Tobii Dynavox TD I Series User manual

TD I-Series
User's Manual
TD I–13
TD I–16

User's ManualTD I-Series
Version1.0
2023-03-20
All rights reserved.
Copyright © Tobii Dynavox AB (publ)
No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form, by any means
(electronic, photocopying, recording, or otherwise) without the prior written permission of the publisher.
Copyright protection claimed includes all forms and matters of copyrightable material and information allowed by
statutory or judicial law or hereafter granted, including without limitation, material generated from the software programs
which are displayed on the screen such as screen displays, menus, etc.
The information contained in this document is proprietary to Tobii Dynavox. Any reproduction in part or whole without
prior written authorization by Tobii Dynavox is prohibited.
Products that are referred to in this document may be either trademarks and/or registered trademarks of the respective
owners. The publisher and the author make no claim to these trademarks.
While every precaution has been taken in the preparation of this document, the publisher and the author assume no
responsibility for errors or omissions, or for damages resulting from the use of information contained in this document or
from the use of programs and source code that may accompany it. In no event shall the publisher and the author be
liable for any loss of profit or any other commercial damage caused or alleged to have been caused directly or indirectly
by this document.
Content subject to change without notice.
Please check Tobii Dynavox website.
www.TobiiDynavox.com for updated versions of this document.
Contact Information:
Tobii Dynavox AB
Karlsrovägen 2D
182 53 Danderyd
Sweden
[phone]
Tobii Dynavox LLC
2100 Wharton Street, Suite 400
Pittsburgh, PA 15203
USA
[phone]
Tobii Dynavox Ltd.
Sheffield Technology Parks
Cooper Buildings
Arundel Street
Sheffield S1 2NS
United Kingdom
[phone]
Tobii Dynavox (Suzhou) Co. Ltd
Unit 11/12, Floor 3, Building B, No.5 Xinghan Street, SIP,
Suzhou
P.R.China 215021
[phone]
The following products are protected by U.S. Patents 7,572,008, 6,659,611, 8,185,845 and 9,996,159:
● TD I–13 Device Identifier: 7340074601998
● TD I–16 Device Identifier: 7340074602001
You can locate the Type of TD I-Series device on the label on the back side.

Table of Contents
1 Introduction....................................................................................................................... 7
1.1 Explanation of Admonitions ................................................................................................ 7
1.2 Symbols and Markings........................................................................................................ 7
1.3 Intended Use....................................................................................................................... 9
1.3.1 Intended User Profile ......................................................................................... 9
1.3.2 Additional Information ........................................................................................ 9
1.3.3 Portable Use ...................................................................................................... 10
1.3.4 Mounted Use...................................................................................................... 10
1.4 Package Contents............................................................................................................... 10
2 Safety................................................................................................................................. 12
2.1 Avoiding Hearing Damage .................................................................................................. 13
2.2 Temperature ....................................................................................................................... 13
2.3 Power Supply and Batteries................................................................................................ 13
2.4 Mounting ............................................................................................................................. 14
2.5 Emergency.......................................................................................................................... 14
2.6 Infrared................................................................................................................................ 14
2.7 Epilepsy .............................................................................................................................. 14
2.8 Electricity............................................................................................................................. 15
2.9 Software.............................................................................................................................. 15
2.10 Child Safety......................................................................................................................... 15
2.11 Environmental Control ........................................................................................................ 15
2.12 Eye Gaze ............................................................................................................................ 15
2.13 Third Party .......................................................................................................................... 15
3 Overview of the TD I–13 and TD I–16.............................................................................. 16
3.1 Key Features....................................................................................................................... 16
3.2 Product Layout.................................................................................................................... 16
3.2.1 The TD I–13 and TD I–16 .................................................................................. 16
3.2.2 Ports, Sensors and Device Buttons ................................................................... 17
3.3 Preinstalled Software .......................................................................................................... 19
4 Batteries in the Device ..................................................................................................... 20
4.1 Batteries.............................................................................................................................. 20
4.2 Charging the TD I-Series .................................................................................................... 20
4.2.1 The Status LED Behavior................................................................................... 20
4.3 Changing the Battery .......................................................................................................... 20
5 Using the Device............................................................................................................... 22
5.1 Starting the Device.............................................................................................................. 22
5.1.1 First Start Up ...................................................................................................... 22
5.1.1.1 Local Account.................................................................................. 22
5.1.1.1.1 What is a local offline account in Windows? .............. 22
5.1.1.2 Creating a Local User Account........................................................ 22

