TMG TMG-GWC4 User manual

4 inch Wood Chipper
MODEL: TMG-GWC4
WWW.TMGINDUSTRIAL.COM Toll Free:1-877-761-2819
PRODUCT MANUAL
V2021.09.28
7HP KOHLER®Powered
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: [e-mail]
Do not return the product to dealer, they are not equipped to handle your
requests

Table of Contents
PART I: General Safety Rules...............................................................................................................03
PART II: Familiar with the Wood Chipper................................................................................................09
PART III: Install the Wood Chipper...................................................................................10
PART IV: Operating the Wood Chipper.............................................................................................18
PART V: Maintaining the Wood Chipper...............................................................................................21
PART VI: Troubleshooting and Parts List...............................................................................................21
Conventions used in this manual
WARNING
This indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
CAUTION
This indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury.
NOTICE
This information is important in proper using of your machine. Failure to follow this instruction could
result in damage to your machine or property.
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve its products at any time without notice or
obligation to the purchaser. The descriptions and specifications contained in this manual were in effect
at printing. Equipment described within this manual may be optional. Some illustrations may not be
applicable to your machine
W W W . T M G I N D U S T R I A L . C O M P 0 2 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

PART I: General Safety Rules
Safety Labels Found on Your Unit
A:
A
B
C
D
E
W W W . T M G I N D U S T R I A L . C O M P 0 3 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

B:
C: D:
E:
WARNING
Read this Safety & Operating Instructions manual before you use the Wood Chipper. Become familiar
with the operation and service recommendations to ensure the best performance of your machine.
W W W . T M G I N D U S T R I A L . C O M P 0 4 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Propose
CAUTION
This machine is designed solely to chip wood and must not be used for any other purpose.
It should only be used by trained operators who are familiar with the content of this manual. It is
potentially hazardous to fit or use any parts other than your dealer parts. The company disclaims all
liability for the consequences of such use, which in addition voids the machine warranty.
Before using the wood chipper
NOTICE
A．Operators must be fully trained before using this machine.
B．User Manual is read and understood.
C．Machine is positioned on level ground, all guards are fitted and in good condition.
D．Blades are in good condition and secure. All blades are sharpened or replaced in sets.
E．All fasteners are checked for tightness.
F．Only WOODEN materials free of nails etc. are fed into the machine.
G．Fire extinguisher is available on site.
When using the wood chipper
NOTICE
A. Always feed from the side.
B. It is better to have a second trained operator within easy reach of the machine.
C. Maintain strict discipline at all times and service machine at specified periods.
D. Note direction of discharge chute and if necessary note the wind direction to prevent debris from
being blown into highway or where it could affect members of the public.
E. DO NOT put any part of your body into the in-feed chute while the machine is running.
F. DO NOT operate the machine whilst under the influence of alcohol or drugs.
G. DO NOT operate inside a building or confined space or Climb on the in-feed chute.
Protecting Yourself and Those Around You
WARNING
This is a high-powered machine, with moving parts operating with high energy. You must operate the
machine safely. Unsafe operation can create a number of hazards for you, as well as anyone else in the
nearby area. Always take the following precautions when using this machine:
W W W . T M G I N D U S T R I A L . C O M P 0 5 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

A. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other
people, their property, and themselves.
B. Always wear protective goggles or safety glasses with side shields while using the Wood Chipper
to protect your eyes from possible thrown debris.
C. Avoid wearing loose clothing or jewelry, which can catch on moving parts.
D. We recommend wearing gloves while using the Wood Chipper. Be sure your gloves fit properly and
do not have loose cuffs or drawstrings.
E. Wear shoes with non-slip treads when using your Wood Chipper. If you have safety shoes, we
recommend wearing them. Do not use the machine while barefoot or wearing open sandals.
F. Wear long pants while operating the Wood Chipper.
G. Keep bystanders at least 50 feet away from your work area at all times. Stop the engine when
another person or pet approaches.
Safety for Children and Pets
WARNING
Tragic accidents can occur if the operator is not alert to the presence of children and pets. Children are
often attracted to the machine and the chipping activity. Never assume that children will remain where
you last saw them. Always follow these precautions:
A. Keep children and pets at least 50 feet from the working area and ensure they are under the
watchful care of a responsible adult.
B. Be alert and turn the machine off if children or pets enter the work area.
C. Never allow children to operate the Wood Chipper.
Safety with Gasoline - Powered Machines
WARNING
Gasoline is a highly flammable liquid. Gasoline also gives off flammable vapor that can be easily ignited
and cause a fire or explosion. Never overlook the hazards of gasoline. Always follow these precautions:
A. Never run the engine in an enclosed area or without proper ventilation as the exhaust from the
engine contains carbon monoxide, which is an odorless, tasteless, and a deadly poisonous gas.
B. Store all fuel and oil in containers specifically designed and approved for this purpose and keep
away from heat and open flame, and out of the reach of children.
C. Replace rubber fuel lines and grommets when worn or damaged and after 5 years of use.
D. Fill the gasoline tank outdoors with the engine off and allow the engine to cool completely. Don't
handle gasoline if you or anyone nearby is smoking, or if you're near anything that could cause it to
ignite or explode. Reinstall the fuel tank cap and fuel container cap securely.
E. If you spill gasoline, do not attempt to start the engine. Move the machine away from the area of
the spill and avoid creating any source of ignition until the gas vapors have dissipated. Wipe up any
spilled fuel to prevent a fire hazard and properly dispose of the waste.
F. Allow the engine to cool completely before storing in any enclosure. Never store a machine that
has gas in the tank, or a fuel container, near an open flame or spark such as a water heater, space
W W W . T M G I N D U S T R I A L . C O M P 0 6 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

heater, clothes dryer or furnace.
G. Never make adjustments or repairs with the engine running. Shut down the engine, disconnect the
spark plug wire, keeping it away from the spark plug to prevent accidental starting, wait 5 minutes
before making adjustments or repairs.
H. Never tamper with the engine’s governor setting. The governor controls the maximum safe
operation speed and protects the engine. Over-speeding the engine is dangerous and will cause
damage to the engine and to the other moving parts of the machine. If required, see your
authorized dealer for engine governor adjustments.
I. Keep combustible substances away from the engine when it is hot.
J. Never cover the machine while the muffler is still hot.
K. Do not operate the engine with the air cleaner or the carburetor air intake cover removed. Removal
of such parts could create a fire hazard. Do not use flammable solutions to clean the air filter.
L. The muffler and engine become very hot and can cause a severe burn; do not touch.
General Safety
WARNING
Operating this Wood Chipper safely is necessary to prevent or minimize the risk of death or serious
injury. Unsafe operation can create a number of hazards for you. Always take the following precautions
when operating:
A. Your Wood Chipper is a powerful tool, not a plaything. Exercise extreme caution at all times. The
machine is designed to Chip Woods. Do not use it for any other purpose.
B. Know how to stop the Wood Chipper quickly.
C. Never operate your unit on a slippery, wet, muddy, or icy surface. Exercise caution to avoid
slipping or falling.
D. See manufacturer’s instructions for proper operation and installation of accessories.
E. Never use the machine without ensuring that all guards and shields are in place.
F. Never, under any conditions, remove, bend, cut, fit, weld, or otherwise alter standard parts on the
Wood Chipper. This includes all shields and guards. Modifications to your machine could cause
personal injuries and property damage and will invalid your warranty.
G. If the machine start to make an unusual noise or vibrate, shut down the engine, disconnect the
spark plug wire, keeping it away from the spark plug to prevent accidental starting, wait 5 minutes
for engine to cool down, then inspect for damage. Vibration is generally a warning of trouble.
Check damaged parts and clean, repair and/or replace as necessary.
H. Never tamper with safety devices. Check their proper operation regularly.
I. Before performing any maintenance or inspection procedure, shut down the engine, disconnect
the spark plug wire keeping it away from the spark plug to prevent accidental starting, wait 5
minutes for machine to cool down.
J. Never allow people who are unfamiliar with these instructions to use the Wood Chipper. Allow only
responsible individuals who are familiar with these rules of safe operation to use your machine.
K. Never overload or attempt to chip woods beyond the manufacturer’s recommendation. It could
result in personal injury or damage to the machine.
L. While using, don't hurry or take things for granted. When in doubt about the equipment or your
surroundings stop the machine and take time to look things over.
W W W . T M G I N D U S T R I A L . C O M P 0 7 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

