Toshiba RUAGP Series User manual

Original instructions
30KQA060-01ISE
Universal Smart Ｘ
Safety Precautions
Original Owner’s Manual
Thank you very much for purchasing this Toshiba heat pump unit.
Please read this instruction manual carefully before using the unit. Be sure to obtain
the “Instruction manual” and “Installation manual” from constructor or dealer.
Request to constructor or dealer; Please clearly explain the contents of this
instruction manual and hand over it.
This unit is not intended for use by person (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the unit
by a person responsible for their safety.
Fluorocarbon must be recovered in accordance with the local laws and regulations
when the product is repaired or thrown away. Type and volume of refrigerant and
conversion values for CO2 are listed.
Keep this manual after you finish reading it.
Please read carefully through these instructions that contain important information
which complies with the “Machinery Directive 2006/42/EC”, and ensure that you
understand them.
This unit is only for industrial uses. And this unit is not usable in residential use.
A
ir-Cooled Chiller
Model Name: RUAGP Series

Contents
Safety Precautions................................................................................................................................. 4
List of Equipment •Configuration of Heat Pump.................................................................................. 9
Dimensional drawings (Integrated inverter pump, pumpless) .............................................................. 11
Control box layout diagram .................................................................................................................. 14
High EER Type Drainage ..................................................................................................................... 15
Module Controller................................................................................................................................. 18
Unit Controller ...................................................................................................................................... 35
Unit Controller (with pressure display function).................................................................................... 39
Main Functions..................................................................................................................................... 42
Control Flow......................................................................................................................................... 47
Refrigerant piping drawings ................................................................................................................. 62
Operating Standard and Operating Range........................................................................................... 64
Component Rating ............................................................................................................................... 67
High EER Type..................................................................................................................................... 68
Maintenance and Inspection ................................................................................................................ 71
Water Heat Exchanger Maintenance ................................................................................................... 75
Pump Maintenance .............................................................................................................................. 76
Water Quality Management.................................................................................................................. 77
Precautions When Operation Is Stopped ............................................................................................. 78
Troubleshooting ................................................................................................................................... 79

- 1 -
Original instructions
Generic Denomination : Heat Pump Unit
Definition of Qualified Installer or Qualified Service Person
The heat pump unit (called "unit" hereafter) must be installed, maintained, repaired and removed by a
qualified installer or qualified service person. When any of these jobs is to be done, ask a qualified
installer or qualified service person to do them for you. A qualified installer or qualified service person is
an agent who has the qualifications and knowledge described in the table below.
.
A
gent Qualifications and knowledge which the agent must have
Qualified installer
The qualified installer is a person who installs, maintains and removes the
units made by Toshiba Carrier Corporation. He or she has been trained to
install, maintain and remove the units made by Toshiba Carrier Corporation
or, alternatively, he or she has been instructed in such operations by an
individual or individuals who have been trained and is thus thoroughly
acquainted with the knowledge related to these operations.
The qualified installer who is allowed to do the electrical work involved in
installation and removal has the qualifications pertaining to this electrical work
as stipulated by the local laws and regulations, and he or she is a person who
has been trained in matters relating to electrical work on the units made by
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in
such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
The qualified installer who is allowed to do the refrigerant handling and piping
work involved in installation and removal has the qualifications pertaining to
this refrigerant handling and piping work as stipulated by the local laws and
regulations, and he or she is a person who has been trained in matters relating
to refrigerant handling and piping work on the units made by Toshiba Carrier
Corporation or, alternatively, he or she has been instructed in such matters by
an individual or individuals who have been trained and is thus thoroughly
acquainted with the knowledge related to this work.
The qualified installer who is allowed to work at heights has been trained in
matters relating to working at heights with the units made by Toshiba Carrier
Corporation or, alternatively, he or she has been instructed in such matters by
an individual or individuals who have been trained and is thus thoroughly
acquainted with the knowledge related to this work.
Qualified service
person
The qualified service person is a person who installs, repairs, maintains and
removes the units made by Toshiba Carrier Corporation. He or she has been
trained to install, repair, maintain and remove the units made by Toshiba
Carrier Corporation or, alternatively, he or she has been instructed in such
operations by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to these operations.
The qualified service person who is allowed to do the electrical work involved
in installation, repair and removal has the qualifications pertaining to this
electrical work as stipulated by the local laws and regulations, and he or she is
a person who has been trained in matters relating to electrical work on the
units made by Toshiba Carrier Corporation or, alternatively, he or she has
been instructed in such matters by an individual or individuals who have been

- 2 -
trained and is thus thoroughly acquainted with the knowledge related to this
work.
The qualified service person who is allowed to do the refrigerant handling and
piping work involved in installation, repair and removal has the qualifications
pertaining to this refrigerant handling and piping work as stipulated by the local
laws and regulations, and he or she is a person who has been trained in
matters relating to refrigerant handling and piping work on the units made by
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in
such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
The qualified service person who is allowed to work at heights has been
trained in matters relating to working at heights with the units made by
Toshiba Carrier Corporation or, alternatively, he or she has been instructed in
such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.

