Portégé M200/205 BTS Rev.1.12 2005-05-10 KK-CB V1.20 Page 1 of 3
Portégé M200/205 Series
Model(s): Description Part Numbers UPC
Portégé M200 Pentium M 735 (1.70GHz), 512MB (256MBx2), 12.1“ SXGA+, 60GB (5400 RPM),
802.11g (Intel), Bluetooth ready (Antenna only), Microsoft Windows XP-Tablet Edition PPM21U-07UEV8 032017268647
Portégé M200 Pentium M 745 (1.80GHz), 512MB (256MBx2), 12.1“ SXGA+, 60GB (5400 RPM),
802.11g (Intel), Bluetooth ready (Antenna only), Microsoft Windows XP-Tablet Edition PPM21U-029CM4 032017249158
Portégé M205-S810 Pentium M 1.50GHz, 512MB (256MBx2), 12.1“ SXGA+, 60GB (5400 RPM), Intel
802.11g, USB DVD-CD/RW, Microsoft Windows XP-Tablet Edition (Retail) PPM20U-07UGSK 032017236677
System Characteristics1
Operating System
Selected systems may have either:
•Microsoft®Windows® XP Tablet Edition, or
•Microsoft®Windows® XP Tablet Edition (Service Pack 2)
Intel® Centrino™ Mobile Technology featuring:
•Choice of Processor2:
oIntel Pentium M Processor 735 [1.7GHz, 2MB L2 Cache,
400MHz FSB]
oIntel Pentium M Processor 745 [1.80GHz, 2MB L2 Cache,
400MHz FSB]
•Intel 855PM system chipset
•Integrated Intel PRO/Wireless 802.11b/g Wi-Fi™ compliant
wireless
Memory
•512MB (256MBx2) PC2700 DDR 333 2.5V SDRAM 3
Hard Disk Drives4:
•60GB (5400 RPM) 2.5” Enhanced IDE (ATA-6) hard disk drive;
9.5mm height
Optical Disk Drive
Selected systems may include:
•Toshiba Slimline External USB2.0 DVD-CD/RW ROM
Combination Drive.
oRead: 24x CD-ROM, 24x CD-R, 24x CD-RW, 8x DVD-ROM
Write: 24x CD-R, 24x CD-RW
oInterface: USB 2.0 and is backward compatible with version
1.1
oDisk supported: Read/Write - CD-R, CD-RW; Read - DVD-
ROM, DVD-R, DVD-RW, DVD-RAM, CD-ROM, CD-R, CD-
RW, CD-I, CD-DA, CD-Mini, CD-Text, CD+(E)G
Display5and Graphics/Video
•12.1” Poly-silicon TFT Color LCD; internal display supports up to
16M colors at 1400 x 1050 (SXGA+)
•NVIDIA® GeForce™ FX Go5200 32M; 32MB DDR dedicated
video memory
•Digital Video Accelerator
•External Color Support
640 x 480 16bit/32bit colors
800 x 600 16bit/32bit colors
1024 x 768 16bit/32bit colors
1280 x 800 16bit/32bit colors
1280 x 1024 16bit/32bit colors
1600 x 1200 16bit/32bit colors
1920 x 1440 16bit/32bit colors
2048 x 1536 16bit/32bit colors
Input Devices
•Keyboard: 84 keys with 12 function keys, 1.7mm key stroke,
4.5mm height, 19mm key pitch; Dedicated Windows®&
Application keys support; HotKey function
•Integrated TouchPad
•Toshiba Digitizer Tablet Pen
•4 Hardware Buttons: Windows Security Button, ESC/Display
Rotation Button, Cross Functional Button,
•4 Tablet Pen Programmable Buttons
Expandability
•2 User-accessible expansion memory slot (including main memory
slot)
•1 Type II/Type I PC Card slot; PCMCIA R2.01, PC Card16,
CardBus
•1 SD card slot
Communications6
•Integrated V.92 modem/56K Data
•Integrated 10 Base-T/100 Base-TX Ethernet
•Integrated Fast Infrared (4Mbps)
•Integrated Bluetooth (v1.1) Antenna only
•Integrated Intel 802.11b/g Wi-Fi compliant wireless
Ports
•RGB (monitor) port
•2 Universal Serial Bus (USB) 2.0 ports
•RJ-45 LAN port
•RJ-11 modem port
•240 Pin Expansion Bus w/shutter cover
•Fast Infrared
Physical Description
•Dimensions (WxDxH Front/H Rear): 11.6” x 9.8” x 1.3/1.5
•Weight7(varies by configuration): 4.4 (min) - 4.6 (max) lbs
•LED Indicators: Power, Hard Drive, DC-IN, Battery, Wireless
Communication, SD Card, Caps Lock, Arrow, Numeric, Main
Battery Charging Status, System Sleep/Suspend Status, Wireless
Communication, SD Card.
