INSTRUCTION MANUAL
TM-U3
Universal D BIT Grinder (240V)
1/4HP
G1975
GRINDING SPINDLE
The spindle bearing has been factory-adjusted to exclude play while allowing for free-running of
the spindle. In the event some play develops in the course of time, such play should be taken
up by tightening the two nuts M. for this purpose, pull spindle from its seat after having loosened
screw S and removed the parts as indicated When tightening the nuts allow for a freerunning
spindle. Excessive tightening will result in bearing failure. After reinserting the spindle assembly
carefully tighten screw S in the bore, to hold the spindle assembly in position:
Wheel Replacement
To remove Grinding wheel you need to lock the spindle.
Firstly remove cup head cap screw (spindle lock screw)
Then line up hole in the spindle with the bolt hole,
may need to move spindle forward or back to correctly align
Use a pin to lock the spindle and the special tool to undo the wheel nut
Fit new wheel, tighten nut, remove pin and replace screw
Nomenclature of Controls
The details below are used in most of the procedures listed in this manual, unless otherwise stat-
ed.
D Wheel dressing attachment
A Spring collet clamping quill
T1 Cross slide clamping lever
S2 Vertical swivel mount setting scale
T2 Vertical swivel mount clamping lever
T3 Horizontal swivel mount clamping lever
T4 Tubular guide clamping lever
F Horizontal swivel mount index drum
T7 Clamping lever for adjustment along tubular guide
H Indexheadbracketneadjustmentscrew
G Adjustable stop screw
T5 Index head slide clamping lever
C Cutter lip aligning gauge
C1
P
S
Cross slide vernier scale for off-center radii
Spring collet index pin
Index head slide
S5 Indexheadslideneadjustmentsetscrew
S1 Indexheadslideneadjustmentscrew
Q Cross slide
T6 Index durm F clamping lever
B1 Collet sleeve
U2 Screw
A1 Stop plate for 90 degree
U3 Screw for Al
N4 Index drum
N5 Ring nut
E Index ring bearing sleeve
M3 Nut for index sleeve
R7 Slotted disc
A3 Adjusting eccentric pin
M4 Nut
INDEX HEAD
Servicing The Index Head Bracket
General
After a major period of use it will be necessary to dismantel the index head bracket and to clean
and lubricate the collet sleeve bearing, the index head slide, and the swivel arm.
Collet Sleeve Bearing
To remove the collet sleeve proceed as follows: Remove ring nut N5, index drum N4, and index
ring, in that order. Remove two M3 nuts out of the index bearing sleeve E. There is a annular
grease chamber in the longitudinal slide which will now be made accessible. This should then be
cleanedwithpetrolandrelledwithgrease.
Slide
Release clamping screw T5 and remove the longtitudinal adjusting screw. Remove the index head
slide S. Clean all working surfaces, smear lightly with oil, cross slide 0 can not be removed. Re-
lease clamping screw T1 and turn screw S4 to move the cross slide to its extreme positions. Clean
the bearing surfaces, smear lightly with oil.
Swivel Arm
To remove the swivel arm and the index head as a unit remove the two nuts M4. Clean the bear-
ing surfaces and smear them with oil.
Adjusting the Clamping Mehanism of Index Drum F.
After constant use the the clamping lever T6 may no longer function correctly to lock the the swivel
index drum F. To correct this screw U2 will need to be asdjusted. To do this remove the swivel arm
as described above. Remove screw U3 and stop plate A1. Back off nut M2 and screw U1 and
pull out the clamping lever T6. Lift off the index drum F to access the adjusting nut and screw U2.
Rotate the screw 180° relative to the nut to reduce the length. Then reassemble.
Adjusting the stop pin for the 90° Swivel Motion
Constant striking of the stop plate Al against stop pin A2 and A3, could cause the angle to no
longer be exactly 90°. Correct the adjustment by turning the two eccentric stop pin A2 and A3 until
the angle is correct. Turning the stop pin A2 will change the cylindrical setting of the collet sleeve
bearing, while turning stop pin A3 will adjust the 90° swivel motion.
NOTE ! Diamond wheels should not be dressed.
If using abrasive wheels, wheel trueing and dressing should be performed at regular intervals.