- 3 -
Warning indications on the heat pump unit
Warning indication Description
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote electric power supplies before
servicing.
WARNING
Moving parts.
Do not operate unit with grille removed.
Stop the unit before the servicing.
CAUTION
High temperature parts.
You might get burned when removing this panel.
CAUTION
Do not touch the aluminum fins of the unit.
Doing so may result in injury.
Do not touch the aluminum
fins of the unit.
D oing so may re sul t in i njury.
CAUTION
High temperature parts.
You might get bur ned
when removing this panel.
CAUTION
Moving parts.
Do not operate unit with grille
removed.
Stop the unit before the servicing.
WARNING
ELECTR ICAL SHOCK HAZARD
Dis connect all re mote electric
power supplies before
servicing.
WARNING

- 4 -
The manufacturer shall not assume any liability for the damage caused by not observing the
description of this manual.
WARNING
General
• Carefully read Instruction Manual before starting the unit. There are many important things to
keep in mind for daily operation. Otherwise, falling down of the unit may occur, or the unit may
cause noise, vibration or water leakage.
• Ask for installation to be performed by the dealer or a professional. Only a qualified installer
(*1) is able to install a unit. If a non-qualified person installs a unit, it may result in problems
such as fire, electric shock, injury, water leakage, noise and/or vibration.
• Take measures to prohibit persons other than those concerned from entering the area where
the unit is installed.
• Be sure to use the company-specified products for the separately purchased parts. Use of
non-specified products may result in fire, electric shock, water leakage, etc. Have the
installation performed by a professional.
• Do not use any refrigerant different from the one specified for complement or replacement.
Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may
result in a failure or explosion of the product or an injury to your body. The refrigerant used by
this unit is the R32.
• Before opening the service panel of the unit, set the circuit breaker to the OFF position, lock
the circuit breaker in the OFF position, place a "work in progress" sign near the circuit breaker,
and wait for 10 minutes to discharge the capacitors completely. Failure to set the circuit
breaker to the OFF position and wait for 10 minutes to discharge the capacitors may result in
electric shocks through contact with the interior parts. Only a qualified installer (*1) or qualified
service person (*1) is allowed to remove the service panel of the unit and do the work
required.
• Use of a stand more than 50 cm high to clean the body of the unit or to carry out other such
jobs constitutes working at heights. Due to the danger of falling off the stand and injuring
yourself while working at heights, this kind of work should not be done by unqualified
individuals. When this kind of work must be carried out, do not do it yourself but ask a qualified
installer or a qualified service person to do it for you.
• Do not touch the aluminum fin of the unit. You may injure yourself if you do so. If the fin must
be touched, do not touch it yourself but contact a qualified installer or a qualified service
person.
• Do not climb onto or place objects on top of the unit. You may fall or the objects may fall off of
the unit and result in injury.
• Do not disassemble, modify, repair or move the product yourself. Doing so may cause fire,
electric shock, injury or water leaks. Ask a qualified installer or qualified service person to do
any repairs or to move the product.
• Using FlashAir make any other machines having problem, deattached FlashAir at once
• Carefully read Instruction Manual before starting the unit. There are many important things to
keep in mind for daily operation.
Transportation and storage
• When transporting the unit, wear shoes with protective toe caps, injury protection gloves with
non-slip function and long sleeved working clothes.
• When transporting the unit, do not take hold of the packing materials. You may injure yourself
if the packing materials should break.
Safety Precautions

- 5 -
• When storing or transporting the unit, heed the precautions written on the packages. Failure
to heed the precautions may cause the unit to be damaged.
• You shall ensure that the unit is transported in stable condition. If you find any part of the
product broken, contact your dealer.
• When storing or transporting the unit, be sure to place the ambient temperature of the unit
within a range of -20 to +60°C.
Selection of installation location
• If you install the unit in a small and/or closed room, take appropriate measures to prevent the
refrigerant from exceeding the limit concentration even if it leaks. Consult the dealer from
whom you purchased the unit when you implement the measures. Accumulation of highly
concentrated refrigerant may cause an oxygen deficiency accident.
• Do not install in a location where flammable gas may leaks are possible. If the gas should
leak and accumulate around the unit, it may ignite and cause a fire.
• Do not provide with permanent scaffolds to easily access to the fans on the top of the unit.
There is a risk of an injury due to the rotating parts.
• Do not place any combustion appliance in a place where it is directly exposed to the wind of
unit, otherwise it may cause imperfect combustion.
• Places where the operation sound of the unit may cause a disturbance. (Especially at the
boundary line with a neighbor, install the unit while considering the noise.)
Installation
• Follow the instructions in the Installation Manual to install the unit. Failure to follow these
instructions may cause the product to fall down or topple over or give rise to noise, vibration,
water leakage or other failure.
• Confirm that the unit is fixed on the base. Otherwise, falling down of the unit or other
accidents may occur.
• After the installation work has been completed, have the installer explain about the circuit
breaker positions. In the event that error has occurred in the unit, set the circuit breaker to
the OFF position, and contact a service person.
Refrigerant piping
• Only a qualified installer (*1) or qualified service person (*1) is allowed to carry out the
welding work of the unit. Under no circumstances must this work be done by an unqualified
individual since failure to carry out the work properly may result in refrigerant leaks.
• Using the service port to charge and discharge the refrigerant. In case of using the other, it
causes overcharge, leak, uncontrollable the refrigerant and unsafe connection and
disconnection.
Electrical wiring
• Only a qualified installer (*1) or qualified service person (*1) is allowed to carry out the
electrical work of the unit. Under no circumstances must this work be done by an unqualified
individual since failure to carry out the work properly may result in electric shocks and/or
electrical leaks.
• Confirm that earthing is performed correctly.
Water piping
• Only a qualified installer (*1) or qualified service person (*1) is allowed to carry out the water
piping work of the unit. Under no circumstances must this work be done by an unqualified
individual since failure to carry out the work properly may result in water leakage.

