SERVICEMANUAL
MULTIFUNCTIONAL DIGITAL SYSTEMS
e-STUDIO165/205
File No. SME06001100
R060121B1400-TTEC
VerA_2006-02

April 2006 © TOSHIBA TEC e-STUDIO165/205 CONTENTS
1
CONTENTS
1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES ...................................1-1
1.1 Specifications.......................................................................................................................1-1
1.2 Accessories .........................................................................................................................1-5
1.3 Options ................................................................................................................................1-6
1.4 Supplies...............................................................................................................................1-7
1.5 System List..........................................................................................................................1-8
2. OUTLINE OF THE MACHINE.......................................................................................2-1
2.1 Sectional View.....................................................................................................................2-1
2.2 Electric Parts Layout............................................................................................................2-4
2.3 Symbols and Functions of Various Components...............................................................2-11
2.4 General Description...........................................................................................................2-15
2.4.1 System block diagram............................................................................................2-15
2.4.2 Construction of boards ...........................................................................................2-16
2.5 Disassembly and Replacement of Covers.........................................................................2-18
2.6 Disassembly and Replacement of PC boards...................................................................2-23
2.7 Removal and Installation of Options..................................................................................2-28
3. COPY PROCESS..........................................................................................................3-1
3.1 General Description of Copying Process.............................................................................3-1
3.2 Details of Copying Process..................................................................................................3-2
3.3 Comparison with e-STUDIO230/280.................................................................................3-13
4. GENERAL OPERATION...............................................................................................4-1
4.1 Overview of Operation.........................................................................................................4-1
4.2 Description of Operation......................................................................................................4-2
4.2.1 Warming-up..............................................................................................................4-2
4.2.2 Ready state (ready for copying) ...............................................................................4-2
4.2.3 Drawer feed copying ................................................................................................4-3
4.2.4 Bypass feed copying ................................................................................................4-4
4.2.5 Interruption copying..................................................................................................4-4
4.3 Detection of Abnormality......................................................................................................4-5
4.3.1 Types of abnormality................................................................................................4-5
4.3.2 Description of abnormality........................................................................................4-6
4.4 Flow Chart .........................................................................................................................4-11
4.4.1 Immediately after the power is turned ON..............................................................4-11
4.4.2 Automatic paper feed copying................................................................................4-13
5. CONTROL PANEL........................................................................................................5-1
5.1 General Description ............................................................................................................5-1
5.2 Items Shown on the Display Panel......................................................................................5-2
5.2.1 Display......................................................................................................................5-2
5.2.2 Message...................................................................................................................5-3
5.3 Relation between Equipment State and Operation..............................................................5-4
5.4 Operation.............................................................................................................................5-5
5.4.1 Block diagram...........................................................................................................5-5
5.4.2 LED display circuit....................................................................................................5-6
5.5 Disassembly and Replacement...........................................................................................5-7
6. SCANNER.....................................................................................................................6-1
6.1 General Description.............................................................................................................6-1
6.2 Construction.........................................................................................................................6-2
6.3 Functions.............................................................................................................................6-3
6.4 Description of Operation......................................................................................................6-5

