Toshiba R700-ST1303 User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege R700- T1303 Page 1 of 4
Portege R700 Detailed Product Specification
1
Model Name Description Part Number UPC
R700
-
ST130
3
Genuine Windows
®
7 Professional, Intel
®
Core™ i5-560M Processor, 2GB DDR3,
320GB 5400rpm ATA, DVD- uperMulti,13.3” widescreen HD, Mobile Intel
®
HD
Graphics, Intel
®
Wi-Fi
®
802.11 a/g/n wireless LAN, 6-cell battery, 1 year standard
limited warranty
PT311U-08404V 883974642458
Operating System
C1 2
• Genuine Windows
®
7 Professional 32-bit, Genuine Windows
®
7
Professional 64-bit
• Genuine Windows
®
7 Ultimate 32-bit, Genuine Windows
®
7 Ultimate 64-
bit(optional)
Processor
3
and raphics
4
• Intel
®
Core™ i5-560M Processor
o 2.66 GHz (3.2 GHz with Turbo Boost Technology), 3MB Cache
• Intel
®
Core™ i7-620M Processor(Optional)
o 2.66 GHz(3.33 GHz with Turbo Boost Technology), 4MB Cache
• Mobile Intel
®
QM57 Express Chipset (AMT 6.0)
• Mobile Intel
®
HD Graphics with dynamically allocated shared graphic
memory
Memory
5
• Configured with 2GB (2GB x 1) DDR3 (max 8GB)
• 3GB (2GB + 1GB) / 4GB (2GB + 2GB) / 4GB (4GB x 1) / 6GB(4GB +
2GB) / 8GB (4GB x 2) (Optional)
Storage Drive
6
• 320GB (5400 RPM); erial ATA hard disk drive
• 500GB (5400 RPM), 320GB (7200 RPM); erial ATA hard disk drive
(Optional)
• 128GB erial ATA olid tate Drive ( D), 3mm height (Optional)
Fixed Optical Disk Drive
7
• DVD uperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (4X),
DVD-RW (6x), DVD+R (8x), DVD+R DL (4x), DVD+RW (8x),
DVD-RAM (5x)
Display
8
• 13.3” diagonal widescreen HD TFT LED display at 1366x768 native
resolution
o Native support for 720p content
o 16:9 aspect ratio
o LED backlight
Sound
• Built-in stereo speakers
Input Devices
• Premium U keyboard (black)
• TouchPad™ pointing device with multi-touch control
• TouchPad™ Enable/Disable
• Control Buttons:
o TO HIBA eco utility™ (Energy-saving mode)
o Touchpad on/off
o Presentation button
Communications
• Webcam (Optional)
• Microphone
• Intel 82577LM Gigabit Network Connection (10/100/1000)
• Intel
®
Centrino
®
Advanced-N 6200 (802.11a/g/n +WiDi Capable)
9
o Intel® Wireless Display (WiDi) Technology Capable (Requires optional
display adapter sold separately)
• Intel
®
Centrino
®
Advanced-N 6250 (802.11a/g/n +WiDi Capable)
10
(optional)
o Intel® Wireless Display (WiDi) Technology Capable (Requires optional
display adapter sold separately)
o Intel® 4G WiMax™ Capable
• Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
• 2 main memory slots accessible from the bottom. Both slots may be
occupied
• ExpressCard™/54 slot
• Memory Card Reader
o ecure Digital, ecure Digital High Capacity, Mini D Card,
DXC, Multi Media Card [shared slot may require adapter for
use]
Ports
• Video
o RGB
o HDMI
• Audio
o Microphone input port
o Headphone output port
• Data
o 3 U B v2.0 ports
• 2 x 1 U B v2.0
• 1 x e ATA/U B combo with U B leep and Charge
11
o RJ-45 LAN port
o Docking connector
• ecurity
o Fingerprint Reader
o lot for security lock
Physical Description
• Magnesium Finish in Black
• Dimensions (W x D x H Front/H Rear): 12.44” x 8.94” x 0.72”/1.04”
without feet
• Weight: tarting at 3.0 lbs. depending upon configuration
12
Power
• 65W (19V 3.42A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x H x D): 4.25” x 1.81” x 1.16”
o Weight: starting at 0.49 lbs.
