Satellite L640-BT2N22 Page 1 of 4

Satellite L640 Detailed Product Specification1

Model Name Description Part Number UPC

L640-BT2N22 Genuine Windows

7 Home Premium, Intel

Core™ i3-350M Processor, 2GB DDR3,

250GB 5400rpm SATA, DVD-SuperMulti,14.0” widescreen HD, Mobile Intel® HD

Graphics, Wi-Fi®802.11 b/g/n wireless LAN, 6-cell battery, 1 year standard limited

warranty

PSK0GU-01F002

883974531158

Operating System C1 2

Genuine Windows®7 Home Premium 64-bit

Genuine Windows®7 Professional 64-bit

Processor3and Graphics4

Intel®Core™ i3-350M Processor

o2.26 GHz, 3MB Cache

Intel® Core™ i5-450M Processor 2.40 GHz (2.66 GHz with Turbo Boost

Technology), 3MB L3 Cache

Intel® Core™ i5-520M Processor 2.40 GHz (2.93 GHz with Turbo Boost

Technology), 3MB L3 Cache

Mobile Intel® HM55 Express Chipset

Mobile Intel®HD Graphics with 64MB-763MB dynamically allocated

shared graphic memory.

Memory5

Configured with 2GB DDR3 (max 8GB)

2GB (2GB x 1), 3GB (2GB + 1GB), 4GB (2GB x 2), 6GB (4GB + 2GB)

(Optional)

2 main memory slots. Both slots may be occupied

Storage Drive6

250/320/400/500GB (5400 RPM) Serial ATA hard disk drive

Fixed Optical Disk Drive7

DVD SuperMulti drive supporting 11 formats

oMaximum Read speed and compatibility: CD-ROM (24x), CD-R

(24x), CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL

(6x), DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW

(8x), DVD-RAM (5x)

DVD SuperMulti drive with Labelflash®supporting 11 formats (Optional)

oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),

CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x),

DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (8x),

DVD-RAM (5x)

oUses Labelflash®media to burn high quality labels directly to disc

Display8

14.0” diagonal widescreen HD TruBrite®TFT LED display at 1366x768

native resolution

oNative support for 720p content

o16:9 aspect ratio

Sound

Built-in stereo speakers

DOLBY®Advanced Audio™

Input Devices

Standard US keyboard (black)

TouchPad™ pointing device with multi-touch control

TouchPad™ Enable/Disable

Communications

Webcam and microphone

10/100 Ethernet

802.11b/g/n wireless LAN9

Bluetooth®version 2.1 plus Enhanced Data Rate (EDR) (Optional)

Modem10 (Optional)

Expandability

2 main memory slots accessible from the bottom. Both slots may be

occupied.

Memory Card Reader

oSecure Digital, Secure Digital High Capacity, mini Secure Digital,

Memory Stick™ , Memory Stick PRO™ , Multi Media Card,

(shared slot-may require adapter for use)

Ports

Video

oRGB

Audio

oMicrophone input port

oHeadphone output port

Data

oUSB v2.0 – 3 ports

o2 x USB v2.0

o1 x eSATA/USB combo port

oRJ-45 LAN port

oRJ-11 port (Optional)

Security

oSlot for security lock

Physical Description

Fusion®Finish in Helios Black with Standard Black keyboard

Fusion®Finish in Helios Grey with Glossy Black keyboard (Optional)

Fusion® Finish in Helios Red with Glossy Black keyboard (Optional)

Fusion®Finish in Helios Brown with Glossy Black keyboard (Optional)

Fusion® Finish in Helios White with White keyboard (Optional)



Dimensions (W x D x H Front/H Rear): 13.3” x 9.13” x 1.34”/1.50”

without feet

Weight: Starting at 4.98 lbs, depending upon configuration11

Power

65W (19V 3.42A) 100-240V/50-60Hz AC Adapter.

oDimensions (W x H x D): 4.21” x 1.85” x 1.20”

oWeight: starting at 0.55 lbs.