5.1.1.3 Tobii Dynavox Configuration ........................................................... 23
5.1.2 Password Information ........................................................................................ 23
5.2 Shutting Down the Device................................................................................................... 23
5.3 Using Eye Gaze .................................................................................................................. 23
5.3.1 Positioning.......................................................................................................... 24
5.3.2 Tips for Outdoor Usage...................................................................................... 24
5.3.3 Track Box ........................................................................................................... 24
5.3.4 Track Status ....................................................................................................... 25
5.3.5 Eye Tracking Settings (Application) ................................................................... 26
5.3.5.1 The Calibration Tab......................................................................... 26
5.3.5.1.1 Manage Profiles ......................................................... 26
5.3.5.1.2 Create New Profile ..................................................... 27
5.3.5.1.3 Calibration Results ..................................................... 27
5.3.5.1.4 Test Calibration .......................................................... 28
5.3.5.1.5 Calibration .................................................................. 29
5.3.5.2 The Activation Tab .......................................................................... 31
5.3.5.2.1 Gaze Settings............................................................. 31
5.3.5.2.2 Gaze & Switch Settings.............................................. 31
5.3.5.3 The Feedback Tab .......................................................................... 32
5.3.5.4 The General Tab ............................................................................. 33
5.3.5.4.1 Wake-on-Gaze®......................................................... 33
5.3.5.4.2 Off-Screen Menu ........................................................ 34
5.3.5.4.3 Show TD Control Shortcut.......................................... 34
5.3.5.4.4 Logs............................................................................ 34
5.4 Using Windows Hello .......................................................................................................... 34
5.4.1 Setup Windows Hello ......................................................................................... 35
5.5 Using the Stand Adjustable Base ....................................................................................... 35
5.6 Using the Partner Window .................................................................................................. 36
5.7 Using the Cameras ............................................................................................................. 37
5.8 Using the Programmable IR Remote Control ..................................................................... 37
5.9 Adjusting the Volume .......................................................................................................... 37
5.10 Adjusting the Sound............................................................................................................ 37
5.11 Tobii Dynavox Hardware Settings....................................................................................... 37
5.11.1 Adaptive Buttons ................................................................................................ 38
5.11.1.1 Triangle Button................................................................................ 38
5.11.1.2 Square Button ................................................................................. 38
5.11.1.3 Volume Buttons............................................................................... 38
5.11.1.3.1 Enabling Volume Buttons ........................................... 38
5.11.1.3.2 Disabling Volume Buttons .......................................... 39
5.11.2 Eye Tracker ....................................................................................................... 39
5.11.2.1 Eye Tracking ................................................................................... 39
5.11.2.1.1 Enabling Eye Tracking ............................................... 39
5.11.2.1.2 Disabling Eye Tracking............................................... 39
5.11.2.2 Eye Tracking Settings ..................................................................... 39
5.11.3 Sound ................................................................................................................ 40
5.11.3.1 Enabling Automatic Headphone Jack Detection ............................. 40
5.11.3.2 Disabling automatic Headphone Jack Detection............................. 40
5.11.4 Switches ............................................................................................................ 40
5.11.4.1 Enabling a Connected Switch ......................................................... 41
5.11.4.2 Disabling a Connected Switch......................................................... 41
5.11.4.3 Select Action for Switch 1 and/or Switch 2...................................... 41
5.11.5 Touch & Gestures ............................................................................................. 41
5.11.5.1 Edge Swipe ..................................................................................... 41

