Introduction
We congratulate you on your new path to better health! Thousands of users enjoy the
benefits of an infrared sauna every day. Now you can enjoy the great benefits of
infrared heat within the privacy of your own home.
Please read this manual carefully and thoroughly before using an Infrared Sauna for the
first time. We recommend for you to keep this manual for future reference.
Benefits:
Superior Detoxification: Removes Heavy Metals & Fat-stored Toxins
Increased Cardiovascular Conditioning
Stimulated Immune System
Improved Circulation
Pain Relief
Weight Loss and Cellulite Reduction
Beautiful Skin
Stress Reduction
Features:
High quality wood craftsmanship
High quality electronic control system & digital control panel
Pre-assembled board and build-in electrical elements makes the installation easy
Accurate temperature sensor
Energy efficient
Considerate detailed designs

►www.tmgindustrial.com P2 / 17 Toll Free: 1-877-761-2819
For any missing parts please contact your local distributor.
TMG-LSN10/20/30 Part List
S/N
PART
PART DESCRIPTION
QTYS
NOTE
1
HY001
Front panel
1
2
HY002
Back panel
1
3
HY003
Side panel (L)
1
4
HY004
Side panel (R)
1
5
HY005
Top panel
1
6
HY006
Bench
1
7
HY007
Floor panel
1
8
HY008
Bench heater
1
9
HY009
Handle
2
Interior&Exterior
10
HY010
Hinge
2
11
HY011
Control panel
1
12
HY012
Heat panel for Back panel
2
13
HY013
Heat panel for side panel
2
14
HY014
Heat panel for bench heater
1
15
HY015
Speaker
2
16
HY016
Glass door
1
1565*540*6mm
17
HY017
Control box
1
18
HY018
Bluetooth
1
19
HY019
Screws: For installing the bench &
the roof panel
10
M4*40
20
HY020
Screws: For installing the handle
2
M6*75

►www.tmgindustrial.com P3 / 17 Toll Free: 1-877-761-2819
1
1
1
1
1

►www.tmgindustrial.com P4 / 17 Toll Free: 1-877-761-2819
Installation Requirements
Install the sauna on a completely level floor.
Do not spray the exterior with water. If the floor is damp, install a floor separator to keep
the sauna high & dry.
Do not store flammable objects or chemical substances near the sauna.
The sauna must be placed indoors and in a dry area. Moisture will cause damage to the
interior and exterior of the sauna.
Assembly Instructions
Assembly of the sauna requires at least 2 adults to complete. Please read
the instructions thoroughly before and during assembly to ensure proper
installation of the sauna.
Step 1: LOCATION OF SAUNA
When you find a good location for your sauna, please notethe following.
The main power cord on the sauna must be easily accessible.
The location must be dry and leveled.
Step 2: PLACING BOTTOM PANEL
Place the bottom panel on the floor. Make sure that the FRONT direction of your sauna
room.
1
1

►www.tmgindustrial.com P5 / 17 Toll Free: 1-877-761-2819
Step 3: CONNECTING THE BACK PANEL TO BOTTOM PANEL
Attach the back panel to the bottom panel by lining up the back panel on the bottom panel.
(Please hold the back panel until one of the side-panel had been installed.)
Step 4: CONNECTING SIDE PANELS WITH BACK PANEL
Align the side panels with back panels’ corresponding outside-buckles. Make sure the
outside-buckles on both side panels and fixed in place.

►www.tmgindustrial.com P6 / 17 Toll Free: 1-877-761-2819
Step 5: INSTALLING THE BENCH HEATER
Slide down the bench heater panel by lining up its sides with the vertical guides on side
panel.
1. The heater grill is facing outward (toward the front of the sauna).
2. Push the bench heater panel all the way down until it is touching the bottom panel and
securely in place.
Step 6: CONNECT THE WIRE OF BENCH HEATER AND THE FLOOR
HEATER
Connect the wire of bench heater and floor heater to the back panel.

►www.tmgindustrial.com P7 / 17 Toll Free: 1-877-761-2819
Step 7: INSTALLING THE BENCH
1. Install the bench by sliding it over the horizontal bench guides on the side panels.
2. Push the bench all the way in until it can touch the back panel and is securely in place.
Step 8: CONNECTING THE FRONT PANEL TO SIDE PANEL

►www.tmgindustrial.com P8 / 17 Toll Free: 1-877-761-2819
Step 9: PLACING TOP PANEL
Lower the roof panel onto the assembled panels.
1. Gently place the top panel onto the rest of the assembled panels. When four corners
are in place, gently push down the roof panel from the outside corners until it is snugly
fit over the rest of panels.
2. Make sure the cables do not get pinched between the panels.
3. Leading the wires of heaters onto the board through the corresponding hole.
4. Fix the roof panels by 8 screws to make sure it is stable enough.

