TECRA 720CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 720.doc Rev. 25 02/07/00 nmm. Page 1 of 3
720CDT
1.2 Billion Bytes: PA1219U-T2C
PROCESSOR
Intel Pentium133Mhz (2.9v/3.3v) w/VRT Yes
External data bus width 64 bit
External data/address bus speed 66 MHz
Integrated Coprocessor Yes
Processor Cache 16KB: (8KB code; 8KB data)
LEVEL 2 (L2) CACHE Yes
Data Bus Width 64 bit
Data Bus Speed 66 MHz
DATA RAM: Yes
1 Mbit Pipelined Burst Synchronous SRAM (32K x 32bit, 3.3V) x 2
Access Time 8 ns
TAG-RAM: Yes
256Kbit Asynchronous SRAM (32K x 8bit, 3.3V) x 1
Access Time 14ns
PCI BUS SYSTEM ARCHITECTURE Yes: 32-bit, 33 MHz
MEMORY: 16Mbit EDO DRAM, 3.3V
Standard 16 MB
Maximum 144 MB
Speed 60ns
Hyper Page mode memory access Yes
Data width 64 bit
BIOS (256KB FLASH EPROM, 150ns, 5V) Yes
PnP 1.0a SUPPORT Yes
DISPLAY
Type TFT Active Matrix Color
Size 12.1" (9.68”W x 7.26”H)
Dot Pitch .24mm x .24mm
Contrast Ratio 100:1 (min)
VIDEO
VRAM: 4Mbit EDO DRAM, 5V 2 MB
Speed 50ns
Hyper Page mode support Yes
Controller Chip C&T HIQV32 (CT65550)
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes
64-bit BitBLT, LINEdraw, H/W Cursor Yes
Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling Support Yes
Zoomed Video Port Support Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Resolution11024 x 768 x 64K/64K colors
Virtual Display Mode 640 x 480 x 64K/64K colors
800 x 600 x 64K/64K colors
N/A
1280 x 1024 x 256/256K colors
External Resolution Colors/Palette
640 x 480 16.7M colors/16.7M colors
800 x 600 16.7M colors/16.7M colors
1024 x 768 64K colors/64K
1280 x 1024 256 colors/256K
Refresh Rate (taken.@ 1024x768 Non-Interlaced) Vert.: 75Hz; Hor.: 60kHz

TECRA 720CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 720.doc Rev. 25 02/07/00 nmm. Page 2 of 3
720CDT (con.)
1.2 Billion Bytes: PA1219U-T2C
STORAGE
Removeable HDD (2.5” Enhanced IDE) 1.2 billion bytes=1.13GB (13msec)
Modular FDD (3.5” 1.44MB) Included/Swappable with CD-ROM
FDD Dimensions 4.57”L x 3.8”W x .59”H
FDD Weight Weight: .29 lbs
Simultaneous FDD & CD-ROM Support Yes: External FDD adapter included
FDD Adapter Dimensions 7.0”L x 5.5”W
FDD Adapter Weight .25 lbs
Modular CD-ROM: Toshiba XM-1402B
5.25” 6x-speed Installed/Swappable with FDD
Interface .ATAPI (Enhanced IDE)
Random Access Time 190 ms
Sustained Transfer Rate 1,026 KB/sec
Supported Disc formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
KEYBOARD
3mm Travel Yes
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted "T") Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slot2Yes: CardBus & ZV Card Ready
32-bit, 3.3V PC CardBus Support Yes
16-bit, 5.0V PC Card Support Yes
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One RJ-11 port for internal modem (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Serial Infrared port Yes: IrDA 115.2Kbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes
One External Floppy Drive port Yes
Microphone (3.5mm mini jack, monoaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes
Noteworthy security lock port Yes
INTERNAL MODEM (All Models) 28.8 /14.4 Kbps Data/Fax modem
Data support
Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Fax class 1
Supported Functions Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Incoming Call Discrimination, Caller ID
NoteDock II

Port Replicator (Optional) Part# PA2713U (for use with Tecra 710CDT or 720CDT only)
Two Type III CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA monitor,
lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone
2. Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.

TECRA 720CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 720.doc Rev. 25 02/07/00 nmm. Page 3 of 3
720CDT (con.)
1.2 Billion Bytes: PA1219U-T2C
Desk Station V Plus (Optional) Part# PA2710U
(2) Full length 32-bit PCI/16-bit ISA slots Yes
(1) Half Length 32-bit PCI slot Yes
(2) Type III PC Card slots Yes
Built-in SCSI II Yes
5.25” half height drive bay Yes
Select Bay for Modular FDD or CD-ROM Yes
Designed for Windows 95 and PNP Yes
Hot Docking Support Yes
POWER
Autosensing External AC Adapter:NW2484U 7.0”L x 2.95”W x .98” --- .75 lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.7A (max)
Power Output (Watts) 40W
Battery Type: Li-Ion (10.8V, 5600mAH) Yes: Part# PA2485UR
Battery Life: (Full Power/Low Power) 4 hrs. (max)
Recharge Time (Computer Off/On) 4 hrs.(Off) /4.5-10.5 hrs.(On)
MaxTimePower Management Yes
SOUND SYSTEM (All Models)
Chipsets: Crystal Semiconductor CS4232, Yamaha OPL3 (YMF262),
Yamaha D/A converter (YAC512)
16 bit stereo audio playback/record Yes
Full duplex function Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI, Zoomed video port audio (stereo),
CardBus audio (monaural), CD-ROM audio
DirectSound support Yes: with Windows 95 Game SDK driver from Microsoft
Speaker system: Two top-mounted stereo speakers (28mm, 8 Ω)
DIMENSIONS 11.8"W x 9.1"D x 2.3”H
WEIGHT (includes 1.32 lbs. battery) < 8.0 LBS.
BUNDLED SOFTWARE (All Models) User selectable Windows 95 or Windows for Workgroups 3.11 and
MS-DOS 6.22w/Special Enhancements; Intel Indeo Video;
Synchro multimedia connect Communications utilities;
Sony Music Screeners; Mediamatics MPEG Arcade Player,
America Online, CompuServe, Netscape Navigator, magiCDisc,
Personal Journal, Fn-esse, Hypertext online documentation
SECURITY (All Models) Lock slot, power-on & HDD password, screen blank, keyboard lock
WARRANTY 3 YR Parts & Labor
ENVIRONMENTAL SPECIFICATIONS
Temperature: Operating 41°F (5°C) to 95°F (35°C)
Non-operating -4°F (-20°C) to 149°(65°C)
Thermal Gradient 20º C per hour (max.)
Relative Humidity: Operating 20%to 80%non-condensing
Non-operating 10%to 95%non-condensing
Altitude: Operating -197 to 9,843ft. (-60 to 3000m)
Non-operating -197 to 32,808ft. (-60 to 10,000m)
Shock: Operating 10G; 1.5G w/CD-ROM installed
Non-operating 60G; 50G w/CD-ROM installed
Vibration: Operating 0.5G; 0.25G w/CD-ROM installed
Non-operating 1G; 1G w/CD-ROM installed
Note: The Tecra 710CDT (Part# PA1214U-T2A) differs from the Tecra 720CDT only in internal screen resolution. The 710CDT has an
internal display resolution of 800 x 600 x 16.7M/16.7M colors through dithering.