5.11.5.1.1 Enabling Edge Swipe ................................................. 41
5.11.5.1.2 Disabling Edge Swipe ................................................ 42
5.11.5.2 Lock Screen .................................................................................... 42
5.11.5.2.1 Enabling Lock Screen ................................................ 42
5.11.5.2.2 Disabling Lock Screen................................................ 42
5.11.6 Product Key ....................................................................................................... 42
5.11.7 System & Diagnostics ....................................................................................... 43
5.12 Reset the Device................................................................................................................. 43
6 Product Care ..................................................................................................................... 46
6.1 Temperature & Humidity ..................................................................................................... 46
6.1.1 General Use - Operating Temperature .............................................................. 46
6.1.2 Transportation and Storage ............................................................................... 46
6.2 Cleaning of the Device........................................................................................................ 46
6.3 Placement ........................................................................................................................... 46
6.4 Transporting the Device...................................................................................................... 47
6.5 Disposing of the Device ...................................................................................................... 47
6.6 Disposing of Batteries ......................................................................................................... 47
Appendix
A Support, Warranty, Training Resources and Trouble-shooting................................... 48
A1 Customer Support............................................................................................................... 48
A2 Warranty ............................................................................................................................. 48
A3 Training Resources............................................................................................................. 48
A4 Trouble-shooting Guide ...................................................................................................... 48
A4.1 If the TD I-Series does not Power up ................................................................. 48
A4.2 How do I carry out a Power Reset on the TD I-Series? ..................................... 49
A5 What do I do if the Status LED Blinks Red Three Times when I Try to Start the TD I-
Series?................................................................................................................................
49
B Compliance Information .................................................................................................. 50
B1 FCC Statement ................................................................................................................... 50
B1.1 For P15B Equipment.......................................................................................... 50
B1.2 For Portable Devices.......................................................................................... 50
B2 Radio Wave Exposure and Specific Absorption Rate (SAR) Information ........................... 50
B3 Industry Canada Statement ................................................................................................ 51
B4 CE Statement...................................................................................................................... 51
B5 Directives and Standards.................................................................................................... 52
C Computer Device States of Operation and LED Status ................................................ 53
D Technical Specifications.................................................................................................. 55
D1 Standard TD I-Series .......................................................................................................... 55
D2 Device Power Adapter ........................................................................................................ 56
D3 Battery pack ........................................................................................................................ 56
D4 Eye Tracker......................................................................................................................... 56
E Maximum Allowed Temperature ..................................................................................... 58

F Approved Accessories..................................................................................................... 59
G Local Certification Partners............................................................................................. 60

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 1 Introduction 7
1 Introduction
Thank you for purchasing a TD I-Series device!
To ensure the optimal performance of this product, please take the time to read this manual carefully.
The TD I-Series device is available in two different sizes: the TD I–13 with a 13.3" screen and the TD I–16 with a 15.6"
screen. The TD I-Series is an Eye Gaze device but can be ordered without the Eye Gaze function.
This User’s Manual covers:
● The TD I-Series device, models TD I–13 and TD I–16.
● The Eye Gaze functions
1.1 Explanation of Admonitions
In this manual we use six (6) levels of admonitions as follows:
The Note symbol is used for notifying the user of something important or of something that needs special attention.
The Tips symbol is used for notifying the user of something they might not have thought of.
The Caution symbol is used to inform of something that could cause harm to, or malfunction of, the equipment.
The Warning symbol is used to inform of something in which there is a conceivable risk of harm to the user if the
Warning is ignored.
The High Volume symbol is used to inform of something that can cause damage to hearing.
The High Temperature symbol is used to inform of surface temperature conditions that may cause injury or
discomfort.
1.2 Symbols and Markings
This section provides information about the symbols that are used on the TD I-Series, its accessories or packaging.
Symbol or Markings Description
USB 3.0 Port.
Stand-by.
SW1
3.5 mm Switch port 1.
SW2
3.5 mm Switch port 2.
Power Connector.
Head phone jack 3.5 mm.