e-STUDIO165/205 CONTENTS April 2006 © TOSHIBA TEC
6.4.1 Scanning operation ..................................................................................................6-5
6.4.2 Scan motor drive circuit............................................................................................6-6
6.5 Contact Image Sensor Unit Control Circuit..........................................................................6-8
6.5.1 Exposure LED control circuit....................................................................................6-8
6.5.2 CCD control circuit ...................................................................................................6-9
6.6 Automatic Original Size Detection Circuit..........................................................................6-12
6.6.1 Principle of original size detection..........................................................................6-12
6.6.2 Process of detection of original size.......................................................................6-13
6.7 Disassembly and Replacement.........................................................................................6-17
7. IMAGE PROCESSING..................................................................................................7-1
7.1 General Description.............................................................................................................7-1
7.2 Configuration .......................................................................................................................7-2
7.3 MAIN Board.........................................................................................................................7-3
7.3.1 Features ...................................................................................................................7-3
7.3.2 Functions of image processing circuit ......................................................................7-4
8. LASER OPTICAL UNIT ................................................................................................8-1
8.1 General Description.............................................................................................................8-1
8.2 Structure..............................................................................................................................8-2
8.3 Laser Diode Control Circuit..................................................................................................8-5
8.4 Polygonal Motor Control Circuit...........................................................................................8-6
8.5 Disassembly and Replacement...........................................................................................8-7
9. DRIVE UNIT ..................................................................................................................9-1
9.1 General Description.............................................................................................................9-1
9.2 Configuration .......................................................................................................................9-2
9.3 Functions ............................................................................................................................9-3
9.4 Main Motor Control Circuit...................................................................................................9-4
9.5 Disassembly and Replacement...........................................................................................9-6
10. PAPER FEEDING SYSTEM........................................................................................10-1
10.1 General Description...........................................................................................................10-1
10.2 Configuration .....................................................................................................................10-2
10.3 Functions...........................................................................................................................10-3
10.4 Operation...........................................................................................................................10-5
10.4.1 Drawer....................................................................................................................10-5
10.4.2 Bypass tray.............................................................................................................10-7
10.4.3 General operation...................................................................................................10-9
10.5 Disassembly and Replacement.......................................................................................10-10
11. DRUM RELATED SECTION.......................................................................................11-1
11.1 General Description...........................................................................................................11-1
11.2 Configuration .....................................................................................................................11-2
11.3 Functions...........................................................................................................................11-3
11.4 High-Voltage Output Control Circuit ..................................................................................11-5
11.4.1 General description ................................................................................................11-5
11.4.2 Description of Operation.........................................................................................11-6
11.5 Drum Temperature Detection Circuit.................................................................................11-7
11.5.1 General description ................................................................................................11-7
11.5.2 Circuit configuration................................................................................................11-7
11.6 Temperature/Humidity Detection Circuit............................................................................11-8
11.6.1 General Description................................................................................................11-8
11.6.2 Circuit configuration................................................................................................11-8
11.7 Disassembly and Replacement.........................................................................................11-9
12. DEVELOPMENT SYSTEM..........................................................................................12-1
12.1 General Description...........................................................................................................12-1

12.2 Construction.......................................................................................................................12-2
12.3 Functions...........................................................................................................................12-3
12.3.1 Function of each unit..............................................................................................12-3
12.3.2 Functions of the toner cartridge PC board (CTRG)................................................12-4
12.3.3 Recovered toner supply mechanism......................................................................12-6
12.4 Toner Motor Control Circuit ...............................................................................................12-7
12.5 Auto-Toner Circuit..............................................................................................................12-8
12.5.1 General description ................................................................................................12-8
12.5.2 Function of auto-toner sensor ................................................................................12-9
12.6 Disassembly and Replacement.......................................................................................12-11
13. FUSER / EXIT UNIT ....................................................................................................13-1
13.1 General Description...........................................................................................................13-1
13.2 Configurations....................................................................................................................13-2
13.3 Functions...........................................................................................................................13-3
13.4 Operation...........................................................................................................................13-5
13.5 Fuser Unit Control Circuit ..................................................................................................13-6
13.5.1 Configuration..........................................................................................................13-6
13.5.2 Temperature detection section...............................................................................13-7
13.6 Disassembly and Replacement.......................................................................................13-12
14. AUTOMATIC DUPLEXING UNIT (ADU) (OPTION: MD-0103) ..................................14-1
14.1 General Description...........................................................................................................14-1
14.2 Construction.......................................................................................................................14-2
14.3 Functions...........................................................................................................................14-3
14.4 Drive of ADU......................................................................................................................14-4
14.5 Description of Operation...................................................................................................14-5
14.6 Flow Chart .......................................................................................................................14-10
14.7 Disassembly and Replacement.......................................................................................14-11
15. POWER SUPPLY UNIT ..............................................................................................15-1
15.1 Construction.......................................................................................................................15-1
15.2 Operation of DC Output Circuit..........................................................................................15-2
15.3 Output Channel .................................................................................................................15-3
15.4 Fuse...................................................................................................................................15-4
15.5 Configuration of Power Supply Unit...................................................................................15-5
15.6 Power Supply Sequence ...................................................................................................15-6
15.7 AC Wire Harness...............................................................................................................15-7
16. PC BOARDS ...............................................................................................................16-1