- 6 -
• When a water supply pipe is connected to the system, relevant local ordinances and
standards must be followed. The improper pipe connection may cause water leakage, etc.
Ask a qualified installer (*1) or qualified service person (*1) to carry out the water piping work.
Operation
• Inside the unit are high-voltage areas and rotating parts. Due to the danger of electric shocks
or of your fingers or physical objects becoming trapped in the rotating parts, do not remove
the service panel of the unit. When work involving the removal of these parts is required,
contact a qualified installer or a qualified service person.
• Fix all of the service panels firmly in place. There are component parts with pressurized gas
and/or high voltage inside the unit. If the panels are opened by accident, an injury and
electric shocks may occur.
• When the unit is operated with a combustion appliance in the same place, be careful of
ventilation to let fresh air enter the room. Poor ventilation causes oxygen shortage.
• When the unit is used in a closed room, be careful of sufficient ventilation of the room. Poor
ventilation causes oxygen shortage.
• Do not expose your body to exhaust air directly for a long time and do not cool or heat
yourself excessively. Doing so may result in deteriorated physical condition and ill health.
• Never insert your finger or a stick into the air discharge. Doing so may result injury as the fan
is rotating at high speed inside the unit.
• Consult the shop where you purchased the unit if water temperature control (cooling and
heating) is not performed properly as a refrigerant leakage may be the cause. Confirm the
repair details with a qualified service person (*1) when the repair includes additional charging
of the refrigerant.
• Be sure to stop running the unit and turn off the circuit breaker before cleaning. Otherwise, a
fire, electric shocks, injury may result.
• Do not insert a finger, stick and so on into the fans and pump.
Repairs
• When you have noticed that some kind of error (such as when an error display has appeared,
there is a smell of burning, abnormal sounds are heard, the unit fails to cool or heat or water
is leaking) has occurred in the unit, do not touch the unit yourself but lock the circuit breaker
in the OFF position, place a "out of service" sign near the circuit breaker, and contact a
qualified service person. Continuing to use the unit in the error status may cause mechanical
problems to escalate or result in electric shocks, etc.
• If you have discovered that the fan grille is damaged, do not approach the unit but set the
circuit breaker to the OFF position, lock the circuit breaker in the OFF position, place a "out
of service" sign near the circuit breaker, and contact a qualified service person to have the
repairs done. Do not set the circuit breaker to the ON position until the repairs are completed.
• If you have discovered that there is a danger of the unit’s toppling over, do not approach the
unit but set the circuit breaker to the OFF position, lock the circuit breaker in the OFF position,
place a "out of service" sign near the circuit breaker, and contact a qualified installer or a
qualified service person to have the improvements or refitting done. Do not set the circuit
breaker to the ON position until the improvements or refitting is completed.
• Do not customize the unit. Doing so may result in fire, electric shock, etc.
• Ensure sufficient ventilation when making repairs indoors. Refrigerant leakage with poor
ventilation may cause an accident such as oxygen shortage.