►www.tmgindustrial.com P9 / 17 Toll Free: 1-877-761-2819
Step 10: THE MAIN POWER CONNECTION ON THE ROOF PANEL
1. Connect all the wires for heaters.
2. Connect the control panel wires.
3. Check if all connections to the control box are secure.
Step 11: INSTALLING DOOR HANDLE

►www.tmgindustrial.com P10 / 17 Toll Free: 1-877-761-2819
Step 12: ENJOY YOUR SAUNA!
Plug in the main power cord into the wall outlet and power up your sauna. Turn on the
radio, grab some towels, a glass of water and step you're your sauna and enjoy the
benefits of the sauna!!
Digital Control Panel Operating Instructions
INSTRUCTION
1. Press quickly to switch the sauna on to a stand-by mode.
2. Set the desired temperature using buttons.
3. Set the time to desired length using buttons.
4. Press quickly a second time to activate the heaters.
5. When time reaches 00, all the heaters will automatically shut off.
6. Press and hold to switch the sauna off.
7. Press SET button. Temp becomes hours ahead. Time becomes minutes ahead. Your
sauna will begin heating after the programmed time has elapsed.

►www.tmgindustrial.com P11 / 17 Toll Free: 1-877-761-2819
8. Press to turn on/ turn off the exterior lights. Press to turn on/turn off the
interior color light. You can change the color of the light by pressing this bottom.
9. How to use Bluetooth connector for music
a) Turn on your sauna, then its inside Bluetooth device would be discoverable
automatically.
b) For your cell phone, Turn on Bluetooth, then select add Bluetooth or other
device > Bluetooth. Choose the device name "IR SAUNA", then select. Done.
10. Sauna Temperature Adjustment
Temperature Adjustment: The sauna will reach a maximum temperature of 150
Fahrenheit under ideal experimental conditions. Under normal environment temperature,
the sauna will reach a maximum temperature anywhere from 140 to 150 Fahrenheit.
Things To Know
1. Set up the desired session temperature and time using the control panel. (suggested
100℉-130℉)
2. Allow approximately 10~15 minutes for the sauna to warm up before beginning a
session.
3. Recommend sauna session use is around 30-45 minutes.
4. The heaters automatically maintain the desired temperature inside the sauna
5. The ceiling vent can be opened at any time to for air circulation.
6. Always drink plenty of water before, during, and after a session. Doing so will
replenish lost fluids from the body through perspiration.
7. Take a hot shower or bath prior to the sauna session will further promote perspiration.
However, dry off thoroughly before going into the sauna because excessive water will
stain or warp the wood. A shower after the session is refreshing and rinsing
perspiration from the body.
8. To absorb perspiration and keep the sauna tidy during the session, place a towel on the
bench and floor of the sauna. Keep one towel handy to wipe excessive sweat from your
body.

►www.tmgindustrial.com P12 / 17 Toll Free: 1-877-761-2819
9. The interior wood is aromatic and adds to the enjoyment of your sauna session. If you
feel the odor is too strong during the first few months of usage, you can wipe the
wood with a damp cloth to minimize the odor.
Recommendation for Use
1. To regulate the temperature inside the sauna during your session, use the roof vent or
the door (by setting it at an angle).
2. To regulate the temperature inside the sauna during your session, use the roof vent or
the door (by setting it at an angle).
3. Drink plenty of fluids prior to, during, and after your sauna session.
4. If you take a hot /warm shower or bath before your sauna session, you may perspire
more. Try it with and without bathing or showering first to determine which way you
prefer.
5. To utilize the sauna’s heat therapy effect, give your hair a hot oil treatment while in
the sauna. Put oil or treatment into your hair and wrap it with towel. After the session
is over, rinse your hair thoroughly.
6. Use at least 2-3 towels; sit on one towel folded over several times for added
cushioning. Put another towel on the floor to absorb excess sweat. A third towel
draped over the knees may aid you in comfort and useful to towel off the sweat.
7. Be sure to towel off excess sweat during your session to help the body perspire more
freely.
8. To help relieve sore and tense muscles, massage the affected areas while in sauna to
help heal faster.
9. Do not put any lotions or oils on the body or face when using the sauna. This may
block the pores.
10.Shaving your face or legs with a razor while profusely sweating in a sauna yields an
incredibly smooth result without the use of gels or foams.
11.Do not eat anything at least an hour before your sauna session. It is better to go in the
sauna on an empty stomach. You are more likely to feel uncomfortable sitting in a
sauna with a full stomach.
12. To make the most out of your sauna session, work your muscles while in the sauna.
Stretch your arms and legs; massage your neck and feet, etc.