1
April 2006 © TOSHIBA TEC e-STUDIO165/205 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES
1
1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES
1.1 Specifications
Copy process Indirect electrophotographic process (dry)
Type Desktop type
Original table Fixed type (the left rear corner used as guide to place originals)
 Accepted originals Sheet, book and 3-dimensional object. The automatic document feeder
(ADF) and reversing automatic document feeder (RADF), only accepts paper
which are not pasted or stapled. (Single-sided originals: 50 to 127 g/m2/13 to
34 lb. Bond) Carbon paper are not acceptable either.
Maximum size: A3/LD
 Copy speed (Copies/min.)
e-STUDIO165
e-STUDIO205
* “–” means “Not acceptable”.
* The copy speed in the above table are available when originals are manually placed for single side,
multiple copying.
* When the ADF and RADF are used, the copy speed of 16[20] sheets per minute is only available
under the following conditions:
• Original/Mode: Single side original/A4/LT size. APS/automatic density are not selected.
• Number of sheets: 16[20] or more.
• Reproduction ratio: 100%
Values in [ ] are for e- STUDIO205 in case that the specification is different among e-STUDIO165
and e-STUDIO205.
Paper size Drawer Bypass feed PFU
Size specified Size not specified
A4, B5, LT 16 16 11 16
A5-R, ST-R - 16 11 -
A4-R, B5-R, LT-R 15.5 15.5 11 15.5
B4, LG, FOLIO, COMPUTER 13 13 11 13
A3, LD 11 11 11 11
Paper size Drawer Bypass feed PFU
Size specified Size not specified
A4, B5, LT 20 20 11 20
A5-R, ST-R - 20 11 -
A4-R, B5-R, LT-R 15.5 15.5 11 15.5
B4, LG, FOLIO, COMPUTER 13 13 11 13
A3, LD 11 11 11 11

e-STUDIO165/205 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES April 2006 © TOSHIBA TEC
1 - 2
Copy speed for thick paper (Copies/min.)
e-STUDIO165/205
Thick 1 (81 g/m2to 105 g/m2, 21.3 lb. Bond to 28 lb. Bond)
Thick 2 (106 g/m2to 163 g/m2, 28 lb. Bond to 90 lb. Index)
 Copy paper
 First copy time .....................Approx. 7.6 sec. or less
(A4/LT, 100%, original placed manually)
 Warming-up time..................Approx. 25 sec. (temperature: 20°C)
 Multiple copying...................Up to 999 copies; Key in set numbers
 Reproduction ratio ...............Actual ratio: 100±0.5%
Zooming: 25 to 200% in increments of 1%
 Resolution/Gradation...........Scanning: 600 dpi x 600 dpi
Printing: Equivalent to 2400 dpi x 600 dpi
Gradation: 256 steps
Paper size Drawer Bypass feed PFU
Size specified Size not specified
A4, B5, LT - [-] 16 [18.5] 10.5 [10.5] - [-]
A5-R, ST-R - [-] 16 [18.5] 10.5 [10.5] - [-]
A4-R, B5-R, LT-R - [-] 14.5 [14.5] 10.5 [10.5] - [-]
B4, LG, FOLIO, COMPUTER - [-] 12 [12] 10.5 [10.5] - [-]
A3, LD - [-] 10.5 [10.5] 10.5 [10.5] - [-]
Paper size Drawer Bypass feed PFU
Size specified Size not specified
A4, B5, LT - [-] 16 [18.5] 10.5 [10.5] - [-]
A5-R, ST-R - [-] 16 [18.5] 10.5 [10.5] - [-]
A4-R, B5-R, LT-R - [-] 14.5 [14.5] 10.5 [10.5] - [-]
B4, LG, FOLIO, COMPUTER - [-] 12 [12] 10.5 [10.5] - [-]
A3, LD - [-] 10.5 [10.5] 10.5 [10.5] - [-]
Drawer PFU Bypass copy Remarks
Size A3, A4, A4-R, B4, B5,
B5-R, LD, LG, LT, LT-R,
FOLIO, COMPUTER,
13"LG, 8.5" x 8.5", 8K,
16K, 16K-R
A3 to A5-R, LD to ST-R, FOLIO, COM-
PUTER, 13"LG, 8.5" x 8.5", 8K, 16K,
16K-R
(Non-standard or user-specified sizes
can be set.)
Weight 64 to 80 g/m250 to 163 g/m2(Single paper feeding)
64 to 80 g/m2(Continuous feeding)
Special
paper – Tracing paper, labels, OHP film (thickness: 80 µm or thicker), These special papers rec- ommended by Toshiba Tec

