TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
A85-S107/S1071 Satellite A85 Rev. 1.10 2005-06-09 CBB T20050418CB1.0 Page 1 of 3
Satellite A851
Model Name Description Part Number UPC Code
A85-S107 Microsoft® Windows® XP Home , Intel® Celeron® M Processor 360J, 256MB, 40GB (5400
RPM), DVD-ROM/CD-RW, 15” TruBrite™ XGA, ATI MOBILITY™ RADEON® 9000, 802.11b/g,
TV-Out, 1-year Limited Warranty
PSA82U-00R004 032017363168
A85-S1071 Microsoft® Windows® XP Pro, Intel® Celeron® M Processor 360J, 256MB, 40GB (5400 RPM),
DVD-ROM/CD-RW, 15” TruBrite™ XGA, ATI MOBILITY™ RADEON® 9000, 802.11b/g, TV-
Out, 1-year Limited Warranty
PSA82U-00R003 032017363144
System Characteristics2
Operating System3
•Microsoft® Windows® XP Home
•Microsoft® Windows® XP Professional
Processor4
•Intel Celeron® M Processor 360J [1.40GHz, 1MB L2, 400MHz
FSB]
Chipset
•ATI MOBILITY™ RADEON® 9000 Chipset
Memory5
•Configured with 256MB SDRAM
•256MB (Min)/1280MB (Max), 256MB on-board memory with 1
available memory slot for 256MB, 512MB, or 1024MB PC2700
DDR 333MHz SDRAM 2.5V SODIMM memory modules
Mass Storage
Hard Disk Drive:6
•40GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive:
•Fixed Bay DVD-ROM/CD-RW, 5,25” EIDE, 12.7mm height.
Maximum Speed:
CD-ROM (24x:read), DVD-ROM (8x:read), CD-R (24x:write),
CD-RW (24x:write)
Display:7
•15.0” diagonal TruBrite™ TFT active-matrix LCD display at
1024x768 native resolution (XGA)
•Brightness Control
Graphics8
•ATI MOBILITY™ RADEON® 9000 IGP with 64MB DDR shared
graphics, user adjustable to 128MB
Sound
•Realtek ALC250 Software Sound
•16-bit stereo; Built-in stereo speakers
•3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•Sound Volume Control Dial
Input Devices
•Keyboard
o85 key US keyboard, 2.7mm key stroke, 6mm keyboard
height, 19.05mm key pitch
oHot Key Functions (FN); please see electronic User’s Guide
for more information
oWindows Key Function
oApplication Key Function
•Pointing Device:
oTouchPad™
Expandability
•1 main memory slot.
•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Communications
•Integrated V.92 modem9
•10/100 Base-TX Ethernet
•Atheros® 802.11b/g wireless-LAN10
Ports
•RGB (monitor) port
•TV-out (S-Video)
•3 Universal Serial Bus (USB) ports (v2.0)
•External Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
Physical Description
•Dimensions (WxDxH Front/H Rear): 13.3'' (338mm) x 11.0''
(279.7mm) x 1.16'' (29.4mm)[F]/1.45'' (36.9mm)[R] without feet
•Weight11: Starting at 6.5 lbs. (2.96kg) depending upon
configuration
•Indicators: DC-In, Power, Battery, Hard Drive, CD-DVD ROM
Access, Caps Lock, Arrow Lock, Numeric Lock, Main Battery
Charging Status, Sleep Suspend Mode, Wireless
Power Supply
•65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Weight: Starting at 0.67 lbs. (305g)
•Dimensions (WxDxH): 4.25'' (108mm) x 1.85'' (47mm) x 1.34''
(34mm)
Battery12
•4-cell (2000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Weight: Starting at 0.6 lbs. (270g)
•Dimensions (WxDxH): 8.15'' (207mm) x 2.13'' (54mm) x 0.87''
(22mm)
•Battery Life: Up to 1:30 (hours:minutes) (4-cell battery)13
•Recharge Time
oMain Battery Off/On – up to 4.0 hrs/up to 12.0 hrs
Security
•Physical Security
oSlot for cable lock;
oMemory (protected by a screw)
oBattery pack (protected by a sliding latch)
oHard disk drive (protected by a screw)
•Software Security
oPasswords: User Power-on password, Supervisor Password,
Hard Disk Drive password
oSoftware: Screen Blank (by Hotkey), Screen Saver (by
software).
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v3.0, DPMS, DDC, SM BIOS
v2.34, PCI BIOS v2.2 support
Software14
Toshiba Software and Utilities
•Toshiba ConfigFree™
•Toshiba Custom Utilities
•Toshiba Notebook Maximizer
•Electronic User’s Guide
Third-party Software
•Microsoft® Works™
•Microsoft® Office™ OneNote™
•Software Decoder: Intervideo® (WinDVD™ 5)
•Sonic® Solutions Drive Letter Access (DLA)
•Sonic® Solutions RecordNow! Basic
•McAfee® VirusScan™ (30-Day Trial)
•Adobe® Acrobat®
•Arcsoft® Showbiz™
•Computer Associates eTrust EZ Firewall™
•Windows Media Player 10 with Napster plug-in
•Intuit® Quicken® 2005
•Google ToolBar (30-day trial)

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
A85-S107/S1071 Satellite A85 Rev. 1.10 2005-06-09 CBB T20050418CB1.0 Page 2 of 3
•AOL® Internet Service (3-months free)15
Environmental Specifications
Operating Non-Operating
Temperature16 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour
maximum 20°C per hour maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to sea
level) -60 to 3000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
Limited Warranty17
Limited Warranty Upgrades and Extensions
Toshiba offers many different limited warranty extensions and enhanced
service plans such as SystemGuard®, At-Home Repair, and Service
Express to provide additional support to your notebook PC. For a full
description and complete list of programs, please visit
http://www.accessories.toshiba.com.
Accessories
Memory
Part Number Description
KTT3311A/256 Kingston DDR 333, 256MB
KTT3311A/512 Kingston DDR 333, 512MB
KTT3311A/1G Kingston DDR 333, 1GB
Power
Part Number Description
PA3396U-1ACA Toshiba 65W Global AC Adapter
PA3457U-1BRS
Toshiba Primary High Capacity Li Ion Battery Pack (8 Cell)
Cases-Security
Part Number Description
PA1370U-1ETC Toshiba Keyboard Protector
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Storage
Part Number Description
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
Bluetooth/Wireless
Part Number Description
PA3455U-1BTM
Toshiba USB Bluetooth 2.0 + EDR Capable Adapter
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Build-to-Order/Configure-to-Order. Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your
select model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have
selected all those features. Configuring (customization) of your notebook takes an additional 12 to 15 working days.
3Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
4Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
A85-S107/S1071 Satellite A85 Rev. 1.10 2005-06-09 CBB T20050418CB1.0 Page 3 of 3
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors.
6Hard Disk Drive (HDD) Capacity. 1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating
system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show
less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft
Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic
of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This
is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.
8Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management
settings and features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in
battery power mode.
9Modem Speed.Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
11 Weight.Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12 Battery Life.Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its
ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
13 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
14 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
15 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges
may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling
plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is
required.
16 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.
17 Warranty. Toshiba’s standard limited warranty, extended warranty and service upgrade terms and conditions are available at
http://www.warranty.toshiba.com.