81 Introduction TD I-Series I-13/I-16 User's Manual v.1.0-en-US
Symbol or Markings Description
Dispose of in accordance with your country's requirements for electronic waste.
CE is the abbreviation of the European Communities and this mark tells customs officials
in the European Union that the product complies with one or more of the EC Directives.
The UKCA (UK Conformity Assessed) marking is a UK product marking that is used for
goods being placed on the market in Great Britain (England, Wales and Scotland). It
covers most goods which previously required the CE marking.
This mark is a certification mark employed on electronic products manufactured or sold in
the United States which certifies that the electromagnetic interference from the device is
under limits approved by the Federal Communications Commission.
Regulatory mark which represent compliant Russia, Kazakhstan, Belarus regulatory
requirement.
The Mark indicates compliance of electronic appliances such as IT and Audio/Video
Equipment with NOM (Normas Oficiales Mexicanas) standards for safety in Mexico.
Japanese certification for electrical/electronic appliances and components.
The Technical Conformity Mark is a proof that the radio equipment conforms to the
technical regulations specified in the Radio Law in Japan. Only valid for TD I–16.
Conforms to relevant Japanese EMC requirements. Only valid for TD I–16.
IC
IC is the abbreviation of the Industry Canada and this mark tells customs officials in
Canada that the product complies with one or more of the Canadian standards.
UL Classification Marks for Canada and the United States.
Recognized component mark for Canada and the United States.
Follow Instructions for Use.
Recyclable material.
Recyclable material in Taiwan.
Conforms to relevant Australian EMC requirements.
Manufacturer.
Reference number.

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 1 Introduction 9
Symbol or Markings Description
Serial Number.
Safety Class II equipment (reinforced insulation).
This mark shows the pin out polarity on the AC/DC Power Adapter.
Enclosure ingress protection code per IEC 60529.
China Compulsory Certificate.
The most recognized International Safety mark. This safety listing signifies that the
product was tested to IEC60601–1.
China RoHS compliance.
RoHS directive compliance.
Unique Device Identifier.
Medical Device Marking.
1.3 Intended Use
The TD I-Series is intended primarily as a speech generating device. The TD I-Series is intended to provide, and act as,
a compliment for everyday communication for people who have challenges in their ability to speak due to injury, disability
or illness. This intended use is reflected in design features such as long-lasting batteries, superior sound quality, high
durability and alternative input methods including Tobii Eye tracking.
Contraindication: The TD I-Series device should never be, for the user, the only means of communicating
important information.
In case of failure of the TD I-Series device, the user cannot communicate using it.
1.3.1 Intended User Profile
The Primary Users of the TD I-Series TD I–13 and TD I–16 are those individuals who, due to physical, language, and/or
cognitive conditions, require an AAC device for Speech. It is appropriate for users of all ages.
1.3.2 Additional Information
The TD I-Series is an Augmentative and Alternative Communication (AAC) product, a purpose-built Speech Generating
Device (SGD) designed to provide to its users increased communication ability and greater independence. The TD I-
Series is intended primarily to provide, and act as, a compliment to everyday communication for people who have
challenges in their ability to speak due to injury, disability or illness. This intended use is reflected in design features such
as long lasting batteries, superior sound quality, high durability, built-in environmental control and alternative input
methods.

10 1 Introduction TD I-Series I-13/I-16 User's Manual v.1.0-en-US
The TD I-Series is a device with an optional Tobii Eye Tracker and a capacitive touch screen for touch access. The
device is intended to be used on a mounting arm, or standing upright on an appropriate surface. In addition to eye gaze
and touch, the device can be operated through switch scanning, mouse, keyboard, or a combination thereof.
The TD I-Series is designed primarily for face-to-face communication and secondarily for long distance communication,
and computer access. The TD I-Series allows the user to communicate via text or symbols to generate text-to-speech or
play back recorded messages for face-to-face communication. The user can also display their messages on the
outwards facing display on the back of the device. The TD I-Series allows users to compose text messages (SMS) and
e-mails through adapted interfaces or access third party apps and services for online communication, such as Skype or
Facebook.
With the TD I-Series, users have the freedom and flexibility provided via the Microsoft® Windows environment.
The TD I-Series meets the definition for medical equipment; and is registered as a Class I medical device with the
Swedish Medical Products Agency, and as Class II durable medical equipment with the US FDA. The TD I-Series is
available in two sizes (13.3 and 15.6); and is available as a dedicated (locked) Speech Generating Device. The TD I-
Series device does not sustain or support life. In case of failure of the TD I-Series device, the user should have a low-
tech backup solution for communication.
1.3.3 Portable Use
A portable TD I-Series can be used in two (2) different positions.
● Upright orientation
● Mounted (see section 1.3.4 Mounted Use, page10)
Upright Orientation
1.3.4 Mounted Use
The mounting plate on the device connects to Connect IT/REHAdapt mounts. If using a Daessy mount, an adapter plate
is needed.
1.4 Package Contents
It is recommended to keep the original packaging materials for the TD I-Series.
If the device needs to be returned to Tobii Dynavox for warranty-related issues or repair, it is beneficial that the
original packaging or equivalent is used for shipping. Most shipping carriers require at least 2 inches of packing
material around the device.
Note: Due to Joint Commission regulations, any shipping materials (including boxes) sent to Tobii Dynavox must
be discarded.
The items below are included with your TD I-Series package:
● 1 Device (13.3ʺ or 15.6ʺ)
● 1 Adjustable Base
● 1 Eye Tracker (built in)
● 1 Mounting plate for Connect IT/REHAdapt (mounted)

