Tornado 98774 Manual

1
TORNADO INDUSTRIES, LLC
3101 WICHITA COURT
FORT WORTH, TX 76140
PHONE: 800-VACUUMS
FAX: [phone]
WWW.TORNADOVAC.COM
Operations & Maintenance Manual
For Commercial Use Only
Form No. L8774AA 05/16 ©Tornado Industries, LLC. All rights reserved
WINDSHEAR 3200 SERIES: 3200 WINDSHEAR and 3200 SAFETY DRYER
MODEL NO: 98774/98786 (Color may vary from that shown)
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

Long Term Buyer Protection Limited Warranty
10 Years*
Plastic water tanks and Rotationally-molded bodies
2 Years*
Parts on all Tornado cleaning equipment
1 Year*
Labor on all Tornado cleaning equipment
1 Year*
Warranty on batteries, one year prorated
All battery warranties are handled directly by the battery manufacturer, on a one year prorated basis
Tornado Industries, LLC. (Tornado) warrants to the end/user customer that the Tornado product(s) will
be free from defects in material and workmanship for the duration(s) described below. This limited
warranty DOES NOT cover machines and/or components subject to normal wear and tear, damage
that occurs in shipping, failures resulting from modication, accident, unsuitable operating environ-
ment, misuse, abuse, neglect, or improper maintenance by you. For full details, contact your Autho-
rized Tornado Distributor, Service Center, or the Tornado Technical Service Department. Tornado
sales and service representatives are not authorized to waive or alter the terms of this warranty, or to
increase the obligations of Tornado under the warranty.
Terms subject to change without notice
1. Except all Windshears™ Blowers, Storm, TV2SS, Side and Downdraft, Insulation Blowers, CV 30,
CV 38, CK14/1 PRO, CK 14/2 PRO, SWM 31/9, CK LW13/1, CK LW 13/1 ROAM, CV 38/48 Dual,
PV6, PV10, PV6 ROAM, Wall Mount Vacuum and all chargers are warranted for 1 (one) year for both
parts and labor.
2. All non-wear item parts purchased after warranty expiration are warranted for 90 days.
3. Warranty starts from the date of sale to the consumer or, at Tornado’s discretion, 6 months after
the dealer purchased the unit from Tornado, whichever comes rst.
4. The EB 30 is warranted for a period of 90 days for both parts and labor.
5. The warranty on engines used on propane powered equipment is limited to motor manufacturer’s
warranty.
6. Ride-on Scrubbers are warranted for 24 months, parts, 6 months labor or 1,000 hours, whichever
occurs rst.
Note: Tornado, The Latest Dirt, Floorkeeper,
Carpetkeeper, Carpetrinser, Carpetrinser/Dryer,
Headmaster, Taskforce, PAC-VAC, T-Lite, Glazer,
Windshear, Max-Vac and Trot-Mop are trademarks
of Tornado Industries
Website: www.tornadovac.com
Phone 1-800-VACUUMS
Fax [phone]
Address 3101 Wichita Court
Fort Worth, TX 76140
Form F2662.©2017. All rights reserved
1-800-VACUUMS 90 Years of Cleaning Innovation A Tacony Company
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

3
NOTES
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

4
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk electric shock. This machine is equipped with a cord having an
equipment -grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet that
is properly installed and grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualied electrician or service person if you are in doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the appliance - if it will not t the outlet, have a proper outlet
installed by a qualied electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the plug
illustrated in sketch A.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

5
Your new Tornado unit is a high quality, precision-made product. All parts used in the manufacturing of this unit
have passed rigid quality control standards prior to assembly. Please safeguard the original receipt / invoice. If
you experience any problems with your unit during the warranty period, the original receipt / invoice will act as
proof of purchase. Contact Tornado for any warranty inquiries.
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating. Safety is a combination of
common sense,staying alert and knowing how your unit works. Use this unit only as described in this manual.
Use only manufacturer’s recommended attachments. To reduce the risk of personal injury or damage to your
unit use only Tornado recommended accessories.
To reduce the risk of re, explosion, electric shock, or injury, the following precautions should
always be followed.
1. Use only as described in this manual. Use only manufacturer’s recommended attachments.
2. Do not operate this machine near ammable liquids, vapors, combustible dusts or material
capable of catching re such as drapes, etc.
3. Connect only to an outlet provided with a ground fault circuit interrupting device.
4. Unplug cord from outlet when not in use and before cleaning or servicing machine.
5. Do not allow to be used as a toy. Close attention is necessary when used near children.
6. This machine is not intended for use by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
7. Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped in water, return it to a service center for repair.
8. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around
sharp edges or corners. Keep cord away from heated surfaces.
9. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
10. Do not handle plug or appliance with wet hands.
11. Do not use an extension cord with this appliance.
12. Do not put any object into openings. Do not use with any opening blocked; keep free of dust,
lint, hair and anything that may reduce air ow.
13. Keep hair, loose clothing, ngers, and all parts of body away from openings and moving parts.
14. Always operate appliance on a stable, at surface such as the oor.
15. Do not use this appliance with any solid-state speed control device.
16. Do not operate appliance without safety devices in place.
17. Turn off all controls before unplugging.
18. All repairs must be must be performed by a qualied service person. Use only
manufacturer-supplied or equivalent replacement parts.
19. Do not use outdoors. Do not expose appliance to rain or moisture. Store indoors.
20. Connect to a properly grounded outlet only. See Grounding Instructions.
21. This appliance is thermally protected.
22. To avoid severe or fatal shock, all electrical cords and components must be kept dry at all
times.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