Sound
•Analog Devices 1981B integrated software sound
•16-bit stereo with built-in speaker and microphone
•Direct 3D Sound; DirectSound and DirectMusic; Full Duplex and
MIDI (play back) support
•Sound Volume dial
•Microphone port (on Portégé M200/205 with “PPM21U-xxxxx” part
numbers, there are 3 Microphone ports for the Microphone Array)
•Headphone port
Power Supply
•60W external AC Adapter (15V 4A), 100-240V/50-60Hz input
•Dimensions (WxHxD): 4.3” x 1.9” x 1.1”
•Weight: 0.6 lbs
Battery8
•Battery Pack: 6-cell, rechargeable, removable Lithium Ion (Li-Ion)
battery; 4400mAh
•Dimension (WxHxD): 4.9” x 0.8” x 2.7”
•Weight: 0.7 lbs
•Battery Life: Up to 4.34 Hrs. with main Battery (measured by
MobileMark™)
•Battery Saver (in Windows XP): Stand by, HDD Auto Off, Display
Auto Off, Throttling, Hibernation
•Recharge time with 60 Watt AC adapter (main off/on): 2.5-
3.0H/10H
Security
•Slot for cable lock; Memory (by 1 screw), HDD (by 1 screw) and
modem/LAN (by screws only); User Power-on password, HDD
Password, Screen Blank and Keyboard Lock (by Hotkey), Screen
Saver (by software).
BIOS
•TSETUP, APM V1.2, ACPI V1.0b, PnP V1.0, VESA V2.0, DPMS
Support, DDC2B Support, SM BIOS V2.3, PCI BIOS V.2.1
Support, Boot Device: FDD/HDD/CD-ROM/LAN/PC-CARD.
Bundled Software
•WinDVD
•Drag ‘n Drop (only on selected models)

TOSHIBA
© 2004 Toshiba America Information Systems, Inc. All rights reserved.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé M200/205 BTS Rev.1.12 2005-05-10 KK-CB V1.20 Page 2 of 3
•Symbol Commander
•Microsoft® Office OneNote™ 2003
•Zinio Reader
•Franklin Covey Tablet Planner (30 Day Trial Version)
•Alias® SketchBook™ (30 Day Trial Version)
•Microsoft Works (M205-S809 only)
•Toshiba Custom Utilities
•Toshiba Audio Effect (for Portégé M200/205 with “PPM21U-xxxxx”
part numbers with the Microphone Array)
•Optional Microsoft® Office Small Business Edition 2003
•(M200 models only)
Environmental Specifications
Operating Non-Operating
Temperature 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour
maximum 20°C per hour maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to sea
level) -60 to 3000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
Limited Warranty
Selected Systems may have either:
•Portégé M200: 3 year parts and labor, 1 year battery; or,
•Portégé M205: 1 year parts, labor, and battery
Limited Warranty Extensions
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description and
complete list of programs, please visit www.accessories.toshiba.com
Models with 3 Year Standard Warranty
SWC-PTQQ4V 4th Year Warranty Extension
SWP-PQGQ3V 3 Years SystemGuard,
SWP-PQQP3V 3 Years ServiceExpress
SWP-PQQH3V 3 Years At-Home Repair
SWP-PQQN3V 3 Years Business On-Site Repair, Next Business
Day Response
SWP-PQGP3V 3 Years SystemGuard + Service Express
See Toshiba Service Plan Agreement for program terms and conditions
at www.pcsupport.toshiba.com.
Models with 1 Year Standard Warranty
SWP-PEQQ3V 2nd/3rd Year Warranty Extension,
SWP-PEGQ3V 3 Years SystemGuard + Warranty Extension
SWP-PEQP3V 3 Years ServiceExpress + Warranty Extension
SWP-PEQH3V 3 Years At-Home Repair + Warranty Extension
SWP-PEGP3V 3 Years SystemGuard + Service Express
SWP-PEGH3V 3 Years SystemGuard + At-Home Repair
See Toshiba Service Plan Agreement for program terms and conditions
at www.pcsupport.toshiba.com.
Accessories
For additional and most update accessories, please visit
www.accessories.toshiba.com.
