Topten MT05S User manual

GPS Motorcycle/Vehicle Tracker
USER MANUAL
(Model:MT05S)
Version 1.0
(Date: July 30, 2020)

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
1
CONTENT
Preface...............................................................................................................................2
I. Features & Functions..................................................................................................... 3
II. How to Operate it......................................................................................................... 4
Authorize the Alarm-received Phone No....................................................................................... 4
Arm/Disarm by Phone Calling....................................................................................................... 4
Check the Vehicle’s Status..............................................................................................................5
Arm/Disarm the System by SMS................................................................................................... 5
Check the location by Google Map’s URL.................................................................................... 5
Stop the Car by SMS...................................................................................................................... 5
Restore the Stopped Car to Normal Status.....................................................................................5
Monitor the Voice (Optional function)........................................................ 错误！未定义书签。
Check the Real Physical Address................................................................................................... 6
Change User Password................................................................................................................... 6
Over-speed Alert.............................................................................................................................6
Power Save Mode...........................................................................................................................7
Other SMS Command List............................................................................................................. 8
III. The Setting for GPRS Connection............................................................................ 10
IV . Specifications........................................................................................................... 11
V. Alarm Types................................................................................................................ 12
VI. Installation.................................................................................................................12
VII. FAQs & Troubleshooting.........................................................................................14
VIII. Maintenance........................................................................................................... 15

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
2
Preface
MT05S GPS Motorcycle/vehicle tracker is the cost-effective solution for
security & real-time tracking. It is specially used for motorcycle/car tracking
because of its compact size and water-proof design.
Read it Firstly:
Please read this manual thoroughly before you use the device; please keep
it for future reference.
Attention:
(1) Please keep the device away from heavy water, high temperature, heavy
dust or strong magnetism.
(2) Please prepare a valid GSM SIM card in advance.
(3) For safety reason, do not tell other people the mobile phone number of
your tracker.
Warning:
We strongly suggest user let the professional car electrician to install the
system.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
3
I. Features & Functions
1. Track on command or by time interval via SMS/GPRS;
2. Arm/disarm by SMS or phone call.
3. Check the car’s real physical address (such as city name, street name.);
4. Track by mobile SMS to get the latitude, longitude, speed, direction &
odometer etc.
5. Check the location directly by the Google map’s URL;
6. Data logger to store 5520 waypoints.
7. Online tracking by website;
8. Odometer function;
9. Over-speed alarm, Movement alarm, Engine on alarm, Vibration alarm;
10. Turn over alarm;
11. Acceleration & Deceleration (Crash) Alarm;
12. OTA function: Upgrade firmware on air;
13. Smart engine ON/OFF status detection without wiring to ACC;
14. Built-in rechargeable backup battery; when the car battery is cut off or low
enough, the system will send out power failure alarm immediately;
15. Cut off engine to stop the car safely by SMS/GPRS;
16. Routine optimization when vehicle turns a corner;
17. A-GPS function to get GPS signal much faster;
18. Support USB configure;
19. Wide working voltage range, from 10V-60VDC, suitable for motorcycle, car
or big truck.
20. Reliable design of framework with hardware watchdog.
21. Extreme power save working mode, power consumption could be less than
4mA.
22. Detection on internal battery's volume & vehicle battery's voltage.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
4
II. How to operate it
The default user password is 111111.
If the user password is changed, user should send the SMS command with
the new user password instead of 111111.
XXX is the control code, all the letters must be capital letters or in small
letters, command with mixed capital letter & small letter is not recognized by
system
Authorize the Alarm-received Phone No.
SMS command: 111111*10 Mobile #1*20 Mobile #2*30 Mobile #3*
In case of alarm, if user wants to get the alarm SMS from the tracker, he/she
needs send the following SMS to program the tracker firstly, otherwise, the alert
information can't be received correctly.
Example: User sends the SMS 111111*1013922713571*2018902267400* to the
tracker’s SIM card number, if there is any alarm, system will send SMS to both of these two
mobiles. In case of SOS alarm, the system will only send alarm to the mobile #2 & mobile
#3.
Arm/Disarm by Phone Calling
User could also use the 1st alarm-received mobile phone to call the
tracker’s SIM card number, so as to arm/disarm the system.
Arm: After hearing several ring tones, if the systems hang up the call
automatically, and call back you, it means that the system is armed.
Disarm: After hearing several ring tones, if the system hangs up the call
automatically, and don’t call back you, it means that the system is disarmed.
Note:
(1) There is no communication fee for this operation, it is a very convenient way to arm
& disarm the system.
(2)The SIM card inside the device must have the function of Caller ID Display.
(3) Only the 1st alarm-received mobile phone can realize this function.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
5
Check the Vehicle’s Status
SMS command: 111111CHK (or 111111chk)
This instruction is used to inquiry the vehicle’s location & system’s status.
The system will send back the SMS, includes the similar information, such
as “Armed……”
Arm/Disarm the System by SMS
SMS command: 111111ARM (or 111111arm)
This SMS instruction is used to arm the system
When the system is armed, the movement alert is activated automatically.
When the motorcycle/car moves, the alarm will be triggered.
SMS command: 111111DSM (or 111111dsm)
This command is used to disarm the system & stop sending alert SMS.
Check the location by Google Map’s URL
SMS command: 111111MAP (or 111111map)
Upon receiving the SMS command, the tracker will automatically send back
the SMS including the Google map’s URL, user can use smart phone (GPRS
data service is enabled) to open the URL link, the car’s location will be showed
on the Google map.
User can also use the 2nd alarm-received phone to call the tracker; the
tracker will send back the same content with Google link.
Stop the Car by SMS
SMS command: 111111STP (or 111111stp)
This instruction is used to stop the motorcycle/car safely. If the car speed is
higher than 30Km/h, it will not carry out until the speed is lower than 30Km/h.
Restore the Stopped Car to Normal Status
SMS command: 111111RES (or 111111res)

