TLS Electronics 860400 User manual

860400 User Manual
Wireless HDMI Splitter

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 2
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be damaged by
electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Safety Information
To reduce the risk of electric shock, do not expose this product to rain or
moisture
Do not modify the wall plug. Doing so will void the warranty and safety
features
If the wall plug does not fit into your local power socket, hire an electrician
to replace your obsolete socket.
This equipment should be installed near the socket outlet and the device
should be easily accessible in the case it requires disconnection

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 3
Content
Safety Information..............................................................................................2
Introduction........................................................................................................4
Features.............................................................................................................4
Panel..................................................................................................................5
Transmitter Front ............................................................................................5
Transmitter Back.............................................................................................5
Receiver Front................................................................................................5
Receiver Back.................................................................................................5
Installation..........................................................................................................6
WiFi channels....................................................................................................7
Specification ......................................................................................................8
Package Contents .............................................................................................9
Maintenance....................................................................................................10
Warranty Policy.............................................................................................10
Limitations of Warranty.................................................................................10
Exclusive Remedies ..................................................................................... 11
RMA Policy ................................................................................................... 11
Standard Replacement.................................................................................12
Once you have obtained an RMA number....................................................12
Please note:..................................................................................................12
Warranty..........................................................................................................13
Return and RMA Policies..............................................................................13

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 4
Introduction
The 860400 Wireless HDMI Splitter transmits HD video and audio signal and
can realize the one-to-many application with up to four receivers. At the same
time it extends infrared signal to make remote control more convenient. The
Wireless HDMI Splitter has excellent image processing and transmission
capacity, it makes signal transmission more smooth and steady. It is a
economic and efficient way of HDMI signal transmission.
Note:
The transmission distance will be different due to the environment. Wall,
brick or glass will shorten the signal cover range or cause big signal loss.
Best place is a position with free sight from transmitter to receivers
Features
HDMI video and audio transmission via wireless WIFI, up to 50m
HD video signal resolution up to 1920x1080@60Hz
HDMI 1.3 compatible
Supports remote control to control video source
Special format is used to compress and decompress video, effectively
improve the transfer quality
HDCP 1.2 ,in accordance with high-bandwidth digital content protection
technology
Supports external remote infrared extension, easy to operate the remote
device
Build-in automatic balance system, the picture is fluent, clear and stable
Build-in ESD electrostatic protection circuit
Simple and convenient installation, plug and play
H.264 video compression

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 5
Panel
Transmitter Front
Transmitter Back
Receiver Front
Receiver Back

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 6
Port name
Description
INPUT/OUTPUT
HDMI signal input/output
IR IN/OUT
IR signal input/output
IR
Remote control receiver
Channel
Digital segment display 21-29 2,4GHz range; 50-59
for 5GHz range
DC 5V
Power adapter socket
Back Down UP OK
Used to adjust the WIFI frequency
LED indicator
Description
STA
Video signal connection
PWR
System power indicator
Installation
1. Connect the HDMI source to the HDMI input of the wireless transmitter
2. Connect the wireless HDMI receiver to a display device, such as HDTV,
monitor , projector etc
3. Connect the IR receiver to the IR-IN of the wireless receiver
4. Connect the IR transmitter to the IR out of the wireless transmitter
5. Connect the power supplies to the wireless transmitter and receiver, wait
until the channel display is ready on the front of the transmitter and on
the front of the receiver
6. The wireless transmitter and receiver must be tuned to the same channel.
Use the Up/Down button to change the channel. Use the OK button to fix
the channel
Every Wireless receiver must be tuned to the same channel
The use of Channel 50 and Channel 51 is not allowed in Europe !
7. You can also use the IR remote control to tune the WIFI channel
8. Connect an additional monitor to the HDMI output of the Wireless
transmitter

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 7
WiFi channels
Channel on display
WiFi channel
21
1
22
2
23
3
24
4
25
5
26
6
27
7
28
8
29
11
50
Not in europe
51
Not in europe
52
132
53
136
54
140
55
153
56
153
57
157
58
161
59
165

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 8
Specification
Parameter Video
Description
Standards
HDMI 1.3; HDCP 1.2
Compression format
H.264
Maximum pixel clock
165 MHz
Maximum data rate
6,75 Gbps
Resolution
Max. 1920x1080@60Hz
Connector
HDMI-A
Impedance
100 Ohms
Recommended HDMI max. input/
output range
Less than 5m, when
1920x1080@60Hz
Parameter IR
Description
Interface
3,5 mm jack
Signal direction
Unidirectional
Signal type
digital
IR frequency
20-60 KHz
Parameter WIFI
Description
Radio frequency power
13 dbm
Wireless standard
802.11n
Signal direction
Unidirectional
Radio frequency
2,4GHz, 5GHz
Transmission distance
50m
Parameter Others
Description
Power
Adapter 5V DC
Power consumption
Max. 9W
Temperature
Operating -5°C - +70°C
Humidity
Operating 5% - 90%
Size
119x82x23mm
Weight
400g

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 9
Package Contents
1. 1x HDMI transmitter, 1x HDMI receiver
2. 2 xPower adaptor 5V 1A
3. IR TX/RX Cable Set
4. 8 rubber pads
5. Remote control
6. User manual

