Toshiba P755-S5265 User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P755-S5265 Page 1 of 4
Satellite P755 Detailed Product Specification1
Model Name: P755-S5265 Part Number: PSAY1U-00V005 UPC: 883974831814
Operating System C1 2
Genuine Windows®7 Home Premium 64-bit
Processor3and Graphics4
Intel®Core™ i5-2410M Processor
o2.3 GHz (2.9 GHz with Turbo Boost Technology), 3MB L3 Cache
Mobile Intel®HM65 Express Chipset
Mobile Intel®HD graphics with 64MB-1696MB shared graphics memory
Memory5
Configured with 6GB DDR3 1333MHz (max 8GB)
2 main memory slots. Both slots occupied.
Storage Drive6
640GB (5400 RPM) Serial ATA hard disk drive
TOSHIBA Hard Drive Impact Sensor (3D sensor)
Fixed Optical Disk Drive7
DVD SuperMulti drive supporting 11 formats
oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x),
DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (6x),
DVD-RAM (5x)
Display8
15.6” diagonal widescreen TruBrite® TFT LCD display at 1366 x 768
native resolution (HD)
oNative support for 720p content
o16:9 aspect ratio
oLED backlit
Intel®Wireless Display Ready
Sound
Built-in harman/kardon®stereo speakers
Dolby®Advanced Audio®
Waves MaxxAudio®3
Input Devices
Premium Raised Tile LED backlit Keyboard with 10-Keypad (black)
Touch pad pointing device with multi-touch control
Media Control Buttons:
oTOSHIBA eco utility™ (Energy-saving mode)
oWireless On/Off
oMute
oCD/DVD control buttons
oVolume up, volume down
Communications
Webcam and microphone
10/100 Ethernet
Intel®802.11b/g/n wireless LAN9
Expandability
Memory Card Reader
oSecure Digital, Secure Digital High Capacity, Secure Digital
Extended Capacity, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [adapter may be required; shared
slot]
Ports
Video
oRGB (monitor) output port
oHDMI
Audio
oMicrophone input port with Toshiba Sleep and Music10
oHeadphone output port
Data
o4 USB ports (1 USB 3.011 with USB Sleep and Charge12 + 3 USB
2.0)
oRJ-45 LAN port
Security
oSlot for Security Lock
Physical Description
Fusion® X2 Finish in Platinum
Dimensions (W x D x H ): 15.0” x 9.8” x 1.1”/1.4” (with feet)
Weight: Starting at 5.8 lbs., depending upon configuration13
Battery14
6 cell/48Wh Lithium Ion battery pack
Battery Life Rating (measured by MobileMark™ Productivity 2007)15
oIncluded 6 cell battery: 6 hours, 28 minutes
Power Supply
65W (19V x 3.42A) Auto-sensing ,100-240V/50-60Hz AC Adapter
Dimensions (W x D x H): 4.21” x 1.85” x 1.2”
Weight: starting at 0.55 lbs.
Software C1 16
Toshiba Software and Utilities
oHDMI Control Manager
oTOSHIBA App PlaceSM
oTOSHIBA Assist
oTOSHIBA BookPlace™
oTOSHIBA Bulletin Board
oTOSHIBA Disc Creator
oTOSHIBA eco Utility™
oTOSHIBA Face Recognition17
oTOSHIBA HDD Protection
oTOSHIBA HDD/SSD Alert
oTOSHIBA HW Setup Utility
oTOSHIBA Laptop Checkup
oTOSHIBA Media Controller18
oTOSHIBA PC Health Monitor
oTOSHIBA Recovery Disc Creator
oTOSHIBA ReelTime
oTOSHIBA Service Station
oTOSHIBA Sleep Utility
oTOSHIBA Supervisor Password Utility
oTOSHIBA Upconvert Plug-in for Media Player19
oTOSHIBA Value Added Package
oTOSHIBA Video Player
oTOSHIBA Web Camera Application
Third-party Software
oAdobe®Acrobat®Reader
oAdobe®AIR®Runtime
oCorel®Digital Studio™ for TOSHIBA
oGoogle®Toolbar
oGoogle®Chrome
oIntel®Wireless Display 2.0
oInternet Explorer
oMicrosoft®Live Essentials
Photo Gallery
Messenger
Mail
Writer
Movie Maker
oMicrosoft®Office Starter 201020
oMicrosoft®Silverlight™
oMicrosoft®Windows Media Player 12
oWildTangent®Games Console
Special Offers and Trial Software
oNetZero®Internet Service
oNorton Internet Security™ 2011 (30-day trial subscription)
oQuickBooks®Online Banking
oSkype®
oToshiba Online Backup (30-day trial subscription)

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P755-S5265 Page 2 of 4
Environmental Specifications
This product is RoHS21 compatible
Energy Star Qualified
EPEAT™ Gold Compliant
Operating Non-operating
Temperature
22
5° to 35° C -20° to 60° C
Relative Humidity
(non-condensing) 20% to 80% 10% to 90%
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Altitude
(relative to sea level) 0 to 3,000 meters 0 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
1 YEAR STANDARD LIMITED WARRANTY23
Includes International Limited Warranty for obtaining service when
traveling outside the United States.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.support.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade
Part Number Description
PA3918U-1M2G Toshiba 2GB DDR3-1333MHz Memory Module
PA3918U-1M4G Toshiba 4GB DDR3-1333MHz Memory Module
Power
Part Number Description
PA3717U-1ACA Toshiba 120W Global AC Adapter
PA3818U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)
PA3819U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack
(12 cell)
