Toshiba 32E2533DG Quick start guide

Copyright 2014 All Rights Reserved Page 1of 3
NOTE: PERSONAL AND CUSTOM PREFRERENCES WILL BE LOST UPON COMPLETION
OF THIS FIRMWARE UPDATE. PLEASE MAKE NOTE OF ANY PREFERENCE SETTINGS
PRIOR YOU START WITH THIS FIRMWARE UPDATE.
How to upgrade the Software
1 Connect the AC power and turn “ON”the TV set.
2 The USB reader is located on the left or right of the cabinet near the side control/jack assembly as
shown in Figure-1.
Figure-1
3 Insert the “USB Drive” into the USB slot as shown in Figure-2.
Figure-2

Copyright 2014 All Rights Reserved Page 2of 3
4 “USB device was connected to TV. Do you want to open Media Player ?”message will be displayed
as shown in Figure-3.
Figure-3
5 Use the arrow buttons on the remote controller to select the “NO”.
6 Press the “MENU”button on the remote controller.
Use the arrow buttons on the remote controller to select the “Installation” menu.
7 “Installation” menu will be displayed as shown in Figure-4
Figure-4
8 In the “Installation” menu, scroll down to select “Software Updade (USB) “as shown in Figure-5 and
press “OK”button on the remote controller:
Figure-5

Copyright 2014 All Rights Reserved Page 3of 3
9 “Do you want to upgrade software”massage will be displayed as shown in Figure-6.
Press “Left Arrow button”on the remote controller to start the upgrade.
Figure-6
10 The Software upgrading process will begin.
During the Software update the TV set will display “SOFTWARE UPDATING NOW”
as shown in Figure-7:
Figure-7
IMPORTANT:
DO NOT unplug the AC power from the TV or press any buttons on the remote controller or
the TV keypad during this process.
11 Upon completion of the software upgrade, TV will reboot automatically.
12 Remove the “USB drive”from the slot.
13 Please follow the instructions on the screen to setup the TV according to your needs
(including channel setup).
During software update, TV will not be
available to response any operation for
a few minutes. Continue to proceed ?
YES NO
Software update (USB)
30%
SOFTWARE UPDATING NOW
PLEASE DO NOT TURN OFF THE TV
UNTIL IT IS 100% FINISHED