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 10
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or
benzene to clean this unit.
Warranty Policy
TLS electronics products are warranted against defects in material and
workmanship for three years from the date of shipment. During the warranty
period, TLS electronics will, at its option, repair or replace products that prove
to be defective. Repairs are warranted for the remainder of the original
warranty or a 90 day extended warranty, whichever is longer.
For equipment under warranty, the owner is responsible for freight to TLS
electronics and all related customs, taxes, tariffs, insurance, etc. TLS
electronics is responsible for the freight charges only for return of the
equipment from the factory to the owner. TLS electronics will return the
equipment by the same method as the equipment was sent to TLS electronics.
All equipment returned for warranty repair must have a valid RMA number
issued prior to return and be marked clearly on the return packaging. TLS
electronics strongly recommends all equipment be returned in its original
packaging.
TLS electronics obligations under this warranty are limited to repair or
replacement of failed parts, and the return shipment to the buyer of the repaired
or replaced parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed,
altered, repaired, or misused in any way that, in the opinion of TLS electronics,
would affect the reliability or detracts from the performance of any part of the
product, or is damaged as the result of use in a way or with equipment that had
not been previously approved by TLS electronics.
The warranty does not apply to any product or parts thereof where the serial
number or the serial number of any of its parts has been altered, defaced, or
removed. The warranty does not cover damage or loss incurred in
transportation of the product.
The warranty does not cover replacement or repair necessitated by loss or
damage from any cause beyond the control of TLS electronics, such as

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 11
lightning or other natural and weather related events or wartime environments.
The warranty does not cover any labor involved in the removal and or
reinstallation of warranted equipment or parts on site, or any labor required to
diagnose the necessity for repair or replacement.
The warranty excludes any responsibility by TLS electronics for incidental or
consequential damages arising from the use of the equipment or products, or
for any inability to use them either separate from or in combination with any
other equipment or products.
A fixed charge established for each product will be imposed for all equipment
returned for warranty repair where TLS electronics cannot identify the cause of
the reported failure.
Exclusive Remedies
TLS electronics’s warranty, as stated is in lieu of all other warranties, expressed,
implied, or statutory, including those of merchantability and fitness for a
particular purpose. The buyer shall pass on to any purchaser, lessee, or other
user of TLS electronics products, the aforementioned warranty, and shall
indemnify and hold harmless TLS electronics from any claims or liability of such
purchaser, lessee, or user based upon allegations that the buyer, its agents, or
employees have made additional warranties or representations as to product
preference or use.
The remedies provided herein are the buyer’s sole and exclusive remedies.
TLS electronics shall not be liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract, tort, or any other legal
theory.
RMA Policy
When returning product to TLS electronics for any reason, the customer should
fill out the official RMA form to obtain a RMA number. Without the permission or
approval, TLS electronics will be no responsible for any return. This can be
initiated by emailing or calling your related sales. All requests are processed
within 48 hours.

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 12
Standard Replacement
For customers that agree to return defective product to TLS electronics first, a
Standard Replacement option is available.
An RMA number must first be issued by sales. This RMA number will need to
be referenced on the outside of the return shipment.
Upon receipt of the defective product, TLS electronics will, at its discretion,
either repair or replace the product and ship it out in the most expeditious
manner possible. Subject to availability, the replacement product will be
shipped on the business day following receipt of the defective product.
In the event the product returned to TLS electronics has been discontinued (i.e.
the product is no longer being manufactured by TLS electronics but is still
under warranty), TLS electronics will, at its discretion, either repair or replace
with recertified product.
Once you have obtained an RMA number
After obtaining an RMA number from TLS electronics, you must send the
product - freight prepaid - to TLS electronics. The TLS electronics RMA number
must be prominently displayed on the outside of your package. If you send your
product to TLS electronics without the RMA number prominently displayed on
the outside of the package, it will be returned to you unopened.
Please use a shipping company that can demonstrate proof of delivery. TLS
electronics does not accept responsibility for any lost shipments unless proof of
delivery to TLS electronics is provided.
Please note:
Product shipped to TLS electronics must be properly packaged to prevent loss
or damage in transit.
Shipping your RMA to TLS electronics using regular mailing envelopes is not
acceptable, as they do not protect the product from damage during shipping.
TLS electronics will not repair or replace a module that is shipped in such a way
that the product is not properly protected.
TLS electronics will not accept any product that has been damaged as a result
of accident, abuse, misuse, natural or personal disaster, or any unauthorized
disassemble, repair or modification.

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 13
Warranty
Warranty time is two year and from the date of original shipment.
This warranty shall be void if a serial number has been removed from the
product.
Upon determination of a legitimate defect covered by this warranty and
at TLS sole discretion, user should bear the transport cost during the
warranty.
If product is out of warranty then repair charge is required. Minimum
repair charge: 10% of the retail price plus the cost of failed components.
We will repair the failed product after repair cost has been approved by
Customers and proper financial arrangements are made. Customer must
cover round trip shipment expenses.
Return and RMA Policies
Shipments will not be received and processed for warranty
repair/replacement without an TLS electronics RMA(Return Materials
Authorization).
Ecco Cine supply and service GmbH
Germany
40721 Hilden
Marie-Curie-Str. 20
info(at)tls-electronics.de
www.tls-electronics.de

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 14

860400 Wireless HDMI Splitter
Ecco Cine supply GmbH Contact: [e-mail] 15
