Topten MT113 User manual
GPS Motorcycle/VehicleTracker
USERMANUAL
(Model: MT113)
TOPTENELECTRONICSTECHNOLOGYLIMITED
Address: Room2007,TowerB, GaokeBuilding,Tianhe NorthRoad, Guangzhou, China.
Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400
Website:http://www.t10.cn Email: sales@t10.cn
Version 1.0
(Date: Mar., 2011)
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 1
CONTENT
Preface...............................................................................................................2
I. Features&Functions......................................................................................3
II. HowtoOperateit...........................................................................................4
Arm/DisarmbyPhone Calling......................................................................4
Arm/Disarmthe SystembySMS..................................................................4
Check the location byGoogleMapsURL....................................................5
Authorizethe Alarm-received Mobile...........................................................5
Change UserPassword...............................................................................5
Check the RealPhysicalAddress................................................................6
Check the GPS CoordinatesbySMS..........................................................6
Stop the CarbySMS...................................................................................6
RestoretheStopped CartoNormalStatus..................................................6
Adjust the Sensitivityof Motion Sensor........................................................7
Switchthe Working Mode of BlueLine........................................................7
OtherSMSCommand List...........................................................................8
III. AlarmTypes................................................................................................12
IV. Installation...................................................................................................13
V. Specifications..............................................................................................15
VI. FAQs&Troubleshooting.............................................................................15
VII. Maintenance..............................................................................................16
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 2
Preface
MT113GPS Motorcycle/vehicletrackeristhecost-effectivesolutionfor
security&real-timetracking. It isspeciallyused formotorcycletrackingbecause
ofitscompact sizeandwater-proofdesign.
ReaditFirstly:
Pleasereadthismanualthoroughlybeforeyou usethedevice;pleasekeep
itforfuturereference.
Attention:
(1)Pleasekeepthedeviceawayfromheavywater, hightemperature,heavy
dustorstrong magnetism.
(2)PleaseprepareavalidGSMSIMcardinadvance.
(3)Forsafetyreason,do nottellotherpeoplethemobilephonenumberof
yourMT113.
Warning:
Westronglysuggestuserlettheprofessionalcarelectriciantoinstallthe
system.
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 3
I.Features&Functions
1.TrackoncommandorbytimeintervalviaSMS/GPRS.
2.Arm/disarmbySMSorphonecall.
3.Checkthecar srealphysicaladdress(suchascityname,street
name..(need support oftheTS01 orTS03center);
4.TrackbymobileSMStogetthelatitude,longitude,speed,direction&
odometeretc.
5.Checkthelocation directlybytheGooglemapsURL;
6.Onlinewebsitetracking byGPRSdatanetwork;
7.Odometer function
8.Movementalert;
9.Geo-fencealert;
10.Over-speedalert;
11.SOSbuttontocallforhelpincaseofemergency;
12.Inbuiltmotionsensor has2kindsofusages(1)itarming status,ifthe
vehicle/motorcycleisvibrated,itwill triggeralarm(2)Thesystemwill enter
intosleepmode forpowersaving if thereisnovibrationforacertaintime.
13.Inbuilt 512KbmemorytostoretheofflineGPS data;
14.Built-inrechargeablebackupbattery;whenthecarbatteryiscutofforlow
enough,thebuilt-in800mAHbackup batterycanworkforemergency,and
thesystemwillsendoutpowerfailurealertimmediately.
15.CutoffenginetostopthecarsafelybySMS/GPRS;(optional)
16.I/O: 2input and1output
17.Compact sizewithwater-proof design
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 4
II. HowtoOperate it
Thedefaultuserpasswordis 000000.
Iftheuserpasswordischanged,usershouldsendtheSMScommandwith
thenewuserpasswordinsteadof000000.
