Toshiba NB505-N500BL User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Toshiba mini NB505-N500BL Page 2 of 5
Toshiba mini NB505 Detailed Product Specification1
Model Name: NB505-N500BL Part Number: PLL50U-01S008 UPC: 883974682928
Operating SystemC1 2
Genuine Windows® 7 Starter 32-bit
Processor3and Graphics4
Intel®Atom™ processor N455
o1.66 GHz, 512KB L2 Cache
Intel®NM10 Express Chipset
Intel®Graphics Media Accelerator 3150 with 0MB-250MB dynamically
allocated shared graphics memory
Memory5
Configured with 1GB (max 2GB-see note accessory section)
1 main memory slot. Slot is occupied.
Storage Drive6
250GB (5400 RPM) Serial ATA hard disk drive
Display7
10.1” diagonal widescreen TruBrite®display at 1024 x 600 native
resolution (WSVGA)
o16:9 aspect ratio
oLED backlit
Sound
Built-in speaker (mono)
Input Devices
Full-size keyboard (black)
Touch pad pointing device with multi-touch control
Communications
Webcam and microphone
10/100 Ethernet
Wi-Fi®Wireless networking (802.11b/g/n)8
Expandability
Memory Card Reader
oSecure Digital (SD), Secure Digital High Capacity (SDHC),
SDXC, Multi Media Card [shared slot]
Ports
Video
oRGB (monitor) output port
Audio
oMicrophone input port
oHeadphone output port
Data
o3 USB v2.0 ports
oRJ-45 LAN port
Security
oSlot for Security Lock
Physical Description
EasyGrip Finish in Blue
Dimensions (W x D x H Front/H Rear): 10.3” x 7.48” x 0.65”/1.4” without
feet
Weight: Starting at 2.9 lbs., depending upon configuration9
Battery10
6 cell (48Wh) Lithium Ion battery pack
Battery Life Rating (measured by MobileMark™ Productivity 2007)
oIncluded 6-cell battery: 8 hours, 21 minutes
Power
30W (19V x 1.58A) Auto sensing ,100-240V/50-60Hz AC Adapter
Dimensions (W x D x H): 3.66” x 1.57” x 1.1”
Weight: starting at .44 lbs.
Software C1 11
Toshiba Software and Utilities
oTOSHIBA Assist
oTOSHIBA Bulletin Board
oTOSHIBA Disc Creator
oTOSHIBA eco Utility™
oTOSHIBA HDD/SSD Alert
oTOSHIBA HW Setup Utility
oTOSHIBA Media Controller12
oTOSHIBA Recovery Disc Creator
oTOSHIBA ReelTime
oTOSHIBA Service Station
oTOSHIBA Supervisor Password Utility
oTOSHIBA Value Added Package
oTOSHIBA Web Camera Application
Third-party Software
oAdobe®Acrobat®Reader
oGoogle®Toolbar
oGoogle®Chrome
oInternet Explorer 8
oMicrosoft®Office Starter 201013
oMicrosoft®Windows Media Player 12
oMicrosoft®Silverlight™
oMicrosoft®Live Essentials
Photo Gallery
Messenger
Mail
Writer
Movie Maker
Special Offers and Trial Software
oNorton Internet Security™ 2011 (30-day trial subscription)
Environmental Specifications
This product is RoHS14 compatible
Energy Star Qualified
EPEAT™ Gold Compliant
Operating Non-operating
Temperature
15
5° to 35° C
-20° to 60° C
Relative Humidity
(non-condensing) 20% to 80% 10% to 90%
Thermal Gradient 15° C per hour (max)
20° C per hour (max)
Altitude
(relative to sea level) 0 to 3,000 meters 0 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
1 YEAR STANDARD LIMITED WARRANTY for Mini
Notebook Computers16
Includes International Limited Warranty for obtaining service when
traveling outside the United States.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade (*** Important Note***)
Part Number Description
In order to upgrade, you will need to determine the current memory speed.
Upgrade using like memory speeds ONLY.
1) Locate gray part number label on bottom of machine

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Toshiba mini NB505-N500BL Page 3 of 5
2) If there is a “D3” in the upper right hand corner of the label, then
DDR3 memory is installed, upgrade using the following-
PA3856U-1M2G Toshiba DDR3-1066MHz, 2GB
Memory
3) All other units, assembled with DDR2 memory, upgrade using the
following module-
PA3669U-1M2G, Toshiba DDR2-800MHz, 2GB
memory Module
Alternate Identification Method(Serial Number)
PLL50U-01S008(4B131114K or greater, or a serial number
starting with 5B , 6B ,7B , 8B) use DDR3
PLL50U-01S008(4B131113K or less, or a serial number starting
with 3B , 2B ,1B, ZA, YA, or XA)- use DDR2
Power
Part Number Description
PA3743U-1ACA Toshiba 30W Global AC Adapter
PA3821U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)
Expansion
Part Number Description
PA3834U-1DV2 Toshiba USB Portable DVD SuperMulti Drive (Tray
Load)
PA3845U-1DV2 Toshiba USB Portable DVD SuperMulti Drive (Slot
Load)
PA3627U-1ETC Toshiba USB 2.0 4-Port Hub
Storage
Part Number Description
PA3877U-1M8B Toshiba 8GB Hi-Speed USB 2.0 Swivel-Retractable
Flash Drive
PA3877U-1MAB Toshiba 16GB Hi-Speed USB 2.0 Swivel-Retractable
Flash Drive
PA3877U-1MBB Toshiba 32GB Hi-Speed USB 2.0 Swivel-Retractable
Flash Drive
E05A050CAU2XK Toshiba Canvio USB 2.0 External Hard Drive, 500GB
(Raven Black)
E05A075PBU2XK Toshiba Canvio Plus USB 2.0 External Hard Drive,
750GB (Raven Black)
E05A100PBU3XW Toshiba Canvio 3.0 Plus USB 3.0 External Hard Drive,
1TB (Black w/White accents
Security & Protection
Part Number Description
PA1469U-1CMN Toshiba LapDesk Dual Function Hardshell Case
PA1489U-1NB Toshiba Neoprene Sleeve for Mini Notebook (Black)
PA1444U-1CS2 Toshiba 12" Envoy Ballistic Polyester Carrying Case
Bluetooth
Part Number Description
PA3710U-1BTM Toshiba Bluetooth V 2.1+EDR USB Nano Adapter
PA3847U-1ETB Toshiba Bluetooth Laser Mouse (Black)
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
ConfigFree and SystemGuard are registered trademarks of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. All other products and
names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Toshiba mini NB505-N500BL Page 4 of 5
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.
4Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized
when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary
depending on system memory size and other factors.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6Storage Drive Capacity. Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109 = 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000
bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB =
240 = 1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed
operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
8Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access
points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic
environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the
theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless function, if available, your client and access point must support the corresponding feature.
Performance of these functions may vary depending on the format of data transmitted.
9Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
10 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. See “Detailed Specifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com.Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any
individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features
utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and
configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the
specific test settings. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
11 Software. Also see 64-Bit Computing Legal Footnote, if applicable.
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Includes Microsoft® Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite.
12 Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Toshiba mini NB505-N500BL Page 5 of 5
13 Microsoft Office Starter 2010.Office Starter consists of reduced-functionality versions of Word and Excel with advertising. PowerPoint, Outlook, OneNote, Access and
Publisher are not included.
14 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
15 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
16 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