- 7 -
Removal
• Do not relocate the unit because this unit is one component part installed in the specified
fixed equipment as an interpretation of the EMC Directive.
• When the unit is to be removed, do not remove it yourself but contact a qualified installer or a
qualified service person. Failure to remove the unit properly may result in a fire, electric
shocks, injury, water leakage, and/or refrigerant leakage.
• Be sure to use a refrigerant recovery machine to recover the refrigerant when removing or
repairing.
• Only a qualified installer or qualified service person is allowed to remove the unit. It is
dangerous for the unit to be removed by an unqualified individual since a fire, electric shocks,
injury, water leakage, and/or refrigerant leakage may result.
(When the unit is to be removed, do not remove it yourself but contact a qualified installer or
a qualified service person. Failure to remove the unit properly may result in a fire, electric
shocks, injury, water leakage, and/or refrigerant leakage.)
CAUTION
To disconnect the appliance form the main supply
• This appliance must be connected to the mains power supply by means of an circuit breaker
with a contact separation of at least 3 mm.
New refrigerant
• This unit adopts the new HFC refrigerant (R32) which does not destroy ozone layer.
• The characteristics of R32 refrigerant are; easy to absorb water, oxidizing membrane or oil,
and its pressure is approx. 1.6 times higher than that of refrigerant R22. Accompanied with
the new refrigerant, refrigerating oil has also been changed. Therefore, during repair work,
be sure that water, dust, former refrigerant, or refrigerating oil does not enter the refrigerating
cycle.
• To prevent charging an incorrect refrigerant and refrigerating oil, the sizes of connecting
sections of charging port of the main unit and installation tools are changed from those for
the conventional refrigerant.
• Accordingly the exclusive tools are required for the new refrigerant (R32).
• For connecting pipes, use new and clean piping designed for R32, and please care so that
water or dust does not enter.
Installation
• Certainly lay the drain pipe for perfect draining. Bad drainage may cause flooding around the
unit and getting ground wet.
• Make sure to connect the unit to an exclusive power supply of the rated voltage, otherwise
the unit may break down or cause a fire.
• After the installation work has been completed, have the installer explain about the circuit
breaker positions. In the event that error has occurred in the unit, set the circuit breaker to
the OFF position, and contact a service person.
Operation
• Do not use this unit for special purpose such as preserving food, precision instruments, art
objects, breeding animals, car, vessel, etc.
• Do not touch any switches with wet finger, otherwise you may get an electric shock.
• If the unit will not be used for a considerably long time, turn off the circuit breaker, for safety.
In addition, bleed the pipe of water or fill with antifreeze solution in the pipe to prevent
breakage caused by freezing.

- 8 -
• To make the unit operate in its original performance, operate it within the range of the
operating temperature specified in the instructions. Otherwise it may cause a malfunction.
• Do not wash the unit. Doing so may result in electric shock.
• Check whether the installation base and other equipment have become deteriorated after
being used for a long time. Leaving them such condition may result in the unit’s falling down
and causing injury.
• Do not leave flammable sprays or other flammable materials near the unit, and do not spray
flammable aerosol directly to the unit. They may catch fire.
• Do not put a water container such as a vase on the unit. Water intrusion into the unit may
occur and it may cause deterioration of electric insulation and result in electric shock.
• Ask for cleaning of the unit to be performed by the dealer. Cleaning the unit in an improper
manner may cause damage to plastic parts, insulation failure of electric parts, etc. and result
in a malfunction. In the worst case, it may result in water leakage, electric shock, smoke
emission and fire.
• Do not wash units with pressure washers. Electric leaks may cause electric shocks or fires.
• Do not short-circuit the protective devices to operate the unit forcibly and do not change the
settings on the protective devices. Doing so may cause a fire or explosion.
• Do not start and stop the unit by turning the circuit breaker ON and OFF. Doing so may
cause a fire and electric shocks.
• Do not fill the fusible plug on the refrigerant pipe with solder, etc. Doing so may cause an
explosion.
• Do not install the unit in a location in which the exhaust air blows directly on plants and
animals. Doing so may adversely affect the plants and animals.
• Do not place objects on the unit. Falling of the objects may cause an injury.
• Do not use any other heat medium except water including water with antifreeze solution.
Doing so may cause a fire or explosion.
• Use water that meets the water quality standards. Lower water quality may cause capacity
shortage and water leakage.
• Do not drink the water. Doing so may adversely affect your health.
Repairs
• Releasing fluorocarbons into the atmosphere is prohibited. The fluorocarbons in the unit
must be recovered when doing repair or removal.
• Dispose of special brine such as antifreeze solution according to legal regulations. Do not
connect any special brine drain pipes to water drain pipes.
• Use only fuses with the correct capacity. Use of wires may cause a fire.
• Do not touch the hot parts of the compressors and refrigerant pipes. You may burn yourself if
you touch the hot parts.

