Tornado LT1 User manual

Garanzie
La Studio Italia Design garantisce i suoi prodotti essere privi da difetti di materiale e di lavorazione per la durata di un anno dalla consegna. Durante tale periodo
la Studio Italia Design riparerà o sostituirà, a sua discrezione, i prodotti che hanno dato prova di difetto.
Questa garanzia non è applicata a danni risultanti dall’incidente , alterazione, manomissione, abuso e negligenza.
Questa garanzia non è applicata alle lampadine, che non sono prodotti fatti dalla Studio Italia Design e fornite dalla Studio Italia Design solo come una
comodità.
Conservare le istruzioni per una manutenzione futura.
ISTRUZIONI DI MONTAGGIO
Disinserire la tensione prima di operare sull’apparecchio.
Montaggio tipo " "
La lampada può essere appoggiata direttamente sul
terreno
Montaggio tipo " "
La lampada può essere ancorata al terreno tramite il
picchetto fornito
" " [T] dall’asta
M1
M2
1) Posizionare la lampada in posizione verticale (Fig.1)
2) Inserire la lampadina
3) Inserire la spina in una presa elettrica.
1) Svitare la base a trifoglio centrale (Fig.3)
2) Avvitare il picchetto [P] sull’asta centrale (Fig.4)
3) Piantare la lampada nel terreno
4) Inserire la lampadina
5) Inserire la spina in una presa elettrica.
Per inserire o sostituire la lampadina:
1) Svitare le tre viti [Y] per staccare la ghiera [R] (vedi Fig.2)
2) Staccare il cappuccio [S]
3) Inserire la lampadina
4) Riposizionare il cappuccio [S] premendo con adeguata
forza.
5) Inserire la ghiera di bloccaggio [R] con le tre viti [Y]
Italiano
TORNADO LT1 max 1x23W (E27)
or max 1x100W Classic A60 (E27)
TC-TSE compact - L max cm12
220-240V 50/60
TORNADO LT2 max 1x23W (E27)
or max 1x100W Classic A60 (E27)
TC-TSE compact - L max cm12
220-240V 50/60
23.10.12_00
TORNADO LT1-LT2
www.studioitaliadesign.com / [e-mail] / Via Pialoi, 32, 30020, Marcon, Venezia, ITALY
T
Fig.1
Fig.4
P
T
Fig.2
Y
Y
S
R
Fig.3

23.10.12_00
TORNADO LT1-LT2
www.studioitaliadesign.com / [e-mail] / Via Pialoi, 32, 30020, Marcon, Venezia, ITALY
T
Fig.1
Fig.4
P
T
Fig.2
Y
Y
S
R
Fig.3
Warranty
Studio Italia Design warrants its to be free from defects in materials and workmanship for a period of one year date of delivery. During this warranty period Studio
Italia Design will repair or replace, at its option, product that are proven to be defective.
This warranty does not apply to damages resulting from accidental, alteration, tampering, misuse, negligence or abuse.
This warranty does not apply to light bulbs, which are not products manufactured by Studio Italia Design and supplied by Studio Italia Design only as an
accomodation.
Keep these instructions for future reference.
English
TORNADO LT1 max 1x23W (E27)
or max 1x100W Classic A60 (E27)
TC-TSE compact - L max cm12
220-240V 50/60
TORNADO LT2 max 1x23W (E27)
or max 1x100W Classic A60 (E27)
TC-TSE compact - L max cm12
220-240V 50/60
Installation type " "
The floor lamp can be placed directly upon the ground.
1) Place the lamp in an upright position (Fig. 1).
2) Insert the light bulb following the instructions provided.
3) Insert the plug into an electrical outlet.
Installation type " "
The lamp can be anchored to the ground using the spike
provided.
1) Unscrew the "clover" base [T] from the stem (Fig. 3).
2) Screw the spike [P] on the stem (Fig. 4).
3) Drive the spike into the ground.
4) Insert the light bulb following the instructions provided.
5) Insert the plug into an electrical outlet.
To insert or replace the light bulb:
- Undo the screws [Y] and remove the ring [R] (see Fig.2)
- Remove the cap [S] (Fig.3) and insert the light bulb.
- Place the cap [S] back and push it firmly into place.
- Put back the ring and secure it with the screws [Y] (Fig.3).
M1
M2
MOUNTING INSTRUCTIONS
Before installing turn off the power to the electrical box.

Warranty
Studio Italia Design warrants its to be free from defects in materials and workmanship for a period of one year date of delivery. During this warranty period Studio
Italia Design will repair or replace, at its option, product that are proven to be defective.
This warranty does not apply to damages resulting from accidental, alteration, tampering, misuse, negligence or abuse.
This warranty does not apply to light bulbs, which are not products manufactured by Studio Italia Design and supplied by Studio Italia Design only as an
accomodation.
Keep these instructions for future reference.
USA
TORNADO LT1 max 1x23W (E26)
or max 1x100W Classic A60 (E26)
TC-TSE compact - L max cm12
220-240V 50/60
TORNADO LT2 max 1x23W (E26)
or max 1x100W Classic A60 (E26)
TC-TSE compact - L max cm12
220-240V 50/60
Installation type " "
The floor lamp can be placed directly upon the ground.
1) Place the lamp in an upright position (Fig. 1).
2) Insert the light bulb following the instructions provided.
3) Insert the plug into an electrical outlet.
Installation type " "
The lamp can be anchored to the ground using the spike
provided.
1) Unscrew the "clover" base [T] from the stem (Fig. 3).
2) Screw the spike [P] on the stem (Fig. 4).
3) Drive the spike into the ground.
4) Insert the light bulb following the instructions provided.
5) Insert the plug into an electrical outlet.
To insert or replace the light bulb:
- Undo the screws [Y] and remove the ring [R] (see Fig.2)
- Remove the cap [S] (Fig.3) and insert the light bulb.
- Place the cap [S] back and push it firmly into place.
- Put back the ring and secure it with the screws [Y] (Fig.3).
M1
M2
MOUNTING INSTRUCTIONS
Before installing turn off the power to the electrical box.
23.10.12_00
TORNADO LT1-LT2
www.studioitaliadesign.com / [e-mail] / Via Pialoi, 32, 30020, Marcon, Venezia, ITALY
T
Fig.1
Fig.4
P
T
Fig.2
Y
Y
S
R
Fig.3
