SATELLITE 2615DVD Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS ~0062059.doc Rev. 24 07/24/00 NMM. Page 1of 4
MODEL PART NUMBER DESCRIPTION
2615DVD PAS261U-T6DW8 IntelMobile Celeron433MHz, 12.1” TFT, 64MB, 6.0bb HDD, Modem,
DVD-ROM, Windows 98 Configuration Builder CD
PROCESSOR Intel Mobile Celeron433Mhz (1.9V) processor
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE Yes: 128KB Integrated into CPU
Data/Address Bus Width 64-bit
Frontside Bus Speed 66MHz
SYSTEM ARCHITECTURE Chipset Connecting Devices
PCI BUS (v.2.2): (32-bit, 33MHz) Intel 440ZX PC Card slots, HDD, CD-ROM, Sound controller, modem
AGP x 2 (R1.0): (32-bit, 66MHz) Intel 440ZX Graphics Controller
ISA BUS: 16-bit, 8MHz N/A BIOS, KBC
MEMORY: 64Mbit SDRAM, 3.3V
Standard 64MB
Maximum 192MB
Speed PC66
Hyper Page mode memory access Yes
Data/Address Bus Width 64bit/32bit
Local Bus Clock Speed 66MHz
BIOS 512KB: 4Mbit FLASH EPROM, 5V
Supported standards APM (v.1.2), ACPI (v.1.0b), PnP 1.0a, VESA (v2.0), DPMS, DCC2B,
SM BIOS (v.2.3), PCI BIOS. FDD/HDD/CD-ROM bootable.
SYSTEM MANAGEMENT SM 2.3 BIOS support with asset tag capability
Wired for Management V1.1a, ACPI power management
Toshiba Configuration Builder – customize software image tool;
Year 2000 Compliant (NSTL Hardware Tested)
VIDEO
Memory 2.5 MB integrated into chipset
Controller Chip Trident Cyber 9525DVD
Data Bus Width 64-bit
AGP Local Bus (2D/3D) support Yes: 33/66MHz
Graphics Accelerator: Yes with 64-bitBitBLT support
2D graphics support BitBLT, DirectDraw, H/W Cursor
3D Supported Features AGP supported
Modeling Fogging, Lighting
Shading Flat shading, Gouraud shading
Rendering Bilinear texture mapping , Anti-aliasing, MIP mapping, Z-buffering (16-bit)
Alpha-blending Yes
Direct3D support Yes
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation/Zoom Yes
DirectVideo/ DirectMPEG Yes
Motion Compensation Yes 2615DVD
Internal Support Resolution Colors Support
Smaller Image 640 x 480 16.7M colors
Full Screen 800 x 600 16.7M colors
Virtual Display Mode 1024 x 768 64K colors
Virtual Display Mode 1280 x 1024 256 colors

SATELLITE 2615DVD Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS ~0062059.doc Rev. 24 07/24/00 NMM. Page 2of 4
MODEL PART NUMBER DESCRIPTION
2615DVD PAS261U-T6DW8 IntelMobile Celeron433MHz, 12.1” TFT, 64MB, 6.0bb HDD, Modem,
DVD-ROM, Windows 98 Configuration Builder CD
EXTERNAL VIDEO SUPPORT
Resolution Colors Support Vertical Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors 85Hz @ 16.7M color
800 x 600 16.7M colors 85Hz @ 16.7M color
1024 x 768 64K colors 85Hz @ 64K color
1280 x 1024 256 colors 60Hz @ 256 color
DISPLAY
Type TFT Active Matrix Color
Resolution 800 x 600
Size 12.1” Diagonal
Dot Pitch 0.3075 x 0.3075mm
Contrast Ratio 100:1 (Min)
ALL-IN-ONE DESIGN
STORAGE
HDD (2.5” Enhanced IDE) 6.0 billion bytes (12/14msec)
Buffer 512KB
Removable Service-removable
Height 9.5mm or 8.5mm
Burst Data Transfer Rate Ultra DMA Mode 2 (33.3MB/s), PIO Mode 4 & Multiword DMA Mode 2 (16.7MB/s)
Certification SMART
FDD (3.5” 1.44MB; 12.7mm high) Yes
Simultaneous FDD & CD-ROM Support Yes: two independent units
DVD-ROM
Type Toshiba (SD-C2202)
Interface Enhanced IDE (ATAPI)
Height/Weight 12.7mm/0.62 lbs .
Buffer 128KB
Operation modes DVD-ROM CD-ROM
Rotational Speed 4X Max 20X Max
Random Access Time 140ms 100ms
Sustained Data Transfer rate 1352KB/sec / 2704KB/sec 1290KB/sec / 3000KB/sec
CD-ROM Compatibility CD-ROM, CD-R, CD-RW (read only)
DVD-ROM Compatibility DVD-ROM, DVD-R(read only), DVD-RW(read only)
DVD-Movie compatibility Region 1 (North America).
SOUND SYSTEM Toshiba Sound System
Chipset ESS ES1978S (PCI audio accelerator) & ESS 1918S
Features Multi-stream DirectSound and DirectSound3D acceleration
Hardware acceleration for DirectMusic and DirectInput
16-bit stereo audio playback/record Yes
Maximum sampling rate 48 kHz
FM Synthesis support 64-channel wavetable music synthesis
Full duplex function Yes
Sound formats supported: SoundBlaster Pro, Windows Sound System v.2.0, .WAV, MIDI
3D Sound Support Yes: HRTF 3D positional audio, DVD AC-3 speaker virtualization
Direct3Dsound support Yes
DirectSound Yes (hardware acceleration)
DirectMusic Yes (hardware acceleration)
Speaker system Stereo Bass-Reflex speaker system
Form factor Two top-mounted stereo speakers (28mm, 8 Ω) with volume control

