Toshiba A5-S6215TD User manual

TOSHIBA
Tecra A5
1
Model Name Description Part Number UPC Code
Tecra A5-S6215TD Microsoft® Windows® XP Professional, Intel® Celeron® M 360 (1.4GHz 1MB L2 Cache
400MHz FSB), 256MB PC2700 DDR 333MHz SDRAM, 40GB(5400rpm), CD-RW/DVD-
ROM, 14" TFT LCD at (1280 x 768) native resolution (WXGA), Intel Graphics Media
Accelerator 900, 10/100 Ethernet, 6-cell battery, 1394, 5-in-1 memory card slot, 1-year
standard limited warranty.
PTA50U-02500Y 032017375246
System Characteristics
2
Custom Configuration options and optional items listed below are highlighted in yellow.
Operating System
3
•Microsoft® Windows® XP Professional
Choice of Processors
4
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A5 BTO Rev. 1.05 2005-06-10 KK T20050418 CB1.00 Page 1 of 4
•Intel Pentium® M Processor 730 [1.6GHz, 2MB L2 Cache,
533MHz FSB]
•Intel Pentium® M Processor 740 [1.73GHz, 2MB L2 Cache,
533MHz FSB]
•Intel Pentium® M Processor 750 [1.86Hz, 2MB L2 Cache,
533MHz FSB]
•Intel Pentium® M Processor 760 [2.0GHz, 2MB L2 Cache,
533MHz FSB]
•Intel Pentium® M Processor 770 [2.13GHz, 2MB L2 Cache,
533MHz FSB]
•Intel Celeron® M Processor 360J [1.4GHz, 1MB L2 Cache,
400MHz FSB]
•Intel Celeron® M Processor 370 [1.5GHz, 1MB L2 Cache,
400MHz FSB]
Chipset
•Mobile Intel 915GM or 915PM Express Chipset depending on
configuration
Memory
5
•Configured with a minimum of 256MB DDR SDRAM
•256MB (Min)/2048MB (Max), 1
st
memory module is installed in
one slot under keyboard, service removable. 2
nd
memory
module can be end user accessed via removable door on
bottom of system chassis. Supports 256MB, 512MB, or
1024MB PC2700 DDR 333MHz SDRAM 2.5V SODIMM
memory modules, (both memory slots may be occupied)
Mass Storage
Choice of Hard Drives
6
•40GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height
•60GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height
•80GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height
•100GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height
Choice of Optical Disk Drives
•Fixed Bay CD-RW/DVD-ROM drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read)
•Fixed Bay DVD SuperMulti drive (double layer):
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (8x:write), DVD-
RW (4x:write), DVD+R (8x:write), DVD+R (Double Layer)
(2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
Choice of Display
7
•14.0” diagonal widescreen TFT High Brightness active-matrix
LCD display at 1280x768 native resolution (WXGA)
•14.0” diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x768 native resolution (WXGA)
•Brightness Control by Fn+F6/F7 and TOSHIBA Power Saver
Choice of Graphics
8
•Intel Graphics Media Accelerator 900; 8MB-128MB of graphics
memory is taken from the main memory via UMA (Unified
Memory Architecture)
•NVIDIA® GeForce™ Go 6200 (32MB or 64MB DDR discrete
graphics memory) with TurboCache™ technology
Sound
•Realtek ALC250 integrated software sound, AC97 compatible
•16-bit stereo; with built-in stereo speakers,
•Built-in microphone
•3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•Sound Volume Control Dial
Input Devices
•Keyboard
o85 key US keyboard
oToshiba FN Shortcut Keys; please see electronic User’s
Guide for more information
oWindows Key Function
oApplication Key Function
•Pointing Device:
oTouchPad™ pointing device
oTouchPad™ Enable/Disable (FN+F9 or by help of software)
•Others:
oButtons (Toshiba Assist, Presentation)
Expandability
•2 main memory slots (Both slots may be occupied)
oOne slot under keyboard, service removable
oOne slot available, end user accessible
•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
•Bridge Media Adapter (Secure Digital®, Memory Stick™,
Memory Stick PRO™, Multi Media Card, xD Picture Card
[shared slots])
•Docking port for Advanced Port Replicator III (see accessories)
Communications
•Integrated V.92 modem
9
•Marvell 88E8036 - 10/100 Base-TX Ethernet
•Choice of Wireless-LAN
10
oIntel® Pro/Wireless 2200BG (802.11b/g) Integrated Wi-Fi™
compliant wireless LAN
oIntel® Pro/Wireless 2915ABG (802.11a/b/g) Integrated Wi-
Fi™ compliant wireless LAN
oAtheros® 802.11b/g wireless-LAN
