Satellite M45 Series Revision 1.08 31-Mar-05 DMD Source: CB V1.20 Page 1 of 4

Satellite®

Model Name Description Part Number UPC Code

Satellite M45-S331 Intel ® Pentium® M processor 730, 512MB DDR SDRAM, 80GB HDD, 15.4” WXGA, DVD

SuperMulti, 802.11b/g, Microsoft® Windows® XP Home (SP2), TOSHIBA® Express

Media Player, i.LINK® 1394/Bridge Media adapter

PSM40U-01R001 032017296794

Satellite M45-S351 Intel ® Pentium® M processor 740, 512MB DDR SDRAM, 100GB HDD, 15.4” WXGA,

DVD SuperMulti, 802.11b/g, Microsoft® Windows® XP Home (SP2), TOSHIBA® Express

Media Player, i.LINK® 1394/Bridge Media adapter

PSM40U-01X001 032017297104

Satellite M45-S3511 Intel ® Pentium® M processor 740, 512MB DDR SDRAM, 100GB HDD, 15.4” WXGA,

DVD SuperMulti, 802.11b/g, Microsoft® Windows® XP Pro (SP2), TOSHIBA® Express

Media Player, i.LINK® 1394/Bridge Media adapter

PSM40U-01X002 032017297111

System Characteristics1

Operating System

•Microsoft® Windows® XP Home (SP2) (S331, S351)

•Microsoft Windows XP Professional (SP2) (S3511)

•TOSHIBA® Express Media Player for quick access to CD, DVD

playback

CPU2

Intel® Centrino™ Mobile Technology featuring

•Intel Pentium® M processor 730 [1.60GHz, 2MB L2 cache,

533MHz FSB] (S331)

•Mobile Intel 915GM Express Chipset

•Intel PRO/Wireless 2200BG (802.11b/g)3

•Intel Pentium® M processor 740 [1.73GHz, 2MB L2 cache,

533MHz FSB] (S351, S3511)

•Mobile Intel 915GM Express Chipset

•Intel PRO/Wireless 2200BG (802.11b/g)4

Memory5

•512MB (Min)/2048MB (Max with two slots occupied)

PC2700 DDR333 SDRAM 2.5V SODIMM Memory modules

•Featured models configured with 512MB (both slots may be

occupied)

Mass Storage

•Hard Disk Drives6

o80GB (4200RPM), Enhanced IDE (ATA-5) hard disk

drive; 9.5mm height; user removable) (S331)

o100GB (4200RPM), Enhanced IDE (ATA-5) hard

disk drive; 9.5mm height; user removable) (S351,

S3511)

•Optical Disk Drive

oFixed Bay DVD SuperMulti drive

oMaximum Speed

CD-ROM(24x:read), CD-R(24x:write), CD-

RW(4x:write), DVD-ROM(8x:read), DVD-

R(8x:write), DVD-RW(4x:write),

DVD+R(8x:write), DVD+RW(4x:write),

DVD-RAM(3x:write)

oCompatibility

CD-ROM(read), CD-R(read/write), CD-

RW(read/write), DVD-ROM(read), DVD-

R(read/write), DVD-RW(read/write),

DVD+R(read/write), DVD+RW(read/write),

DVD-RAM(read/write)

oODD Interface – Enhanced IDA

Display7

•15.4” diagonal widescreen TruBrite™ TFT active-matrix LCD

display at 1280 x 800 native resolution

•Contrast 400:1

•Brightness Control – FN+F6/ F7

Graphics

•Intel® Graphics Media Accelerator 900, 64-128MB Internal

(UMA) shared video memory

Input Devices

•Keyboard

o85 key US keyboard, 2.7mm key stroke, 6mm

keyboard height, 19.05mm key pitch

oHot Key Functions (FN); please see electronic User’s

Guide for more information

oWindows Key Function

oApplication Key Function

•TouchPad™ (scroll with help of driver)

•Internet Button

•CD Control Button

oExpress Media Player button, Skip Previous, Skip

Next, Play/Pause, Stop

Expandability

•2 available expansion memory slots (both slots may be

occupied at time of purchase)

•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,

CardBus

•Bridge Media Adapter8(Secure Digital®, Memory Stick™,

Memory Stick PRO™, SmartMedia™, Multi Media Card, xD

Picture Card [shared slots])

Communications

•Integrated V.92 modem

•Marvell® 10BASE-T/100BASE-TX Ethernet

•Integrated Intel® Pro/Wireless LAN 2200BG (802.11BG)

Ports and Slots

•RGB (monitor out port)

•3 Universal Serial Bus (USB) ports

•TV-Out (S-Video)

•RJ11 modem port

•RJ45 LAN port

•i.LINK™ IEEE 13949

Physical Description

•Dimensions (WxDxH[front/back]): 14.17”x10.55”x1.14”/1.71”

without feet

•Weight10: starting at 6.20 lbs.