- 9 -
List of Equipment (standard line-up and capacities)
(common to integrated inverter pump and pumpless)
Reading a model name
List of Equipment • Configuration of Heat Pump
Universal Smart X EDGE(R32)
Air-cooled chiller
Cooling Capacity USRT
42: 42RT / 150kW / 50HP
51: 51RT / 180kW / 60HP
56: 56RT / 200kW / 70HP Version No.
Classification Code for Destination
C: China
E: Europe
K: Korea
S: South East Asia model
Thailand, Indonesia, India, Vietnam, Singapore, Philippine,
Brunei, Taiwan, Sri Lanka, Nepal, Bhutan, Cambodia,
Bangladesh, Malaysia, Myanmar, Laos, Moldiv, Australia
(Total: 18 countries)
* For other countries, the regulations need to be confirmed.
TR: Turkey
Type of refrigerant cycle
C: Cooling Only
H: Heat pump (for both cooling and heating)
F: High heating capacity model
None: Standard type
**: See next page
Type of pump
1: Pre-installed inverter Pump (Pump Output : 1.5kW)
2: Pre-installed inverter Pump (Pump Output : 2.2kW)
3: Pre-installed inverter Pump (Pump Output : 3.7kW)
5: Pre-installed inverter Pump (Pump Output : 5.5kW)
7: Pre-installed inverter Pump (Pump Output : 7.5kW)
L: Pumpless
Power Supply
3: 3ph 50/60Hz 380V
4: 3ph 50/60Hz 400V
5: 3ph 50/60Hz 415V
6: 3ph 60Hz 440V
8: 3ph+N 50/60Hz 380V
ＲＵＡGＰ５１１ＨＬＺG3TR
Unit
- 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Hors e
power
50 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800
Cooling
Capa city
Heating
Capa city
Coolin g o nly
Cooling
Capa city
Cooling
Capa city
Heating
Capa city
Hors e
power
60 120 180 240 300 360 420 480 540 600 660 720 780 840 900 960
Cooling
Capa city
Heating
Capa city
Coolin g o nly
Cooling
Capa city
Cooling
Capa city
180 360 540 720 900 1080 1260 1440 1620 1800 1980 2160 2340 2520 2700 2880
Heating
Capa city
200 400 600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200
Hors e
power
70 140 210 280 350 420 490 560 630 700 770 840 910 980 1050 1120
Cooling
Capa city
Heating
Capa city
Coolin g o nly
Cooling
Capa city
24001500 1650 1800 1950 2100 2250
2400
50HP
(powerful
heating type)
Standard type
High EER type Heat pump
kW 150 300 450 600 750
1500 1650 1800 1950 2100 2250
3000 3200
Horse power
50HP Standard type
High EER type
Heat pump
kW 150 300 450
1800 2000 2200 2400 2600
600
2800600 800 1000 1200 1400 1600
70HP Standard type
High EER type
Heat pump
kW 200 400
2880
60HP
(powerful
heating type)
Standard type
High EER type Heat pump
kW
Horse power
1800 1980 2160 2340 2520 2700720 900 1080 1260 1440 1620
Horse power
60HP Standard type
High EER type
Heat pump
kW 180 360 540
900 1050 1200 1350
Item
Number of modules
1350750 900 1050 1200

- 10 -
Configuration of Heat Pump
Note)One module controller can control up to 16 modules
.
code High EER
type
Brine
specifications
Resistance
to salt
High
resistance
to salt
N●
R●
Z●
ZG ●
NR ● ●
NZ ● ●
NG ● ●
RZ ● ●
RG ● ●
WZ ● ● ●
WG ● ● ●
Module (up to 16)
Module controller