Battery
13
• 6 cell/66Wh Lithium Ion battery pack
• 9-cell/93Wh extended capacity battery pack(Optional)
Toshiba Easy uard
® 14
• Protect & Fix
o Toshiba PC Health Monitor
o TO HIBA HDD protection
o TO HIBA hock Protection ystem
o HALT Tested Design
o LCD Cover pressure Resistant Design
o Hinge Design Enhancement
o Polyurethane (PU) Coated Palm Rest
o pill Resistant Keyboard
o TO HIBA PC Diagnostic Tool
• ecure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad
®
True uite
®
o Infineon TPM oftware Professional Package
o Trusted Platform Module v1.2
o TO HIBA ecure Digital Token Utility
o Reinforced ecurity Cable Lock lot
o Execute Disable Bit
• Connect
o Diversity Antenna
o TO HIBA ConfigFree
®

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege R700- T1303 Page 2 of 4
o Voice-over-IP Ready Design
o TO HIBA Bluetooth
®
tack
o Wireless Communication On/Off witch
• Optimize
o Toshiba Disc Creator
o TO HIBA Device Access Control
o TO HIBA Power Management Extension
o TO HIBA Password Utilities
o TO HIBA Recovery Media Creator
o TO HIBA eco Utility
o TO HIBA Assist
o TO HIBA U B leep and Charge
o TO HIBA Zooming Utility
o FN hortcut Keys
Software
C1
15
• Toshiba oftware and Utilities
o TO HIBA Recovery Disc Creator
o TO HIBA ervice tation
o TO HIBA Face Recognition
o TO HIBA HW etup Utility
o TO HIBA Value Added Package
o TO HIBA Web Camera Application
o TO HIBA Disc Creator
o TO HIBA PC Health Monitor
o TO HIBA Eco Utility
o TO HIBA upervisor Password Utility
o TO HIBA Media Controller Plug-in
o TO HIBA Assist
o TO HIBA Media Controller
16
o TO HIBA Bulletin Board
o TO HIBA ReelTime
• Third-party oftware
o Microsoft
®
Windows Media Player
o Intel
®
Wireless Display(WiDi) Technology 1.2(optional)
o Intel
®
WiMax Connectivity Manager(optional)
o Microsoft
®
Windows
®
Live™ Essentials including Photo Gallery,
Messenger, Mail and Writer.
o Microsoft
®
Office tarter 2010 (Reduced functionality Word
®
and
Excel
®
with advertising)
17
o Microsoft
®
ilverlight™
o Internet Explorer
o Adobe
®
Acrobat
®
Reader
o Google
®
Toolbar
o Microsoft
®
Office
®
Home and tudent 2010 (If purchased at time
of system configuration)
o Microsoft
®
Office
®
mall Business 2010 (If purchased at time of
system configuration)
o Microsoft
®
Office
®
Professional 2010 (If purchased at time of
system configuration)
• Trial oftware
o Norton Internet ecurity™ 2010 (30-day trial trial subscription)
• pecial Offers
o Toshiba Online Backup (30-day trial subscription available)
o Intuit® Quickbooks
®
Financial Center
o kype
®
Environmental Specifications
• This product is RoH
18
compatible
• Energy tar Qualified
• EPEAT™ Gold Compliant
Operating Non-operating
Temperature
19
5° to 35° C -20° to 65° C
Thermal Gradient 15° C per hour (max) 20° C per hour
Relative Humidity
(non-condensing)
20% to 80% 10% to 90%
Altitude
(relative to sea level)
-60 to 3,000 metres -60 to 10,000 metres
hock 10G 60G
Vibration 0.5G, 0.25G w/ODD 1.0G
1 YEAR STANDARD LIMITED WARRANTY
20
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
2 YEAR STANDARD LIMITED WARRANTY
21
(optional)
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
3 YEAR STANDARD LIMITED WARRANTY
22
(optional)
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as ystemGuard
®
,
On- ite Repair, and erviceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade
Part Number Description
PA3676U-1M2G Toshiba 2GB DDR3-1066 memory module
PA3677U-1M4G Toshiba 4GB DDR3-1066 memory module
Power
Part Number Description
PA3714U-1ACA Toshiba 65W Global AC Adapter
PA3832U-1BR Toshiba Primary Li-Ion Battery Pack (6 Cell)
PA3833U-1BR Toshiba Primary Extended Capacity Li-Ion Battery Pack
(9 Cell)
Expansion
Part Number Description
PA3838U-1PRP Toshiba Hi- peed Port Replicator for R700
Carrying Case
Part Number Description
PA1445U-1C 4 Toshiba 14” Envoy eries Ballistic Polyester Carrying
Case(Fits up to 14.1”)
PA1457U-1CL4 Toshiba 14” Envoy Leather Carrying Case(Fits up to
14.1”)
PA1485U-1 N3 Toshiba 13.3" Neoprene leeve
Storage
Part Number Description
PA3556U-1M2G Toshiba 2GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M4G Toshiba 4GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M8G Toshiba 8GB U B Hi- peed Flash Drive, ReadyBoost
E05A050CAU2XK Toshiba 500GB U B 2.0 Port Hard Drive, Raven Black