XXXisthecontrolcode,allthelettersmustbe capitallettersorinsmall
letters,commandwithmixed capitalletter&small letterisnotrecognized by
system
Arm/Disarm byPhoneCalling
Usercouldalsousethe alarm-received mobilephonetocallthetracker s
SIMcardnumber, soastoarm/disarmthesystem.
Arm:Afterhearingseveralring tones,ifthesystemshang upthecall
automatically, andcallbackyou,itmeansthat thesystemisarmed.
Disarm:Afterhearing severalringtones,ifthesystemhangsup thecall
automatically, anddontcallbackyou,itmeansthatthesystemisdisarmed.
Note:
(1)Thereisnocommunicationfeeforthisoperation,it isaveryconvenientwaytoarm
&disarm thesystem.
(2)The SIMcardinsidethe devicemusthavethefunction of CallerIDDisplay.
(3)Onlythe alarm-receivedmobilephone can realizethisfunction.
Arm/Disarm the SystembySMS
SMScommand: 000000ARM(or 000000arm)
ThisSMSinstructionisused toarm thesystem
Whenthesystemisarmed,themovementalertisactivated automatically.
Whenthemotorcycle/carmoves, thealarmwillbetriggered.
SMScommand: 000000DSM(or 000000dsm)
Thiscommandisused todisarmthesystem&stopsendingalert SMS.
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 5
Check the location byGoogleMap sURL
SMScommand: 000000MAP(or 000000map)
Upon receiving theSMScommand,thetrackerwillautomaticallysendback
theSMSincludingtheGooglemapsURL,usercanusesmartphone(GPRS
dataserviceisenabled)toopen theURLlink, thecar slocationwillbeshowed
ontheGooglemap.
Authorizethe Alarm-received Mobile
SMScommand: W******,003,F,P,MobileNo.
******istheuserpassword,defaultoneis000000.
(F=0,toturnoffthisfunction;F=1,tosendalertSMS)
(P=1,thefirst phone; P=2,thesecondphone; P=3,thethirdphone)
Incaseofalert,thealarmSMSwill besenttothispresetmobileno.
automatically.
Example:W000000,003,1,1,13922713571 tothe tracker sSIMcardnumber,ifthereis
anyalert, systemwill send alertSMStothefirstmobile13922713571
Change UserPassword
SMScommand: W******,001,######
******isoldpassword, ###### isnewpassword, default oneis000000
Thelengthoftheuser spasswordis6 digits.Usersaresuggested to
changetothenewpasswordinuse.
Example:W000000,001,123456
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 6
Check the Real PhysicalAddress
SMScommand: 000000ADD (or 000000add)
When usersendsthisSMScommandtothetracker,thetrackerwill automaticallysend
back thecar srealphysicaladdress (suchascityname, streetname)toyourmobileby
SMS.Thereisnoneed fortheusertosetupanyserver, but itneedssupportsfromour
TS03server.
Remark: (1)TheGPRSdataserviceof the trackersSIMcardmust beactivated,and
thecorrect GPRSsetting isneeded(refertothe chapterofthesettingofGPRS
connection),usercansetuptheGPRSuploadtimeintervalto0soastosavetheGPRS
flow; (2)The physicaladdress dependsontheGooglemapsaddressinformation.Ifthe
placehasverydetailedinformationonGooglemap, thenthephysicaladdressbySMSis
verydetailed.
Check the GPS Coordinates bySMS
SMScommand: 000000CHK (or 000000chk)
Thisinstructionisused toinquirythevehicle slocation&systemsstatus.
ThesystemwillsendbacktheSMS,includesthesimilarinformation,such
as “SystemisArmed……”
Stop the CarbySMS
SMScommand: 000000STP(or 000000stp)
Thisinstructionisusedtocutoffthepowersupplyorfuelsupply,soasto
stop themotorcycle/carimmediately
Attention: It isverydangeroustostopthecarwhen thevehicleisrunningathigh
speed. Wedo not takeanyresponsibilitytotheconsequencecausedbythisaction.