oAtheros® 802.11a/b/g wireless-LAN with Atheros SuperG™
technology
•Optional Bluetooth® version 2.0 plus Enhanced Data Rate
(EDR) with Toshiba Bluetooth stack software
Ports
•RGB (monitor) port
•TV-out (S-Video)
•i.LINK(tm) IEEE-1394
•4 Universal Serial Bus (USB) ports (v2.0)
•External Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
•240-pin docking connector
•DVI connector (with NVIDIA GeForce Go 6200 via Advanced
Port Replicator III only)

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A5 BTO Rev. 1.05 2005-06-10 KK T20050418 CB1.00 Page 2 of 4
Physical Description
•Dimensions (WxDxH Front/H Rear): 13.5'' (343mm) x 9.5''
(242mm) x 1.2'' (29.8mm)[F]/1.5'' (38.0)[R] without feet
•Weight
11
: 4.99 ~ 5.31 lbs (2.262 ~ 2.407 kg) depending upon
configuration
•Indicators: Power, DC-IN, Primary HDD Access, CD/DVD-ROM
Access, CapsLock, Arrow Mode, Numeric Mode, Battery
Charging Status, System Sleep/Suspend Status, Wireless
Communication, Bridge Media Reader
•Items protected by a screw: Memory, Hard Disk Drive
•Case material: Polycarbonate ABS
Power Supply
•75W (15V 5A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Weight: starting at 0.88 lbs (0.40 kg.)
•Dimensions (WxDxH): 5.4'' (136.0mm) x 1.2'' (30.0mm) x 2.1''
(53.0mm)
Battery
12
•6-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Weight: starting at 0.75 lbs. (0.34 kg.)
•Dimensions (WxDxH): 8.2'' (207.0mm) x 2.1'' (54.0mm) x 0.9''
(23.0mm)
•Battery Life: Up to 3 hours 31 minutes (measured by
MobileMark™) (6-cell battery)
13
•Recharge Time
oMain Battery Off/On – approximately 3.0 hrs/approximately
4.0 to 12.0 hrs
Toshiba EasyGuard™
Connect
•Toshiba ConfigFree™
Optimize
•Toshiba Power Saver utility
•Toshiba FN Shortcut Keys(see User’s Manual for description)
•Toshiba Zooming Utility
•Presentation Button
•One-touch Resolution Change
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v3.0, DPMS v2.0, DDC v2.0, SM
BIOS v2.34, PCI BIOS v2.2 support
Software
14
Toshiba Software and Utilities
•Toshiba ConfigFree™ with ConfigFree Summit Feature
•Toshiba PC Diagnostic Tool
•Toshiba Custom Utilities
•Electronic User’s Guide
•Toshiba Touch and Launch
Third-party Software
•Microsoft® Works™
•Microsoft® Office OneNote™
•Software Decoder: InterVideo® (WinDVD™ 5)
•Sonic® Solutions Drive Letter Access (DLA)
•Sonic® Solutions RecordNow! Basic
•eTrust™ EZ Firewall (30 Day Trial)
•McAfee® VirusScan (30 Day Trial)
•AOL® Internet Service
15
(3 Month Offer)
•AT&T® Worldnet® Service
16
(1 Month Offer)
Environmental Specifications
Operating Non-Operating
Temperature
17
5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour
maximum 20°C per hour maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to sea
level) -60 to 3000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
Limited Warranty18
•Standard 1-year standard limited warranty
Standard Limited Warranty Upgrades and Extensions
Toshiba offers many different standard limited warranty extensions and
enhanced service plans such as SystemGuard®, At-Home Repair, and
Service Express to provide additional support to your notebook PC. For a
full description and complete list of programs and program terms and
conditions, please visit www.pcsupport.toshiba.com
Recommended Services
Limited Warranty Extensions
Extends the standard limited warranty for up to 3 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at www.pcsupport.toshiba.com.
Part Number Description
SWC-PEQQ2V 2
nd
Year Limited Warranty Extension
SWP-PEQQ3V 2
nd
/3
rd
Year Limited Warranty Extension
SystemGuard
19
Advanced Protection Coverage w/ ServiceExpress
Provides advanced protection from damage caused by accidental drops,
spills and even screen breakage. Select your express repair service with
either Depot Express or Carry-In Express and go to the front of the line.
Limited Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSGQ1V 1
st
Year
SWC-PEGQ2V 1
st
/2
nd
Year + Limited Warranty Extension
SWP-PEGQ3V 1
st
/2
nd
/3
rd
Year + Limited Warranty Extension
SystemGuard Advanced Protection Coverage + Business On-Site
Repair
Combines SystemGuard and Business On-Site Repair coverage. Limited
Warranty Extension included except with 1 Year plan.