For abrasive wheels, dressing is done by means of a diamond set into a tip of a rod. The diamond
dresser is attached to a arm. The in feed is done by the main spindle feed knob. The diamond tool
assembly is supported by the wheel guard. (see Fig. l and 2) Wheel turing and dressing Is particu-
larity necessary when the wheel has become hardened or when sharp corner has been worn off.
Wheelsinthisconditionresultinpoorsurfacenishandoverheatingofthecuttingtools.
Dressing:
1. Loosen clamping grub screw that holds the diamond dresser. Move the diamond dresser
away from the wheel so it clears the wheel. Swing the dressing attachemnt in front of the wheel
2. Set diamond, dresser 1 mm away from the wheel. Lock the clamping grub screw
3. Turn Feed screw until the dressing diamond contacts the wheel. The maximum cut should
be around 0.2mm.
DRESSING THE GRINDING WHEEL
Cutter Proles-Tool Angle-Cutting Speeds
Cutter Proles
Asrule,single-lipmillingcuttersaregivenoneofthesevenbasicprolesIllustratedbelow,
1. cylindrical, w/end relief 2. cylindrical, w/off-center radius
3. cylindrical, rounded off 4. pointed
5. tapered, w/end relief 6, tapered, w/off-center radius
7. tapered, w/rounded point
Aboveareillustratedthesevenbasiccutterprolesandcrossseciionalviewsoftheprolesthey
will produce,
Cutter with end relief. Cutter with pointed end. Rounded-off cutter
Tool Angles
As is the case with all metal cutting tools, single-lip milling cutters require the proper amout of cut-
tingedgerelieforbackrakeangleformaximumstockremovalandhighsurfacenish.Asregards
single-lip cutters, three different tools angles will have to be taken care of these angles being used
in all kinds of cutters.
Angle B applies to end relieved cutters only. Cutters having an angle of less than 20° should be
relief ground at between 25° and 30°
Fig 1.
Cutter Speeds
As regards singie-lip milling cutters, it is recomended to use cutting speeds three times higher
than those used with standard type milling cutters. The data tabulated below should be used only
as a guide, as such factors as, drive conditions and available spindle speeds will also have to be
taken into consideraton. In end cutting edges the cutting speed will decrease towards the cutter
center line. This effect is particularly noticeable in rounded-off cutters, As a consequence, care
should be taken that stock is preferably removed by the outer portion of the cutting edge.
When cutting soft aluminium, use kerosene as a coolant. When cutting celluloid, the cutter must
alwaysbeinfeedmotion,inordertoavoidthematerialcatchingre.
Tool angles and recommended cutting speeds for single-lip cutters
Material to be cut a B TRecomended cutting Speeds for single lip
cutters of High Speed Steel
m/min
Grey cast iron 25° 15° 5° 60
Cast steel
Malleable cast iron
Machinery steel,
57,000 to 85,000 psi (40 to 60 kg/mm) 70
85000 to 115,000 psi 60
(60 to 80 kg/mm)
over 115,000 psi 40
(80 kg/mm)
Tool steel soft grade . 60
hard grade 50
Brass, 58/41 soft grade 200
hard grade 250
Brass, 63/37 soft grade 30° 15° 5° 120
hard grade 150
Bronze soft grade 260
hard grade 200
Aluminium soft grade 35° 200
hard grade 250
Wood 25° 15° 5°
35° 250
Plastic : Trolon 200
Pert inaz, Fiber 45° 25° 20° 200
Circular . Grinding of -Cutters
Grinding the Back Angle of End Cutting Edges(Round)
Cutterproleshavingeitheron-centeror-off-centerradiiarederivedfromcylindricalsinglelipcut-
ters having a straight end cutting edge by rounding off the corner as shown in Fg.1(No. 2 and 3
proles).
In rounded cutters of this type the back rake angle of the side cutting edge is the same as that of
the end cutting edge.
Forthisreasonitisnecessary,:duringgrindingtheendrakeangle,thattheworkxtureissetat
the side rake angle by means of setting scale S2. If the end cutting edge is ground immediately af-
tergrindingthesidesuttingedge,itwillnotbenecessarytore-settheworkxtureandtore-align
the cutting lip by means of gauge C.