M. Never operate the machine when under the influence of alcohol, drugs, or medication.
N. Use the machine only in daylight.
O. Stay alert for hidden hazards or traffic.
P. Keep all nuts and bolts tight and keep the equipment in good operating condition.
A Note to All Users
List of warnings and cautions cannot be all-inclusive. If situations occur that are not covered by this
manual, the operator must apply common sense and operate this WOOD CHIPPER in a safe manner.
Contact the dealers for assistance in your area.
W W W . T M G I N D U S T R I A L . C O M P 0 8 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

PART II: Familiar with the Wood Chipper
It may be helpful to familiarize yourself with the controls and features of the Wood Chipper. If you have
any question, please contact the dealers in your area.
TECHNICAL SPECIFICATIONS
Start
Recoil Start
Engine
7HP four strokes
Power
Gasoline
Chipper Capacity
3CBM/hour to 5CBM/hour
Wood Diameter
diameter 100mm
Permitted wood width
150mm
Chipper Blade
twin reversible blades
Tire
4.10/3.5-4
Overall Height
870mm
Overall Length
555mm
Width
850mm
Weight
100/85kgs
Roller Max RPM
2400rpm
W W W . T M G I N D U S T R I A L . C O M P 0 9 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

PART III: Install the Wood Chipper
1. After unpacking, check the following components
No
Description
Quantity
No
Description
Quantity
1
Emergency switch extension
1
16
Tire
2
2
In-feed extension
1
19
Feet assembly
1
7
In-feed assembly
1
21
Tire axis
1
11
Discharge chute assembly
1
79
Tool-wrench
2
12
Machine body assembly
1
W W W . T M G I N D U S T R I A L . C O M P 1 0 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

2. Installation in-feed assembly
Parts no.
Description
Specifications
Quantity
3
Washer
M8
1
7
In-feed assembly
1
8
Lock nut
M8
2
9
Spring washer
M8
2
12
Machine body assembly
1
3. Installation front standing leg assembly
W W W . T M G I N D U S T R I A L . C O M P 1 1 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Parts no.
Description
Specifications
Quantity
12
Machine body assembly
1
13
Lock nut
M10
2
14
Spring washer
M10
2
15
Washer
M8
4
19
Feet assembly
1
20
Bolt
M10x45
2
4. Installation tire system
Parts no.
Description
Specifications
Quantity
3
Washer
M8
2
8
Lock nut
M8
2
9
Spring washer
M8
2
12
Machine body assembly
1
16
Tire
4.10/3.5-4
2
17
Washer
M16
2
18
Split pin
Ø4x30
2
21
Tire axis
1
22
Bolt
M8x45
2
W W W . T M G I N D U S T R I A L . C O M P 1 2 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

5. Installation discharge chute assembly
Parts no.
Description
Specifications
Quantity
3
Washer
M8
4
9
Spring washer
M8
4
10
Bolt
M8x30
4
11
Discharge chute assembly
1
12
Machine body assembly
1
6. Installation in-feed extension
Parts no.
Description
Specifications
Quantity
2
In-feed extension
1
3
Washer
M8
10
4
Bolt
M8x55
2
5
Bolt
M8x30
3
7
In-feed assembly
1
8
Lock nut
M8
5
9
Spring washer
M8
5
W W W . T M G I N D U S T R I A L . C O M P 1 3 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

7. Installation emergency switch extension
W W W . T M G I N D U S T R I A L . C O M P 1 4 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Parts no.
Description
Specifications
Quantity
1
Emergency switch extension
1
6
Split pin
Ø4x40
2
7
In-feed assembly
1
8. Connect electric wire
Step. 1: Check the electric wire on the machine Step. 2: Find the A and B electric wire
find the ①②③ contact join
Step. 3:Contact ①and A electric wire
Contact ②and B-1 electric wire
Contact ③and B-2 electric wire
B-2
Emergency
Stop Switch
A
B
Protection
Switch
B-1
1
3
2
3
A
B
1
2
B-2
B-1
W W W . T M G I N D U S T R I A L . C O M P 1 5 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