6
1. 3-Speed Switch
2. Carrying Handle
3. Power Cord Storage
4. Air Outlet Vent
5. Air Intake Vent
6. Kick Stand
Ensure machine is in a safe operating location. Do not
place machine in a puddle and make sure it is protected
from drips and splashes.
Plug the power cord into a grounded electrical outlet.
Always unwind power cord completely before operating
machine. Inspect power cord for damage before each use.
Replace cord immediately if damaged.
Place the machine in the desired operating position.
A. Horizontal - dry oors and carpets
B. Tilted - dry oor nishes, paint, etc.
C. Vertical - dry wall and ceiling
Set the desired speed by turning switch.
Check for proper operation before leaving the machine
unattended. Do not move or carry the machine when it is
operating.
To shut-off machine, turn the switch to the off (O) position.
The machine is equipped with an automatic reset motor
overload shut-off thermal sensor to protect motor from
overheating. Should the shut-off thermal sensor trip, it will
reset automatically when the motor has cooled sufciently,
usually after 15-30 minutes.
A. B. C.
To keep machine in good working condition, simply perform
the following maintenance procedures.
Unplug cord from outlet when not in use and before
servicing machine.
1. Inspect power cord for damage after each use. Replace
power cord immediately if damaged.
2. Clean machine with a damp cloth.
3. Check for dust accumulation around the air inlet and
outlet vents and clean if necessary. Blocked vents will
cause the motor to overheat, and may lead to premature
failure. Warranty claims for this type of damage will not
be accepted.
Unplug cord from outlet when not in use and before
servicing machine.
If machine fails to operate:
- Check power cord for damage.
- Check plug connection.
- Check building circuit breaker.
- Thermal sensor shut-off - wait 15-30 minutes to cool.
- Contact service center.
MODEL 3-SPEED BLOWER
Width x Height x Depth 15 in x 18.5 in x 18 in
38.1 cm x 47 cm x 45.7 cm
Weight 22.5 lb / 10.2 kg
Voltage / Frequency 120 V / 60 Hz
Motor Rating .6 HP, 522 W, 4.35 A
Air Flow 3,800 feet per minute
Speeds - Low/Med/High 710 rpm/1105 rpm/1550 rpm
Power Cord Length 18.5 ft / 5.6 m
Sound Pressure Level LpA 69 dBA
Protection Grade IP20
MACHINE OPERATION
MACHINE MAINTENANCE
STORING AND TRANSPORTING MACHINE
TROUBLE SHOOTING
MACHINE SPECIFICATIONS
Neatly wrap power cord and store
machine in a cool dry area. Do not
expose to rain, store indoors.
Stack machines for storage as
shown.
CAUTION: Do not stack beyond
four high. Do not stack during
transporting and secure with strap.
1
2
4
5
6
3
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

Please provide additional information on
Tornado equipment: (Check choices below)
__ Automatic Scrubbers __Sweepers
__Propane Floor Machines __Rotary Floor Machine
__High Speed Burnishers __Carpet Vacuums
__Carpet Extractors & Spotters __Wet/Dry Vacs
__ Steam Cleaners __Jumbo Vacs
__Ride-On Equipment __Pressure Washers
See complete product info at www.tornadovac.com
Selling Dealer:(Required)__________________________
Warranty
Registration
Form
_____________________________________________________________________________
Company/Institution
_____________________________________ ____________________________________
Contact Name Title
_____________________________________ ____________________________________
Address City/State/Zip Code
_____________________________________ ____________________________________
Phone Fax
_____________________________________ ____________________________________
Date of Purchase Email
Please Print Clearly
See white metal plate or sticker on unit for this information.
MACHINE TYPE/MODEL NUMBER: MACHINE SERIAL NUMBER:
1. 1.
2. 2.
3. 3.
4. 4.
How did you rst learn about
Tornado cleaning and
maintenance equipment?
In square feet (meters)
Total Hard Floor Area
Total Carpeted Area
Square feet (square meters)
o Contacted by local dealer
o Previous experience with
Tornado products
o Reputation/
Recommendation
o Advertising
o Direct mail
o Internet
o Other
o 0-10,000 (0-930)
o 10-50,000 (930-4,650)
o 50-250,000 (4,650-23,250)
o Over 250,000 (over
23,260)
o 0-10,000 (0-930)
o 10-50,000 (930-4,650)
o 50-250,000 (4,650-23,250)
o Over 250,000 (over
23,260)
Damage or defect arising from abuse, neglect or other misuse is excluded from this warranty. Other items
may or may not apply based on your specic machine. If any defect occurs, the warranty is voided if service is
attempted by non-Authorized Tornado Service Centers.
©2017 Tornado Industries. All rights reserved.
X8449-TOR 1/2017
Facility Description (please circle all that apply)
1. School 9. Hospital 17. U.S. Govt.
2. Retail Store 10. Nursing Home 18. Other Govt.
3. Restaurant 11. Religious Institution 19. Auto Service
4. Ofce Building 12. Airport 20. Airport
5. Contract Cleaning 13. Warehouse 21. Non-Prot
6. Light Manufacturing 14. Apartment/Condo 22. Other (specify)
7. Heavy Manufacturing 15. Warehouse
8. College/University 16. Supermarket
Return to :
Tornado Industries
3101 Wichita Court
Fort Worth, TX 76140
Fax: [phone]
or online at
www.tornadovac.com
https://harrissupplyind.com-ToOrderPartsCall608-268-8080