1
April 2006 © TOSHIBA TEC e-STUDIO165/205 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES
1 - 3
 Eliminated portion................Leading edges: 3.0±2.0 mm, Side/trailing edges: 2.0±2.0 mm (copy)
Leading / trailing edges: 5.0±2.0 mm, Side edges: 5.0±2.0 mm (print)
Paper feeding.........................Standard drawer:
1 drawer (stack height 28 mm, equivalent to 250 sheets; 64 to
80 g/m2(17 to 22 lb. Bond))
Paper Feed Unit (PFU):
Option (One drawer: stack height 28 mm, equivalent to 250
sheets; 64 to 80 g/m2(17 to 22 lb. Bond))
Bypass feeding:
Stack height 11.8 mm: equivalent to 100 sheets; 64 to 80 g/m2
(17 to 22 lb. Bond)
Paper Feed Pedestal (PFP):
Option (One drawer or two: stack height 60.5 mm, equivalent to
550 sheets; 64 to 80 g/m2(17 to 22 lb. Bond))
Capacity of originals in the automatic document feeder (Option)
..................................................A3 to A5-R, LD to ST-R:
100 sheets / 80 g/m2(Stack height 16 mm or less)
Toner supply...........................Automatic toner density detection/supply
Toner cartridge replacing method (There is a recovered toner supply
mechanism.)
 Density control.....................Automatic density mode and manual density mode selectable in 7
steps
 Weight..................................Approximately 32 kg (70.55 lb.) (excluding the developer material and
toner)
 Power requirements.............AC 110 V / 13.2 A, 115 V or 127 V / 12 A
220-240 V or 240 V / 8 A (50/60 Hz)
* The acceptable value of each voltage is ±10%.
 Power consumption.............1.5 kW or less (100 V series)
1.6 kW or less (200 V series)
* The electric power is supplied to the ADF and RADF through the equipment.
 Total counter........................Electronical counter