►www.tmgindustrial.com P13 / 17 Toll Free: 1-877-761-2819
13. You can benefit from the relaxing and soothing effects of a regular sauna session by
going to sleep afterwards. The peaceful and relaxed state rendered by a sauna session
will help you sleep easier and better.
14. At the first sign of cold or flu, increasing your sauna sessions may be beneficial in
boosting your immune treatment and decreasing the reproductive rate of the viruses.
Consult your physician for the proper treatment and care for this or any other
conditions.
15. To treat your ankles and feet more effectively, elevate them while inside the sauna.
Any area that you wish to achieve a specific deep heating effect should be moved as
close to one of the heaters as feels comfortable.
16. After the session is over, do not immediately jump into the shower. Since your body
was heated up during the session, if will continue to sweat even after the heaters are
off. Sit in the sauna with the door open and allow the body to sweat a little more as it
cools off. Once you feel comfortable enough, take a warm (or cool) shower to rinse
the sweat off your body completely.
Safety
Read all health and safety instructions. If in doubt as to the advisability of using
your infrared sauna, consult with your physician prior to use. If you feel light-
headed or heat exhaustion during session, exit the sauna immediately.
1. Read and follow all instructions carefully.
2. When installing and using this electrical equipment, basic safety precautions should
always be followed.
3. To reduce the risk of injury, do not allow children to use the sauna unless they are
closely supervised at all.
4. Do not use the sauna immediately following strenuous exercise. Wait at least 30
minutes to allow the body to cool down completely.
5. Excessive temperature has a high potential for causing fetal damage during the early
months of pregnancy. Pregnant or possibly pregnant women should contact their
physician prior to using the sauna.
6. Hyperthermia Danger: Prolonged exposure to hot air will induce hyperthermia.
Hyperthermia occurs when the internal temperature of the body reaches a level several
degrees above the normal body temperature of 37ºC (98.6ºF). While hyperthermia has

►www.tmgindustrial.com P14 / 17 Toll Free: 1-877-761-2819
many health benefits, it is important not to allow your body’s core temperature to rise
above 103ºF. Symptoms of excessive hyperthermia include dizziness, lethargy,
drowsiness, and fainting. The effects of excessive hyperthermia may include failure to
perceive heat, failure to recognize the need to exit, unawareness of impending hazard,
fetal damage in pregnant women, physical inability to exit the sauna, and
unconsciousness.
7. The use of alcohol, drugs, or medications prior to or during the sauna session may lead
to unconsciousness.
8. Persons suffering from obesity or with a medical history of heart disease, low or high
blood pressure, circulatory system problems, or diabetes should consult a physician
prior to using the sauna.
9. Persons using medications should consult a physician before using the
sauna since some medications may induce drowsiness while others may affect heart
rate, blood pressure, and circulation.
10.Never sleep inside the sauna while the unit is in full operation.
11.DO NOT use any type of cleaning agents on the interior of the sauna.
12.DO NOT stack or store any object on top of or inside the sauna.
13.If power supply cord becomes damaged it must immediately be replaced by the
manufacturer, or its agent, or a similarly qualified person to avoid a hazard.
14.DO NOT use the unit during an electrical storm, as there is a remote risk of shock.
15.Altering or tampering of any electrical connections on the power supply will void the
manufacturer’s warranty.
16.Dry your hands before handling electrical controls. Never unplug the power cord or
adjust the controls with wet hands or when you have wet bare feet. A danger of
electrical shock exists.
17. DO NOT attempt any repair without consulting the manufacturer first. Unauthorized
repair attempts will void manufacturer’s warranty.
18. All natural wood articles have variations in the color, grain, and irregularities such as
knots, and fine cracks. These characteristics are a part of the natural beauty of the
wood, and in no way should be considered defective.

