SERVICE MANUAL

Plasma Color Television

42HPX95

50HPX95

FILE NO. 023-200520R

SUPPLEMENT

Published in Japan, Sep. 2005 (YC)

42HPX95/50HPX95 is the same as 42HP95/50HP95 except for the parts list on

back of this sheet.

Use this service manual together with the original service manual of 42HP95/50HP95

(File No. 020-200517).

SUMMARY

TOSHIBA CORPORATION 2005

*Service Manual 50HP95 is attached.

REVISION-1

#1:[42HPX95]

#2:[50HPX95]

MISCELLANEOUS

B205 23940528 PIECE, AV COVER ASSEMBLY 42HPX95

N100 #2 23969797 TAPE

PP22 #2 23748085 WASHER, 10X4.2XT=0.3

PC BOARD ASSEMBLIES

U101 75006105 PC BOARD ASSY, SIGNAL, 42HPX95

U102 75001681

PC BOARD ASSY, PD2266E1 SEIN FPD WITH LAN

U105A #1 75001682 PC BOARD ASSY, PD2220C1 TN/AV-AOUT

U105B #1 75001683 PC BOARD ASSY, PD2220C2 FRONT-AV

U105C #1 75001684 PC BOARD ASSY, PD2220C3 LED-RMT

U105D #1 75001685 PC BOARD ASSY, PD2220C4 KEY-SW

ACCESSORIES

A701A #1 23015199 CARTON, CASE 42HPX95

#2 23015279 CARTON, TOP CASE

Y101 #1 23566767 OWNERS MANUAL, ENGLISH/FRENCH 42HPX95

CABINET PARTS

A201 #1 23533642 COVER, FRONT BEZEL ASSY 42HPX95

#2 23533639 COVER, FRONT COVER ASSY 50HPX95

A235 #2 23738074 SCREW, PP 5X16 SW+W SBN

A237 #2 23717250 SCREW, PP4X12+SW+W SBN

A238 #2 23717177 SCREW, PP5X12+SW+W SBN

Location Parts No. Description

No.

CHASSIS AND CABINET REPLACEMENT PARTS LIST

U101 75006106 PCBOARDASSY,SIGNAL,50HPX95

- 2 -

(＊2 ）

LEAD-FREE SOLDER

This product is manufactured using lead-free solder as a part of a movement within the

consumer products industry at large to be environmentally responsible. Lead-free solder

must be used in the servicing and repair of this product.

WARNING

This product is manufactured using lead free solder.

DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT!

The melting temperature of lead-free solder is higher than that of leaded solder by 86°F to

104°F (30°C to 40°C). Use of a soldering iron designed for lead-based solders to repair

product made with lead-free solder may result in damage to the component and or PCB

being soldered. Great care should be made to ensure high-quality soldering when servicing

this product especially when soldering large components, through-hole pins, and on PCBs

as the level of heat required to melt lead-free solder is high.

(＊１）

GREEN PRODUCT PROCUREMENT

The EC is actively promoting the WEEE & RoHS Directives that define standards fo

recycling and reuse of Waste Electrical and Electronic Equipment and for the Restriction

of the use of certain Hazardous Substances. From July 1, 2006, the RoHS Directive will

prohibit any marketing of new products containing restricted substances.

Increasing attention is given to issues related to the global environmental. Toshiba

Corporation recognizes environmental protection as a key management tasks, and is doing

its utmost to enhance and improve the quality and scope of its environmental activities. In

line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase

and use products, parts and materials that have low environmental impacts.

Green procurement of parts is not only confined to manufacture. The same green parts

used in manufacture must also be used as replacement parts.

Location

No.

Parts No. Description Location

Parts No. Description

CAPACITOR CV24 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

CS502 76092726 CAPACITOR, CERAMIC CHIP, 10V B 2.2UF K CV76 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

CS10 76092609 CAPACITOR, CERAMIC CHIP, 10V B 4,7UF K CB03 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

CS11 76092609 CAPACITOR, CERAMIC CHIP, 10V B 4,7UF K CB04 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

CS15 76092609 CAPACITOR, CERAMIC CHIP, 10V B 4,7UF K CB38 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

CS16 76092609 CAPACITOR, CERAMIC CHIP, 10V B 4,7UF K CC42 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC12 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C168 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC22 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C169 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC24 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C1802 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC25 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C1803 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC40 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C1804 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

C685 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C1805 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC01 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1806 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC02 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1807 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC03 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1808 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC05 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1809 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC06 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1810 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC08 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1811 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC09 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1812 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC10 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C684 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC13 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CV286 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC14 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CV291 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC16 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CV292 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC18 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CV294 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC19 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CV121 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K

CC21 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C1801 76285104 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K

CC26 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C678 76285104 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K

CC27 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C679 76285104 CAPACITOR, CERAMIC CHIP, 50V B 0.1UF K

