Toshiba R15-S8222 User manual

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite R15 Series BTS Rev. 0.10 3-16-2005 LTA CB1.00
Page 1 of 3
Satellite R15 Series
Model Name Description Part Number UPC Code
Satellite
R15-S8222
Pentium M 725 (1.60GHz), 512MB, 14.1”XGA, 60GB(4200 RPM), 802.11bg (Intel),
DVD-SuperMulti, Microsoft Windows XP Tablet Edition
PSR10U-0K900G 032017325302
System Characteristics1
Operating System
•Microsoft® Windows® XP Tablet Edition 2005 (SP2)
Intel® Centrino™ Mobile Technology featuring:
•Intel Pentium® M Processor 725 [1.60GHz, 2MB L2 cache,
400MHz FSB]2
•Intel 855GME Chipset
•Intel PRO/Wireless 2200BG (802.11b/g) integrated Wi-Fi™
compliant wireless LAN3
Memory
•512MB (Min)/2048MB (Max) DDR333 SDRAM 2.5V SODIMM
Memory configurable from 256MB to 2048MB.4
•Both Slots may be occupied
Mass Storage
Hard Drive5
•60GB (4200 RPM) Parallel (ATA) hard disk drive; 9.5mm height
Optical Disk Drive
•Fixed Bay DVD-SuperMulti Drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW (4x:write),
DVD-ROM (8x:read), DVD-R (8x:write), DVD-RW
(4x:write), DVD+R (2x:write), DVD+RW (4x:write), DVD-
RAM (3x:write)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read/write), DVD-RW
(read/write), DVD+R (read/write), DVD+RW (read/write),
DVD-RAM (read/write)
Optional Floppy Disk Drive & Optical Disk Drive & Hard Drive
(See Accessories)
•Optional External USB Floppy Drive, 3.5”, 1.44MB
•Optional SelectBay DVD SuperMulti Drive
•Optional SelectBay Hard Disk Drive
Display6
•14.1” diagonal standard TFT active-matrix LCD display at
1024x768 (XGA) native resolution
•Contrast – 500:1
•Brightness --S 170 Cd/m2
•Viewing angle:
oHorizontal – 140 degrees
oVertical – 120 degrees
•Brightness Control – FN+F6/ F7 and Toshiba Power Saver
Graphics
•Intel Extreme Graphics 2, 16MB-64MB (DVMA) shared video
memory
Input Devices
•Toshiba Digitizer Tablet Pen
•3 Hardware Buttons: Windows Security Button, ESC/Display
Rotation Button, Cross Funtional Button
•Keyboard
o85 key US keyboard, 2.7mm key stroke, 6mm keyboard
height, 19.05mm key pitch
oHot Key Functions (FN); please see electronic User’s Guide
for more information
oWindows Key Function
oApplication Key Function
•Mouse:
oTouchPad™ pointing device
oTouchPad Enable/Disable (FN+F9 or by help of software)
Expandability
•2 main memory slots. Both slots may be occupied.