E05A075CAU2XL Toshiba 750GB U B 2.0 Port Hard Drive, Liquid Blue
E05A100PBU2XY Toshiba 1TB U B 2.0 Port Hard Drive, atin ilver
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege R700- T1303 Page 3 of 4
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
ystems, Inc. (“TAI ”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAI dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information ystems, Incorporated (“TAI ”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAI website for resellers: http://sell.toshiba.com
TAI PC upport website: http://pcsupport.toshiba.com
Qosmio, atellite, Portégé, Tecra, electBay, ConfigFree, ystemGuard, EasyGuard are registered trademarks of Toshiba America Information ystems, Inc.
and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating ystem
- 64-bit CPU, Chipset and BIO (Basic Input/Output ystem)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. ee "Detailed pecs" for more information.
1
Product Series Legal Footnote. The product specifications and configuration information are designed for a product eries. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information ystems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2 Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3 Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed pecs.” Contact Toshiba Technical
ervice and upport for more information.
4 raphics ( raphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memor is the total of, as applicable, Dedicated Video Memory, ystem Video Memory and hared ystem Memory. hared ystem Memory will vary
depending on system memory size and other factors.
5 Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege R700- T1303 Page 4 of 4
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6 Storage Drive
Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer
includes one or more pre-installed operating systems, such as Microsoft Operating ystem and/or pre-installed software applications, or media content. Actual formatted capacity
may vary.
7 Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8 Display. mall bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9
Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment .
10
Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment .
11
USB Sleep & Charge. The "U B leep & Charge function" may not work with certain external devices even if they are compliant with the U B specification. In those cases, turn
the power of the computer ON to charge the device.
12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
13 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. ee “Detailed pecifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com
Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any individual user. Actual battery life may vary considerably from
specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by
the design of individual components. The battery life rating is only achieved on the select models and configurations tested by Toshiba under the specific test settings at the time of
publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.
After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
14 Easy uard. Toshiba EasyGuard™ technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the
model selected. ee www.easyguard.toshiba.com for detailed information.
15 Software. ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software products (including Microsoft Office mall Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office mall Business Accounting 2006) which may be included with this computer.
16
Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.
17 Microsoft® Office Starter 2010: Includes Microsoft® Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite
18 RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous ubstances in electrical and electronic equipment
(RoH ), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoH requirements
and verifies its suppliers' commitment to meeting RoH requirements by conducting component sampling inspections during the product design approval process.
19 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
20 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
21 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
22 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
