Toshiba Satellite M30X User manual

Toshiba Personal Computer
Satellite M30X
Maintenance Manual
TOSHIBA CORPORATION

Copyright
© 2004 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual
cannot be reproduced in any form without the prior written permission of Toshiba. No patent
liability is assumed with respect to the use of the information contained herein.
Toshiba Personal Computer Satellite M30X Maintenance Manual
First edition September 2004
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The
included set of instructions and descriptions are accurate for the M30X Series at the time of this
manual's production. However, succeeding computers and manuals are subject to change
without notice. Therefore, Toshiba assumes no liability for damages incurred directly or
indirectly from errors, omissions, or discrepancies between any succeeding product and this
manual.
Trademarks
IBM is a registered trademark, and OS/2 and PS/2 are trademarks of IBM Corporation.
Microsoft, MS-DOS, Windows, DirectSound and DirectMusic are registered trademarks of
Microsoft Corporation.
Intel and Pentium are registered trademarks, and SpeedStep is a trademark of Intel Corporation.
Sound Blaster is a registered trademark of Creative Technology Ltd.
Centronics is a registered trademark of Centronics Data Computer Corporation.
Photo CD is a trademark of Eastman Kodak.
All other properties are trademarks or registered trademarks of their respective holders.
ii Satellite M30X Maintenance Manual

Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer Satellite SATELLITE M30X, referred to as the M30X Series in this
manual.
The procedures described in this manual are intended to help service technicians isolate faulty
Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your attention.
Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety precautions
are adhered to strictly.
Be sure to fasten screws securely with the right screwdriver. If a screw is not fully
fastened, it could come loose, creating a danger of a short circuit, which could cause
overheating, smoke or fire.
If you replace the battery pack or RTC battery, be sure to use only the same model battery
or an equivalent battery recommended by Toshiba. Installation of the wrong battery can
cause the battery to explode.
Satellite M30X Maintenance Manual iii

The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the M30X Series system unit and each
FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU
problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
Handling the LCD module
Board layout
Pin assignments
Keyboard scan/character codes
Key layout
Screw torque list
Reliability
iv Satellite M30X Maintenance Manual

Conventions
This manual uses the following formats to describe, identify, and highlight terms and operating
procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on the
keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If three
keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the computer that appears on its display is presented in the type face below:
Format complete
System transferred
Satellite M30X Maintenance Manual v

vi Satellite M30X Maintenance Manual

Table of Contents
Chapter 1 Hardware Overview
1.1 Features............................................................................................................................ 1-1
1.2 System Unit...................................................................................................................... 1-5
1.3 2.5-inch Hard Disk Drive................................................................................................. 1-9
1.4 Removable Drives.......................................................................................................... 1-10
1.5 Power Supply................................................................................................................. 1-16
1.6 Batteries ......................................................................................................................... 1-18
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting Introduction .......................................................................................... 2-1
2.2 Troubleshooting Flowchart.............................................................................................. 2-2
2.3 Power Supply Troubleshooting ....................................................................................... 2-7
2.4 Display Troubleshooting................................................................................................ 2-12
2.5 Keyboard Troubleshooting ............................................................................................ 2-15
2.6 External USB Devices Troubleshooting........................................................................ 2-17
2.7 TV-Out Failure Troubleshooting ................................................................................... 2-19
2.8 Printer Port Troubleshooting ......................................................................................... 2-21
2.9 TouchPad Troubleshooting............................................................................................ 2-23
2.10 Speaker Troubleshooting ............................................................................................... 2-25
2.11 Optical Drive Troubleshooting ...................................................................................... 2-27
2.12 Modem Troubleshooting................................................................................................ 2-30
2.13 PCMCIA Troubleshooting............................................................................................. 2-32
2.14 IEEE 1394 Troubleshooting .......................................................................................... 2-34
2.15 Wireless LAN Troubleshooting..................................................................................... 2-36
Satellite M30X Maintenance Manual vii

Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test .........................................................................................................3-1
3.2 Executing the Diagnostic Test..........................................................................................3-2
3.3 Config Check Test............................................................................................................3-6
3.4 DMI Check Test ...............................................................................................................3-7
3.5 PIO Loopback Test...........................................................................................................3-8
3.6 IEEE 1394 Test ................................................................................................................3-9
3.7 Speaker Audio Test ........................................................................................................3-10
3.8 Fan ON/OFF Test...........................................................................................................3-11
3.9 Main Battery Charge Test ..............................................................................................3-12
3.10 FDD Test ........................................................................................................................3-13
3.11 CD-ROM Test ................................................................................................................3-14
3.12 Keyboard Test ................................................................................................................3-15
3.13 Mouse (Pad) Test ...........................................................................................................3-17
3.14 LCD Pixels Mode Test...................................................................................................3-19
3.15 Lid Switch Test ..............................................................................................................3-20
3.16 HDD R/W Test...............................................................................................................3-21
3.17 LAN Test........................................................................................................................3-23
3.18 RTC Test ........................................................................................................................3-25
3.19 CD Control Button Test .................................................................................................3-26
viii Satellite M30X Maintenance Manual

Chapter 4 Replacement Procedures
4.1 General............................................................................................................................. 4-1
4.2 Battery.............................................................................................................................. 4-7
4.3 PC Card............................................................................................................................ 4-9
4.4 HDD............................................................................................................................... 4-11
4.5 Optical Drive Module .................................................................................................... 4-13
4.6 Optical Drive.................................................................................................................. 4-15
4.7 Wireless LAN Unit ........................................................................................................ 4-17
4.8 Expansion Memory........................................................................................................ 4-20
4.9 Keyboard........................................................................................................................ 4-23
4.10 Modem ........................................................................................................................... 4-26
4.11 Display Assembly .......................................................................................................... 4-28
4.12 Touch Cover................................................................................................................... 4-31
4.13 Touch Pad ...................................................................................................................... 4-34
4.14 Speakers ......................................................................................................................... 4-36
4.15 System Board ................................................................................................................. 4-37
4.16 Fan, Heat Sink, & CPU.................................................................................................. 4-39
4.17 Display Mask ................................................................................................................. 4-42
4.18 LCD Module .................................................................................................................. 4-44
4.19 FL Inverter Board .......................................................................................................... 4-47
Satellite M30X Maintenance Manual ix

x Satellite M30X Maintenance Manual
Appendices
Appendix A Handling the LCD Module..................................................................................A-1
Appendix B Board Layout....................................................................................................... B-1
Appendix C Pin Assignments..................................................................................................C-1
Appendix D Keyboard Scan/Character Codes.........................................................................D-1
Appendix E Key Layout .......................................................................................................... E-1
Appendix F Series Screw Torque List .................................................................................... F-1
Appendix G Reliability ............................................................................................................G-1

Chapter 1
Hardware Overview
1

1 Hardware Overview
1-ii Satellite M30X Series Maintenance Manual

1 Hardware Overview
Chapter 1 Contents
1.1 Features...................................................................................................................... 1-1
1.2 System Unit................................................................................................................ 1-6
1.3 2.5-inch Hard Disk Drive......................................................................................... 1-11
1.4 Optical Device Drives..............................................................................................1-12
1.5 Power Supply ........................................................................................................... 1-12
1.6 Batteries ................................................................................................................... 1-14
1.6.1 Main Battery.............................................................................................. 1-14
1.6.2 RTC battery............................................................................................... 1-15
Satellite M30X Series Maintenance Manual 1-iii

1 Hardware Overview
1-iv Satellite M30X Series Maintenance Manual

1.1 Features 1 Hardware Overview
1.1 Features
The Satellite M30X Series Personal Computer uses extensive Large Scale Integration (LSI), and
Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide
compact size, minimum weight and high reliability. This computer incorporates the following
features and benefits:
CPU
•Intel Pentium M Dothan :1.5G/1.6G/1.7G/1.8G/2G/2.1G/1.4G(Trailing CMT 85Tj,
TDP=21W)
•Intel Pentium M Banias 1.5G/1.6G/1.7G
•Intel Celeron M Banias 1.3G/1.4G/1.5G
•Intel Celeron M Dothan 1.3G/1.4G/1.5G
•Micro FC-PGA package CPU
Chipset
•Intel 855GME
•Intel ICH4-M
•ENE KB910 for Keyboard Controller, Battery management Unit, and RTC.
•ENE CB1410 for Card Bus PCMCIA controller or CB714 for Card Bus PCMCIA
controller with Multiple Digital Media Card Slot
•ALC250 for AC97 CODEC.
•VIA VT6301S for IEEE 1394 controller.
•Realtek RTL8100CL on board LAN.
Memory
•DDR333 specification compliant
•Two DDR SODIMM with 256M/512M/1G
•Max. upgrade to 2G
•Two SODIMM socket in the bottom side (one screw), support Toshiba accessory
SODIMM
Satellite M30X Series Maintenance Manual 1-1