- 11 -
Standard type_50HP, 60HP
Standard type_70HP
73
170
230
1000
339
62
178
500
760
254
510
545
28
75
2350
998
109
34
470
1
2
8
4
5
7
10
3
69
269
950
2366
181
90
20
2960
3300
25
339
3000
500
3030
A
116
77060
11
1
2
3
4
7
6
5
8
9
10
11
73
170
230
1000
339
62
178
500
760
254
510
545
28
75
2350
998
109
34
470
1
2
8
4
5
7
3
6
9
269
950
2366
181
90
20
2960
3300
339
3000
500
3030
A
116
77060
10
11
25
1
2
3
4
7
6
5
8
9
10
11
Dimensional drawings
(Integrated inverter pump, pumpless)
WATER INLET
NAME
No. JOINT
2-1/2" FLANGE
2-1/2" FLANGE
PT1-1/2" EXTERNAL THREAD
PT1/2" INTERNAL THREAD
CASING: Equivalent to FC250
CASING: Equivalent to FC200
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
CASING: FC200
Equivalent to SUS316
PURE COPPER
EPDM
WATER OUTLET
WATER
PIPING (INLET)
PLATE, JOIN
T
WATER
PIPING (OUTLET)
WATER HEAT
EXCHANGER
COIL DRAIN
A
IR VENT VALVE
COIL DRAIN
STRAINE
R
CHECK VALVE
PUMP
HOUSING TYPE JOIN
T
JIS10K FLANGE
PIPING
JIS10K FLANGE
PIPING
GASKET *1
*1 DESCRIPTION OF WETTED PART
SOLDE
R
WATER INLE
T
2-1/2" FLANGE: 4-φ19
WATER OUTLE
T
2-1/2" FLANGE: 4-φ19
WATER PIPING
(OUTLET)
A
IR VENT VALVE
STRAINE
R
BOTTOM (φ35 KNOCK OUT PUNCH)
CHECK VALVE
(CENTRALIZED
CONTROLLER)
WATE
R
PIPING
(INLET)
THERMAL INSLATION
(FIELD-SUPPLIED)
PUMP DRAIN PLUG
WATER HEAT EXCHANGE
R
CONTROL LINKAGE WIRING BETWEEN MODULES
EXTERNAL CONTROL
LIFTING HOLE
(4-φ25)
(φ80)
POWER SUPPL
Y
SERIAL PLATE
POWER LAMP, SWITCH
MODULE CONTROLLE
R
(INSTALLED IN ONLY ONE
MODULE)
DRAIN
(Note. 12)
(BOTTOM-φ40) (Note. 4)
(MOUNTING HOLE PITCH)
(4-φ20)
EXTERNAL CONTROL
DETAIL
A
MOUNTING HOLE
(MOUNTING HOLE PITCH)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH) (Note. 13)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
BASE, SIDE
(Note. 9)
HOUSING TYPE JOIN
T
(Pump-integrated
machine only)
(20Meshes/in.)
(Note. 8)
(Note. 11)
WATER INLET
NAME
No. JOINT
3" FLANGE
3" FLANGE
PT1-1/2" EXTERNAL THREAD
PT1/2" INTERNAL THREAD
CASING: Equivalent to FC250
CASING: Equivalent to FC200
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
CASING: FC200
Equivalent to SUS316
PURE COPPER
EPDM
WATER OUTLET
WATER
PIPING (INLET)
PLATE, JOIN
T
WATER
PIPING (OUTLET)
WATER HEAT
EXCHANGER
COIL DRAIN
A
IR VENT VALVE
COIL DRAIN
STRAINE
R
CHECK VALVE
PUMP
HOUSING TYPE JOIN
T
BOTTOM (φ35 KNOCK OUT PUNCH)
JIS10K FLANGE
PIPING
JIS10K FLANGE
PIPING
GASKET *1
*1 DESCRIPTION OF WETTED PART
SOLDE
R
CHECK VALVE
WATER INLE
T
3" FLANGE: 8-φ19
WATER OUTLE
T
3" FLANGE: 8-φ19
WATER PIPING
(OUTLET)
A
IR VENT VALVE
STRAINE
R
(CENTRALIZED
CONTROLLER)
(20Meshes/in.)
W
A
TER PIPING
(INLET)
THERMAL INSLATION
(FIELD-SUPPLIED)
PUMP DRAIN PLUG
WATER HEAT EXCHANGE
R
CONTROL LINKAGE WIRING BETWEEN MODULES
EXTERNAL CONTROL
LIFTING HOLE
(4-φ25)
(φ80)
POWER SUPPL
Y
SERIAL PLATE
POWER LAMP, SWITCH
MODULE CONTROLLE
R
(INSTALLED IN ONLY ONE
MODULE)
DRAIN
(Note. 12)
(BOTTOM-φ40) (Note. 4)
(MOUNTING HOLE PITCH)
(4-φ20)
EXTERNAL CONTROL
DETAIL
A
MOUNTING HOLE
(MOUNTING HOLE PITCH)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH) (Note. 13)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
BASE, SIDE
(Note. 8)
(Note. 11)
(Note. 9)
HOUSING TYPE JOIN
T
(Pump-integrated
machine only)

