FormNo.3435-312RevA
BackupAlarmKit
ModelNo.31512
InstallationInstructions
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Backupalarm1
Hex-headscrew(1/4x3/4inch)2
Flangenut(1/4inch)2
Wireharness1
Tieclip2
Clamp1
2
Cabletie2
Installthebackupalarm.
3Nopartsrequired–EnablethealarmintheInfoCenter.
4Nopartsrequired–Checkthebackupalarm.
TheBackupAlarmKitcanbeinstalledonthefollowing
machines:
•Groundsmaster4000Series
•Groundsmaster4100Series
•Groundsmaster5900Series
Note:ThiskitisnotforuseontheOutcross9060.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowerthecuttingunits.
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
5.Disconnectthenegativebatterycablefromthe
battery.
6.Disconnectthepositivebatterycablefromthe
battery.
©2019—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3435-312*A

2
InstallingtheBackupAlarm
Partsneededforthisprocedure:
1Backupalarm
2Hex-headscrew(1/4x3/4inch)
2Flangenut(1/4inch)
1Wireharness
2Tieclip
1Clamp
2Cabletie
InstallingtheBackupAlarm
Groundsmaster4000and4100Series
Machines
1.Securethebackupalarmtotherearframewith
2hex-headscrews(1/4x3/4inch)and2ange
nuts(1/4inch)asshowninFigure1.
g032352
Figure1
1.Hex-headscrews(1/4x
3/4inch)
3.Backupalarm
2.Flangenuts(1/4inch)4.Rearframe
2.Installthetieclipstothewireharnessand
securethetieclipsandwireharnesstotherear
frame(Figure2).
g032353
Figure2
1.Wireharness3.Rearframe
2.Tieclips
3.Insertthewireharnessintotheclamp(Figure3).
g032354
Figure3
1.Wireharness2.Clamp
4.Removetheboltandwasherlocatedunderneath
therearframe(Figure4).
g032355
Figure4
1.Rearframe3.Bolt
2.Washer
2

5.Securetheclampandwireharnesstotherear
framewiththeboltandwasherremovedinthe
previousstep(Figure5).
g032356
Figure5
1.Rearframe3.Washer
2.Clamp4.Bolt
6.Connectthemaleandfemaleconnectorsofthe
wireharnesstothemaleandfemaleterminals
ofthebackupalarm(Figure6).
g032357
Figure6
1.Femaleterminal—backup
alarm
3.Maleconnector—wire
harness
2.Maleterminal—backup
alarm
4.Femaleconnector—wire
harness
7.Connectthebackupalarmwireharnesstomain
machinewireharness.
8.Connectthepositivebatterycablefromthe
battery.
9.Connectthenegativebatterycablefromthe
battery.
InstallingtheBackupAlarm
Groundsmaster5900SeriesMachines
1.Coiltheharnessandsecureitwithacabletie
(Figure7).
2.InstallthebackupalarmasshowninFigure7.
g035700
Figure7
1.Hex-headscrews(1/4x
3/4inch)
4.Flangenut(1/4inch)
2.Cable-tiearoundthecoil5.Backupalarm
3.Wireharness
3.Connectthepositivebatterycablefromthe
battery.
4.Connectthenegativebatterycablefromthe
battery.
3
EnablingtheAlarminthe
InfoCenter
NoPartsRequired
EnablingtheAlarm
Groundsmaster4000and4100Series
Machines
Note:Forthebackupalarmtofunctionona
Groundsmaster4000and4100,installsoftware
versionKorgreater.
1.PresstheleftbuttontwicetogettotheMain
Menu(Figure8).
3

g020650
Figure8
1.Indicatorlight3.Middlebutton
2.Rightbutton4.Leftbutton
2.Unlocktheprotectedmenuasfollows:
A.FromtheMainMenu,scrolldowntothe
SettingsMenuandpresstherightbutton.
B.IntheSettingsMenu,scrolldowntothe
ProtectedMenuandpresstherightbutton.
C.Toenterthepasscode,usethecenter
buttontosettherstdigit,thenpressthe
rightbuttontomoveontothenextdigit.
D.Usethecenterbuttontosetthesecond
digit,thenpresstherightbuttontomoveon
tothenextdigit.
E.Usethecenterbuttontosetthethirddigit,
thenpresstherightbuttontomoveonto
thenextdigit.
F.Usethecenterbuttontosetthefourthdigit,
thenpresstherightbutton.
G.Pressthemiddlebuttontoenterthecode.
3.IntheSettingsMenu,scrolldowntoBackup
Alarm.
4.Presstherightbuttontoturnthealarmon.
5.Presstheleftbutton2timestoexit.
EnablingtheAlarm
Groundsmaster5900SeriesMachines
1.FromtheMainMenu,selecttheSettingsMenu.
Note:Holdtherightbuttonfor3secondstoget
totheMainMenu.
2.IntheSettingsMenu,selectDisplay.
3.IntheDisplayMenu,selectAlarms.
4.IntheAlarmsMenu,toggletheRevoptiontoOn.
4
CheckingtheBackupAlarm
NoPartsRequired
Procedure
Performthefollowingstepstoensurethatthebackup
alarmisworking:
1.TurnthekeyintheswitchtotheONposition.
Note:Donotstarttheengine.
2.Useyourheeltopressthebottomofthetraction
pedal.
3.Listenforthealarmsound.
4