•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
•1 SD card slot
Communications
•Integrated V.92 modem7
•Integrated 10/100 Base-TX Ethernet
•Integrated Intel® Pro/Wireless Network Connection 2200BG
(802.11b/g)
Ports
•RGB (monitor) port
•TV-out (S-Video)
•i.LINK(tm) IEEE-1394
•3 Universal Serial Bus (USB) ports (v2.0)
•External Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
•240 pin docking connector
Physical Description
•Approximate Dimensions (WxDxH Front/H Rear):
12.9”x11.4 x1.45”/1.57”
•Approximate Weight8: Starting at 6.12lbs depending on
configurations
Sound
•Analog Devices 1981B integrated Software Sound
•16-bit stereo; Built-in stereo speakers, Built-in microphone
•Direct 3D Sound; DirectSound, Direct Music, MIDI (playback)
Support
•Sound Volume Control Dial
•Built-in microphone (monoaural)
•SRS® TruSurround XT® Technology with Virtual Surround with
Dialog Clarity (SRS® TruSurround XT® Technology features:
TruSurround, SRS Dialog Clarity FOCUS, & TruBass)
Power Supply
•60W (15V x4A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 4.38” x 1.14” x 1.94”
•Weight: starting at 0.57 lbs
Battery9
•6-cell (4700mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Dimensions (WxDxH): 4.92” x 2.68” x 0.80”
•Weight: starting at 0.74 lbs
•Battery Life: Up to 4 hours (measured by MobileMark™) (6-cell
battery) 10
Security
•Slot for cable lock, HDD, memory (by screw only; User Power-
on Password, Supervisor Password, Screen Blank (by HotKey),
Screen Saver (by software)
Software11
Toshiba Software and Utilities
•Toshiba ConfigFree™
•Toshiba Custom Utilities
•Electronic User’s Guide
•Toshiba Speech System
•Toshiba Touch and Launch
Third-party Software
•Microsoft® Works
•Microsoft® Office OneNote™ 2003
•Zinio Reader

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite R15 Series BTS Rev. 0.10 3-16-2005 LTA CB1.00
Page 2 of 3
•Franklin Covey Tablet Planner (30 Day Trial )
•Alias® SketchBook™ (30 Day Trial)
•Software Decoder: Intervideo® (WinDVD™ 5
•Sonic® Solutions Drive Letter Access (DLA)
•ArcSoft ShowBiz® DVD Version 1.3
•Intuit® Quicken® New User Edition 2004
•Norton AntiVirus™ 2004 – w/3-Month Subscription
•AOL® (3 –Month offer)
•AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL
BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services
carry surcharges and communication surcharges may apply, including AK, even
during promotional period. Members may incur telephone charges on their phone bill,
depending on their location and calling plan, even during promotional period.
Available to new AOL members in the United States, age 18 or older; a major credit
card or checking account is required.
•Adobe® Acrobat Reader
•AT&T® Worldnet® Service – 1 Month FREE
•Telephone access and other charges and other terms and conditions may apply.
Offer available to new customers only.
•QuickTime™ Player
•RealOne™ Player 8 Basic
•Microsoft® Internet Explorer
•Napster® online digital music service (30-day trial)
•TOSHIBA MyConnect™ - 45 day free trial offer
•MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your
Access Plan before the end of the trial period to avoid being charged the $39.95
monthly Access Service fee for the six month plan commitment period. Monthly
automatic renewal feature after end of commitment period. Available to new members
in the U.S., age 18 or older, and a major credit card for billing is required. Offer is for
unlimited dial-up, wired broadband, or Wi-Fi remote access connection time in the 50
United States and the District of Columbia within the MyConnect service area for 30
day continuous service periods. Use of optional 800 telephone number dial-up usage
will incur additional fees even during the trial period. Other terms and conditions
apply. Offer expires June 30, 2005.