•Switch: Power, Wireless Communication

•LED Indicators: Power (common with Power/System Sleep

Status), DC-IN, Primary HDD access, Power Save mode (with

ACPI-OS, common to Power), Caps Lock, Arrow mode,

Numeric mode, Main Battery Charging Status, System

Sleep/Suspend Status (common with Power/System Sleep

Status), Wireless Communication (for Wireless LAN), SD Card,

System sleep status (shared with Power)

Sound

•Analog Devices, Inc. AD1981D Software Sound, AC'97 Rev2.2

Compatible

•16-bit stereo; Built-in harman/kardon® stereo speakers

•Direct 3D Sound; DirectSound, Direct Music, MIDI (playback)

Support

•Audio Ports: External Microphone (monoaural), Headphone

(stereo), Sound Volume (by dial)

Power Supply

•75W (15V x 5A) Auto sensing external AC Adapter, 100-240V /

50-60Hz frequency (Universal) input.

•Dimensions (WxHxD): 5.35” x 2.09” x 1.18”

•Weight11: starting at .88 lbs

Battery12

•6-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)

•Dimensions (WxHxD): 8.13” x 0.87” x 1.1””

•Weight13: .071 lbs

•Recharge Time: Main Battery Off/On – approximately 4.0 hours

hrs/approximately 12 hours

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite M45 Series Revision 1.08 31-Mar-05 DMD Source: CB V1.20 Page 2 of 4

•Battery Life: Up to 2 hour, 45 minutes (when using in Windows®

mode) (measured by Mobilemark™ 2002)14

Security

•Slot for cable lock, Memory (by one screw), Main HDD (by six

screws)

•Passwords: User Power on Password, CPU Serial Number,

Setup, Supervisor Password

•Hotkey locks: Keyboard (FN+F1), Screen Blank

•Software: Screen Saver

BIOS

•APM Support (V1.2), ACPI Support (V1.0b), PnP Support

(V1.0), VESA Support, DPMS Support, DDC Support, SM BIOS

Support (V2.3), PCI BIOS Support (V2.1)

Software15

TOSHIBA Software and Utilities

•TOSHIBA Express Media Player

•TOSHIBA ConfigFree™

•TOSHIBA Custom Utilities

•TOSHIBA Common Modules

•TOSHIBA Hotkey Utility for Display Devices

•TOSHIBA Zooming Utility

•TOSHIBA Power Saver

•TOSHIBA Utilities

•TOSHIBA Controls

•TOSHIBA Wireless Hotkey

•TOSHIBA Touch Pad On/Off Utility

•TOSHIBA Touch and Launch

•TOSHIBA Display Device Change Utility

•TOSHIBA Speech System

•TOSHIBA PC Diagnostic Tool

•TOSHIBA CD/DVD Drive Acoustic Silencer

•Satellite M45 Electronic User’s Guide

Third-party Software16

•Microsoft® Office® OneNote™ 2003

•Microsoft® Works™ Version 8.0 with Office® 2003 Trial -

Student/Teacher Edition

•Sun® Java™ 2 Runtime Environment

•Adobe® Acrobat® Reader version 5.0

•Software Decoder: InterVideo® (WinDVD™ 5)

•InterVideo® WinDVD™ Creator 2 Platinum

•Sonic™ Solutions RecordNow!™ Basic for TOSHIBA

•Sonic™ Solutions Drive Letter Access (DLA)

•Microsoft® Windows® Media Player version 10

•Napster® Digital Music Service – 30 days trial

•Easy FireWall – 30 days trial

•Norton® AntiVirus™ 2004 – w/3-Month Subscription

•AOL® version 9.0 – 3-Month offer17

•AT&T® Worldnet® Service – 1 Month offer

•Intuit® Quicken® New User Edition 2004

•QuickTime™ Player

•RealOne™ Player 8 Basic

Environmental Specifications18

Operating Non-Operating

Temperature 5°to 35°C

(41°to 95°F) -20°to 65°C

(-4°to 149°F)

Thermal Gradient 15°C per hour maximum 20°C per hour

maximum

Relative Humidity 20% to 80% 10% to 90%

Altitude (relative to

sea level) -60 to 3000 meters -60 to 10,000

meters

Shock 7G, 1.5G when CD/DVD-

ROM installed 60G

Vibration 0.2G, 0.25G when

CD/DVD-ROM installed 1G

Limited Warranty

•1-year Standard, Limited Warranty

•Limited Warranty Upgrades and Extensions

Toshiba offers many different warranty extensions and

enhanced service plans such as SystemGuard®, At-Home

Repair, and Service Express to provide additional support to

your notebook PC. For a full description and complete list of

programs, please visit www.accessories.toshiba.com

Recommended Services

Extended Warranty

Extends the standard warranty for up to 4 years from the original

notebook purchase date. See Toshiba Service Plan Agreement for

program terms and conditions at www.pcsupport.toshiba.com.

Part Number Description

SWC-PEQQ2V 2nd Year Warranty Extension

SWP-PEQQ3V 2nd/3rd Year Warranty Extension

SystemGuard Accidental Damage Coverage1

Provides coverage of accidental damage caused by drops, spills and

even screen breakage. Warranty Extension included except with 1 Year

plan.