- 12 -
High EER Type_50HP, 60HP
High EER Type_70HP
73
170
230
1000
339
62
28
75
2350
109
34
470
8
4
5
7
10
69
269
178
500
760
254
510
545
2356
12
3
1
2
A
950
2366
181
216
20
2960
3300
339
3000
500
79
500
141
30 30
77060
90 116
11
25
1
2
3
4
7
6
5
8
9
10
12
11
73
170
230
1000
339
62
28
75
109
34
470
8
4
5
7
69
269
178
500
760
12
3
1
2
A
950
2366
181
20
2960
3300
339
3000
500
79
500
141
30 30
77060
254
510
545
2356
2350
10
11
216
90 116
25
1
2
3
4
7
6
5
8
9
10
12
11
WATER INLET
NAME
No. JOINT
2-1/2" FLANGE
2-1/2" FLANGE
PT1-1/2" EXTERNAL THREAD
PT1/2" INTERNAL THREAD
CASING: Equivalent to FC250
CASING: Equivalent to FC200
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
CASING: FC200
Equivalent to SUS316
PURE COPPER
EPDM
PT1/2" EXTERNAL THREAD
WATER OUTLET
WATER
PIPING (INLET)
PLATE, JOIN
T
WATER
PIPING (OUTLET)
WATER HEAT
EXCHANGER
COIL DRAIN
A
IR VENT VALVE
COIL DRAIN
STRAINE
R
CHECK VALVE
PUMP
WATER SUPPLY PORT FOR SPRA
Y
HOUSING TYPE JOIN
T
BOTTOM (φ35 KNOCK OUT PUNCH)
JIS10K FLANGE
PIPING
JIS10K FLANGE
PIPING
GASKET *1
*1 DESCRIPTION OF WETTED PART
SOLDE
R
CHECK VALVE
WATER SUPPLY POR
T
FOR SPRAY
WATER INLE
T
2-1/2" FLANGE: 4-φ19
3" FLANGE: 8-φ19
WATER OUTLE
T
2-1/2" FLANGE: 4-φ19
3" FLANGE: 8-φ19
WATER PIPING
(OUTLET)
A
IR VENT VALVE
STRAINE
R
(CENTRALIZED
CONTROLLER)
(20Meshes/in.)
WATER PIPING
(INLET)
THERMAL INSLATION
(FIELD-SUPPLIED)
PUMP DRAIN PLUG
WATER HEAT EXCHANGE
R
CONTROL LINKAGE WIRING BETWEEN MODULES
EXTERNAL CONTROL
LIFTING HOLE
(4-φ25)
(φ80)
POWER SUPPL
Y
SERIAL PLATE
POWER LAMP, SWITCH
MODULE CONTROLLE
R
(INSTALLED IN ONLY ONE
MODULE)
DRAIN
(Note. 12)
(BOTTOM-φ40) (Note. 4)
EXTERNAL CONTROL
(MOUNTING HOLE PITCH)
(4-φ20)
DETAIL
A
MOUNTING HOLE
(MOUNTING HOLE PITCH)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
BASE, SIDE
(Note. 8)
(Note. 11)
(Note. 9)
HOUSING TYPE JOIN
T
(Pump-integrated
machine only)
BOTTOM (φ35 KNOCK OUT PUNCH)
(MOUNTING HOLE PI
T
CH)
EXTERNAL CONTROL
MOUNTING HOLE
(MOUNTING HOLE PITCH)
WATER INLET
NAME
No. JOINT
3" FLANGE
3" FLANGE
PT1-1/2" EXTERNAL THREAD
PT1/2" INTERNAL THREAD
CASING: Equivalent to FC250
CASING: Equivalent to FC200
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
Equivalent to SUS304
CASING: FC200
Equivalent to SUS316
PURE COPPER
EPDM
PT1/2" EXTERNAL THREAD
WATER OUTLET
WATER
PIPING (INLET)
PLATE, JOIN
T
WATER
PIPING (OUTLET)
WATER HEAT
EXCHANGER
COIL DR
A
IN
A
IR VENT VALVE
COIL DRAIN
STRAINE
R
CHECK VALVE
PUMP
WATER SUPPLY PORT FOR SPRA
Y
HOUSING TYPE JOIN
T
JIS10K FLANGE
PIPING
JIS10K FLANGE
PIPING
GASKET *1
*1 DESCRIPTION OF WETTED PART
SOLDE
R
CHECK VALVE
WATER SUPPLY POR
T
FOR SPRAY
WATER INLE
T
3" FLANGE: 8-φ19
WATER OUTLE
T
3" FLANGE: 8-φ19
WATER PIPING
(OUTLET)
A
IR VENT VALVE
STRAINE
R
(CENTRALIZED
CONTROLLER)
(20Meshes/in.)
WATER PIPING
(INLET)
THERMAL INSLATION
(FIELD-SUPPLIED)
PUMP DRAIN PLUG
WATER HEAT EXCHANGE
R
CONTROL LINKAGE WIRING BETWEEN MODULES
EXTERNAL CONTROL
LIFTING HOLE
(4-φ25)
(φ80)
POWER SUPPL
Y
SERIAL PLATE
POWER LAMP, SWITCH
MODULE CONTROLLE
R
(INSTALLED IN ONLY ONE
MODULE)
DRAIN
(Note. 12)
(BOTTOM-φ40) (Note. 4)
(4-φ20)
DETAIL
A
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
POWER SUPPL
Y
BOTTOM (φ80 KNOCK OUT PUNCH)
(Note. 13)
BASE, SIDE
(Note. 8)
(Note. 11)
(Note. 9)
HOUSING TYPE JOIN
T
(Pump-integrated
machine only)

- 13 -
● Installed in a connected state
3391030
(1030)
62
2350
1030
1030
(1030)
1000
30
(1000)
30
10 0 0
(1030)
(1030)
1030
500
76 0
178
254
510
545
405 1030
52
F
E
500 1030 (1030)
20
2960
2366
3300
25 950 80 (950) 80
950
339
770 (1030) 1030
1030 (1030)
60 60 60
A
79
11 690 181
A
1000
2030
3060
4090
5120
6150
7180
10270
11300
12330
B
32
44
48
40
36
20
28
24
4
8
16
12
C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
13360 52
14390 56
15420 60
16450 64
9240
A
rrow E
A
rrow F
COIL DRAIN
(B)
WATER OUTLE
T
(B)
(B)
POWER SUPPL
Y
(B)
WATER INLE
T
PUMP DRAIN
(B)
MOUNTING HOLE
(C)
(B)
DRAIN
POWER SUPPL
Y
BOTTOM (KNOCK OUT PUNCH)
(B)
(MODULE MAIN BODY)
(MOUNTING HOLE PITCH)
POWER SUPPL
Y
BOTTOM (KNOCK OUT PUNCH)
(MOUNTING HOLE PITCH)
(B)
EXTERNAL CONTROL
BOTTOM (KNOCK OUT PUNCH)
Number of Modules
Note 2.number for A, B, C in the drawing.

