Acer Aspire Notebook Series User manual

Aspire Notebook Series
Quick Guide
Product registration
When using your product for the first time, it is recommended that you immediately
register it. This will give you access to some useful benefits, such as:
•Faster service from our trained representatives.
•Membership in the Acer community: receive promotions and participate in customer
surveys.
•The latest news from Acer.
Hurry and register, as other advantages await you!
How to register
To register your Acer product, please visit www.acer.com. Select your country, click
PRODUCT REGISTRATION and follow the simple instructions.
You will also be asked to register your product during the setup process, or you can
double-click the Registration icon on the desktop.
After we receive your product registration, you will be sent a confirmation email with
important data that you should keep in a safe place.
Obtaining Acer accessories
We are happy to inform you that Acer's warranty extension program and Notebook
accessories are available online. Come and visit our online shop and find what you need
at store.acer.com.
The Acer store is being progressively rolled out, and, unfortunately may not be available
in some regions. Please check back regularly to see when it will be available in your
country.

Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
© 2011. All Rights Reserved.
Aspire Notebook Series Quick Guide
Original Issue: 06/2011
Acer recommends...
Productivity Software
Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects
with Office 2010.
Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,
YouTube or Windows Live.
Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more
informed decisions.

3
English
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your
computer.
The Aspire User’s Manual contains useful information applying to your
new computer. It covers basic topics such as using the keyboard and
audio, etc.
The Quick Guide introduces you to the basic features and functions of
your new computer. For more on how your computer can help you to be
more productive, please refer to the Aspire User’s Manual. This guide
contains detailed information on such subjects as system utilities, data
recovery, expansion options and troubleshooting. In addition it contains
warranty information and the general regulations and safety notices for
your notebook. It is available from your computer desktop; simply double-
click the Acer User’s Manual icon.

4
English
Your Acer notebook tour
After setting up your computer as illustrated in the setup poster, let us
show you around your new Acer notebook.
Top view
#Icon Item Description
1 Microphone Internal microphone for sound recording.
1
3
2
4
5
6
7
8
9

5
English
2 Display screen
Also called Liquid-Crystal Display (LCD),
displays computer output (configuration
may vary by model).
3Power button /
indicator
Turns the computer on and off. Indicates
the computer's power status.
4 Keyboard For entering data into your computer.
5Touchpad
Touch-sensitive pointing device which
functions like a computer mouse.
6Click buttons (left
and right)
The left and right buttons function like the
left and right mouse buttons.
7
NumLk indicator Lights up when Num Lock is activated.
Caps Lock
indicator Lights up when Caps Lock is activated.
8
PAcer PowerSmart
button
Puts your computer into power-saving
mode (configuration may vary by model).
P key Programmable key (configuration may
vary by model).
9Integrated
webcam Web camera for video communication.
#Icon Item Description

6
English
Hotkeys
The computer employs hotkeys or key combinations to access most of
the computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the
other key in the hotkey combination.
Hotkey Icon Function Description
<Fn> +
<F3>Communication Enables/disables the computer’s communication devices.
<Fn> +
<F4>Sleep Puts the computer in Sleep mode.
<Fn> +
<F5>Display toggle
Switches display output between
the display screen, external
monitor (if connected) and both.
<Fn> +
<F6>Screen blank
Turns the display screen backlight
off to save power. Press any key to
return.
<Fn> +
<F7>
Touchpad
toggle
Turns the internal touchpad on and
off.
<Fn> +
<F8>Speaker toggle Turns the speakers on and off.
<Fn> +
<> Brightness up Increases the screen brightness.
<Fn> +
<>
Brightness
down Decreases the screen brightness.
<Fn> +
<> Volume up Increases the sound volume.
<Fn> +
<> Volume down Decreases the sound volume.
<Fn> +
<Home>Play/Pause Play or pause a selected media file.
<Fn> +
<Pg Up>Stop Stop playing the selected media file.
<Fn> +
<Pg Dn>Previous Return to the previous media file.
<Fn> +
<End>Next Jump to the next media file.

7
English
Closed front view
#Icon Item Description
1
Battery indicator
button
Press to indicate the computer's
battery status.
Note: Also
functions when the
computer is turned
off.
When plugged in:
Blue: Fully charged
Amber: Charging
When on battery power:
Blue: >30% battery charge remaining
Amber: Remaining charge is between
10% and 30%
Red: <10% charge remaining
2
Power indicator Indicates the computer's power status.
HDD indicator Indicates when the hard disk drive is
active.
Communication
indicator
Indicates the computer’s wireless
connectivity device status.
3Multi-in-1 card
reader
Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
PRO (MS PRO), xD-Picture Card (xD).
Note: Push to remove/install the card.
Only one card can operate at any time.
12 3

8
English
Rear view
Left view
#Icon Item Description
1SIMcardslot
Accepts a 3G SIM card (configuration
may vary by model).
#Icon Item Description
1
Kensington lock slot
Connects to a Kensington-compatible
computer security lock.
Note: Wrap the computer security
lock cable around an immovable
object such as a table or handle of a
locked drawer. Insert the lock into
the notch and turn the key to secure
the lock. Some keyless models are
also available.
2 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-
based network.
3External display
(VGA) port
Connects to a display device (e.g.,
external monitor, LCD projector).
4HDMIport Supports high-definition digital video
connections.
1
23145

9
English
Information on USB 3.0
•Supports power-off USB charging, allowing you to charge supported
mobile devices while the notebook is switched off.
•Defined by the USB 3.0 (SuperSpeed USB) specification.
•Devices without USB 3.0 certification may not be compatible.
Right view
5USB 3.0 port
Connects to USB devices.
A USB 3.0 port can be distinguished by its
blue connector.
#Icon Item Description
1
Microphone jack Accepts inputs from external
microphones.
Headphones/
speaker jack
Connects to audio devices
(e.g., speakers, headphones).
2 USB 2.0 ports Connect to USB 2.0 devices (e.g.,
USB mouse, USB camera).
3 Optical drive Internal optical drive; accepts CDs or
DVDs.
4Optical disk access
indicator
Lights up when the optical drive is
active.
5Optical drive eject
button Ejects the optical disk from the drive.
#Icon Item Description
2134567

10
English
Base view
6Emergency eject
hole
Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the
emergency eject hole to eject the
optical drive tray when the computer
is off.
7 DC-in jack Connects to an AC adapter.
#Icon Item Description
1 Battery reset pinhole
Insert a paperclip into the hole to reset
the computer (simulates removing and
reinstalling the battery).
2 Speakers Deliver stereo audio output.
#Icon Item Description
1
22

11
English
Environment
•Temperature:
•Operating: 5 °C to 35 °C
•Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
•Operating: 20% to 80%
•Non-operating: 20% to 80%