SERVICEHANDBOOK
MULTIFUNCTIONAL DIGITAL SYSTEMS
e-STUDIO165/205
File No. SHE060005F0
R060121B1600-TTEC
Ver06_2006-11

© July 2006 TOSHIBA TEC e-STUDIO165/205 CONTENTS
CONTENTS
1. SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES ...................................1-1
1.1 Specifications.......................................................................................................................1-1
1.2 Accessories .........................................................................................................................1-4
1.3 Options ................................................................................................................................1-5
1.4 Supplies...............................................................................................................................1-6
1.5 System List..........................................................................................................................1-7
2. ERROR CODE AND SELF-DIAGNOSTIC MODE........................................................2-1
2.1 Error Code List.....................................................................................................................2-1
2.1.1 Jam...........................................................................................................................2-1
2.1.2 Service call...............................................................................................................2-3
2.2 Self-diagnosis Modes ..........................................................................................................2-4
2.2.1 Adjustment mode (05)..............................................................................................2-6
2.2.2 Setting mode (08)...................................................................................................2-23
2.2.3 Function test...........................................................................................................2-77
2.2.4 AUTO TEST ...........................................................................................................2-94
2.2.5 INDIVIDUAL TEST.................................................................................................2-95
2.2.6 TEST RESULT LIST ..............................................................................................2-96
2.2.7 Function test...........................................................................................................2-98
2.2.8 MAINTENANCE .....................................................................................................2-99
2.2.9 SERVICE LIST.....................................................................................................2-102
2.2.10 FUNCTION (Jam counter ROM ver.) ...................................................................2-105
2.2.11 RAM clear.............................................................................................................2-107
2.2.12 Country/Region code............................................................................................2-109
3. ADJUSTMENT ..............................................................................................................3-1
3.1 Adjustment of Auto-Toner Sensor .......................................................................................3-1
3.2 Image Dimensional Adjustment...........................................................................................3-3
3.2.1 General description ..................................................................................................3-3
3.2.2 Paper alignment at the registration roller .................................................................3-5
3.2.3 Printer related adjustment ........................................................................................3-7
3.2.4 Scanner related adjustment ...................................................................................3-11
3.3 Image Quality Adjustment (Copying Function)..................................................................3-19
3.3.1 Density adjustment.................................................................................................3-19
3.3.2 Gamma slope adjustment ......................................................................................3-20
3.3.3 Sharpness adjustment............................................................................................3-21
3.3.4 Setting range correction .........................................................................................3-22
3.3.5 Setting range correction (Adjustment of background peak) ...................................3-22
3.3.6 Setting range correction (Adjustment of text peak) ................................................3-23
3.3.7 Adjustment of smudged/faint text...........................................................................3-23
3.3.8 Adjustment of image density ..................................................................................3-24
3.4 Image Quality Adjustment (Printing Function)...................................................................3-25
3.4.1 Adjustment of smudged/faint text...........................................................................3-25
3.4.2 Adjustment of image density ..................................................................................3-26
3.4.3 Gamma balance adjustment ..................................................................................3-28
3.5 Image Quality Adjustment (Scanning Function) ................................................................3-29
3.5.1 Density adjustment.................................................................................................3-29
3.5.2 Sharpness adjustment............................................................................................3-30
3.5.3 Setting range correction .........................................................................................3-31
3.5.4 Setting range correction (Adjustment of background peak) ...................................3-31
3.5.5 Setting range correction (Adjustment of text peak) ................................................3-32
3.6 Adjustment of High-Voltage Transformer ..........................................................................3-33
3.6.1 Adjustment .............................................................................................................3-33

e-STUDIO165/205 CONTENTS © July 2006 TOSHIBA TEC
2
3.6.2 Precautions ............................................................................................................3-39
3.7 Adjustment of the Scanner Section ...................................................................................3-41
3.7.1 CIS unit...................................................................................................................3-41
3.7.2 CIS unit drive belt-1................................................................................................3-41
3.7.3 Scan motor (CIS unit drive belt-2)..........................................................................3-42
3.8 Adjustment of the Paper Feeding System.........................................................................3-43
3.8.1 Sheet sideways deviation caused by paper feeding ..............................................3-43
3.9 Adjustment of Developer Unit............................................................................................3-44
3.9.1 Doctor-to-sleeve gap..............................................................................................3-44
3.10 Adjustment of the ADF/RADF (MR-2017/3019).................................................................3-47
3.10.1 Adjustment of ADF/RADF Position.........................................................................3-47
3.10.2 Adjustment of ADF/RADF Height...........................................................................3-52
3.10.3 Adjustment of Skew................................................................................................3-54
3.10.4 Adjustment of the Leading Edge Position ..............................................................3-57
3.10.5 Adjustment of Horizontal Position ..........................................................................3-59
3.10.6 Adjustment of Copy Ratio.......................................................................................3-60
3.10.7 Adjustment of ADF/RADF Opening/Closing Sensor...............................................3-61
4. PREVENTIVE MAINTENANCE (PM)............................................................................4-1
4.1 General Descriptions for PM Procedure..............................................................................4-1
4.2 Operational Items in Overhauling........................................................................................4-2
4.3 Preventive Maintenance Checklist.......................................................................................4-3
4.4 PM KIT...............................................................................................................................4-13
4.5 Jig List ...............................................................................................................................4-14
4.6 Grease List ........................................................................................................................4-15
4.7 Precautions for Storing and Handling Supplies.................................................................4-16
4.7.1 Precautions for storing TOSHIBA supplies ............................................................4-16
4.7.2 Checking and cleaning of photoconductive drum...................................................4-17
4.7.3 Checking and cleaning of drum cleaning blade......................................................4-18
4.7.4 Checking and cleaning of fuser roller and pressure roller......................................4-18
5. TROUBLESHOOTING ..................................................................................................5-1
5.1 Diagnosis and Prescription for Each Error Code.................................................................5-1
5.1.1 Paper transport jam..................................................................................................5-1
5.1.2 Paper misfeeding .....................................................................................................5-7
5.1.3 Cover open jam......................................................................................................5-12
5.1.4 Transport jam (ADF)...............................................................................................5-14
5.1.5 Drive system related service call............................................................................5-17
5.1.6 Paper feeding system related service call..............................................................5-18
5.1.7 Scanning system related service call .....................................................................5-20
5.1.8 Fuser unit related service call.................................................................................5-21
5.1.9 ADF related service call .........................................................................................5-23
5.1.10 Laser optical unit related service call .....................................................................5-23
5.1.11 Service call for others.............................................................................................5-24
5.2 Troubleshooting for the Image...........................................................................................5-25
5.3 Replacement of PC Boards...............................................................................................5-47
5.3.1 Replacing MAIN board ...........................................................................................5-47
5.3.2 Replacing SRAM board..........................................................................................5-47
6. FIRMWARE UPDATING ...............................................................................................6-1
6.1 Firmware Updating with Download Jig ................................................................................6-1
6.1.1 PWA-DWNLD-350-JIG.............................................................................................6-3
6.1.2 Writing the data to the download jig (PWA-DWNLD-350-JIG) .................................6-7
6.1.3 K-PWA-DLM-320......................................................................................................6-9
6.2 Firmware Updating with TOSHIBA Viewer........................................................................6-10
6.3 Firmware Updating with USB Storage Device (When GA-1190/GA-1200 is installed)......6-13