Environmental Specifications
Operating Non-Operating
Temperature 5
° to 35 ° C
(41
° to 95 ° F)
-20
° to 65 ° C
(-4
° to 149 ° F)
Thermal Gradient 15
° C per hour
maximum
20 ° C per hour
maximum
Relative Humidity 20% to 80% 10% to 90%
Altitude (relative to sea
level)
-60 to 3000 meters -60 to 10,000
meters
Shock 10G 60G
Vibration 0.5G 1.0G
Limited Warranty
•1 year parts, labor and battery
Extended Warranty
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description
and complete list of programs, please visit www.accessories.toshiba.com
Models with 1 Year Standard Limited Warranty
Part Number Description
SWP-PEQQ3V 2nd/3rd Year Warranty Extension
SWP-PEGQ3V 3 Year SystemGuard + 2nd/3rd Year Warranty
Extension
SWP-PEQP3V 3 Year ServiceExpress + 2nd/3rd Year Warranty
Extension
SWP-PEQH3V 3 Year At-Home Repair + 2nd/3rd Year Warranty
Extension
SWP-PEGP3V 3 Year SystemGuard + Service Express + 2nd/3rd
Year Warranty Extension
Accessories
For additional and most update accessories, please visit
www.accessories.toshiba.com
Memory
Part Number Description
KTT3311/256 Kingston DDR2 256MB
KTT3311/512 Kingston DDR2 512MB
KTT3311/1G Kingston DDR2 1GB
SD Memory Cards
Part Number Description
SD-M5124B3 Toshiba 512MB SD (Secure Digital)
Power
Part Number Description
PA3283U-2ACA Toshiba 75W Global AC adapter
PA3191U-4BRS Toshiba Primary Li-Ion Battery Pack (6 cell)
PA3091U-1CHG Toshiba Battery Charger w/Integrated AC Adapter
Cases-Security
Part Number Description
PA1335U-1NCS Toshiba Ambassador Leather Case (15.4")
PA1377U-1NCS Toshiba/Brenthaven Universal Case (15.4")
PA1378U-1NCS Toshiba/Brenthaven Roller Case (17")
NWDEFCL Targus-NoteWorthy DEFCON CL Cable Lock
Expansion/Docking
Part Number Description
PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC
Adapter
PA3109U-1FDD Toshiba USB Floppy Disc Drive Kit
PA3390U-1MPM Toshiba MultiMedia Center/Audio USB Hub
PA3359U-1DV2 Toshiba Slim SelectBay DVD SuperMulti Drive Kit
Input Devices
Part Number Description
PA3316U-2ETC Toshiba Tablet PC Pen II
PA3317U-1ETC Toshiba Tablet PC Reserve Pen
PA1357U-2ETC Toshiba Tablet Pen Tether II
PA1336U-1NKB Toshiba USB Keyboard
PA1337U-1NMS Toshiba USB Optical Scroller Mouse
PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller Mouse
PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC adapter)
PA1370U-1ETC Toshiba Keyboard Protector
Storage & HDD
Part Number Description
PA3204U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 5400 rpm
PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm
PA3134U-1ETC Toshiba Slim SelectBay HDD Adapter (Blk Bezel)
PA3404U-1H40 Toshiba USB Mobile Hard Drive 40GB (1.8")
HDD1232CZP41002 Toshiba 5GB Type II PC Card HDD w/Back-up
software
UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup Syst
UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup Syst
BlueTooth
PA3370U-1BTM Toshiba Bluetooth SD Card V1.2
PA3405U-1BTM Toshiba Bluetooth USB adapter
PA1381U-1ETC Toshiba Bluetooth Headphones
PA1380U-1NMS Toshiba Bluetooth Travel Mouse
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://pcsupport.toshiba.com. The product
specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or
illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
http://pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite R15 Series BTS Rev. 0.10 3-16-2005 LTA CB1.00
Page 3 of 3
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your select model may not have all the
features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.
2CPU performance in your computer product may vary from specifications under the following conditions:
1. Use of certain external peripheral products
2. Use of battery power instead of AC power
3. Use of certain multimedia, computer generated graphics or video applications
4. Use of standard telephone lines or low speed network connections
5. Use of complex modeling software, such as high end computer aided design applications
6. Use of several applications or functionalities simultaneously
7. Use of computer in areas with low air pressure (high altitude greater than 1,000 meters or greater than 3,280 feet above sea level)
8. Use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at
www.pcsupport.toshiba.com for details.)
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions
under “Environmental Conditions” in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.
3Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone
charges or air time to achieve the functionality as advertised. The transmission speed over the wireless LAN and the distance over which wireless LAN can
reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and
software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
4The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system
memory available for other computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system,
applications utilized, system memory size and other factors
5One (1) Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage
capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available
storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-
installed software applications, or media content. Actual formatted capacity may vary.
6Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT)
and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT
manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an
intrinsic characteristic of LCD technology.
7Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
8Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
9Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at
maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that
shipped with your computer or visit the Toshiba web site at http://www.accessories.toshiba.com.
10 MobileMark™ is a registered trademark of Business Applications Performance Corporation.
11 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