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 1 Introduction 11
● 1 Battery
● 1 Power Supply
● 1 Windows 10 license
● 1 Tobii Dynavox Communicator 5 software (pre-installed)
● 1 TD Control software (pre-installed)
● 1 TD Snap software (pre-installed)
● 1 TD Browse software (pre-installed)
● 1 TD Talk software (pre-installed)
● 1 TD Phone software (pre-installed)
● 1 TD Switcher software (pre-installed)
● 1 Tobii Dynavox Gaze Viewer software (pre-installed)
● 1 Tobii Dynavox Accessible Literacy Learning (ALL) software (pre-installed) (Not available for all markets)
● 1 Tobii Dynavox Hardware Settings software (pre-installed)
● 1 Boardmaker 7 Student Center software (pre-installed)
● 1 Eye FX2 Demo software (pre-installed)
● 1 TD I-Series User’s Manual (on the device as a PDF document)
● 1 Getting Started Guide (printed)
● 1 TD Snap Basics Training Cards (printed)
● 1 Communicator 5 Training Cards (printed)
● 1 Safety and Compliance documents (printed)
● 1 Software License Documents (printed)
● 1 Warranty Document (printed)

12 2 Safety TD I-Series I-13/I-16 User's Manual v.1.0-en-US
2 Safety
The TD I-Series device has been tested and approved as compliant to all the Specifications and Standards listed in
Appendix B Compliance Information, page50 of this manual and in the Appendix D Technical Specifications, page55 --
including, but not limited to, the Medical Device Standard (Class 1/Type B). Nevertheless, in order to ensure safe
operation of your TD I-Series device, there are a few safety warnings to bear in mind:
No modification of this equipment is allowed
Repairs to a Tobii Dynavox device must only be performed by Tobii Dynavox or a Tobii Dynavox authorized and
approved repair center.
Contraindication: The TD I-Series device should never be, for the user, the only means of communicating
important information.
In case of failure of the TD I-Series device, the user cannot communicate using it.
In case of serious incident that has occurred, please contact the manufacturer and local authorities immediately.
Notice: It is recommended to install the appropriate software, if have any question, please contact the
manufacturer for further assistance.
Notice: To prevent unauthorized access, it is recommended to install suitable anti-virus software or do not connect
to unsafe external networks.
The TD I-Series is not to be used as a life supporting device, and it shall not be relied on in case of loss of function
due to power loss or other causes.
There could be a choking hazard risk if small parts detach from the TD I-Series device.
The TD I-Series device shall not be exposed to or used in weather conditions outside the Technical Specification
of the TD I-Series device.
The TD I-Series device shall only be used with TD I-Series specific accessories that have a mounting instruction
included with the accessory.
The charging cable could present strangulation hazards to young children. Never leave small children unattended
with the charging cable.
Young children or people with cognitive disabilities should not have access to, or the use of, the TD I-Series device
without parental or guardian supervision.
Do no attach any decorations, post it notes or similar on the screen side of the TD I-Series device. These may
interfere with the Eye Gaze or touch screen performance.
Never force a connector into a port. If the connector and port do not join with reasonable ease, they probably do
not match. Make sure that the connector matches the port and that you have positioned the connector correctly in
relation to the port.
Be extra careful with the USB connectors.