Restorethe Stopped CartoNormal Status
SMScommand: 000000RES (or 000000res)
Thisinstructionisusedtorestorethecartonormalstatusafterstoppingthe
car.
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 7
Adjust the Sensitivityof Motion Sensor
SMScommand: W******,027,S(S=0~3)
(S=0,disable;S=1:Max.sensitivity; S=2:medium;S=3:less)
******istheuserpassword,defaultoneis000000.
Thisinstructionisused toadjustthesensitiveofinternalmotionsensor.
Theinternalmotionsensorhas2kindsof usages(1)itarmingstatus,ifthe
vehicle/motorcycleisvibrated,itwilltriggeralarm(2)Thesystemwillenterinto
sleep modeforpowersavingifthereisnovibrationforacertaintime.
Switch the Working Mode of Blue Line
SMScommand:
000000LNK0(or 000000lnk0)
Defaultsetting,inthismode,thebluelineisconnectedtoACC ONposition.
Inarming status,istheengineisstarted, itwilltriggerthealarm immediately.
000000LNK1(or 000000lnk1)
If thetrackerisused toupgradetheexisting normalcaralarm,thisSMS
commandneedstobesentfirstly,thebluelineshouldbeconnected tothe
positivepoleoftheexisting caralarmssiren. Oncetheoriginalalarmis
triggered,theMT113 trackerwillbetriggeredalsotosendoutalarmmessage.
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 8
OtherSMSCommand List
Note:****** isuser spasswordandthedefaultpasswordis000000.The
trackerwillonlyaccept commandswiththecorrect password.
Functions SMS Command Example
Track onDemand W******,000 W000000,000
Remarks:Togetthecurrentlocationofthetracker,itcarryoutthe sameoperationas
******CHK
Track byGoogleLink W******,100 W000000,100
Remarks: Remarks: Send thiscommandtothetrackerand thenyou receiveanSMSwithan
httplink,it carryout thesameoperationas******MAP
ChangePassword W******,001,###### W000000,001,123456
Remarks:Tochangeuser spassword.###### isthe newpassword.Passwordshouldbe 6
digits.
AutoReportbySMS W******,002,XXX W000000,002,010
Remarks:Toset timeintervalforcontinuousautomaticreport viaSMS.
XXXisthe intervalinminute. IfXXX=000toturnoff tracking bytime.
Inthisexample,the trackerwillsendlocation databacktoyourmobilephone every10
minutes.
SettheAlarm-received
Phone W******,003,F,P,Phone W000000,003,1,1,13922713571
Remarks:Toauthorizephone numbersforreceiving alarm bySMS.
F=0,toturnoff thisfunction; (default)
F=1, sendsSMStotheauthorizedphonenumber;
P=1,set an1st authorizednumber
P=2,set an2nd authorizednumber
P=3,set an3rd authorizednumber
Phone: Preset phonenumber. Max.16 digits
Over-SpeedAlarm W******,005,XX W000000,005,08
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page 9
Remarks: When the trackerspeedshigherthan the presetvalue,itwill sendanSMStothe
authorizedphonenumber.
XX isthepreset value of speedandin2digits.
=00, toturnoff thisfunction
=[01,20](unit:10Km/h)
Inthisexample, whenthetracker sspeedisover80km/h,anSMSalarm will besent out.
Geo-fenceAlarm W******,017,X
W******,117,X
W000000,017,
11404.0000,E,2232.0010,N,
11505.1234,E,2333.5678,N
Remarks:017isforalarmwhentrackermovesoutthepresetscope;117isforalarmwhen
trackermovesin.
When thetrackermovesinorout,it will send anSMSalarm totheauthorizedphonenumber
forSOS.