Battery12

6 cell/48Wh Lithium Ion battery pack,

6 cell/61Wh Extended Capacity Lithium Ion battery pack (Optional)

Software C1 13

Toshiba Software and Utilities

oTOSHIBA Recovery Disc Creator

oTOSHIBA Laptop Checkup

oTOSHIBA Service Station

oTOSHIBA Face Recognition

oTOSHIBA HW Setup Utility

oTOSHIBA Value Added Package

oTOSHIBA Web Camera Application

oTOSHIBA Disc Creator

oTOSHIBA PC Health Monitor

oTOSHIBA Eco Utility

oTOSHIBA Supervisor Password Utility

oTOSHIBA Media Controller Plug-in

oTOSHIBA Assist

oTOSHIBA Media Controller14

oTOSHIBA Bulletin Board

oTOSHIBA ReelTime

Third-party Software

oMicrosoft®Works 9

oMicrosoft®Windows Media Player 12

oMicrosoft®Silverlight™

oMicrosoft®Windows®Live™ Essentials including Photo Gallery,

Messenger, Mail, Writer and Movie Maker

oMicrosoft® Office Home and Student 2010 (Optional)

oMicrosoft® Office Home and Business 2010 (Optional)

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite L640-BT2N22 Page 2 of 4

oMicrosoft® Office Professional 2010 (Optional)

oMicrosoft®Internet Explorer 8

oCorel®Label@Once

oAdobe®Acrobat®Reader

oGoogle®Toolbar

oSun®Java™ 2 Runtime Environment

oWildTangent®Orb™ Game Console

Special Offers and Trial Software

oMicrosoft®Office Home and Student 2007 Edition 60-day trial

oToshiba Online Backup (30-day trial subscription available)

oNorton Internet Security™ 2010 (30-day trial subscription)

oIntuit®Quickbooks®Simple Start Online

oSkype®

oNetZero®Internet Service

Environmental Specifications

This product is RoHS15 compatible

Energy Star Qualified

EPEAT™ Gold Compliant

Operating Non-operating

Temperature

5° to 35° C -20° to 60° C

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Relative Humidity

(non-condensing) 20% to 90% 10% to 95%

Altitude

(relative to sea level) 0 to 10,000 meters 0 to 40,000 meters

Shock 10G 60G

Vibration 0.5G 1.0G

1 YEAR STANDARD LIMITED WARRANTY17

Includes International Limited Warranty for obtaining service when

traveling outside the United States.

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

On-Site Repair, and ServiceExpress to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com.

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3675U-1M1G Toshiba 1GB DDR3-1066 memory module

PA3676U-1M2G Toshiba 2GB DDR3-1066 memory module

PA3677U-1M4G Toshiba 4GB DDR3-1066 memory module

Power

Part Number Description

PA3717U-1ACA Toshiba 120W Global AC Adapter

PA3818U-1BRS Toshiba Primary Li Ion Battery Pack(6 cell)

PA3819U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack(12

cell)

Expansion

Part Number Description

PA3778U-1PRP dynadock V USB Docking Station with DVI/VGA port

PA3575U-1PRP dynadock U USB Docking Station with DVI/VGA port

PA3686U-1PRP dynadock Wireless U Docking Station with Wireless

USB Adapter

Carrying Case

Part Number Description

PA1445U-1CS4 Toshiba 14” Envoy Series Ballistic Polyester Carrying

Case

Storage

Part Number Description

PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M8G Toshiba 8GB USB Hi-Speed Flash Drive, ReadyBoost

E05A050CAU2XK Toshiba 500GB USB 2.0 Port Hard Drive, Raven Black

E05A075CAU2XL Toshiba 750GB USB 2.0 Port Hard Drive, Liquid Blue

E05A100PBU2XY Toshiba 1TB USB 2.0 Port Hard Drive, Satin Silver

Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Qosmio, Satellite, Portégé, Tecra, SelectBay, ConfigFree, SystemGuard, EasyGuard are registered trademarks of Toshiba America Information Systems, Inc.

and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite L640-BT2N22 Page 3 of 4

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may

not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,

please visit Toshiba's Web site at pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice

2Operating System.

Also see 64-Bit Computing Legal Footnote, if applicable.

Certain Microsoft®software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are

approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your

computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical

Service and Support for more information.

4Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features

utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary

depending on system memory size and other factors.

5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system

memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a

64-bit operating system can address 4 GB or more of system memory.

6Storage Drive

Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity

using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer

includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity

may vary.

7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical

drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical

media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or

optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.

Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.

8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a

period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.

9Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,

certain Wi-Fi® equipment.

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite L640-BT2N22 Page 4 of 4

10 Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary

depending on line conditions.

11 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

12 Battery Life Rating.Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark

Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. See “Detailed Specifications” for test used.

Details of MobileMark 2007 testing are available at www.bapco.com

Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any individual user. Actual battery life may vary considerably from

specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by

the design of individual components. The battery life rating is only achieved on the select models and configurations tested by Toshiba under the specific test settings at the time of

publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.

After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

13 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft®software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy

protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION

PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software

products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office Small Business Accounting 2006) which may be included with this computer.

The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation

procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which

time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without

charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the

perpetual version of such Office Product.

14 Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.

15 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements

and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

16 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when

operating within the recommended temperature range.