Setup Operations
1, Engage index pin P into short slot and bring the white dot into window O.
2. a, No. 2 prole : Release clamping lever T1; rotate knurled knob S4 to set cross slide
by means of vernier scale C1 for desires radius (to the right) tingten clamping lever T1, (see
Fig. 2) as the radiused corner is required to be tangent to the cutter diameter, the amount of
off-set
“a” is : a=D - r.
2
Example: Given r = 0.06” (1.51mm); D= 0.30” (8mm)
a = 0.15” (4mm) - 0.06” (1.5mm) = 0.09” (2.5mm)
b. No. 3 prole : The vernier scale C1 of the cross slide must be set zero (see Fig. 3).
3. RotateneadjustmentscrewHtobringthesidecuttingedgeofthecutterintolight
contact with the face of the grinding wheel. Caution: do not injure the land of the side
cutting edge. Now screw H must no longer be rotated.
Grinding the Back Rake Angle
4. Swivel the index head through 90° (see Fig. 4). ‘Depth of cut adjustment now is by index
head slide Si. Rne adjustment is by mfcromenter screw S6 of the index head slide with
adjustment screw S5 thghtened. The end of the cutter is rounded by slowly swivelling the
index head back to its original position while the collet bearing is continously rotated back
and forth between the stops, the rotation being through 180° (see Fig. 5 and 6). Prior to
grinding, be sure to with draw the index head a slight amount by rotating screw S in order
to prevent overheating of the cutter by excessive stock removal.
After each pass of the grinding wheel the cutter is then fead toward the wheel by means of
screw S.
InordertoobtainasatisfactorycuttingedgeitIsadvisable,asanaloperationtoswivelthe
index head through 90° with the cutter lip pointing vertically upward.
IncasewherecuttersgivenaNo.3proleareintendedthemachiringofhardsteelwhich
requiresasmallofbackrakeangle,itisgoodpracticetoattenthecurvatureofthecutter
by a manual grinding operation as shown in Fig. 7.
Centering the Cutter Lip by Grinding
Cylindrical single-lip milling cutters are supplied by the manufacturer with the lip preformed
byroughmilling(seeFig.1).Asaresult,thecutterlipwillrsthavetobeaccuratelycentered
by grinding. Rough grinding of the lip is performed manually by holding the cutter gainst the
circumferenceofthegrindingwheel(seeMg.2).Thisoprationisfollowedbynishgrindingin
the machine. The off-center tolerance Is ± .0004” (0.01mm), which should be checked with a
micrometer caliper (see Fig, 3 on the last page). To grind the cutter lip correctly, proceed as
follows:
Setup Operations
1. Set swivel arm and index drum F at zero, tighten clamping lever T3: set vertical setting
scale S2 at zero, tighten clamping lever T2 (see Fig. 4).
2. Have index pin P engage the short-slot (see Fig 5).
3. Set cutter with aligning gauge C clamp cutter in position, return aligning gauge C (see
Fig. 6).
4. Withdraw index pin P, rotate spring collet bearing 180° , allow index pin P to engage
the short-slot.
5. Shift index head bracket along tubular guide to bring cutter lip into light contact with
end face of grinding whee. Be sure, prior to tightening clamping lever T7, to align
vertical swivel mount index mark with tubular guide.
Tighten clamping lever T7, releaseclamping lever T4.
Centerinq the Cutter Lip
6. Fine adjustment screw H serves to set the index head accurately relative to the wheel
and to provide;the desired depth of cut. The travel of the cutter past the wheel can be limited
by means of adjustable stop screw G.- Thus it`is possible, during grinding to advance the cut-
ter as far as it will go. To bring the cutter lip within the prescribed off-center tolerance, recipro-
catetheindexheadbracketwhileadvancingthecutterbyrotationneadjustmentscrewH.
In order to prevent the cutter from being overheated, it is recomended to ieave only a narrow
cutting zone on the grinding wheel (see page 5 “Dressing the Grinding Wheel’). The length of
the, cutter lip should equal one and one half times the diameter of the cutter.