SATELLITE 2615DVD Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS ~0062059.doc Rev. 24 07/24/00 NMM. Page 3of 4
MODEL PART NUMBER DESCRIPTION
2615DVD PAS261U-T6DW8 IntelMobile Celeron433MHz, 12.1” TFT, 64MB, 6.0bb HDD, Modem,
DVD-ROM, Windows 98 Configuration Builder CD
INTERNAL MODEM Internal 56K ITU w/V.90 support
DAA support US/Canada
Data support Protocols supported ITU-T V.21/V.22/V.22bis/V.23/V.32/V.32bis/V.34/BELL 103/212A/V.90
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Telephony Functions
Standard software RingZeroRingCentralmodem software
Supported Functions Ring Wake-up Resume
KEYBOARD
85 keys, 2.7mm Travel Yes
Key support Windows 95/98, Application
Application Key support Yes
Easy Access Internet Key Yes: Upper left side of keyboard
CD-ROM functions Yes: 4 control buttons support“Play”, “Stop”, “Next Track”and“Previous Track”.
Slide On/Off power switch Yes
Dedicated function keys 12 dedicated function keys
Keyboard height 9.5mm
Key Pitch 19.05mm
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Pointing Device Integrated AccupointII Pointing Device with scroll function
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC CardType III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART equivalent) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
TV-Out (NTSC/PAL output) Yes: RCA conversion cables included
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
RJ-11 modem port Yes
Microphone (3.5mm mini jack, monaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Noteworthy security lock port Yes
POWER
Autosensing External AC Adapter Part#: PA2450U
Dimensions/Weight 4.9”L x 2.46”W x .97”H --- Weight: .66lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3.0A
Power Output (Watts) 45W
Battery Type: Li-Ion (4330mAH, 10.8V) -- one standard: Part# PA2487URG
Battery Life: (Full Power) 3.0 hrs
Recharge Time (Computer Off/On) 3/4-10 hrs. depending on the computer function performed
Power Saving Features APM v.1.2 BIOS, CPU Sleep mode, HDD Auto Off, Auto Resume, Display Auto Off
CPU speed change, Hibernation, Standby

SATELLITE 2615DVD Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS ~0062059.doc Rev. 24 07/24/00 NMM. Page 4of 4
MODEL PART NUMBER DESCRIPTION
2615DVD PAS261U-T6DW8 IntelMobile Celeron433MHz, 12.1” TFT, 64MB, 6.0bb HDD, Modem,
DVD-ROM, Windows 98 Configuration Builder CD
DIMENSIONS Dimensions Weight
Notebook (2615DVD) 12.2”W x 10.2”D x 1.6”H 7.0 lbs.
AC Adapter 4.9”L x 2.46”W x .97”H .66lbs.
Battery (Standard) 6.87”L x 2.76”W x 0.73”H .88 lbs.
BUNDLED SOFTWARE Standard Software
Windows98 Second Edition, LotusSmartsuite Millenium, Intuit Quicken 99 Basic, RingZeroRing Central, User’s Guide
MediaMatics DVD Express, Symantec NortonAntiVirus5.0, Customizable My Yahoo! For Toshiba start page, AT&T Worldnet
Free Trial, Toshiba Accessories (Desktop Shortcut to purchase Toshiba Accessories Online),
Toshiba Custom Utilities (HWSetup, Quick Hibernation, Power Saver, Toshiba Hibernationutility,Hotkey utility),
CD’s Included:Bootable Windows 98 Configuration Builder CD (CBCD Pro compatible), LotusSmartsuite CD,
Toshiba Companion Disk
Toshiba Take 2 Software: Select a Totalof 2 Additional Software Titles. Pay only $7.95 shipping
Mobile Productivity
LaplinkPro Print Artist6.0
Route Planner Snapshot
Street Wizard 6.0 Education
The New Way Things Work Encyclopedia of Science 2.0
Eyewitness Children’s Encyclopedia 1999 Grolier Multimedia Encyclopedia®
Entertainment
Smart Games2 All-American Sports: Golf
YahtzeeHoyle Classic Card Game
Boggle
SECURITY Hardware Cable Lock slot; By screw only: PC Card lock slot, HDD, internal modem
Password Power-on, Supervisor, & HDD password
Miscellaneous Screen blank, keyboard lock
WARRANTY 1 YR Parts / 1 YR. Labor / 1 YR. Battery
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