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
6
It is used to restore the car to normal status after being stopped.
Check the Real Physical Address
SMS command: 111111ADD (or 111111add)
User can program the tracker to work with our platform. Once connected, user can
send this SMS command to get the actual address which is translated by the platform..
Remark: (1) The GPRS data service of the tracker’s SIM card must be activated, and
the correct GPRS setting is needed (refer to the chapter of the setting of GPRS
connection); (2) The physical address depends on the map of the platform..
Change User Password
SMS command: 111111PSWnnnnnn (or 111111pswnnnnnn)
This instruction is used to change the user password. The length of the
user’s password is 3~6 digits. Users are suggested to change to the new
password in use.
Example: User sends the SMS “111111PSW12345” to the system SIM card
number, and gets the confirmed SMS “111111PSW12345” in 3 seconds. It
means that the user password has been changed to 12345.
Remark: Please keep the password deep in mind if it is changed.
Odometer
SMS command: 111111ODO:
It is used to read the present odometer
SMS command: 111111ODO:X
It is used to set the basic value of odometer
Over-speed Alert
111111SPD:X x is the speed in KM/H , maximum value is 255KM/H
(For example: 111111SPD:120, if the car speed is over 120KM/H, it will
send alert SMS to warn you).
111111SPD:0 to disable the over-speed alert. It is the default setting.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
7
111111SPD: to check the setting of over-speed alert.
When the car speed is higher than the speed value, it will trigger the
over-speed alarm.
Remark: this function is just for reference, because there might be some
time delay or error in detecting the running car’s real speed by GPS.
Upgrade
111111UPG
This instruction is used to upgrade the equipment firmware.
Reply：Upgrade successfully!
Upgrade fail! Network error
Upgrade fail! No upgrade files
Upgrade fail! Upgrade files error
This is the latest version
The Setting for Upgrade
SMS format: 111111FTP:IPN:X;USE:X; PWD:X;NAM:X; AUT:X;
IPN: The IP address of the FTP server to upgrade.
USE: The User name of FTP server.
PWD: The password of FTP server.
NAM: The name of upgrade file
AUT: auto updates setting. 0=close, 1= auto update.
Example, if server IP address is: 103.56.17.22, User name is topten,
Password is 111111, upgrade file is upgrade418.bin, AUT is close, then the
command is:
111111FTP:IPN:103.56.17.22;USE:topten;PWD:111111;NAM:upgrade108.bin;A
UT:0;
Power Save Mode
SMS command: 111111PWR:X
Value of X
Actions
0
Disable power save mode

