Thank you for purchasing TOA's UHF Wireless Microphone.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
WM-5220UHF WIRELESS MICROPHONE
INSTRUCTION MANUAL
1. SAFETY PRECAUTIONS
• Be sure to read the instructions in this section carefully before use.
• Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
• We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.
• To prevent the electromagnetic wave from badly influencing medical equipment, make sure to switch off the
unit's power when placing it in close proximity to the medical equipment.
• When the unit is not in use for 10 days or more, be sure to take the battery out of the unit because battery
leakage may cause personal injury or contamination of environment.
• Make sure to observe the following handling precautions so that a fire or personal injury does not result from
leakage or explosion of the battery.
· Do not short, disassemble, heat nor put the battery into a fire.
· Never charge batteries of the type which are not rechargeable.
· Do not solder a battery directly.
· Be sure to use the specified type of battery.
· Note correct polarity (positive and negative orientation) when inserting a battery in the unit.
· Avoid locations exposed to the direct sunlight, high temperature and high humidity when storing batteries.
CAUTION TO USER: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
WARNING
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
CAUTION

3. FEATURES
• One frequency can be selected from 64 frequencies (16 channels x 4 banks) of 636 – 698 MHz.
• An optimized PLL-synthesizer minimizes the oscillation frequency drift resulting from the ambient
temperature or voltage fluctuation.
• Power/Battery lamps indicate battery consumption to prevent the unit from malfunctioning when the battery
level remarkably decreases.
• Operates on a single AA battery.
• Employs a built-in antenna.
• The state of battery consumption can be displayed on the tuner's indicator when the unit is used in
conjunction with the optional WT-5800, WT-5805 or WT-5810 Wireless Tuner.
2. GENERAL DESCRIPTION
The TOA's WM-5220 Wireless Microphone employs an electret condenser microphone element of high
sensitivity and intelligible sound quality, and is suitable for speech use.
Power/Battery lamps
Power ON/OFF switch
A green LED lights as long as the battery
capacity is sufficient.
When the battery capacity becomes low, the
green LED starts to dim, while the red LED to
light.
The microphone does not transmit the signal if
the channel selector switch is set to the empty
channel. In this case, the red LED and green
LED flash alternately.
•
•Channel selector switch
Keep the switch in the "L"
position (factory-preset).
Leave the switch setting to
qualified service technicians.
BANK CHANNEL
4
3
2
1
4
56789A
B
C
D
E
F
0
321
BANK CHANNEL
4
3
2
1
4
56789A
B
C
D
E
F
0
321
4. HANDLING PRECAUTIONS
• Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as
doing so may result in unit failure.
• Never open nor remove the unit case to modify the unit. Refer all servicing to your nearest TOA dealer.
• Take care not to drop the unit onto the floor nor bump it against a hard object as the unit could fail.
• Do not place the unit in locations of high temperature (ex. in an ill-ventilated car in summer) or high humidity
as the unit could fail.
• Do not use the unit in locations where it is exposed to seawater.
• To clean, use a dry cloth. When the unit gets very dirty, wipe lightly with a cloth damped in a dilute neutral
cleanser, then wipe with a dry cloth. Never use benzine, thinner, or chemically-treated cleaning towel.
• Avoid using a mobile telephone near the wireless microphone in use. Noise could be picked up.
• When using two or more wireless microphones, keep them at least 50 cm away from each other to avoid
malfunctions or noise.
• Keep the wireless microphone at least 3 m away from the receiving antenna. Using the microphone in close
proximity to the antenna could result in malfunctions or noise.
5. NOMENCLATURE

6. BATTERY INSERTION
Step 1. Turn off the power switch.
Step 2. Hold the microphone body and rotate the microphone
grip counterclockwise to remove it.
Step 3. Insert an AA battery according to (+) and (–)
indications on the battery compartment.
Step 4. Replace the microphone grip by sliding and rotating it
clockwise.
Battery replacement
• A brand-new AA alkaline battery will continuously operate the unit for
about 10 hours.
• When the battery capacity becomes low, the green LED of the
Power/Battery lamps starts to dim, while the red LED to light.
When only the red LED lights, replace the battery with a new one. In this
condition, the unit transmits the remaining battery capacity information to
the tuner, causing the tuner's BATT indicator to light.
2
3
Green LEDRed LED
7. CHANNEL NUMBER SETTING
Step 1. Switch off the power. Rotate the microphone grip
counterclockwise to remove it.
Step 2. Using the supplied screwdriver, set the Channel
selector switch pointer to the desired channel number.
Step 3. Replace the microphone grip.
Note: Make sure that the wireless microphone is identical to
the wireless tuner in the channel number. Should the
microphone's setting differ from that of the tuner, the
tuner does not receive the microphone signal.
BANK CHANNEL
4
3
2
1
4
56789A
B
C
D
E
F
0
321
Channel selector switch
9. OPERATIONAL HINTS
• The microphone's service distance is 3 – 120 m. When the microphone user moves in a facility, signal
dropouts (momentary losses of signal reception) may be encountered. These dropouts are caused by the
building's architectural designs or materials which block the travel of or reflect the radio signal. If this occurs,
the user needs to change locations for better signal reception.
• The proper operation of your wireless system may be interfered with by other system operating on the same
frequency. In such cases, change the operating frequency of your system. (As to dealing with the
interference, refer to the operating instructions of the wireless tuner.)
• Should you have any questions regarding the use or availability of TOA wireless products, please contact
your local TOA dealer.
8. OPERATION
Step 1. Confirm that the wireless microphone and the wireless tuner are identical in the channel number. If
not identical, turn the power ON/OFF switch to the OFF position, then set the channel number to the
same channel number as the tuner.
Step 2. Turn the Power ON/OFF switch to the ON position. Then, confirm the green LED of the Power/Battery
lamps will light.
Step 3. Turn the Power ON/OFF switch to the OFF position after use.

133-07-265-30
URL: http://www.toa.jp/
10. SPECIFICATIONS
Microphone Element Electret condenser type, cardioid pattern
Modulation Frequency modulation
Frequency Range 636 – 698 MHz, UHF
Selectable Channel 64 channels
RF Carrier Power Less than 50 mW
Tone Frequency 32.768 kHz
Oscillator PLL synthesized
Maximum Input Level 126 dB SPL
Maximum Deviation ±40 kHz
Audio Frequency Response 100 – 15,000 Hz
Dynamic Range (AF Circuit) More than 95 dB (with WT-5800)
Battery LR6 (AA)
Battery Life More than 10 hours (alkaline)
Indicator Power/Battery lamps
Antenna Built-in type
Operating Temperature –10 to +50°C
Finish Resin, rubber coating
Dimensions ø43.6 x 231.5 mm
Weight 180 g (with battery)
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Microphone holder (with stand adapter) ............... 1
Screwdriver (for setting) ....................................... 1
Storage case ........................................................ 1
License requirement
The term "IC:" before the radio certification number only signifies that Industry Canada Technical
specifications were met. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could result
in the device exceeding the RF exposure requirements and void user's authority to
operate the device.