Part Number Description

SWC-PSGQ1V 1st Year

SWC-PEGQ2V 1st/2nd Year + Warranty Extension

SWP-PEGQ3V 1st/2nd/3rd Year + Warranty Extension

ServiceExpress

Select your express repair service with either Depot Express or Carry-In

Express. Depot Express: Notebook repaired the same day it is received,

and returned via overnight delivery. Shipping and box provided. Carry-In

Express: Notebook repaired by the next business day at any Premier

Authorized Service Provider. Warranty Extension included except with 1

Year plan.

Part Number Description

SWC-PSQP1V 1st Year

SWC-PEQP2V 1st/2nd Year + Warranty Extension

SWP-PEQP3V 1st/2nd/3rd Year + Warranty Extension

At-Home Repair

A technician arrives with parts at the customer’s business location the

next business day and performs the necessary hardware repairs.

Warranty Extension included except with 1 Year plan.

Part Number Description

SWC-PSQH1V 1st Year

SWC-PEQH2V 1st/2nd Year + Warranty Extension

SWP-PEQH3V 1st/2nd/3rd Year + Warranty Extension

SystemGuard1 + ServiceExpress

Combines SystemGuard and ServiceExpress coverage. Warranty

Extension included except with 1 Year plan.

Part Number Description

SWC-PSGP1V 1st Year

SWC-PEGP2V 1st/2nd Year + Warranty Extension

SWP-PEGP3V 1st/2nd/3rd Year + Warranty Extension

SystemGuard1 + At-Home Repair

Combines SystemGuard and Business On-Site Repair coverage.

Warranty Extension included except with 1 Year plan.

Part Number Description

SWC-PSGH1V 1st Year

SWC-PEGH2V 1st/2nd Year + Warranty Extension

SWP-PEGH3V 1st/2nd/3rd Year + Warranty Extension

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Category Part Number Description

Memory KTT3311/256

Kingston DDR 333,

256MB

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite M45 Series Revision 1.08 31-Mar-05 DMD Source: CB V1.20 Page 3 of 4

Memory KTT3311/512

Kingston DDR 333,

512MB

Memory KTT3311/1G Kingston DDR 333, 1GB

Power PA3283U-2ACA

Toshiba 75W Global AC

Adapter

Power PA3399U-1BRS

Toshiba Primary Li Ion

Battery Pack (6 Cell)

Power PA3400U-1BRS

Toshiba Primary High

Capacity Li Ion Battery

Pack (12 Cell)

Storage PA3109U-1FDD

Toshiba USB Floppy

Disk Drive Kit

Security &

Protection PA1370U-1ETC Toshiba Keyboard

Protector

(Tecra/Satellite/Qosmio)

Security &

Protection NWDEFCL Targus-Noteworthy

DEFCON CL Cable Lock

Wireless/Bluetooth PA3405U-1BTM Toshiba Bluetooth USB

Adapter

Wireless/Bluetooth PA3370U-1BTM Toshiba Bluetooth SD

Card V 1.2

Subject to Change

a. “While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices,

system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the various

computer software or hardware options, visit Toshiba’s Web site at pcsupport.toshiba.com.”

b. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or

illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at pcsupport.toshiba.com.

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information Systems, Inc. (“TAIS”)

does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on individual PC components or bundled

software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the TAIS dealer where you purchased the product, and comply

with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

Toshiba website for resellers: http://sell.toshiba.com

Toshiba PC Support website: http://pcsupport.toshiba.com

Portégé, Satellite, Tecra, Satellite Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information Systems, Inc. and/or

Toshiba Corporation.

Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the

United States and other countries.

Microsoft and Windows are registered trademarks and OneNote is a trademark of Microsoft Corporation in the United States and/or other countries.

Winstone® is a registered trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries.

MobileMark™ is a trademark of the Business Applications Performance Corporation.

1Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your select model may not have all the features and specifications

corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.

2 Central Processing Unit (“CPU”) Performance Disclaimer.

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are approximate and may vary

depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. For optimum

performance, use your computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product Resource Guide.

Contact Toshiba Technical Service and Support for more information.

3 The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic environment, obstacles,

access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.

4 The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic environment, obstacles,

access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.

5The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system memory available for other

computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other

factors.

6 1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for

the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage capacity will also be less if the product

includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity

may vary.

7 Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is manufactured

using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology.

(a) Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an intrinsic characteristic of LCD technology.

(b) Screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen.

8Optional on some systems. Your system may or may not have these options.

9Optional on some systems. Your system may or may not have these options.

10 Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

11 Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

12 Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the

natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations tested by

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite M45 Series Revision 1.08 31-Mar-05 DMD Source: CB V1.20 Page 4 of 4

Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery

will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information

that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com..

13 Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

14 MobileMark is a trademark of the Business Applications Performance Corporation.

15 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

16 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

17 AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL BEFORE

THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges may apply, including AK, even during promotional

period. Members may incur telephone charges on their phone bill, depending on their location and calling plan, even during promotional period. Available to new AOL members in

the United States, age 18 or older; a major credit card or checking account is required.

18 All temperature references are approximate and the performance of your computer may vary from specifications even when operating within the recommended temperature

range.