It is not advisable to increase the length of the cutter lip beyond a cetain limitl In the case of
deep engraving work where stepped cutter are used the shank of the cutter will be increased
instead of the lip,
Circular Grinding of Cutters
Grinding the Back Angle of Side Cutting Edges
After centering the lip it will be necessary to grind the back rake angles to the sides of the cutting
edge and the end cutting edge. The back rake angles of both cutting edges should be selected to
suit the material to be cut.
Setup Operations
1. Rotate swivel arm to set index F at zero; tighten clamping lever T3.
2. Engage index pin P Into the long slot.
3. Align cutter by means of gauge C; grip cutter in po§itibn return gauge’C (see Fig.4).
4. Release clamping lever T2; set swivel arm at desired back rake angle using setting scale
S2; tighten clamping lever T2 (see Fig, 3).
5. TightenclampingleverT4;releaseclampingleverT7;shiftworkxtureontubularguide
to bring cutter into light contact with grinding wheel, tighten clamping lever T7; release
clamping lever T4.
Circular Grinding
6, Draw index pin P out of the slot; grind desired diameter by rotating spring collet bearing
through 360° . During this operation slowly rotate adjustable stop screw G, while
continuouslyrotatingthespringcolletbearing,toadvancetheworkxturepastthe
grinding wheel; this will produce uniform stock removal. Fine adjustment during circu
lar grinding is by screw H. Stop screw G is used to establish the length’of the cylindrical
portion which should always be slightly longer than the cutting lip.
7. Engage Index pin P into short slot to enable the collet bearing to be rotated 160°
between the index plate stops.
Grinding the Back Rake Angle
8. Whengrindingthebackrakeangle,usetheneadjustmentscrewHovertheentirerange
of rotation of the collet bearing (see Fig. 3a). Grinding of the back rack angle is posative
controlled. The angle is required over the entire length of the cutting lip.
Theverticalswivelbearing,whichpermitstheworkholdingxturetobeswungback,
enables relief angles up to 40° to be produced, Relief angles over 40° can be obtained by
additionally rotating the collet bearing In the index head. (Only for cylindrical or tapered
cutter with straight end cutting edges or for pointed cutters.)
Upon completion of grinding operations a very narrow land must remain at the cutting edge
(see Fig. 4).
Circular Grinding of . Cutters
Grinding the Back Angle of End Cutting Edges(Straight)
The end cutting edge illustrated in Fig.1 may be ground In an operation immediately following the
grinding of the side cutting edge; or it may be ground independently. In the latter case the cutter
will have to be aligned by means of gauge C and clamped in position. Whenever a single-lip cut-
ter is to be ground, the aligning gauge will have to be used, as one leg of the cutting angle should
be selected to suit the material to be cut.
Setup Operations
1. Engage Index pin P into the long slot,
2. Release clamping levers T2, and using setting scale S2, set swivel arm at approx. 3°
Tighten clamping lever T2. Release clamping levers T3 and T6 and hold the Index drum F
against stop and, beginning at 90° position.
3. Set the swivel arm at the desired angle; for example set the arm at 75° for back angle of
15° (see Fig. 2 and Fig. 3). Tighten clamping lever T3 and T6.
4. TightenclampingleverT4andreleaseleverT7.Shifttheworkxtureonthetubularguide
to bring cutter into light contact with grinding wheel. Tighten clamping lever T7; and release
lever T4.
Grinding the Back Rake Angle
5. Fine adjustment screw H serves to set the index head laterally relative to the wheel and to
set the work for the desired depth of cut.
It is also possible to produce the desired back rake by holding the cutter against the cir-
cumference of the grinding wheel as is shown In Fig.4,_
Circular Grinding of -Cutters
Grinding the Back Angle of End Cutting Edges
Cutterproleshavingeitheron-centeror-off-centerradiiarederivedfromcylindricalsinglelipcutters
havingastraightendcuttingedgebyroundingoffthecornerasshowninFig.1(No.2and3proles).
In rounded cutters of this type the back rake angle of the side cutting edge Is the same as that of the
end cutting edge.
Forthisreasonitisnecessary,:duringgrindingtheendrakeangle,thattheworkxtureissetattheside
rake angle by means of setting scale S2. If the end cutting edge is ground immediately after grinding
thesidesuttingedge,itwillnotbenecessarytore-settheworkxtureandtore-alignthecuttinglipby
means of gauge C.
