SATELLITE PRO 400 SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is
subject to change without notice. Copyright 1995TAIS Sp400.doc Rev. 1 02/07/00 nmm.
Page 1 of 2
400CS 400CDT
810MB: PA1207U-S2W 810MB: PA1207U-T2W
PROCESSOR
Intel SL-Enh. Pentium 75Mhz(2.9V/3.3V) Yes Yes
Integrated Coprocessor Yes Yes
Processor Cache 16KB: (8KB code; 8KB data) 16KB: (8KB code; 8KB data)
STORAGE
Fixed HDD (2.5” IDE) 810mb=770MB (13msec) 810mb=770MB (13msec)
Modular FDD (3.5” 1.44MB) Integrated Bundled/Swappable with CD
FDD Dimensions 4.47”L x 3.78”W x .6”H 4.47”L x 3.78”W x .6”H
FDD Weight Weight: .29 lbs Weight: .29 lbs
Modular CD-ROM: Toshiba XM-1202B
5.25”Quad-speed (4x) Optional/Swappable with FDD Installed/Swappable with FDD
Interface .ATAPI (Enhanced IDE) .ATAPI (Enhanced IDE)
Average Access Time 210 ms 210 ms
Sustained Transfer Rate 684 KB/sec 684 KB/sec
MEMORY: 16Mbit EDO DRAM, 3.3V
Standard 8MB 8MB
Maximum 40MB 40MB
Speed (hyper-page mode supported) 70ns 70ns
Data width 64 bit 64 bit
BIOS (128KB FLASH EPROM, 150ns) Yes Yes
PnP 1.0a SUPPORT Yes Yes
DISPLAY
Type Dual Scan Color Passive Matrix TFT Active Matrix Color
Size 10.4" (8.31"W x 6.24"H) 10.4" (8.31"W x 6.24"H)
Dot Pitch .33mm x .33mm .33mm x .33mm
Contrast Ratio 20:1 (typ); 15:1 (min) 100:1 (min)
Display Resolution 640 x 480 640 x 480
VIDEO
VRAM: 4Mbit DRAM, 5V 1 MB 1 MB
Speed (fast-page mode supported) 60ns 60ns
Controller Chip C&T CT65546 C&T CT65546
Bus Type Vesa Local Bus Vesa Local Bus
Graphics Accelerator BitBLT support BitBLT support
Color Palette 226,981 colors 16.7 million colors
Internal color support 640 x 480 x 256 colors 640 x 480 x 16.7M colors
Virtual Display Mode N/A 800 x 600 x 64K colors
N/A 1024 x 768 x 256 colors
External color support1Colors/Palette Colors/Palette
640 x 480 16.7M colors/16.7M colors 16.7M colors/16.7M colors
800x600 64K colors/64K colors 64K colors/64K colors
1024 x 768 256 colors/256K colors 256 colors/256K colors
Refresh Rate(Vert./Hor.)275Hz/60Hz 75Hz/60Hz
KEYBOARD
82 keys, 3mm Travel Yes Yes
12 dedicated function keys Yes Yes
Cursor control (8 Keys, Inverted "T") Yes Yes
Numeric keypad (Integrated Overlay) Yes Yes
Integrated Pointing Device AccuPointAccuPoint
1. SVGA color requires Windows driver includeded by Toshiba. Simultaneous viewing at supported resolutions greater than 640 x
480 occur in virtual display mode only. 2. Refresh rate taken @ 1024x768 Non-Interlaced.

SATELLITE PRO 400 SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is
subject to change without notice. Copyright 1995TAIS Sp400.doc Rev. 1 02/07/00 nmm.
Page 2 of 2
400CS (con.) 400CDT (con.)
810MB: PA1207U-S2W 810MB: PA1207U-T2W
EXPANSION SLOTS
One Stacked PC Card Slot3Yes Yes
Internal Memory Slot Yes Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART compliant) Yes Yes
One 25-Pin Parallel (ECP) Yes Yes
One 15-Pin RGB (SVGA video) Yes Yes
One (PS/2) 101 Keyboard/Mouse port Yes Yes
One External Floppy Drive port Yes Yes
Microphone (monoaural) Yes Yes
Headphone (stereo) Yes Yes
Line-in (stereo) Yes Yes
Serial Infrared port Yes: IrDA 115.2Kbps compatible Yes: IrDA 115.2Kbps compatible
Enh. Port Replicator w/PC card Slots4Optional: Part# PA2711U Optional: Part# PA2711U
POWER
INTERNAL AC Power Unit Yes Yes
Input (Voltage/Frequency) 100-240V; 50-60Hz 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.0A 15 VDC; 2.0A
Power Output (Watts) 30W 30W
Battery Type: Li-Ion (10.8V, 3600mAH) Yes: Part# PA2487UR Yes: Part# PA2487UR
Battery Life 2.5+ hrs. 2.5+ hrs.
Recharge Time (Computer Off/On) 2-3 hrs.(Off) /5-8 hrs.(On) 2-3 hrs.(Off) /5-8 hrs.(On)
MaxTimePower Management Yes Yes
SOUND SYSTEM (All Models) 16bit stereo. Supports SoundBlaster Pro, .WAV & MIDI files
w/single front-mounted speaker Chipsets: ESS Technologies ESS688 & Yamaha OPL3 (YMF262)
DIMENSIONS 11.8"W x 8.9"D x 1.9” 11.8"W x 8.9"D x 2.0"H
WEIGHT (includes Battery: 1.32 lbs.) < 7.0 LBS. 7.3 LBS.
BUNDLED SOFTWARE (All Models)5Choice of Windows 95 or Windows for Workgroups 3.11
and MS-DOS 6.22 w/Special Enhancements; MagiCDisk;
Note: Satellite Pro 405CS offers RunTime Video for Windows w/Indeo 3.2; Toshiba Card Manager;
Windows™ 95 only ESS Sound System; Animotion Music Rack;
Enhanced IDE Disk Driver; Puma TranXit (Infrared software)
SECURITY (All Models) Kensingtionlock slot, Power-on password, screen blank
WARRANTY 3 YR Parts & Labor 3 YR Parts & Labor
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°(65°C)
Thermal Gradient 20°C per hour (max.) N/A N/A
Relative Humidity: 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. -197 to 32,808ft.
Shock: 10G 60G
Vibration: 0.25G 1G
3. Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III. 4.Optional Port Replicator adds (2) Type III PC slots and a
MIDI/Joystick port. 5. Satellite Pro 405CS (Part# PA1207U-S6W) is the Retail equivalent of the Satellite Pro 400CS, but includes a
1 year warranty and the following additional software: ClarisWorks3.0, Lotus Organizer2.0, and Quicken SE1.0.