Power
PA3283U-2ACA Toshiba 75W Global AC Adapter
PA3191U-3BRS Toshiba Primary Li Ion Battery Pack (6 cell)
PA3091U-1CHG Toshiba Battery Charger with integrated AC Adapter
Memory Upgrades & SD Memory Options
KTT3311/512 Kingston PC2100/PC2700, 512MB DDR
KTT3311/1G Kingston PC2100/PC2700, 1GB DDR
SD-M2564B3 Toshiba 256MB SD (Secure Digital) Card
SD-M5124B3 Toshiba 512MB SD (Secure Digital) Card
Primary Hard Drive Upgrades (or Replacements)
PA3204U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 5400 rpm
PA3306U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 7200 rpm
PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm
Backup
HDD1232CZP41002 Toshiba 5GB Type II PC Card HDD w/Back-up
software
UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup System
UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup System
Optical Drives
PA3352U-2CD2 Toshiba Slimline External USB 2.0 CD-RW/DVD-
ROM Combo Drive
Bluetooth
PA3235U-5BTM Toshiba Bluetooth Module Kit (Dealer installed only)
PA3370U-1BTM Toshiba Bluetooth SD Card Version 1.2
Cases & Security
PA1331U-1NCS Toshiba 3-in-1 Portfolio Leather
PA1329U-1NCS Toshiba Portege M200 Enhanced Protection Case
PA1330U-1ETC Toshiba User Harness for M200 Enhanced
Protection Case
NWDEFCL Targus Noteworthy DEFCON CL Cable Lock
Input & Miscellaneous
PA3316U-2ETC Toshiba Tablet PC Pen
PA3317U-1ETC Toshiba Tablet PC Reserve Pen
PA1357U-2ETC Toshiba Tablet Pen Tether
PA1336U-1NKB Toshiba USB Keyboard
PA1337U-1NMS Toshiba USB Optical Scroller Mouse
PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller Mouse
PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC Adapter)
PA1371U-1ETC Toshiba Keyboard Protector (Portege)
Expansion
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC
Adapter
PA3315U-1PRP Toshiba Tablet Multi Dock (see list of options for the
Toshiba Tablet Multi Dock below).
Options Available for the Toshiba Tablet Multi Dock
Secondary HDD Kits
To use the secondary HDD Kits for extra storage capacity in the Toshiba
Slim SelectBay, you must also purchase the Toshiba Slim SelectBay
HDD Adaptor (part number: PA3134U-1ETC).
PA3204U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 5400 rpm
PA3306U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 7200 rpm
PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm
PA3134U-1ETC Toshiba Slim SelectBay HDD Adaptor (Black Bezel)
(use only in the Toshiba Tablet Multi Dock)
Optical Drives
PA3137U-3CD2 Toshiba Slim SelectBay CD-RW/DVD-ROM Drive Kit
(Black)
PA3231U-1DV1 Toshiba Slim SelectBay DVD Multi Drive Kit (Black)
Expansion
PA3224U-2ETC Toshiba Bridge Media Adapter (Slim SelectBay
device)
Return Policy
TAIS does not accept the return of component parts, or bundled software, which have been removed from the PC system. Pro-rata refunds on individual PC
components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the TAIS dealer
where you purchased the product, and comply with the dealer’s standard return policies and procedures.

TOSHIBA
© 2004 Toshiba America Information Systems, Inc. All rights reserved.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé M200/205 BTS Rev.1.12 2005-05-10 KK-CB V1.20 Page 3 of 3
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation.
Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or registered trademarks of Intel Corporation or
its subsidiaries in the United States and other countries.
Microsoft and Windows are registered trademarks and OneNote is a trademark of Microsoft Corporation in the United States and/or other countries.
Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such
marks by Toshiba is under license.
NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States and/or other countries.
BAPCo is a U.S. Registered Trademark of the Business Applications Performance Corporation. MobileMark is a U.S. Registered Trademark of the Business
Applications Performance Corporation.
All other trademarks are the property of their respective owners.
1While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at pcsupport.toshiba.com. The product
specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or
illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
pcsupport.toshiba.com.
2CPU performance in your computer product may vary from specifications under the following conditions:
use of certain external peripheral products
use of battery power instead of AC power
use of certain multimedia games or videos with special effects
•use of standard telephone lines or low speed network connections
•use of complex modeling software, such as high end computer aided design applications
•use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
•use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at
www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions
under “Environmental Conditions” in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.
3Not all memory module combinations may be available. Consult with your Toshiba Sales Representative or, if available, go to config.toshiba.com to
configure your system.
41 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage
capacity will also be less if the product includes pre-installed operating system and/or application software. Actual formatted capacity may vary.
5Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT)
and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT
manufacturing technology.
6Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions. Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware
and/or services or pay for phone charges and air time, etc. to achieve the functionality as advertised.
7Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
8Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at
maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that
shipped with your computer or visit the Toshiba web site at accessoryfinder.toshiba.com.
MobileMark™ is a registered trademarks of Business Applications Performance Corporation