Setup Operations
1. Engage index pin P into short-slot; and bring the white dot Into window O.
2. a. No. 2 Prole : Release clamping lever Ti and rotate knurled knob S4 to set cross slide by
means of vernier scale C1 for desires radius (to the right). Tingten the clamping lever Ti,(see
Fig. 2) as the radiused corner is required to be tangent to the cutter diameter, the amount
of off-set
“a” is a = D - r.
2
Example : Given r =0.06” (1.5mm); D=0.30” (8mm)
a =0.15”(4mm) - 0.06” (1.5mm) = 0.09” (2.5mm)
b. No. 3 Prole : The vernier scale Cl of the cross slide must be set zero (see Fig. 3).
3, RotateneadjustmentscrewHtobringthesidecuttingedgeofthecutterintolightcontactwith
the face of the grinding whe.el. Caution ! Do not injure the land of the side cutting edge. Now
screw H must no longer be rotated.
Grinding the Back Rake Angle
4. Swivel the index head through 90° (see Fg, 4). Depth of cut adjustment now is by index head
slide S1. The adjustment is by micromenter screw S6 of the index head slide with adjusment
screw S5 thghtened. The end of the cuuter is rounded by slowly swivelling the index head back
to its original position while the collet bearing is continously rotated back and forth between the
stops, the ratation being through 180° (see Fig. 5 and 6).
Prior to grinding, be sure to with draw the index head a slight amount by rotating screw S in
order to prevent overheating of the cutter by excessive stock removal. After each pass of the
grinding wheel the cutter is then feed toward the wheel by means of screw S.
Inordertoobtainasatisfactorycuttingedgeitisadvisable,asanaloperation,toswivelthe
Index head through 90° with the cutter lip pointing vertically upward.
IncaseswherecuttersgivenaNo.3proleareintendedforthemachiringofhardsteelwhich
requiresasmallbackrakeangie,itisgoodpracticetoattenthecurvatureofthecutterbya
manual grinding operation as shown in Fig. 7.
Grinding Pointed Cutters
Where pointed cutters are concerned, both the included angle of the point and the back rake angle are
produced In one operation (see Fig. 1). The back rake angle should be selected to suit the material to be
cut. (see page 5)
Setup Operations
1. Engage index pin P Into long slot;
2 Align cutter lip by means of gauge ‘C. Grip the cutter in position and return gauge C
3. Engage index pin P into short slot to enable collet bearing to be rotated 180° between stops.
4. Release clamping levers T3 and T6 and hold index drum F against stop and, beginting at zero
position, set the swivel arm at one half of the desired point angle (see Fig. 2).
Example : Given a point angle of 60° Set swivel arm by index drum F at 30° . Retighten clamping
levers T3 and T 6.
5. ReleaseclampingleverT2.Settheworkxtureforthedesiredbackrakeanglebymeansof
setting scale S2, see Fig. 3. Tighten clamping lever T2.
6. TightentheclampingleverT4.ReleaseleverT7;andshifttheworkxtureonthetubularguideto
bring the cutter into light contact with grinding wheel. Tighten clamping lever T7; release lever T4.
Grinding the Back Rake Angle
7. DuringgrindingslowlyreturnstopscrewGtoadvancetheworkxturepastthewheel.
At the same time contiuously rotate the collet bearing back and forth between the stops, the
rotation being through 180 °. This ensures uniform stock removal (see Fig. 4a,b,c),
Uniform stock removal will protect the cutter from overheating. Whet the cutter point by means
of an oil stone. It Is advisable to whet the point as far as engraving conditions permit. This
operation will give the point a small end cutting edge which will participate in removing stock
(see Pg. 5).
However; where arline engraving work Is concerned (depth of cut not to exceed 0.0004” (.01imm)
the shape of the point should not be changed. Only the cutting edge proper should be carefully
whetted.
In addition it is recommended to whet also the cutting lip by means of an oil stone in order to
remove burrs. However, care should be exercised not to remove notoiceable amounts of
stock from the cutting lip, as this would destroy the centering of the lip, morevoer this would
render a greater or lesser part of it useless.
Whengrindingthecuttinglipforthersttime,careshouldbetakentogrindwithapositive
tolerance.
Table of contents