1 Hardware Overview 1.1 Features
BIOS
•512KB Flash ROM for system BIOS.
•Suspend to RAM/Disk.
•Password protection (System).
•Various hot key for system control.
•Refreshable
•Complete ACPI 1.0b Function
Power
•8-cell Li-Ion battery pack w/up to 63.64Wh capacity(14.8V*4300mAh)
•Charging time 4~12hrs (System on)
•Charging time 4hrs max. (System off or suspend)
•Life cycle: 300 times with minimum reside capacity of 50% compare with original
capacity. Smart battery compliant.
HDD
•9.5mm, 2.5" HDD with 40/60/80GB(4200rpm)
•Design ready for 9.5mm, 2.5" HDD with 40/60/80GB(5400rpm )
•Design ready for 9.5mm, 2.5" HDD with 100GB(4200rpm)
•fixed HDD module but design for easy service replaceable
•PCI Bus Master Enhanced IDE.
•Ultra DMA 100 support.
•No 2nd HDD support.
Optical Device Drivers
•Fixed ODD module Bay with 12.7 mm devices.
•Designed for service easily.
•Combo:24x,24x,8x,24x(CD-R/CD-RW/DVD read/CD read).
•DVD+-R/+-RW: 24x/24x/8x/4x/8x/4x (CD-R write /CD-RW write /DVD-R
write/DVD-RW write/DVD+R write /DVD+RW write).
•DVD Super Multi: 16x/8x/4x/2x/2.4x/2.4x/2x (CD-R write /CD-RW write /DVD-R
write/DVD-RW write/DVD+R write /DVD+RW write.
/DVD-RAM write).
Optional Devices
•PC2700 256MB/512MB/1GB SO-DIMM modules
•MINI PCI module(802.11g,802.11a+g wireless LAN module)
Keyboard
An easy-to-use 87-key keyboard provides a numeric keypad overlay for fast numeric data
entry or for cursor and page control. It supports software that uses a 101- or 102-key
enhanced keyboard. Includes one Windows®key and one Application key.
1-2 Satellite M30X Series Maintenance Manual

1.1 Features 1 Hardware Overview
TouchPad
This pointing control device, located in the center of the keyboard palm-rest, provides
convenient control of the cursor without requiring desk space for a mouse. The TouchPad
incorporates two mouse buttons.
Display
•15.4”WXGA(1280 x 800),” Wide Screen LCD (16:10), Non-CSV/VA version
•15.4”WXGA(1280 x 800), Wide –Screen LCD (16:10), CSV(200-220nit)
•15.0” XGA(1024*768) color LCD
I/O Ports
•USB x 3 ports (V 2.0)(2 in rear side, 1 in right side)
•RGB; One DDC2b compliant 15 pin VGA port (Rear side)
•Microphone-in(Right side)
•Headphone-out jack x 1(Right side)
•DC-in jack(Rear side)
•RJ-11 jack for 56Kbps V.92 Modem (US/Canada), V.90 (Others) (Rear side)
•RJ-45 jack x 1 with LED indicator.(Rear side)
•Kensington lock(Rear side)
•TV-Out (S-Video, 4 pins type) x1. (Rear side)
•IEEE 1394 x1 (Right side)
•FIR *1 (Right side)(Combination BTO with FIR and PIO) (Covered by dummy
lans)
•VR for volume control(Right side) (Sound smaller : close to user , Large : away
from user)
•PIO; High speed bi-directional parallel port, 25 pins, ECP/EPP capability, (Rear
side)(Combination BTO with FIR and PIO)(Change core)
•5 in 1 port, BTO (Right side)
•Card bus slot x1 (Right side)
•No PS/2
•No Serial port
PCMCIA Card Organization
•One type II card socket only
•SRAM, OTPROM, FLASH ROM
•Mask ROM memory card
•MODEM/LAN card
•Card bus card
•PC Card 8.0 Compliant, supports 3V and 5V cards
Multiple Digital Media Card
•ENE CB1410 controller for PCMCIA only,
or ENE CB714 controller for PCMCIA and 5 in one reader
Satellite M30X Series Maintenance Manual 1-3