Xisthe coordinateswhichinclude:
Lower-leftX,Lower-left Y,Upper-rightX,Upper-right Y
Forexample,11404.0000,E,2232.0010,N,11505.1234,E,2333.5678,N
Note:
1.Lower-leftXshouldbelessthanUpper-right X;
2.All longitudesand latitudesshouldbeinASCIIformatasfollows:-
Longitude:DDDMM.MMMM,E/W.4placesof decimal. ‘0isneeded tobestuffedif novalue
available.
Latitude:DDMM.MMMM,N/S.4placesofdecimal. ‘0isneededtobestuffedifnovalue
available;
3.Onlyonealarm canbeset ineitherMovementAlarm orGeo-fenceAlarm;
4.SendW******,006,00 toturnoff Geo-fencefunction.
Stop theCarinSafeMode
W******,120,F
W******,220,F W000000,120,1
W000000,220,1
Remarks:Thisfunctionisachievableonlywhenthespeedisbelow10km/h(command120)
or20km/h(command 220)andatthe meantimeGPS isavailable.
F=0,toclosetheoutput (Normal)=1,toopentheoutput(Being Stopped)
SMS Commands for Settings of GPRS Tracking
(For mass programming, user is suggested to use application
---Parameter Editor to do the settings)
Tracker sGPRSID Last14numberof IMEInumber
Remarks:TheTracker sGPRSIDisthe last14digitsoftheIMEInumber.Usercannot
changeit. E.g.: IMEI:355840023214059, thenGPRSIDis: 55840023214059
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page10
SetAPN W******,011,APN,Username,
Password W000000,011,internet,web,gprs
Remarks: Ifno APNusernameandpasswordarerequired,justinputAPNonly;
APNdefaultedas ‘internet ;APN+ username+ passwordshouldnotover 49characters.
SetIPandPort W******,012,IP,Port W000000,012,220.121.7.89,8500
W000000,012,www.track800.com,8500
Remarks: IPisyourserver sIPorthedomainname. Port:[1,65534]
SetGPRSConnection W******,013,X W000000,013,1
Remarks:X=0, toturnoffGPRStracking(default)
X=1,toenableGPRStrackingviaTCP
X=2,toenableGPRStrackingviaUDP
SetGPRSInterval W******,014,XXXXX W000000,014,00060
Remarks: tosettimeintervalforsendingGPRSpackets.
XXXXX shouldbeinfivedigitsandinunitof10seconds.
XXXXX=00000,toturnoff thisfunction;
XXXXX=00001~65535,timeintervalforsendingGPRSpacket andinunitof 10seconds.
Inthisexample,thetrackerwill sendevery600seconds(10minutes).
VeerReport W******,036,degree W000000,036,90
Remarks:whentheheadingdirectionofthe trackerchangesoverthe presetdegree,a
message withlocation datawill besentback totheserverbyGPRS.
degree=0,toturnoff thisfunction.
degree=[1,360], tosetdegreeof directionchange.
SleepMode W******,026,XX W000000,026,10
Remarks: toset sleepmodewhen thetrackerisinactiveforaperiodoftime.
Insleepmode,GPS stopsworkingandGSMenterssleepandstopsendingoutmessage
until itisactivatedbymessage, incomingcallsortriggeredbybuttons.
XX=00,toturnoffthisfunction.
XX=01~99,toturnonPowerDownafteraspecified periodofbeing inactive.Itisinunitof
minute.
Inthisexample,thetrackerwill entersleepmodeafteritisinactivefor10minutes.
SetTimeZone W******,032,T W000000,032,480
W000000,032,-120
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page11
Remarks:DefaulttimeofthetrackerisGMT,youcanusethiscommand tocorrectittoyour
localtime.ThiscommandisforSMSdisplayonly.
trackingonly.
T=0,toturnoff thisfunction.
T=[1,65535]toset timedifferenceinminutetoGMT.
ForthoseaheadofGMT,justinputthetimedifferenceinminutedirectly.Forexample,
GMT+8,W000000,032,480
‘-‘isrequiredforthosebehind GMT. Forexample,W000000,032,-120.
