1. Recommended hook-up procedure is shown in fig.1.
4.1.1. Ensureairsawtriggerisin“o󰀨”positionbeforeconnectingtotheairsupply.
4.1.2. You will require an air pressure of 90psi, and an air flow according to specification.
▲WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the tool. Too high an air pressure and unclean air
will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
4.1.3. Drain the air tank daily. Water in the air line will damage the tool.
4.1.4. Clean air inlet filter weekly.
4.1.5. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres).
4.1.6. The minimum hose diameter should be 1/4” I.D. and fittings must have the same internal dimensions.
4.1.7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are secure.
4.2. COUPLINGS
4.2.1. Vibration may cause failure if a quick change coupling is connected directly to the tool.
4.2.2. To overcome this, connect a leader hose to the tool. A quick change coupling may then be used to connect the leader hose to the air
 linerecoilhose(g.2).AvailablefromyourSealeydealer(ModelNo.-AH2R)
5. OPERATION
5.1.  BLADEGUARDADJUSTMENT(g.3)
5.1.1. Usingthehexagonalkeysupplied,loosenthefasteningonthetopofthetool(g.3).Slidetheguardtotherequiredpositionand 
fully retighten the fastening.
5.2.  BLADEMOUNTING(g.4)
5.2.1. Usingthehexagonalkeysupplied,loosenbladefastening(g.4).Slidethebladefullyintothetoolbodyandxinplacebyfully 
tightening the fastening. NOTE: Ensure that the blade teeth are in the required orientation within the tool and that the blade is correct
for the task.
5.3.  EXHAUSTDIRECTION(g.5)
5.3.1. To direct exhaust air, rotate the collar such that the holes are facing the required direction.
5.4. SPEED CONTROL (g.6)
5.4.1. Speed control of the cutting blade is achieved by use of the trigger mechanism.
5.5. Ensure that your workpiece is properly secured and, if necessary, marked out.
5.6. Start the saw by pushing the safety catch forward (fig.6), then pushing the trigger (fig.6) down.
8DO NOT attempt to start the saw with the stationary blade in contact with the workpiece. Start the saw and bring the moving blade onto
the workpiece.
5.7. If the cut ends within the sheet material, allow the blade to come to a stop before removing the saw from the workpiece.
5.8. If the cut starts within the bounds of the material, cut a starter slot by hand.
8DO NOT allow the saw to run without load for any length of time as this will cause it damage.
Original Language Version
© Jack Sealey Limited
fig.1 fig.2
fig.3fig.4
fig.5fig.6
SA348 Issue 1 12/02/19

6. MAINTENANCE
WARNING! Disconnect saw from air supply before changing the blade or file, servicing or performing maintenance. Replace or repair
damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
6.1. Unless the air supply system includes an oiler, lubricate the air saw daily with a few drops of air tool oil, dripped into the air inlet before
use (Sealey part no’s. ATO500S (500ml) or ATO1000S (1 Litre).
6.2. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air line. Moisture or restriction in the air line. Incorrect size or type of hose connectors. To remedy, check the
air supply and follow instructions in Section 4.
b) Grit or gum deposits in the saw may also reduce performance. If your model has an air strainer (located in the area of the air inlet),
remove the strainer and clean it. Flush the saw out with gum solvent oil or an equal mixture of SAE No 10 oil and kerosene. Allow to
dry before use. If you continue to experience problems, contact your local Sealey service agent.
6.3. For a full service, contact your local Sealey stockist.
6.4. When not in use, disconnect from air supply, clean saw and store in a safe, dry, childproof location.
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measuredvibrationemissionvalue(a): 11.985m/s²
Uncertaintyvalue(k): 1.5m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission.
We recommend that a specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of
Hand Arm Vibration Syndrome.
Health surveillance.
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can be modified
accordingly.
Personal protective equipment.
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the uncontrolled
use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and dry and maintain good
blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the Correct Use and Maintenance section
in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSC website www.hse.gov.uk - Hand-Arm
Vibration at Work.
SA348 Issue 1 12/02/19
Original Language Version
© Jack Sealey Limited