© July 2006 TOSHIBA TEC e-STUDIO165/205 CONTENTS
7. POWER SUPPLY UNIT ................................................................................................7-1
7.1 Output Channel ...................................................................................................................7-1
7.2 Fuse.....................................................................................................................................7-2
7.3 Configuration of Power Supply Unit.....................................................................................7-3
8. SERVICE NOTIFICATION ............................................................................................8-1
8.1 Outline .................................................................................................................................8-1
8.2 Setting .................................................................................................................................8-2
8.3 Items to be notified ..............................................................................................................8-3
9. WIRE HARNESS CONNECTION..................................................................................9-1
9.1 AC Wire Harness.................................................................................................................9-1
9.2 DC Wire Harness....................................................................................................... Appendix
9.3 Electric Parts Layout..................................................................................................Appendix

PCBOARDREPAIRMANUA
MULTIFUNCTIONAL DIGITAL SYSTEM
e-STUDIO163/165/203/205
e-STUDIO166/167/206/207/237
File No. RME050003A0
R05092196500-TTEC
Ver01_2007-03

© June 2006 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO163/165/166/167/203/205/206/207/237
CONTENTS
1
CONTENTS
1. SYSTEM BLOCK DIAGRAM........................................................................................1-1
1.1 e-STUDIO163/166/203/206.................................................................................................1-1
1.2 e-STUDIO165/205...............................................................................................................1-2
1.3 e-STUDIO167/207/237........................................................................................................1-3
2. GENERAL DESCRIPTION OF MAIN IC.......................................................................2-1
2.1 ASIC (EC/N106) ..................................................................................................................2-1
2.1.1 Functions..................................................................................................................2-1
2.1.2 Pin assignment.........................................................................................................2-1
2.1.3 Signals......................................................................................................................2-2
3. ELECTRIC CIRCUIT DIAGRAMS.................................................................................3-1
3.1 Main circuit (MAIN board: e-STUDIO163/165/203/205)......................................................3-2
3.2 SRAM circuit (SRAM board: e-STUDIO163/165/203/205)................................................3-36
3.3 Laser drive circuit (LDR board)..........................................................................................3-37
3.4 H-sync signal detection circuit (SNS board)......................................................................3-39
3.5 Fuse circuit (FUS board)....................................................................................................3-40
3.6 Control panel circuit (LPNL board: e-STUDIO163/166/203/206).......................................3-41
3.7 Control panel circuit (HPNL board: e-STUDIO165/205)....................................................3-45
3.8 Paper feed control circuit (PFC board: GH-1050)..............................................................3-49
3.9 Facsimile circuit (FAX board: GD-1220)............................................................................3-53
3.10 Telephone line network control circuit (NCU board: GD-1220NA/TW)..............................3-58
3.11 Telephone line network control circuit (NCU board: GD-1220EU/AU) ..............................3-60
3.12 TELBOOK circuit (TELBOOK board: GJ-1040).................................................................3-62
3.13 External keyboard circuit (OTK board: GJ-1040)...............................................................3-63
3.14 Memory circuit (MEM board: GC-1240).............................................................................3-64
3.15 Main circuit (MAIN board: e-STUDIO166/206)..................................................................3-65
3.16 Main circuit (MAIN board: e-STUDIO167/207/237)...........................................................3-99
3.17 SRAM circuit (SRAM board: e-STUDIO166/167/206/207/237).......................................3-134
3.18 Control panel circuit (HPNL board: e-STUDIO167/207/237)...........................................3-135
3.19 Paper feed control circuit (PFC board: GH-1060)............................................................3-139
07/03

