Portégé R600-S4212 Page 1 of 5
Portégé R600 Detailed Product Specification1
Model Name Description Part Number UPC
R600-S4212 Genuine Windows® XP Professional, SP3, Intel® Core™ 2 Duo Processor SU9400,
3GB DDR2, 128GB SSD, DVD-SuperMulti, 12.1” widescreen WXGA, Intel® Wireless
WiFi Link 5100AGN, Webcam, Bluetooth v2.1 + EDR, 3 year standard limited warranty
(1-year warranty on battery)
PPR60U-04F034
883974333837
Operating System C1 2
Genuine Windows® XP Professional, SP3
oRecovery media for Genuine Windows® 7 Professional
Processor and Chipset3
Intel® Centrino® 2 processor technology featuring:
oIntel® Core™ 2 Duo Processor SU9400
1.4GHz, 3MB L2, 800MHz FSB with 64-bit C1
Chipset
oMobile Intel® GS45 Express Chipset
Integrated Wi-Fi® compliant wireless LAN
oIntel® Wireless WiFi Link 5100AGN (802.11a/g/n)4
Memory5
Configured with 3GB PC2-6400 DDR2 SDRAM
3GB (Min)/5GB (Max), 1GB on motherboard with one memory slots
occupied with 2GB PC2-6400 memory module
Storage Drive Capacity 6
128GB Serial ATA Solid State Drive (SSD), 3mm height
Fixed Optical Disk Drive7
DVD SuperMulti (+/-R) drive supporting 9 formats
oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
Display8
12.1” diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) - Transreflective type
oLED sidelight
Graphics9
Mobile Intel® Graphics Media Accelerator 4500MHD with 128MB-
1340MB dynamically allocated shared graphics memory
Sound
Built-in mono speaker
Sound volume control dial
Built-in microphone
Input Devices
85 key US keyboard
TouchPad™ pointing device
Control Buttons:
oToshiba Assist button
oToshiba Outdoor Display Switch
Communications
Integrated Webcam
Intel® PRO/1000 - 10/100/1000 Ethernet
Integrated Intel® Wireless WiFi Link 5100AGN (802.11a/g/n) 10
Bluetooth® version 2.1 plus Enhanced Data Rate (EDR)
Expandability
ExpressCard™ slot
Secure Digital (SDHC) slot
Ports
Video
oRGB (monitor) output port
Audio
oMicrophone input port
oHeadphone output port
Data
oUSB v2.0 – 3 ports
o2 x USB v2.0
o1 x eSATA/USB combo port with USB Sleep and
Charge11
o64-pin docking connector
Supported on Toshiba Slim Port Replicator lll
oDVI-D output port
oUSB v2.0 – 6 ports
oAudio In
oRGB
oAudio Out
oDC-IN
oLAN (RJ45)
Security
oFingerprint reader
Physical Description
Dimensions (WxDxH Front/H Rear): 11.1” x 8.5” x 0.77”(f)/1.0”(r) with
feet
Weight: Starting at 2.4 lbs depending upon configuration12
LCD Cover Color: Aluminum Silver
Power
45W (15V x 3A) 100-240V AC Adapter.
Dimensions (WxDxH): 3.66” x 1.09” x 1.57”
Weight: starting at 0.4 lbs
Battery13
(5800mAh) Lithium Ion battery pack
Dimensions (WxDxH): 8.1” x .79” x 1.72”
Weight: starting at 0.69 lbs
Battery Life (measured by MobileMark™)14
oIncluded 6-cell battery: 7 hours, 32 minutes
Toshiba EasyGuard®15
Protect & Fix
oPC Health Monitor
oShock Absorbing Design16
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
oHard Disk Drive Protection
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
oSpill-Resistant Keyboard17
oMagnesium Alloy Casework
Secure
oMultiple-Level Password Utilities
oFingerprint Reader (includes software for password and identity
management)
oAuthenTec EntréPad® TruePrint® technology
oInfineon TPM Software Professional Package
oTrusted Platform Module (TPM v1.2)
oTOSHIBA Secure Digital Token Utility
oExecute Disable Bit
oOptional Services and Accessories (additional purchase required)
CompuTrace®
Connect
oDiversity Antenna
oTOSHIBA ConfigFree®
oVoice-over-IP Ready Design
oTOSHIBA Bluetooth® Stack
Optimize
oTOSHIBA Zooming Utility
oOne-touch Resolution Change
oTOSHIBA Power Saver Utility

© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R600-S4202 1.0 Page 2 of 5
oTOSHIBA Optical Disc Drive Power On/Off Utility
oWireless On/Off Switch
oTOSHIBA Fn-esse® Shortcut Utility
oTOSHIBA Mouse Utility
oFN Shortcut Keys
BIOS
ACPI v2.0, PNP, VESA, SM BIOS v2.5, PCI BIOS v2.1 support
Software C1 18
Toshiba Software and Utilities
oElectronic User’s Guide
oBluetooth Stack for Windows by Toshiba
oTOSHIBA ConfigFree®
oTOSHIBA Management Console
oTOSHIBA Assist
oTOSHIBA Security Assist
oTOSHIBA Disc Creator
oTOSHIBA Recovery Disc Creator
Third-party Software
oSun® Java™ 2 Runtime Environment
oAdobe® Acrobat® Reader
oGoogle™ Desktop
oGoogle™ Toolbar
oGoogle™ Picasa™
oInfineon TPM Software Professional Package
Trial Software
oMicrosoft Office Ready with Microsoft Office Professional 2007
60-day Trial Edition
oNorton Internet Security™ 2008
Special Offers
oComputrace® LoJack® for Laptops (BIOS Enabled)
Environmental Specifications
Operating Non-operating
Temperature
19
5° to 35° C
(41° to 95° F) -20° to 65° C (-4° to 149° F)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Relative Humidity
(non-condensing) 20% to 80% 10% to 90%
Altitude
(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
Energy Star 5.0 Compliant
EPEAT™ Gold
This product is RoHS20 compatible
TECRA / PORTEGE / LIBRETTO – 3 YEAR STANDARD
LIMITED WARRANTY21
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date. Must be purchased within the first 6 months of
notebook purchase.
Part Number Description
WSN-PTQQ4V 4th Year Extended Service Plan
SystemGuard Accidental Damage Service w/ ServiceExpress22
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Extended Service Plan included with 4 Year
plan. Must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PQGP3V 1st/2nd/3rd Year
WSN-PTGP4V 1st/2nd/3rd/4th Year + Extended Service Plan
SystemGuard Accidental Damage Service + On-Site Repair23
Combines SystemGuard and On-Site Repair coverage. Extended Service
Plan included with 4 Year plan. Must be purchased within the first 30 days
of notebook purchase.
Part Number Description
WSN-PQGN3V 1st/2nd/3rd Year
WSN-PTGN4V 1st/2nd/3rd/4th Year + Extended Service Plan
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included with 4 Year plan.
Must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PQQP3V 1st/2nd/3rd Year
WSN-PTQP4V 1st/2nd/3rd/4th Year + Extended Service Plan
On-Site Repair Service
On-site service will be provided at the customer’s home or business location
(excluding weekends and holidays) to perform the necessary hardware
repairs. Extended Service Plan included with 4 Year plan. Must be
purchased within the first 6 months of notebook purchase.
Part Number Description
WSN-PQQN3V 1st/2nd/3rd Year
WSN-PTQN4V 1st/2nd/3rd/4th Year + Extended Service Plan
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Power
Part Number Description
PA3282U-2ACA Toshiba 60W Global AC Adapter
PA3612U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3091U-2CHG Toshiba Battery Charger w/Integrated AC Adapter
Expansion
Part Number Description
PA3603U-1PRP Toshiba Slim Port Replicator II
PA3579U-1ETC Toshiba Universal Notebook/Projector Stand
Security & Protection
Part Number Description
PA410U Targus DEFCON CL Notebook Cable Lock
Storage
Part Number Description
HDDR250E03X Toshiba External USB Hard Drive, 250GB
HDDR320E03X Toshiba External USB Hard Drive, 320GB
HDDR400E03X Toshiba External USB Hard Drive, 400GB
PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive
PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash Drive
PA3556U-1M8G Toshiba 8GB USB Hi-Speed Flash Drive
Carrying Case
Part Number Description
PA1402U-1NCS Toshiba Executive leather Portfolio for A600, R200,
R500, R600
Security & Protection
Part Number Description
PA410U Targus DEFCON CL Notebook Cable Lock

© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R600-S4202 1.0 Page 3 of 5
Bluetooth/Wireless
Part Number Description
PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/Silver)
PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/Red)
Article I. Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Article II. Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled
on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features
and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.

© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R600-S4202 1.0 Page 4 of 5
4Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less
and will vary by model and system configuration.
6Storage Drive Capacity
Solid State Drive (SSD) Capacity.
Computer (Internal) SSD Capacity. One Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer
includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity
may vary.
7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized
when operating in AC power mode and may decrease considerably when operating in battery power mode.
10 Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment.
11 USB Sleep & Charge. The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn
the power of the computer ON to charge the device.
12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
13 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as
well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations
tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while
computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
Battery life will be less than when using similar applications in the Windows Operating System
14 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
15 EasyGuard. Toshiba EasyGuard™ technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the
model selected. See www.easyguard.toshiba.com for detailed information.
16 Shock Protection. Toshiba’s shock absorption technology provides higher impact protection for your system as compared to Toshiba systems without similar shock protection
features based on Toshiba’s drop tests. Toshiba’s standard limited warranty terms and limitations apply. Visit www. warranty.toshiba.com for details.
17 Spill-Resistant Keyboard. Under Toshiba testing conditions, the spill-resistant keyboard delayed the time for a water spill to reach the PC's main board to allow more time to
properly close down the machine. Toshiba’s standard limited warranty terms and limitations apply. Visit www.warranty.toshiba.com for details.
18 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products which may be included with this computer.
The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation
procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which
time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without
charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the
perpetual version of such Office Product.
19 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
20 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R600-S4202 1.0 Page 5 of 5
21 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
22 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
23 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