Expansion
Part Number Description
PA3778U-1PRP dynadock V USB Docking Station with DVI/VGA port
PA3575U-1PRP dynadock U USB Docking Station with DVI/VGA port
PA3686U-1SET dynadock Wireless U Docking Station with Wireless
USB Adapter
Storage
Part Number Description
PA3877U-1M8B Toshiba 8GB USB Hi-Speed Swivel-Retractable Flash
Drive
PA3877U-1MAB Toshiba 16GB USB Hi-Speed Swivel-Retractable Flash
Drive
PA3877U-1MBB Toshiba 32GB USB Hi-Speed Swivel-Retractable Flash
Drive
E05A050CAU3XW Toshiba 500GB USB 3.0 Canvio 3.0 Portable Hard
Drive, Black with White Accents
E05A075CAU3XW Toshiba 750GB USB 3.0 Canvio 3.0 Portable Hard
Drive, Black with White Accents
E05A100PBU3XW Toshiba 1TB USB 3.0 Canvio 3.0 Plus Portable Hard
Drive, Black with White Accents
Bluetooth
Part Number Description
PA3710U-1BTM Toshiba Bluetooth 2.1+EDR USB Nano Adapter
Carrying Case
Part Number Description
PA1463U-1SP6 Toshiba 16" Metropolitan Carrying Case (Fits up to 16")
PA1505U-1CS6 Toshiba 16" Extreme Briefcase (Fits up to 16")
PA1448U-1RS6 Toshiba 16" Envoy Roller Case (Fits up to 16")
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.support.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://support.toshiba.com
Satellite, ConfigFree and SystemGuard are registered trademarks of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. All other
products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P755-S5265 Page 3 of 4
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not
have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.
4Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary
depending on system memory size and other factors.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6Storage Drive (Internal HDD Capacity). One Gigabyte (GB) means 109= 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000 bytes using powers of
10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB = 240 =
1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed operating
systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9Wireless. May require purchase of additional software, external hardware, or services. Transmission speeds may vary. Certain optional features within the wireless-n
specifications (if available on your system) may not be supported.
10 Sleep & Music: In this mode, the headphone jack and mute functions are disabled. The volume and sound quality will diminish as the speakers not tuned in Windows®
mode. Use the volume control on your audio device to adjust sound. Audio line-in cable is not included
11 USB 3.0. 5Gbps is the maximum theoretical interface transfer rate per the specifications of the Universal Serial Bus 3.0. Actual transfer rate will vary depending on your system
configuration and other factors.
12 USB Sleep & Charge.The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn
the power of the computer ON to charge the device.

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P755-S5265 Page 4 of 4
13 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
14 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. See “Detailed Specifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com.Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any
individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features
utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and
configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the
specific test settings. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
15 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
16 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft®software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office Small Business Accounting 2006) which may be included with this computer.
Includes Microsoft®Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite.
17 Toshiba Face Recognition. For high security purposes, Toshiba Face Recognition is not a suitable substitute for Windows®passwords. To ensure the security of your system
use your established Windows® passwords to logon.
18 Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.
19 Upconverter/UpconversionTechnology (Resolution+® Technology). Viewing enhancements may vary depending upon content quality and display device
capability/functionality/settings. Depending on the quality of the content, some video noise may be visible.
20 Microsoft Office Starter 2010.Office Starter consists of reduced-functionality versions of Word and Excel with advertising. PowerPoint, Outlook, OneNote, Access and
Publisher are not included.
21 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
22 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
23 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
