Satellite P100-ST9772 Detailed Product Specification1
Model Name Description Part Number UPC
P100- ST9772 Genuine Windows® Vista Ultimate Edition, Intel® Core™ 2 Duo Processor T7200,
2048MB DDR2 667MHz SDRAM, 160GB HDD (5400RPM). 17” WSXGA+
TruBrite™, DVD SuperMulti DL, Intel 802.11a/b/g, NVIDIA® GeForce® Go
7900GTX w/512MB GDDR3 VRAM, 5-in-1 Card reader, Fingerprint reader,
Bluetooth v2.0+EDR, Dual-mode Pad, 1-Year Standard Limited Warranty.
PSPAGU-017017 032017815964
Section 1.01Operating System2CPU_64
•Genuine Windows® Vista Ultimate Edition (32-bit version)
Section 1.02Processor and Chipset3
Intel® Centrino® Duo Mobile Technology featuring:
•Choice of processors:
oIntel® Core™ 2 Duo Processor T7200
2.00GHz, 4MB L2, 667MHz FSB with
64-bitCPU_64
•Chipset
oMobile Intel® 945 PM Express Chipset
•Integrated Wi-Fi® compliant wireless LAN
oIntel® PRO/Wireless 3945ABG (802.11a/b/g)
Section 1.03
Section 1.04
Section 1.05
Section 1.06
Section 1.07
Section 1.08
Section 1.09
Section 1.10
Section 1.11
Section 1.12
Section 1.13
Memory4
•Configured with 2048MB PC5300 DDR2 SDRAM
•512MB (Min)/4096MB (Max), with 512MB, 1024MB or 2048MB
PC4200 or PC5300 DDR2 memory modules.
Hard Disk Drive5
•160GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 12.5mm
height
Fixed Optical Disk Drive6
•DVD SuperMulti (+/-R double layer) drive supporting 11 formats
oMaximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (5x)
Display7
•17.0” diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1680x1050 native resolution (WSXGA+)
Graphics8
•PCI-Express™ x16 graphics subsystem, featuring:
oNVIDIA® GeForce® Go 7900GTX with 512MB GDDR3
SDRAM discrete graphics memory
Sound
•Built-in harman/kardon® stereo speakers
•Sound Volume Control Dial
Input Devices
•Keyboard
o103 key US with 10-key
oHot Key Functions (Fn)
oWindows Key Function
oApplication Key Function
•Dual Mode Pad pointing device
•TouchPad™ Enable/Disable
•Control Buttons:
oInternet button to launch default browser
oExpress Media Player CD/DVD launch button
oCD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
•Remote Control
oExpress Media Player remote control
Communications
•Toshiba V.92 software modem9
•Intel® PRO/1000 PL Network Connection - 10/100/1000 Base-TX
Ethernet
•Integrated Wireless-LAN:10
oIntel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
•Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
•Consumer Infrared for remote control (for the Express Media Player
Remote)
Expandability
•2 main memory slots. Both slots may be occupied.
•One PCMCIA – Type II/Type I Card Slot
•ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
•5-in-1 Bridge Media Adapter
oSecure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
oSecure Digital slot supports SDIO
Ports
•Video
oRGB (monitor) output port
oS-Video output port
oDVI-D output port
•Audio
oS/P DIF output port (shared with headphone port)
oMicrophone input port
oHeadphone output port
•Data oi.LINK™ IEEE-1394
oUSB v2.0 – 4 ports
oRJ-45 LAN port
oRJ-11 modem port
Physical Description for this Product Series
•Dimensions 15.5” (394.0mm) x 10.8” (275.0mm) x 1.41”
(35.9mm)[F]/1.65” (41.9mm)[R] without feet
•Weight: Starting at 7.1 lbs (3.2 kg) depending upon configuration11
•Chassis Description
oCase material: Polycarbonate ABS
oLCD Cover Color: Onyx Blue Metallic
•Physical Security
oSlot for cable lock;
oItems protected by a screw: Memory, Main HDD, WiFi
Card
oFingerprint reader
•Software Security
oPasswords: User power-on password, supervisor
password
oHotkey locks: Screen Blank