SetContentforSOS W******,033,1,Char W000000,033,1,helpmeplease
Remarks:thiscommand istosetinitialcharactersforSOSmessagewhen the SOSbutton
ispressed.
Charisthe characterinSOSmessage andmax32charactersanddefaultedas ‘SOSAlarm!
GetFirmwareVersion W******,600 W000000,600
Remarks: toget the versionof tracker sfirmware
GetIMEInumber W******,601 W000000,601
Remarks: toget the IMEInumberoftracker sGSMmodule
RebootGSM W******,901### W000000,901###
Remarks: toreboottheGSMmoduleofthetracker
RebootGPS W******,902### W000000,902###
Remarks: toreboottheGPSmoduleof thetracker
Initialization W******,990,099### W000000,990,099###
Remarks:SendthisSMStothetrackertomakeall settings(exceptforthepassword&
odometer) back tofactorydefault. ### istheending character.
ResetOdometer W******,046 W000000,046
Remarks:Thiscommandwill reset the odometervalueto0.
ResetPassword W888888,999,666 W888888,999,666
Remarks:Send thisSMStothetrackertoresetthepasswordas000000
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page12
III. AlarmTypes
SOSAlarm
Inanycondition,if theSOSbuttonispressed, itwilltriggertheSOSalarm.
Shake Alarm
Inarming status,if thecar/motorcycleisvibrated,itwilltriggerthisalarm.
PowerFailureAlarm
Inarmingstatus,ifthecar/motorcycle sbatteryiscutoff,itwilltriggerthis
alarm.
EngineONAlarm
Inarming status,ifthecar/motorcycle sengineisON,itwilltriggerthis
alarm.Ifthetrackerisused toupgraded theexistingnormalcar
alarm(connectthebluelinetothepositivepoleofthealarmssiren,then
send000000LNK1tomakeitworkinthismode),thealarmwill betriggered
when thebluelinedetectsacontinuouspositivesignalfor5seconds.
MovementAlarm
Inarming status,themovement alertisenabled automatically.Oncethecar
movesawayfromtheparking point for80 meters,itwilltriggerthisalarm.
Geo-Fence Alarm
OncetheGeo-fenceisactivated,ifthecar/motorcycleoverstepsthe
boundary,itwill triggerthisalarm.
Over-speedAlarm
If thecar/motorcyclerunsoverthespeed limitation,itwilltriggerthisalarm.
(Remark:thisfunction isjustforreference,becausetheremightbe some
timedelayorerrorindetectingtherunningcar srealspeed byGPS.)
NOTE:theSOSalarm willonlybesenttothe2nd phone,the3rd phone
number&theGPRStrackingcenter,theotheralarmswillsendtoallthethree
programphonenumbers&GPRStracking center.