- 14 -
Control box layout
The layout of the control boxes in the module is as shown below.
The power supply control box contains a power supply switch, module controller (*typical model only), unit
controller and CPU control board.
Each of the inverter boxes contains two compressor (PWM) control boards. Each of the EEV boxes contains one
EEV board.
Note 1) Pump inverter box is limited to integrated inverter pump only.
Note 2) The heater box is limited to 50HP, 60HP (Powerful heating type) only.
Note 3) The relative humidity sensor box is limited to 50HP, 60HP (Powerful heating type) including MC only.
BOX Layout Diagram
(Water spray system is omitted)
Control box layout diagram
Fan Reactor Box
Relative Humidity Sensor Box
(
Note 3
)
Cooling Fan
Inverter Box
(
Back Side
)
(
Circuits C, D
)
Power supply control box
Power supply cable access
(Ø80 mm hole)
(Circuits A, B)
(2 positions)
(Note 2)
Heater Box
EEV Bo
x
(Note 1)
Pump Inverter Box
Inte
r
-module control circuit cable access
External operation circuit - cable
Inverter box (front side)

- 15 -
During the winter, water inside the sprinkler can freeze, creating the risk of spray damage. If the outdoor air
temperature becomes 0°C or less, use one of the following two methods to drain water from the sprinkler.
[Drain all at once from module controller] * Group must be stopped
(1) Set the operation of the heat pump to Stop.
To stop using the module controller, switch to "Stop" in the MC operation change screen.
(2) Set the module controller to Unit.
In the Remote change screen of the module controller, switch to "Unit".
(3) Close the gate valves of the water supply main pipe for the spray and stop water supply to each
module.
(4) Fully open the manual flow rate adjustment valve of the sprinkler inlet.
High EER Type Drainage
Open manual valve fully
Flow control valve (with strainer 60 mesh)
Solenoid valve
Water supply pipe
connection port
(PT15A male screw)
Close the gate valve.
Sprinkler inlet
Main pipes
Strainer (required)
Gate valves (required)
Water drain valves (required)
A
ir breather valves (required)
(1) Stop
(2) Unit
Module controller screen

- 16 -
(5) Set the solenoid valve for the spray to ON (open).
From the operation screen, select "Main screen →Service →MC func →MC mainte →Fan and Spray check",
and set the spray of "System A (or B)" to ON.
(6) When water of all modules are completely drained, set the solenoid valve for the spray to OFF
(close).
(5) Set to ON (open).
(6) Set to OFF (close).
This method can only drain water from the spray inside each module.
As shown in "Pipe example", water drain valves (procured locally) also need to be provided in the
collecting pipe to each module. Be sure to use these valves to drain water.
Cautions

- 17 -
[When draining separately with unit controller of each module] *Stopping by each module is possible
(1) Touch REMOTE in the power control box of the module to drain, set it to Unit (REMOTE lamp off),
and touch STOP to stop the module.
(2) Close the gate valves of the main pipe and stop water supply to the module.
(3) Fully open the manual flow rate adjustment valve of the spray inlet.
(4) Use UP or DOWN of the unit controller to select "E.COdE", and touch ENTER.
(5) Use UP or DOWN to select SPry, and touch ENTER to enter the manual mode of the solenoid
valve for the spray.
(6) Use UP or DOWN to select On (open), and touch ENTER.
* In the manual mode, use UP or DOWN to select Ctrl (automatic), On (open), or OFF (close), and touch ENTER to confirm.
(7) When water is completely drained, select Ctrl (automatic) and touch ENTER. Then touch BACK
to exit the manual mode.
(8) Perform the same procedure to drain water from the other modules.
C t Lr O n
O FF
S P yr C t r L * Or ON/OFF
(1) REMOTE lamp (off)
(4) to (7) UP, DOWN, ENTER buttons
(7) BACK button
(1) REMOTE button
This method can only drain water from the spray inside each module.
As shown in "Pipe example", water drain valves (procured locally) also need to be provided in the
collecting pipe to each module. Be sure to use these valves to drain water.
Cautions

- 18 -
Lamp display
Button layout and name
Button name Display Description
Home button • Returns to the home screen.
Menu button • Displays the menu list.
Cursor operation button • Moves the cursor and applies various settings.
Return button
• Returns to the previous screen.
• Displays a message to confirm the setting change.
Confirm button
• Applies various settings.
• Move on to the next screen.
Module Controller
Lamp display Screen display
You can switch screens,
select functions and enter
numerical values by
pressing the buttons.
Buttons
Home button
Operation buttons
(left/right)
Menu button
Return button
Confirm button
POWER lamp (green)
Lit when controller is powered.
RUN lamp (green)
Lit when heat pump is running.
ALARM lamp (yellow)
Lights up in the event of a minor error and flashes in the event of a major error.
Operation buttons
(up/down)
