TONGFANG GK5CP4X User manual

User Manual
GK5CP4X
GK5CP5X
GK5CP6X

The information in this user’s manual is protected by copyright
laws, all parts of this manual, including the products and software
described in it, can not be reproduced, transmitted, transcribed,
stored in a retrieval system, nor translated into any language.
THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE
FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL
AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL
DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE
OR USE OF THIS MANUAL.
The illustrations in this user’s manual are for reference only.
Actual product specications may vary with territories.
The information in this user’s manual is subject to change without
notice.
Notice

TABLE OF CONTENTS
Notice ...................................................................................................... 2
Preface .................................................................................................... 5
1.1 Regulations Information..................................................................... 6
1.2 Safety Instructions............................................................................. 9
1.3 Conventions for this Manual............................................................ 10
1.4 Release History ................................................................................11
Getting to know the basics .................................................................... 12
2.1 Product Specication....................................................................... 13
2.2 Preparing your Computer ............................................................... 17
2.3 Product Overview ........................................................................... 18
Getting started........................................................................................27
3.1 AC Adapter ...................................................................................... 28
3.2 Knowing the Keyboard .................................................................... 29
3.2.1 For keyboard users....................................................................... 30
3.3 Using the touchpad / clickpad.......................................................... 33
BIOS setup ............................................................................................ 34

4.1 About BIOS Setup ........................................................................... 35
4.1.1 When to Use BIOS Setup ?.......................................................... 35
4.1.2 How to Run BIOS Setup ?............................................................ 35
4.2 BIOS Setup Menu............................................................................ 37
4.2.1 Main Menu.................................................................................... 37
4.2.2 Advanced Menu ........................................................................... 39
4.2.3 Security Menu............................................................................... 41
4.2.4 Boot Menu .................................................................................... 42
4.2.5 Exit Menu...................................................................................... 44

Notebook Manual 5
English
Preface
Chapter 1

6 Notebook Manual English
1.1 Regulations Information
¤ CE compliance
This device is classed as a technical information equipment (ITE) in
class B and is intended for use in living room and o󰀩ce. The CE-mark
approves the conformity by the EU-guidelines:
- EMC Directive 2014/30/EU,
- Low Voltage Directive 2014/35/EU(equals A2 : 2013) ,
- RF Directive 2014/53/EU
The unit can be operated at an ambient temperature of max. 35°C
(95°F). Do not subject it to temperatures below 5°C (41°F) or
above 40°C (104 °F).
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
PREVENTION OF HEARING LOSS
CAUTION: Listening to music at high volume levels and for
extended durations can damage one’s hearing. In
order to reduce the risk of damage to hearing, one
should lower the volume to a safe, comfortable level,
and reduce the amount of time listening at high
levels. Headsets should comply with EN 50332-2
requirements.

Notebook Manual 7
English
FCC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guar-
antee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o󰀨 and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit di󰀨erent from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.

8 Notebook Manual English
CAUTION: Any changes or modications not expressly approved
by the grantee of this device could void the user's
authority to operate the equipment.
FCC Information
This device meets the government’s requirements for exposure to radio
waves. This device is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal Commu-
nications Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for
SAR are conducted using standard operating positions accepted by the FCC
with the EUT transmitting at the specied power level in di󰀨erent channels.
The FCC has granted an Equipment Authorization for this device with all re-
ported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this device is on le with the FCC and can
be found under the Display Grant section of www.fcc.gov/eot/ea/fccid after
searching on FCC ID: 2AKHF9560NG
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.

Notebook Manual 9
English
1.2 Safety Instructions
Do not apply heavy pressure to the computer or subject it to any form of
strong impact as this can damage the computer's components or otherwise
cause it to malfunction.
To keep your computer in prime operating condition, protect your work area
from direct sunlight.
Never cover or block the air vents including those located at the base of the
computer. Never cover your computer or AC adapter with any object.
Do NOT expose to or use near liquid, rain, or moisture.
Do NOT use the modem during electrical storms.
Do not use or expose this device around magnetic elds as magnetic
interference may a󰀨ect the performance of the device.
1
2
3
4
5
1
52
3
4
100kg

10 Notebook Manual English
1.3 Conventions for this Manual
CAUTION : This message contains important information that must
be followed for safe operation.
NOTE : This message contains information for special situations.