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page13
IV. Installation
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page14
Installation Steps:
(1)Pleasereadthemanualcarefullybeforeinstallation. Pleaseprepareavalid
GSMSIMcardwithCallerIDDisplay&GPRSfunction;
(2)Pleaseusethescrewdrivertoopenthecover;
(3)InsertthevalidGSMSIMcard,thenturnon thepowerswitch;
(4)Closethecover,andfixthemainunittightlywiththewiringharnessatthe
correctplace,pleasemakesurethattheside withGPS antennaisplaced
upside tosky,pleasemakesuretoinstallthemainunitatbroad placeso
thatitcanreceiveGPS signalwell.Formotorcycle,itisbettertoinstall
insidetheheadbulblight wherethereispowersupplyandwaterproof.For
vehicle, itisbettertoinstallinsidetheupperrim ofthedriving roomorinside
thedashboard.Therecommendinstallationplaceisshowed inthefollowing
picture:
FormotorcycleForvehicle
(5)Dothewring connectionaccordingtothediagram;
(6)Call theSIMcard,tocheckif rings, if not,then checkthepowersupplyand
thechangetheplaceofinstallation;
(7)Ifit ringswhencallingtheSIMcard, thensendSMStothetrackertocheck
theGPS coordinate,if theGPS location isnot correct, thenfixthemainunit
tootherplacesothatitcanreceivebetterGPS signal.Pleasetakecareof
thattheside withGPS antennamust beplaceupsidetothesky;
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page15
V.Specifications
Working voltage:
+5.3~+24VDC
PowerConsumption:
Working current: 50mA;
Peakcurrent: 800mA;
Inside Backup battery: Rechargeable3.7V800mAhLi-ionbattery
Sizeof the mainunit:
80*58*22 (mm)
Weight of the mainunit:
90g
Working temperature:
-20 ~70
Humidity:
0~95%
GSMfrequencies:
Dual-band:900MHz/1800MHz
(orQuad-band:850MHz/900MHz/1800MHz/1900MHz)
GPS chip:
Latest SiRF-StarIII chipset
Receivingways 20 channel
Working frequencies 1575.42MhzC/A（GPS）
Receivingsensibility-158db
Positioningaccuracy ≤10m(wide-openarea)
Speed accuracy ≤0.2M/S(wide-openarea)
Positioningmode Auto2D/3D
Hot start 1sec.,average
Warm start 38 sec.,average
Coldstart 42 sec.,average
VI.FAQs&Troubleshooting
FAQ Troubleshooting
I callthe tracker,it doesnot ring
(1)The GSMSIMcardhasno credit;
(2)The SIMcardisprotected byPINcode;
(3)Check the powersupply,if 2LEDsflash;
(4)The SIMcardisplaced correctlyinthe slot;
Icallthe tracker,itrings,butit
doesn t responsewithSMS
(1)The userpasswordiswrong, pleaseusethe
correct passwordorreset the passwordtotest;
(2)Lowpower,pleaseuseoutside powersupply
topoweron the unit totest
I can notgetthe alarm message
(1)The SIMcardinside the devicehasno credit;
(2)TheAlert-received mobilenumberisnot
programmed correctly, orthe SMScommand is
TOPTEN
MT113 GPS Motorcycle/VehicleTrackerUserManual
Page16
not incorrect format;
(3)The mailboxof the user smobileisfull;
Ican notgetthe correctGPS
coordinatesorthe location is
wrong
(1)Pleasemakesurethereisno metalobstacles
abovethetracker. Pleaseplacethe side with
GPS antenna upsidetothe sky;
(2)Pleasecheck it at broad place;
(3)Pleasecheck ifthe GPS LEDflashonce
every3seconds;placethe trackertootherplace,
soastomakesurethatitcan receivethe GPS
siganlwell
(4)Incloudycondition,itisalittlehardtogetthe
GPS signal,and the GPS coordinatemighthave
someerrors.
Trackerfailstoconnect to
serverbyGPRS (1)The SIMcardmust be activated withGPRS
function;
(2) Do the correct setting forGPRSconnection
VII. Maintenance
²Pleasemakethelocalprofessionalstodotheinstallation&maintenanceof
theGPS terminal.Iftheuserassemble/disassembleorrepairtheterminal
withoutpermission,weholdnoresponsibilityforanyloss causedthereafter.
²Pleasekeeptheterminaldry.Incaseofsoakingorleakingwater,contact
thelocalprofessionals.Donotstartthecaryourself, orweholdno
responsibilityforanyloss causedthereafter.
²Whenthecarisinside buildings, cave,tunnel,orveryclosetotallbuildings,
theGPS/ GSMsignalmaynotworkwelland thesystemmayfailtoworkat
thatmoment.
²Pleasecheckthebalanceofthetracker sSIMcardperiodically.
²Thebackup battery.Thebackup batterycan onlyworkforacertaintime
when temporarypoweroff.
²Foranyotherunusualsituations,pleasecontactthelocalagent.
TOPTEN
Table of contents
Other Topten GPS manuals