CC31 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C103 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CC33 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C151 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CC34 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C152 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CC41 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C161 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

C164 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C668 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CB503 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K C669 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CB507 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CC01 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CB511 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CC02 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CV33 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CC03 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

C691 76092463 CAPACITOR, CERAMIC CHIP, 16V B 0.22UF K CC04 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

C692 76092463 CAPACITOR, CERAMIC CHIP, 16V B 0.22UF K CC05 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

C674 76092731 CAPACITOR, CERAMIC CHIP, 16V B 1UF K CC06 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

C677 76092731 CAPACITOR, CERAMIC CHIP, 16V B 1UF K CC07 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CS12 76109473 CAPACITOR, CERAMIC CHIP, 25V B 0.047UF K CC08 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K

CH01 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z

- 3 -

CHASSIS AND CABINET REPLACEMENT PARTS LIST

Model : 42HPX95

Capacitors............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic

Resistors............... CF : Carbon Film CC : Carbon Composition MF : Metal Film

MF : Oxide Metal Film VR : Variable Resistor FR : Fusible

Resistor

(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND

"PRODUCT SAFETY NOTICE" ON PAGE 3 OF THE ORIGINAL SERVICE MANUAL (File No. 063-200467)

CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components

which have special characteristics important for safety and should be replaced only with types identical t

those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with

originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade

the safety of the receiver through improper servicing.

NOTICE:

• The part number must be used when ordering parts, in order to assist in processing, be sure to include the

Model number and Description.

• The PC board assembly with  mark is no longer available after the end of the production.

• The green parts describes in "G" mark, listed to the left side of the Parts No. item.

Parts No. Description Parts No. Description

CC11 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CH02 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC12 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CS501 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC14 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CS503 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC15 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV267 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC16 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV27 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC17 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV270 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC18 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV273 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC19 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV28 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC40 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV282 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC41 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV289 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CV38 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV293 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CV39 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CS64 76619101 CAPACITOR, ELECTROLYTIC CHIP, 16V 22UF M

C605 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CC28 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M

C606 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K C673 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M

CC10 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CS57 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M

CC13 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CV21 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M

C662 76109681 CAPACITOR, CERAMIC CHIP, 50V B 680PF K CV287 76619102 CAPACITOR, ELECTROLYTIC CHIP, 16V 47UF M

C663 76109681 CAPACITOR, CERAMIC CHIP, 50V B 680PF K C2607 76619048 CAPACITOR, ELECTROLYTIC CHIP, 25V 4.7UF M

C162 76105101 CAPACITOR, CERAMIC CHIP, 50V CH 100PF J C104 76619143 CAPACITOR, ELECTROLYTIC CHIP, 50V 4.7UF M

CV122 76105101 CAPACITOR, CERAMIC CHIP, 50V CH 100PF J CB509 76619098 CAPACITOR, ELECTROLYTIC CHIP, 6.3V 100UF M

CY650 76105101 CAPACITOR, CERAMIC CHIP, 50V CH 100PF J CE62 76073020 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A

CV31 76105220 CAPACITOR, CERAMIC CHIP, 50V CH 22PF J CB01 76202221 CAPACITOR, ELECTROLYTIC, 10V 220UF M

CV34 76105270 CAPACITOR, CERAMIC CHIP, 50V CH 27PF J CB02 76202221 CAPACITOR, ELECTROLYTIC, 10V 220UF M

CV35 76105330 CAPACITOR, CERAMIC CHIP, 50V CH 33PF J CB05 76202221 CAPACITOR, ELECTROLYTIC, 10V 220UF M

CS504 76105470 CAPACITOR, CERAMIC CHIP, 50V CH 47PF J C102 76073019 CAPACITOR, ELECTROLYTIC, 10V 470UF M

CS505 76105470 CAPACITOR, CERAMIC CHIP, 50V CH 47PF J C105 76073019 CAPACITOR, ELECTROLYTIC, 10V 470UF M

CB505 76100103 CAPACITOR, CERAMIC CHIP, 50V F 0.01UF Z CV74 76666101 CAPACITOR, ELECTROLYTIC, 16V 100UF M 3A

CB506 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE61 76617028 CAPACITOR, ELECTROLYTIC, 16V 1200UF M

CB508 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CV72 76794471 CAPACITOR, ELECTROLYTIC, 16V 470UF M

CB510 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C150 76073041 CAPACITOR, ELECTROLYTIC, 16V 470UF M 3A

CS36 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C680 76668102 CAPACITOR, ELECTROLYTIC, 35V 1000UF M

CS37 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE30 76073189 CAPACITOR, ELECTROLYTIC, 35V 1000UF M

CS40 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE30 76073189 CAPACITOR, ELECTROLYTIC, 35V 1000UF M

CS41 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE70 76073189 CAPACITOR, ELECTROLYTIC, 35V 1000UF M