Power Supply
© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P100-ST9772 BTS Rev. 1.00 2007-02-07 SK T20060830 CB1.70 Page 2 of 5
Section 1.14
Section 1.15
Section 1.16
•120W (15V x 8A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 5.90” (150.0mm) x 1.20” (36.0mm) x 2.60”
(65.0mm)
•Weight: starting at 1.1 lbs (650 g)
Battery12
•9-cell (6000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Dimensions (WxDxH): 8.11” (206.0mm) x 2.99” (76.0mm) x 0.79”
(20.0mm)
•Weight: starting at 0.99 lbs (451 g)
•Recharge Time
oMain Battery Off/On – approximately 4.0 hrs/approximately
4.0 to 13.0 hrs
Software13CPU_64
•Toshiba Software and Utilities
oTOSHIBA ConfigFree®
oTOSHIBA Custom Utilities
oTOSHIBA Disc Creator
oTOSHIBA Game Console
oElectronic User’s Guide
oToshiba Bluetooth driver software
•Third-party Software
oAdobe® Acrobat® Reader
oInterVideo® WinDVD® 8
oMicrosoft® Money 2007 Essentials
oSun® Java™ 2 Runtime Environment
oULEAD DVD Movie Factory 5
oYahoo! Music Engine
•Trial Software
oMicrosoft® Office Ready Suite 2007 (60-day trial)
oMcAfee® Internet Security Suite (30-day trial)
oAOL® Internet Service (6-month trial)14
Section 1.17Environmental Specifications
Operating Non-operating
Temperature15 5° to 35° C
(41° to 95° F) -20° to 65° C (-4° to 149° F)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Relative Humidity
(non-condensing) 20% to 80% 10% to 95%
Altitude
(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
•Energy Star Compliant
•This product is RoHS16 compatible
TECRA / PORTEGE / SATELLITE / LIBRETTO – 1 YEAR
STANDARD LIMITED WARRANTY17
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook computer. For a full description and complete list of programs
and program terms and conditions, please visit
www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date.
Part Number Description
WSN-PEQQ2V 2nd Year Extended Service Plan
WSN-PEQQ3V 2nd/3rd Year Extended Service Plan
WSN-PEQQ4V 2nd/3rd/4th Year Extended Service Plan
SystemGuard Accidental Damage Service w/ ServiceExpress18
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Extended Service Plan included except with
1 Year plan. SystemGuard coverage must be purchased within the first 30
days of notebook purchase.
Part Number Description
WSN-PSGP1V 1st Year
WSN-PEGP2V 1st/2nd Year + Extended Service Plan
WSN-PEGP3V 1st/2nd/3rd Year + Extended Service Plan
SystemGuard Accidental Damage Service + On-Site Repair19
Combines SystemGuard and Business On-Site Repair coverage.
Extended Service Plan included except with 1 Year plan. SystemGuard
coverage must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PSGN1V 1st Year
WSN-PEGN2V 1st/2nd Year + Extended Service Plan
WSN-PEGN3V 1st/2nd/3rd Year + Extended Service Plan
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included except with 1
Year plan.
Part Number Description
WSN-PSQP1V 1st Year
WSN-PEQP2V 1st/2nd Year + Extended Service Plan
WSN-PEQP3V 1st/2nd/3rd Year + Extended Service Plan
On-Site Repair Service
On-site service will be provided at the customer’s home or business
location (excluding weekends and holidays) to perform the necessary
hardware repairs. Extended Service Plan included except with 1 Year plan.
Part Number Description
WSN-PSQN1V 1st Year
WSN-PEQN2V 1st/2nd Year + Extended Service Plan
WSN-PEQN3V 1st/2nd/3rd Year + Extended Service Plan
Article II. Accessories
For memory compatibility and the most updated accessories, please visit
www.accessories.toshiba.com
Memory
Part Number Description
PA3512U-1M1G Toshiba 1GB DDR2 667MHz PC2-5300 Memory
Module, RoHS
PA3513U-1M2G Toshiba 2GB DDR2 667MHz PC2-5300 Memory
Module, RoHS
Power
Part Number Description
PA3507U-1ACA Toshiba 120W Global AC Adapter
PA3480U-1BRS Toshiba Primary Li Ion Battery Pack 9-Cell, RoHS
Security & Protection
Part Number Description
PA410U Targus DEFCON CL Cable Lock
Storage
Part Number Description

PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit, RoHS
© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P100-ST9772 BTS Rev. 1.00 2007-02-07 SK T20060830 CB1.70 Page 3 of 5
PA1399U-1MEM Toshiba 1GB USB Hi-Speed Flash Drive
Bluetooth
Part Number Description
PA1381U-1ETC Toshiba Wireless Audio Headphones with Bluetooth
Technology
Article III. Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Article IV. Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your computer, Toshiba America
Information Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the computer system.
Pro-rata refunds on individual computer components or bundled software, including the operating system, will not be granted. If you wish to return a complete
computer system, contact the TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS computer Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo
are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are
registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered
trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the
Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.
CPU_64 64-bit computing:
64-bit processors are designed to take advantage of 32 and 64 bit computing.
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device Drivers
- 64-bit Applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the
operating system is preinstalled on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).

© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P100-ST9772 BTS Rev. 1.00 2007-02-07 SK T20060830 CB1.70 Page 4 of 5
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental
Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information.
4Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors. For computers configured with 4 GB of system memory, the full system
memory space for computing activities will be considerably less and will vary by model and system configuration.
5Hard Disk Drive (HDD) Capacity.
1 Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2
for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product
includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content.
Actual formatted capacity may vary.
6Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain
cases, your Toshiba optical drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other
computers or optical media recorders. Additionally, certain optical media recorded on your optical drive may not playback or operate properly on other
computers or optical media players. These problems are not due to any defect in your Toshiba computer or optical drive. Please refer to your computer
product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
7Display. Small bright dots may appear on your screen display when you turn on your computer. Your display contains an extremely large number of thin-
film transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic
characteristic of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will
deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.
8Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU
performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
9Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
11 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its
ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
13 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
14 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE SIX-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges may
apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling plan,
even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is required.
15 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.

© Copyright 2005 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P100-ST9772 BTS Rev. 1.00 2007-02-07 SK T20060830 CB1.70 Page 5 of 5
16 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and
electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook
component suppliers to meet RoHS requirements and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling
inspections during the product design approval process.
17 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
18 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
19 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