PART IV: Operating the Wood Chipper
It may be helpful to better familiarize yourself with the features of your Wood Chipper before beginning
the steps outlined in this chapter.
WARNING
A. Read and understand all instructions, safety precautions, and/or warnings listed in “PART I:
General Safety Rules” before operating the WOOD CHIPPER. If any doubt or question arises about
the correct or safe method of performing anything found in this manual, please contact the dealers
in your area.
B. When operating the Wood Chipper, make sure you are standing in the safe operating area
(OPERATOR ZONE). You must stay in the safe operating area at all times when the ram is in motion
(whether extending or retracting). Never place any part of your body into a position that causes an
unsafe operating condition.
C. Before loading and operating the Wood Chipper, always wear protective gear, including safety
goggles, hearing protection, tight-fitting gloves without draw strings or loose cuffs, and steel-toed
shoes.
D. Knowing the correct and incorrect methods of Chipping woods. Never using an incorrect or unsafe
method.
Starting
1. Position your Wood Chipper on flat, dry ground, and then stop the front wheel with brake, make
sure the machine cannot be moved.
2. Make sure the fuel shut-off valve is in the “ON” position.
3. Move the choke control lever to the “CHOKE” position (should only be needed if the engine is
cold).
4. Move the throttle control lever to the “FAST” position.
5. Recoil Start: Turn the Ignition Switch to the “On” position. Grasp the recoil starter handle and
slowly pull until you feel resistance. Let the cord retract a little bit then pull the cord rapidly to start
the engine. One or two pulls usually starts the engine.
6. Electric Start: Turn and hold the Key in the start position until Engine starts then let the Key return
to run position.
7. Move the choke control lever (if used for cold engine) slowly back to the “RUN” position when the
engine is running well.
8. If the Wood Chipper has not been running (cold engine), warm up the engine by running the engine
at half throttle for 3 to 4 minutes, then advance the engine throttle control to the maximum speed.
W W W . T M G I N D U S T R I A L . C O M P 1 6 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Stopping
1. Move the Throttle Lever to IDLE.
2. Recoil Start: Turn the Ignition Switch to the OFF position.
3. Electric Start: Turn the Key to the OFF position.
Operator Zone
Wood Chipping
NOTICE
Woods’ and branches’ diameter should be no bigger than 100mm.
WARNING
Do not place your hands into the chute when loading. This is a very UNSAFE method and could result in
injury to your hands.
Do not reach or step across the rail while the Wood Chipper is running. This is a very UNSAFE method
which could cause personal injury, even death.
When Blocked
If the Roller stops while chipping woods or branches, the engine should be stopped, and take out the
woods which stuck the roller, and then restart the engine, and chip again.
W W W . T M G I N D U S T R I A L . C O M P 1 7 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

PART V: Maintaining the Wood Chipper
Regular maintenance is the way to ensure the best performance and long life of your machine. Please
refer to this manual and the engine manufacturer's user manual for maintenance procedures.
WARNING
Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow
all parts to cool. Disconnect the spark plug wire, keeping it away from the spark plug. Disconnect the
Battery Terminals (Electric start only).
Regular Maintenance Checklist
Procedure
Before Each Use
Every 3
Hours
Every 25
Hours
Every 100
Hours
Check engine oil level
Δ
Check general equipment condition
Δ
Check wedge for sharpness
Δ
Grease surface of slide rail
Δ
Check belts
Δ
Check tire pressure
Δ
Clean engine exterior and cooling
Δ
Change Engine Oil
First time 5hours
Δ
Replace air filter
Δ
Replace spark plug
Δ
Engine Service
Refer to the engine manufacturer’s user manual for engine maintenance.
Lubrication
NOTICE
All Bearings of your Chipper are sealed units and should have sufficient lubricant to last the life of your
machine with normal use.
W W W . T M G I N D U S T R I A L . C O M P 1 8 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Replace the blade
NOTICE
The blade is a bidirectional blade. If one side of the blade is worn, the blade can be used after changing
the direction without immediate replacement.
Turn the roller axle with wrench
1. Loosen the screws with T wrench when you see the blade
2. Replace with a new blade
3. After changing the blade, adjust the lower blade to keep the gap of 1-3mm
Oil filter
W W W . T M G I N D U S T R I A L . C O M P 1 9 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Adjust the clearance between blade and lower blade
Loosen the #67 screw, then loosen the #48 screw, Move #66 on U-groove observe that
the spacing between the roller blade and the lower blade spacer is within 1-3mm, Lock screw
#48,Finally lock screw #67
Adjust blade
clearance
1~3mm then
lock screw
W W W . T M G I N D U S T R I A L . C O M P 2 0 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9
1
48
66
49
67