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 2 Safety 13
2.1 Avoiding Hearing Damage
Permanent hearing loss may occur if earphones, headphones or speakers are used at high volume. To prevent
this, the volume should be set to a safe level. You can become desensitized over time to high sound levels which
may then sound acceptable yet still could be damaging your hearing. If you experience symptoms such as ringing
in your ears, please lower the volume or stop using the earphones/headphones. The louder the volume, the less
time is required before your hearing could be affected.
Hearing experts suggest the following measures to protect your hearing:
● Limit the amount of time you use earphones or headphones at high volume.
● Avoid turning up the volume to block out noisy surroundings.
● Turn the volume down if you cannot hear people speaking near you.
To establish a safe volume level:
● Set your volume control at a low setting.
● Slowly increase the sound until you can hear it comfortably and clearly, without distortion.
The TD I-Series device can produce sounds in decibel ranges that may cause hearing loss for a normal hearing
person, even when exposed for less than a minute. The maximum sound level of the unit is in parity with the
sound levels that a healthy young person can produce while screaming. Since the TD I-Series device is intended
as a voice prosthetic, it shares the same possibilities and potential risks of causing harm to hearing. The higher
decibel ranges are offered to enable communication in a noisy environment and should be used with care and only
in said noisy environments.
2.2 Temperature
When used in direct sunshine or in any other hot environment, the TD I-Series device may have hot surfaces.
There are built-in temperature sensors that monitors the temperature. If the sensors detects temperatures above
the temperature specified in Appendix E Maximum Allowed Temperature, page58, the device will automatically
trigger a Windows Shut Down or Hibernate (depending on Windows Power Button configuration) to prevent risk of
harm to the user. It may take a while before the TD I-Series device can be restarted, as the unit may need time to
cool down.
Do not touch the area specified in Illustration 9: Temperature Threshold Area, page58 when the TD I-Series
device is running. The specified area can reach temperatures which may cause permanent bodily harm in the
event of prolonged direct skin contact. Use appropriate precautions to avoid injury.
2.3 Power Supply and Batteries
The TD I-Series device uses lithium-ion batteries. These batteries have a storage temperature range of between
-20 °C/-4 °F and 40 °C/104 °F within 3 months.
If you are in a hot environment, be aware that it can affect the ability to charge the batteries. The internal
temperature has to be between 0 °C/32 °F and 45 °C/113 °F for the batteries to charge. If the internal battery
temperature raises above 45 °C/113 °F the batteries will not charge at all.
Move the TD I-Series device and the batteries to a cooler environment to let the batteries charge properly.
Avoid exposing the batteries to fire or to temperatures above 50 °C/122 °F. These conditions may cause a battery
to malfunction, generate heat, ignite or explode. Be aware that it is possible, in a worst case scenario, for
temperatures to reach greater than those stated above in, for example, the trunk of a car on a hot day. So, storing
the device, with batteries installed, in a hot car trunk could conceivably lead to a malfunction.
Do not disassemble or harm the battery. Follow the environmental laws and regulations which apply in your area
when disposing of batteries.
The battery may only be replaced by the user with a TDG G1 battery pack sold by Tobii Dynavox. There is a risk of
explosion if the battery is replaced with an incorrect type.
For safe operation of the TD I-Series device, use only chargers, batteries, and accessories approved by Tobii
Dynavox.