1
SystemGuard
coverage must be purchased within the first 30 days of purchase. See
Toshiba Service Plan Agreement for program terms and conditions at
www.pcsupport.toshiba.com.
Part Number Description
SWC-PSGN1V 1
st
Year
SWC-PEGN2V 1
st
/2
nd
Year + Limited Warranty Extension
SWP-PEGN3V 1
st
/2
nd
/3
rd
Year + Limited Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Toshiba will make reasonable efforts to
complete repair of your notebook and return the notebook to you by the
next business day via overnight shipment (excluding weekends and
holidays). Instructions and box will be provided to you for packing and
shipping the notebook to Toshiba. Carry-In Express: A Premier ASP will
make reasonable efforts to complete repair of your notebook by the next
business day (excluding weekends and holidays). Limited Warranty
Extension included except with 1 Year plan. See Toshiba Service Plan
Agreement for program terms and conditions at
www.pcsupport.toshiba.com.
Part Number Description
SWC-PSQP1V 1
st
Year
SWC-PEQP2V 1
st
/2
nd
Year + Limited Warranty Extension
SWP-PEQP3V 1
st
/2
nd
/3
rd
Year + Limited Warranty Extension
Business On-Site Repair
Toshiba will make reasonable efforts to provide on-site service at
customer’s business location by the next business day (excluding
weekends and holidays) to perform the necessary hardware repairs.
Limited Warranty Extension included except with 1 Year plan. See
Toshiba Service Plan Agreement for program terms and conditions at
www.pcsupport.toshiba.com.
Part Number Description
SWC-PSQN1V 1
st
Year
SWC-PEQN2V 1
st
/2
nd
Year + Limited Warranty Extension
SWP-PEQN3V 1
st
/2
nd
/3
rd
Year + Limited Warranty Extension
Accessories
Memory
Part Number Description
KTT3311A/256 Kingston DDR 333, 256MB
KTT3311A/512 Kingston DDR 333, 512MB
KTT3311A/1G Kingston DDR 333, 1GB

TOSHIBA
Power Expansion
Part Number Description Part Number Description
PA3283U-2ACA Toshiba 75W Global AC Adapter PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC
AdapterPA3399U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3400U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack
(12 Cell) Wireless / Bluetooth
Part Number Description
Cases-Security PA3455U-1BTM Toshiba USB Bluetooth 2.0 + EDR Capable Adapter
Part Number Description Storage
PA1370U-1ETC Toshiba Keyboard Protector (Tecra/Satellite/Qosmio) Part Number Description
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1
Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2
Build-to-Order/Configure-to-Order. Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your
select model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have
selected all those features. Configuring (customization) of your notebook takes an additional 12 to 15 working days.
3
Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
4
Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental
Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A5 BTO Rev. 1.05 2005-06-10 KK T20050418 CB1.00 Page 3 of 4

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A5 BTO Rev. 1.05 2005-06-10 KK T20050418 CB1.00 Page 4 of 4
5
Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors.
6
Hard Disk Drive (HDD) Capacity. 1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating
system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show
less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft
Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7
Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic
of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This
is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.
8
Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management
settings and features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in
battery power mode.
nVIDIA GeForce™ Go 6200 with TurboCache™ with 32MB or 64MB for dedicated graphics memory. The revolutionary new nVIDIA GeForce™ Go 6200
GPU utilizes the additional bandwidth of PCI Express to reach higher levels of graphics performance than traditional graphics memory solutions. The nVIDIA
GeForce™ Go 6200 GPU shares the capacity and bandwidth of dedicated graphics memory and dynamically available system memory for turbocharged
performance and larger total graphics memory. The VRAM capacity indicated in the NVIDIA display is the sum of the discrete graphics memory and the
maximum possible graphics memory allocated dynamically by the system memory. The system memory capacity indicated in the Microsoft Windows
PROPERTIES display is the maximum possible system memory capacity without adjustment for any system memory which may be dynamically allocated to
the graphics system depending on demand..
9
Modem Speed.Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
10
Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
11
Weight.Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12
Battery Life.Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its
ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
13
Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
14
Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
15
AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges
may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling
plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is
required.
16
AT&T® Worldnet® Service. Telephone access and other charges and other terms and conditions may apply. Offer available to new customers only.
17
Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.
18
Warranty. Toshiba’s standard limited warranty, extended warranty and service upgrade terms and conditions are available at
http://www.warranty.toshiba.com.
19
SystemGuard. SystemGuard coverage must be purchased within the first 30 days of purchase. See Toshiba Service Plan Agreement for program terms
and conditions at www.pcsupport.toshiba.com.