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
8
1(default)
GPS on when ACC is on
2
Close GPRS connection, GPS module
After setting 111111PWR:2, if there is no vibration and ACC is turned OFF,
the tracker will go into power save mode after 5 minutes.
Once there is vibration or engine is turned ON, or incoming call/SMS, the
tracker will wake up from the power save mode immediately.
Other SMS Command List
Note: ****** is user’s password and the default password is 111111. The
tracker will only accept commands with the correct password.
Functions
SMS Command
Example
Auto Report by SMS
******RPT:X
111111RPT:5
Remarks: To set time interval for continuous automatic report via SMS.
X is the interval in minute. If X=0 to turn off tracking by time.
Example, the tracker will send location data back to 3rd alarm-received phone (XXX) every 5
minutes. 111111*10*20*30XXX*
Movement Alarm
******MOV:X
111111MOV:500
X: X is the radius of the fence. default setting is 500 meters
=0: close the movement alarm (when tracker is armed, it will be activated automatically.)
Example: it is set the radius of movement alarm as 500meters.
Set the Shock Sensor
******SHK:X
111111SHK:3
It is to set the sensitivity of the shock sensor. X=1~5. (X=1, less sensitive; X=5, most
sensitive; default X=2).
Clear the Parameters
******CLR
111111CLR
Remarks: it will reset all the parameters to the default settings.
Reboot the Tracker
******STR
111111STR
It will reboot the tracker immediately.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
9
Routine Optimization
******DEG:X
111111DEG:30
It is to set the angle. When the car turns a corner over this angle, then it will sample a location
to optimize the routine.
Check Vehicle battery
******ADC:X
111111ADC:
It will reply the voltage of external power battery.
Adjust harsh brake &
acceleration threshold
******USP:X
******DSP:X
111111USP:30
111111DSP:70
X: is the speed(km/h), value range: 0~100 Km/h
If the change of car speed is larger than X between 2 seconds, it will be triggered as harsh
brake or harsh acceleration.
******USP:X : to set the threshold of harsh acceleration
******DSP:X : to set the threshold of harsh brake
Set Heartbeat interval
******HRT:X
111111HRT:5
It is to set the time interval of the tracker's heartbeat packet, default: 3minute. Maximum:
65535 minutes.
Clear Data Logger
******NUL
111111NUL
It is to clear the offline GPS data in the data logger
Check the Gprs Setting
******WWW:
111111WWW:
It is to check the GPRS settings.
Set the threshold of
smart engine detection
******ACC:X
111111ACC:13.0
The default setting is 13.0. For big truck, it is suggested to set as 26.0. User can send
111111ADC to check the real value. the last number in the feedback SMS is vehicle's voltage.
Check firmware version
& IMEI, others
111111PAR
111111PAR
It is to check the firmware version, IMEI, device ID GPRS settings, time zone.

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
10
III. The Setting for GPRS Connection
The GPRS setting is necessary for using the following 2 functions:
(1) Check the car’s real physical address by send 111111ADD
(2) Online tracking service by web-based tracking platform
SMS format:
111111WWW:IPN:X;COM:X;APN:apn,user,password;RPT:X;SLP:X;RUN:X;
IDN: The tracker’s ID, it is the last 14 digits of IMEI which can't be
changed.
IPN: The IP address or domain name of the GPRS server
COM: The communication port for the GPRS server
APN: The Access Point Name for the GSM SIM card.
RPT: The interval for the uploading GPRS packet (Unit: sec.)
SLP: The interval for uploading GPRS packet when Engine is OFF. (unit:
sec.);
RUN: GPRS connection setting. 0=close, 1=TCP.
Example, if server is: www.51track.com, TCP port is 8500, APN is
web.gprs,mtnnigeria.net, apn user:web, apn password: web, time interval is 60
seconds, Then the command is:
111111WWW:IPN:www.51track.com;COM:8500;APN:web.gprs.mtnnigeria.net,
web,web;RPT:60;SLP:60;RUN:1;
User can send one or more options at the same SMS commands, such as:
111111WWW:IPN:X;COM:X;
This is to set the server’s address and port separately.
Example: 111111WWW:IPN:www.51track.com;COM:8500;
111111WWW:APN:X;
The tracker can automatically detect most of the APNs of GSM operator in
the world. But for some operator SIM card, you need to set it manually. Please
use “,” to separate the APN, APN username & APN password.
Example: 111111WWW：APN：web.gprs.mtnnigeria.net,web,web;

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
11
111111WWW:RPT:X;
This is to set the upload time interval. The unit is second, the minimum
value is 10 seconds. The default setting is 60
Example: 111111WWW:RPT:60;SLP:300；(Upload time interval: Engine ON:
60s, Engine OFF: 300seconds)
111111WWW:RUN:X;
X=0; is to close down the GPRS;
X=1; is to open the GPRS via TCP
E.g.: 111111WWW：RUN：1；(Open the TCP connection)
111111WWW:
You can send 111111WWW: to check the GPRS settings.
Default GPRS Setting
The initiated GPRS setting is:
IPN: www.51track.com COM:8500
APN:(auto detection) RPT: 20
SLP:120 RUN:1
IV . Specifications
Working voltage:
+6.0 ~+60VDC
Power Consumption:
Standby current:8mA
Working current: 20mA;
Deep sleep mode current: <4mA;
Inside Backup battery:
Rechargeable 3.7V 180mAh Li-ion battery
Size of the main unit:
58*40*15 (mm)
Weight of the main unit:
34g
Working temperature:
-20 ~ 85℃
Humidity:
0 ~ 95%
GSM frequencies:
Quad-band: 850MHz/900MHz/1800MHz/1900MHz
GPS chip:
U-blox 7 chipset
Receiving ways
56 channels
Working frequencies
1575.42Mhz C/A（GPS）
Receiving sensibility
-162dBm
Positioning accuracy
≤10m (wide-open area)
Speed accuracy
≤0.2M/S (wide-open area)
Positioning mode
Auto 2D/3D
Hot start
1 sec., average