Date: July 7, 2006
Page: 1 of 10
Models: e-STUDIO 165 / 205
Subject: SERVICE PARTS LIST
Overview
Because the e-STUDIO165/205 uses the same frame as the e-STUDIO163, a
unique parts list will not be created for this product. This document describes and
illustrates only those e-STUDIO165/205 parts that differ from the e-STUDIO163.
Detail
See attached pages.
Copyright-2006 Toshiba America Business Solutions, Inc. (TABS). This publication contains proprietary and confidential
information retained for reference purpose by authorized TABS dealers. Unauthorized use of this information is prohibited.
TABS makes no express or implied warranty, including implied warranties of merchantability for a particular purpose, with regard
to this technical publication and disclaims any claim arising by reason of the possession or use thereof.
9Copier Bulletin: DIG-1 4

e-STUDIO165/205 CONTROL-PANEL-ASY
1
2
3
4
6
7
8
9
7
18
19
14
11
15 16
12 13
17
24
20
23
22
21
101
101
101
100 100
100 100
100
101 101
103
103 103
103
103
5
10
25
101
26 B
B
A
A
APRIL 2006

MULTIFUNCTIONAL DIGITAL SYSTEM
File No. PLE050045000
e-STUDIO163/203

CONTENTS
COVER-1-ASY............................................ 1
COVER-2-ASY............................................ 2
COVER-3-ASY............................................ 3
CONTROL-PANEL-ASY.............................. 4
BASE-FRAME-ASY..................................... 5
FRONT-FRAME-ASY.................................. 6
REAR-FRAME-ASY .................................... 7
STAY-ASY ................................................... 8
OPTICAL-FRAME-ASY............................... 9
OPTICAL-DRIVE-ASY .............................. 10
COVER-GUIDE-ASY................................. 11
MAIN-DRIVE-ASY..................................... 12
BYPASS-ASY............................................ 13
BYPASS-FEEDER-ASY ............................ 14
GUIDE-ALIGNING-ASY ............................ 15
ALIGNING-ASY......................................... 16
PLATEN-ASY ............................................ 17
MAIN-CHARGER-ASY.............................. 18
TRANSPORT-CHARGER-ASY................. 19
CLEANER-ASY......................................... 20
DEVELOPER-ASY .................................... 21
RECYCLE-ASY......................................... 22
FUSER-1-ASY........................................... 23
FUSER-2-ASY........................................... 24
DRAWER-ASY .......................................... 25
JIGS & GREASE..................................... 101
DOWNLOAD JIGS .................................. 102
SUPPLIES............................................... 103
REPLACE UNIT ...................................... 104
PM-KIT .................................................... 105

1
e-STUDIO163/203 DECEMBER 2005
8
7
102
102
102
102
102
102
101
102
105
102
104
104
104
104
19
102
104
104
104
104
104
102
17
16
14
15
20
13
10
11
12
1
2
3
6
5
4
9
18
A
A
COVER-1-ASY