1 Hardware Overview 1.1 Features
•ENE CB1410 and CB714 can be co-layout.
PC Card 95 supported with one type II Card sockets
•PCI card bus
•NO ZV-Port support
•With dummy card for PCMCIA
•5 in 1 reader,BTO(Rubber cap ) (Support XD, SD, SM, MS, MS Pro and MMC)
•No SD-IO support
Universal Serial Bus (USB)
The computer comes with three USB ports that comply with Universal Host Controller
Interface (UHCI). The USB enables daisy-chain connection of up to 127 USB-equipped
devices. It is designed for easy configuration by a Plug-and-Play operating system and
provides hot insertion/ejection capability.
Parallel port
A 25-pin parallel port enables connection of a printer or other parallel device. The port
supports Extended Capabilities Port (ECP) conforming to IEEE-1284 and is Enhanced
Parallel Port (IEEE 1284) compliant. It features ChiProtect circuitry for protection against
damage due to printer power-on.
External monitor port
A 15-pin CRT port supporting DDC 2B enables connection of an external monitor, which
is recognized automatically by Video Electronics Standards Association (VESA) Display
Data Channel (DDC) compatible functions.
Sound system
A Cirrus logic ALC250 for AC97 codec audio subsystem offers industry leading mixed
signal technology to enhance the computer’s multimedia capability. The sound system is
equipped with stereo speakers and jacks for headphone and external microphone.
TV-out port
This video-out mini-jack enables transfer of NTSC or PAL data (video and right/left
audio) to external devices such as a TV.
LAN port
The computer comes with an RJ-45 Local Area Network (LAN) port. The LAN port
provides connectivity for LAN.
Programmable button
When system is off, pressing this button will turn on CD Playback mode. Pressing this
button again will turn off CD Playback mode. When system is turned on, pressing this
button will launch the program which you defined with Programmable Button utility.(The
default setting is Windows Media Player)
1-4 Satellite M30X Series Maintenance Manual

1.1 Features 1 Hardware Overview
Satellite M30X Series Maintenance Manual 1-5

1 Hardware Overview 1.2 System Unit
1.2 System Unit
The system unit is composed of the following major components:
Processor
•Intel Pentium M Dothan :1.5G/1.6G/1.7G/1.8G/2G/2.1G/1.4G(Trailing CMT 85Tj,
TDP=21W)
•Intel Pentium M Banias 1.5G/1.6G/1.7G
•Intel Celeron M Banias 1.3G/1.4G/1.5G
•Intel Celeron M Dothan 1.3G/1.4G/1.5G
•Micro FC-PGA package CPU
System Logic
•Integrated DRAM controller
•Hub Interface to Intel ICH4-M
•Power Management Functions
Keyboard Controller
•KB910 is use as keyboard controller and battery management unit
Memory
•System DRAM
•Two JEDEC standard 200-pins DDR SO-DIMM memory support +2.5V
PC2700 256/512MB/1024MB.
•System & KB Combine ROM BIOS
•512KB Flash ROM
Video Subsystem (Intel 855GME)
•UMA VGA Memory up to 64MB
•Display Core Frequency of 200/250/266/333MHZ
•3D Graphics Engine
•Analog Display support
•Digital Video out port(DVOB and DVOC)support
•DVOB With 165-MHZ clot clock support for 12 bit interface.
•Dedicated 2FP(local flat panel) interface
•Single or dual channel LVDS panel support up to WXGA panel, resolution with
frequency range from 25MHZ to 112MHZ per channel.
SMsC LPC 47N217 Super I/O with LPC Interface
•PC99a, PC2001
•ACPI 2.0 Compliant
1-6 Satellite M30X Series Maintenance Manual