14 2 Safety TD I-Series I-13/I-16 User's Manual v.1.0-en-US
Do not open (except for the battery cover), or modify, the metal casing of the TD I-Series device or of the power
supply, since you may be exposed to potentially hazardous electrical voltage. The device contains no serviceable
parts. If the TD I-Series device or its accessories are mechanically damaged, do not to use them.
If the battery is not charged or the TD I-Series is not powered up by the power supply, the TD I-Series device will
shut down.
If the Power Supply Cord becomes damaged, contact Tobii Dynavox for replacement.
Do not connect any devices with a non-medical grade power supply to any connector on the TD I-Series device.
Furthermore, all configurations shall comply with the system standard IEC 60601-1-1. Anyone who connects
additional equipment to the signal input part or signal output part is configuring a medical system and is therefore
responsible for ensuring that the system complies with the requirements of the system standard IEC 60601-1-1. If
in doubt, consult the technical services department or your local representative.
The appliance coupler of the power supply or separable plug is used as the Mains Disconnection Device, please
do not position the TD I-Series device so that it is difficult to operate the disconnection device.
Special regulations apply to shipping Lithium-ion batteries. If dropped, crushed, punctured, thrown, abused or
short-circuited, these batteries can release dangerous amounts of heat and may ignite, and are dangerous in fires.
Please reference IATA regulations when shipping lithium metal or lithium-ion batteries or cells: http://
www.iata.org/whatwedo/cargo/dgr/Pages/lithium-batteries.aspx
2.4 Mounting
The TD I-Series should be mounted according to manufacturer instructions of approved mounts. Tobii Dynavox or
its agents are not liable for damage or injuries to a person or its property due to a TD I-Series falling from a
mounted configuration. The mounting of a TD I-Series is done entirely at the user’s own risk.
2.5 Emergency
Do not rely on the device for emergency calls or banking transactions. We recommend having multiple ways to
communicate in emergency situations. Banking transactions should only be carried out with a system
recommended by, and approved according to the standards of your bank.
2.6 Infrared
The TD I-Series emits pulsed infrared (IR) light both from the eye tracker and from the Environmental Control Unit.
Other devices controlled by IR or susceptible to disturbance by IR light might be affected by the IR light emitted
from the TD I-Series. Do not use the TD I-Series in the vicinity of such devices if their functionality is of critical
importance.
2.7 Epilepsy
Some people with Photosensitive Epilepsy are susceptible to epileptic seizures or loss of consciousness when
exposed to certain flashing lights or light patterns in everyday life. This may happen even if the person has no
medical history of epilepsy or has never had any epileptic seizures.
A person with Photosensitive Epilepsy would also be likely to have problems with TV screens, some arcade
games, and flickering fluorescent bulbs. Such people may have a seizure while watching certain images or
patterns on a monitor, or even when exposed to the light sources of an eye tracker. It is estimated that about 3-5%
of people with epilepsy have this type of Photosensitive Epilepsy. Many people with Photosensitive Epilepsy
experience an "aura" or feel odd sensations before the seizure occurs. If you feel odd during use, move your eyes
away from the eye tracker.

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 2 Safety 15
2.8 Electricity
Do not open the casing, except for the battery cover, of the TD I-Series device, since you may be exposed to
potentially hazardous electrical voltage. The device contains no user serviceable parts.
2.9 Software
Windows comes with Windows Defender included, providing protection from viruses, malware, and other potential
threats. Regardless of whether you use Windows Defender or a third party anti-virus software, we recommend that
you always keep your antivirus software up-to-date.
Software other than that which is pre-installed on the TD I-Series is installed at the user's own risk. External
software could cause the TD I-Series to malfunction and might not be covered by the warranty.
2.10 Child Safety
The TD I-Series are advanced computer systems and electronic devices. As such they are composed of numerous
separate, assembled parts. In the hands of a child these parts have the possibility of being separated from the
device, possibly constituting a choking hazard or another danger to the child.
Young children should not have access to, or the use of, the device without parental or guardian supervision.
2.11 Environmental Control
The Programmable IR Remote Control — Environmental Control Unit (ECU) is not to be relied on as the only
method of interaction with IR controlled devices.
2.12 Eye Gaze
Some people may experience a certain amount of fatigue (due to intentional eye focusing and hard concentration)
or even a dryness of the eyes (due to less frequent blinking) when first getting used to Eye Gaze. If you are
experiencing fatigue or dry eyes start off slowly and limit the length of your Eye Gaze sessions to your comfort
level. Remoisturizing eye drops can be helpful to combat dryness.
2.13 Third Party
Tobii Dynavox assumes no responsibility for any consequence resulting from use of the TD I-Series in a manner
inconsistent with its intended use, including any use of the TD I-Series with third-party software and/or hardware
that changes the intended use.