Notebook Manual 11
English
1.4 Release History
1.0 03/2019
Version Date Revision
Initial release

12 Notebook Manual English
Getting to know the basics
Chapter 2

Notebook Manual 13
English
2.1 Product Specication
This User’s Manual provides technical information of instructions
and illustrations on how to operate this notebook for the customer.
Please read this manual carefully before using this notebook.
・CPU
Support Processor
NVIDIA GTX1050 ( For 4X)
NVIDIA GTX1650 ( For 5X)
NVIDIA GTX1660Ti ( For 6X)
・Memory
DDR
DDR4 2666 MHz
・Physical Characteristic
Dimension
359.8*243.3*19.8mm
1.89kg +/- 5%
・GPU
Support Processor
CFL-H Refresh

14 Notebook Manual English
・I/O Port
DC-in
USB
RJ45
Card Reader
HDMI
x 1
x 1
x 1 (2 in 1 Card reader-support SD/SDHC/SDXC card)
x 1
USB 3.1 X 2 (Gen1)
USB 2.0 X 1
USB type C 3.1 X 1 (Gen1 )
・Audio
Audio Codec
Speaker/MIC
*Build-in 2 speakers
*Speaker : 2W/each
*Digitial Microphone support
Azalia standard support , D3 mode support
x 2
Audio out & Mic in
x 2
Mini DP

Notebook Manual 15
English
・Input
Keyboard
RGB backlight support
Pointing Device
Touch pad 104*72
LCD
・Display
LAN
*Supports 10/100/1000 Mb/Sec
*PCI-E interface
*DSM (Deep sleep mode) support
Wireless LAN
*M.2 2230 w/ CNVI interface (Intel 9)
*IEEE802.11b/g/n support; AC mode support
・Communication Port
HD webcam
HD webcam with D-MIC*1
・Webcam
15.6" FHD, 16:9 (Narrow border )

16 Notebook Manual English
・Power
AC Adapter
Automatics Voltage adjustment between 100 and 240VAC 50/60Hz,
120 Watts (19V/6.32A), 3 Pins
180 Watts (19.5V/9.23A), 3 Pins for GK5CP6X
Li- polymer Battery, SW Gas Gauge IC, soft pack,
3 cells (3S1P 4100mAh) 46.74 Wh
4 cells (4S1P 4100mAh) 62.32 Wh
Battery
CAUTION: MODEL IS DESIGNED TO USE WITH THE
DC INPUT: 19V/6.32A or 19.5V/9.23A (for GK5CP6X)
・Storage
HDD
*2.5" SATA HDD support
*7mm height
SSD
*2 Slots (NVMe)
*M.2 2280,
Slot 1 : NVMe/PCIEX4
Slot 2: NVMe/PCIEX4/SATAX1
*RAID 0/1 support

Notebook Manual 17
English
2.2 Preparing your Computer
Connect the AC adapter’s DC output plug to the DC IN jack.
A
BThe display panel can be opened to a wide range of angles for
optimal viewing.
CPress the power button to turn on your notebook computer.

18 Notebook Manual English
Top-Open View
2.3 Product Overview
Please become familiar with each component before you operate
the computer.
NOTE: The product’s color/ LED color, I/O port, indicator location, and speci-
cation will depend upon the actually shipping product.
CAUTION:When you are not using the computer, keep the LCD-
screen closed to protect it from dust.
1
2
5
6
3
7
4
8
9
10

Notebook Manual 19
English
1
3
2
4
5
Webcam
A device that allows you to record video or take photographs with your
computer.
Camera Status LED
The Camera Status LED shows the Camera status.
Microphone
Built-in microphone.
Power Button
Press this button to turn the computer's power on or o󰀨.
Caps Lock Status LED
Default: Green
Charging & Battery indicator
Charging(Power ON): Orange
Charging(Power O󰀨): Orange
Battery Low (<6%): Orange (3 Sec/Cycle)
Charging nish (w/AC ): Green, (w/o AC): O󰀨
Power indicator
Power ON: Green
Suspend: Green , Slow / Smooth, Blinking Green (3 Sec/Cycle)
Power O󰀨: OFF
6O󰀩ce/Game Mode Switch
On screen display

20 Notebook Manual English
7
9
8
Touchpad/Click pad
Touch-sensitive pointing device which functions like the mouse.
Keyboard
Full 15.6" KB with RGB backlight support.
(The keyboard will depend upon the actually shipping product)
Touchpad LED indicator/ Touchpad switch
LCD screen
Displays of your notebook computer.
The built-in ngerprint scanner allows use of security software using
your ngerprint as your identication key.
Finger printer (Optional)
10