►www.tmgindustrial.com P15 / 17 Toll Free: 1-877-761-2819
19.All natural wood articles have variations in the color, grain, and irregularities such as
knots, and fine cracks. These characteristics are a part of the natural beauty of the
wood, and in no way should be considered defective.
Important Safeguards For Your Sauna
1. READ INSTRUCTIONS -- All the safety and operating instructions should be read
before the sauna is installed and operated.
2. RETAIN INSTRUCTIONS -- The safety and operating instructions should be retained
for future reference.
3. FOLLOW INSTRUCTIONS -- All operating and usage instructions should be
followed at all times.
4. CLEANING -- Unplug the sauna from the wall outlet before cleaning DO NOT use
liquid cleaners or aerosol cleansers inside the sauna. Use a damp cloth for cleaning.
5. ATTACHMENTS-- Do not use any attachments that are not recommended by the
manufacturer, may be hazardous.
6. WATER OR MOISTURE—DO NOT use your sauna near water, e.g. near a bathtub,
in a wet basement, or near a swimming pool, etc.
7. POWER-CORD PROTECTION-- Power supply cord should be routed so it is not
likely to be walked on or pinched by items placed upon or against it.
8.LIGHTING-- For added protection for your sauna during a lightning storm, or when it
is left unattended and unused for long time, unplug it from the wall outlet.
9. OVERLOADING-- Do not overload wall outlet and extension cord as this can result in
a risk of fire or electric shock.
10. SERVICING-- Always unplug your sauna from the wall outlet before servicing.
11. REPLACEMENT PARTS--When replacement parts are required, be sure it is
specified by the manufacturer or have the same characteristics as the original parts.
Unauthorized substitutes may result in fire, electric shock or other hazards.
12. SAFETY CHECK--Upon completion of any service or repairs to your sauna, ask the
service technician to perform safety checks and determine that your sauna is in proper
operation condition.

►www.tmgindustrial.com P16 / 17 Toll Free: 1-877-761-2819
Cleaning and Maintenance
Before using your infrared sauna for the first time, clean the inside of the sauna with a
damp cloth. If the smell of the sauna is strong at first, that is normal and please open
the door while the sauna is working. The smell will diminish within a weekend.
Use furniture polish to clean the exterior.
We recommend placing a soft towel on the floor and on the bench of the sauna to
absorb perspiration during sauna use.
Scratches and stains on the sauna can be removed by simply using fine grade
sandpaper over the damaged area.
Troubleshooting Guide
Problems
Explanations
Solutions
1
Power indicator
light not on
Power cord is not plug-in
1. Check for power to the outlet.
2. Check connection between power
cord and main control unit.
The fuse is burned out
Check or replace the fuse.
2
Function
indicator
light not on
The corresponding indicator
light is
broken or burned out.
Repair or replace the control
panel.
The wiring or some
electronic component in the
circuit has failed
Repair or replace what has failed in
that circuit.
3
Infrared Heater
will
not heat up
The heater is broken
Replace with a new heater of the
same specifications.
Its life will be shortened
gradually from excessive use.
The fuse is burned out.
Check or replace the fuse.
The wiring connection for the
heater is loose or in the
wrong location.
Check it, and reconnect tightly.
The circuit board is not
functioning.
Check power output on the circuit
board
4
Sauna room not
maintaining
correct
temperature/
Display shows
E1
Problem with heater.
See Item #3.
Incorrect setting on control
panel
Reset it.
The temperature sensor wire
may be loose or broken.
Check sensor wire connection and
condition. Check to see if sensor
head is visible inside the sauna room.

►www.tmgindustrial.com P17 / 17 Toll Free: 1-877-761-2819
5
Peculiar burning
smell
Circuit problems (broken
component, short circuit,
failure of controlling system)
causing the burning of some
component in the electrical
system
1. Unplug sauna, check the voltage.
2. Find the objects with problems
3. Replace the parts
6
The light not
working
The light bulb is burned out.
Replace light
Replace light bulb.
The bulb is not secured in the
base
1.Make sure the bulb is tight enough
to make good contact in the light
fixture.
2.Check the lighting protection fuse.
The socket is broken.
Replace it.
Problems with electrical
control panel.
Check or replace the panel.
Disclaimers
We shall not be liable for any loss due to use (or misuse) of the sauna or other our
products or other incidental or consequential costs, expense or damages without
irrefutable foundations. Under no circumstances shall we or any of its representatives be
held liable for injury to any person or damage to any property, however arising. Any
implied warranty shall have duration equal of the applicable warranty stated above.
Specifications are subject to change without notice or obligation.
Legal Remedies
This limited warranty gives the original purchaser specific legal rights. Other rights may
vary from state to state.