16 3 Overview of the TD I–13 and TD I–16 TD I-Series I-13/I-16 User's Manual v.1.0-en-US
3 Overview of the TD I–13 and TD I–16
3.1 Key Features
The TD I-Series has several built-in features. Some of these come standard and some can be ordered as additional
features.
Standard features: 2 × Camera, 1 × microphone, 2 × speakers, 1 × IR ECU (Environmental Control Unit), 1 ×
Bluetooth® and 1 × WLAN (Wireless Local Area Network)
3.2 Product Layout
A TD I-Series device has a color capacitive touch, LED Backlight screen. The TD I–13 has a 13.3ʺ screen with a 1920 ×
1080 pixel resolution. The TD I–16 has a 15.6ʺ screen with a 1920 × 1080 pixel resolution.
3.2.1 The TD I–13 and TD I–16
13.3”
15.6”

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 3 Overview of the TD I–13 and TD I–16 17
3.2.2 Ports, Sensors and Device Buttons
1 2 3 4
6 55 57 8 9
Illustration1: Front
Position Description Position Description
1 Status LED 6 Adaptive Button 1 — Triangle (Configurable)
Track Status (Default for touch)
See 5.11.1 Adaptive Buttons, page38.
2 Light Sensor 7 Adaptive Button 2 — Square (Configurable)
Calibrate Eye Tracker (Default for touch)
See 5.11.1 Adaptive Buttons, page38.
3 Microphone 8 Volume Down
4 Camera 2 MP Fixed Focus(FF) 9 Volume Up
5 Eye Tracker

18 3 Overview of the TD I–13 and TD I–16 TD I-Series I-13/I-16 User's Manual v.1.0-en-US
10 11 12
13
14 1415
Illustration2: Back
Position Description Position Description
10 Camera 8 MP Auto Focus (AF) 13 Mounting Plate
11 Power Button 14 Speakers
12 Partner Window 15 Programmable IR Remote/ECU (transmitter
and receiver)

TD I-Series I-13/I-16 User's Manual v.1.0-en-US 3 Overview of the TD I–13 and TD I–16 19
17
18
19
20
21
16
Illustration3: Bottom, Left, and Right Side
Position Description Position Description
16 Power Connector 19 Switch Port 1
17 USB 3.0 connectors (2) 20 Switch Port 2
18 Head phone jack 3.5 mm 21 Battery Cover
Never force a connector into a port. If the connector and port do not join with reasonable ease, they probably do
not match. Make sure that the connector matches the port and that you have positioned the connector correctly in
relation to the port.
Be extra careful with the USB connectors.
3.3 Preinstalled Software
The TD I-Series device is delivered with all pre-ordered and required software installed and ready to use. Should a
reinstallation become necessary at any stage, perform a Factory Recovery. For more information, see 5.12 Reset the
Device, page43.

20 4 Batteries in the Device TD I-Series I-13/I-16 User's Manual v.1.0-en-US
4 Batteries in the Device
4.1 Batteries
The TD I-Series device has one built-in battery and a battery indicator. The battery indicator will send out a warning of
low battery when the battery drops below 10% of its capacity. The low battery warning will show on the screen. If the TD
I-Series device is not powered up by the power supply for charging, the TD I-Series device will shut down automatically.
For more information, see Appendix D Technical Specifications, page55.
4.2 Charging the TD I-Series
1. Connect the Power cable to the Power Connector on the device.
2. Connect the Power adapter to an electrical outlet and charge the tablet until the battery is fully charged.
For device storage and battery charging temperatures, see 2 Safety, page12.
4.2.1 The Status LED Behavior
The status LED will shine with three (3) different colors:
● Green — Fully charged
● Blue — Charging
● Red — Fault
If the LED blinks red three (3) times when the power button is pressed, the battery level is below the critical level
and the battery needs to be charged.
4.3 Changing the Battery
The battery may only be replaced by the user with a TDG G1 battery pack sold by Tobii Dynavox. There is a risk of
explosion if the battery is replaced with an incorrect type.
1. Make sure to shut down the device. For more information, see 5.2 Shutting Down the Device, page23.
2. Disconnect the Power connector from the device.
3. Place the device with the display facing down.
4. Unscrew the five (5) screws holding the battery cover in place with a Phillips screw driver.
5. Remove the battery cover plate.
6. Pull the Battery strap to remove the battery from the battery compartment.