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
12
Warm start
2 sec., average
Cold start
40 sec., average
V. Alarm Types
Vibration Alarm
In arming status, if the vehicle is vibrated, it will send out the alarm.
Power Failure Alarm
At any time, if the car battery is cut off, it will send out the alarm.
Engine ON Alarm
In arming status, if the vehicle engine is ON, it will send out alarm SMS and
call the preset phone.
Movement Alarm
In arming status, the movement alert is enabled automatically. Once the car
moves away from the parking point for the preset distance, it will send out
the alarm.
Over-speed Alarm
At any time, if the vehicle runs over the speed limitation, it will send out the
alarm.
SOS Alarm (optional)
At any time, if the SOS button is pressed for 3 seconds, it will send out the
alarm.
Turn Over Alarm
At any time, if the vehicle turns over more than 60 degree last 16 second, it
will send out the alarm.
Acceleration & Deceleration (Crash) Alarm
At any time, if the vehicle speeds up suddenly or harsh brake, it will trigger
the event alarm
VI.Installation
The Wiring diagram of MT05S

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
13

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
14
Installation Steps:
(1) Please read the manual carefully before installation. Please prepare a valid
GSM SIM card with Caller ID Display & GPRS function;
(2) Please use screw driver to open the cover of the box;
(3) Insert the valid GSM SIM card, then turn on the backup battery switch;
(4) Close the cover, and fix the main unit tightly with the wiring harness at the
correct place, please make sure that the side with GPS antenna(with
satellite icon) is placed upside to sky or away from the metal materials,
please make sure to install the main unit at broad place so that it can
receive GPS signal well. For motorcycle, it is better to install inside the head
bulb light where there is power supply and water proof. For vehicle, it is
better to install inside the upper rim of the driving room or inside the
dashboard. The recommend installation place is showed in the following
picture:
(5) Do the wring connection according to the diagram;
(6) Call the SIM card, to check if rings, if not, then check the power supply and
the change the place of installation;
(7) If it rings when calling the SIM card, then send SMS to the tracker to check
the GPS coordinate, if the GPS location is not correct, then fix the main unit
to other place so that it can receive better GPS signal.
(8) IMPORTANT: The side with GPS antenna(satellite icon) must be placed
upside to the sky and kept away from the metal materials, otherwise, it can’t
get GPS signal well.
VII. FAQs & Troubleshooting
FAQ
Troubleshooting
I call the tracker, it does not ring
(1) The GSM SIM card has no credit;
(2) The SIM card is protected by PIN code;
(3) Check the power supply, if 2 LEDs flash;
(4) The SIM card is placed correctly in the slot;
I call the tracker, it rings, but it
doesn’t response with SMS
(1)The user password is wrong, please use the
correct password or reset the password to test;
(2) Low power, please use outside power supply to
power on the unit to test
I can not get the alarm message
(1) The SIM card inside the device has no credit;
(2) The Alert-received mobile number is not
programmed correctly, or the SMS command is not

MT05S GPS Motorcycle/Vehicle Tracker User Manual
Page
15
in correct format;
(3) The mailbox of the user’s mobile is full;
I can not get the correct GPS
coordinates or the location is
wrong
(1) Please make sure there is no metal obstacles
above the tracker. Please place the side with GPS
antenna upside to the sky;
(2) Please check it at broad place;
(3) Please check if the GPS LED flash once every
3 seconds; place the tracker to other place, so as
to make sure that it can receive the GPS siganl well
(4) In cloudy condition, it is a little hard to get the
GPS signal, and the GPS coordinate might have
some errors.
Tracker fails to connect to
server by GPRS
(1) The SIM card must be activated with GPRS
function;
(2) Do the correct setting for GPRS connection
VIII.Maintenance
Please make the local professionals to do the installation & maintenance of
the GPS terminal. If the user assemble/ disassemble or repair the terminal
without permission, we hold no responsibility for any loss caused thereafter.
Please keep the terminal dry. In case of soaking or leaking water, contact
the local professionals. Do not start the car yourself, or we hold no
responsibility for any loss caused thereafter.
When the car is inside buildings, cave, tunnel, or very close to tall buildings,
the GPS/ GSM signal may not work well and the system may fail to work at
that moment.
Please check the balance of the tracker’s SIM card periodically.
The backup battery. The backup battery can only work for a certain time.
For any other unusual situations, please contact the local agent.