CS42 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE70 76073189 CAPACITOR, ELECTROLYTIC, 35V 1000UF M

CS43 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C681 76073073 CAPACITOR, ELECTROLYTIC, 35V 2200UF M 3A

CS44 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C682 76073073 CAPACITOR, ELECTROLYTIC, 35V 2200UF M 3A

CS45 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE31 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS46 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE31 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS47 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE60 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS48 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE60 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS49 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE71 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS50 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE71 76073186 CAPACITOR, ELECTROLYTIC, 35V 470UF M

CS51 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE25 76668470 CAPACITOR, ELECTROLYTIC, 35V 47UF M 3A

CS52 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE05 76073090 CAPACITOR, ELECTROLYTIC, 50V 100UF M

CS53 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE08 76073090 CAPACITOR, ELECTROLYTIC, 50V 100UF M

CS54 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C670 76669100 CAPACITOR, ELECTROLYTIC, 50V 10UF M

CS55 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C671 76669100 CAPACITOR, ELECTROLYTIC, 50V 10UF M

CS56 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C660 76669479 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M

CS82 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C661 76669479 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M

CS85 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE32 76073128 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M

CS86 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE72 76073128 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M

CV67 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C690 76664102 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M 3A

CV68 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K C690 76664102 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M 3A

CV69 76092611 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CE03 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CE10 76666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M CE03 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CE12 76666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M CE63 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CE65 76666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M CE63 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CE67 76666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M CE64 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CE85 76666470 CAPACITOR, ELECTORLYTIC, 16V 47UF M CE64 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J

CC04 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CB82 76567474 CAPACITOR, PLASTIC FILM, 50V 0.47UF J

CC07 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CE11 76539474 CAPACITOR, PLASTIC FILM, 50V 0.47UF J

CC11 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CE11 76567474 CAPACITOR, PLASTIC FILM, 50V 0.47UF J

CC15 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CE66 76539474 CAPACITOR, PLASTIC FILM, 50V 0.47UF J

CC17 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M CE66 76567474 CAPACITOR, PLASTIC FILM, 50V 0.47UF J

CC20 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

CC30 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M

ESISTOR

CC32 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M GJ413 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

CC36 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M GJ414 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

CB504 76619100 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M GR04 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

- 4 -

Location

No.

Location

Parts No. Description Parts No. Description

GR05 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R695 76871102 RESISTOR, CHIP, 1/8W 1K OHM J

GR110 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA71 76011683 RESISTOR, CHIP, 1/20W 68K OHM J

GR112 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA72 76011223 RESISTOR, CHIP, 1/20W 22K OHM J

GR150 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA73 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

GR605 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA74 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

GR610 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA76 76011223 RESISTOR, CHIP, 1/20W 22K OHM J

GR611 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA77 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

GR612 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA78 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

GR613 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RA79 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

GRV55 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB08 76011470 RESISTOR, CHIP, 1/20W 47 OHM J

GRV56 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB09 76011470 RESISTOR, CHIP, 1/20W 47 OHM J

GRV57 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB10 76011331 RESISTOR, CHIP, 1/20W 330 OHM J

R103 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RB15 76011471 RESISTOR, CHIP, 1/20W 470 OHM J

R104 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RB24 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

R105 76011273 RESISTOR, CHIP, 1/20W 27K OHM J RB502 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J

R107 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB503 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J

R108 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB504 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

R110 76011682 RESISTOR, CHIP, 1/20W 6.8K OHM J RB505 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R114 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB506 76872750 RESISTOR, CHIP, 1/16W 75 OHM J

R161 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB507 76872820 RESISTOR, CHIP, 1/16W 82 OHM J

R165 76011392 RESISTOR, CHIP, 1/20W 3.9K OHM J RB510 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

R166 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RB513 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

R167 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RB514 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

R168 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RB515 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

R264 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB516 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R265 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB517 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R266 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB518 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R286 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB519 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R287 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB520 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R288 76871750 RESISTOR, CHIP, 1/8W 75 OHM J RB521 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4100 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB522 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4101 76011681 RESISTOR, CHIP, 1/20W 680 OHM J RB523 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4102 76011471 RESISTOR, CHIP, 1/20W 470 OHM J RB524 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4103 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB525 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R4104 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J RB526 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

R4105 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB527 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

R4106 76011681 RESISTOR, CHIP, 1/20W 680 OHM J RB528 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4107 76011471 RESISTOR, CHIP, 1/20W 470 OHM J RB529 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

R4108 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB554 76011471 RESISTOR, CHIP, 1/20W 470 OHM J

R4109 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J RB555 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

R4120 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB556 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R4122 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RB557 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

R6601 76011223 RESISTOR, CHIP, 1/20W 22K OHM J RB562 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

R6602 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RB563 76872750 RESISTOR, CHIP, 1/16W 75 OHM J

R6603 76011223 RESISTOR, CHIP, 1/20W 22K OHM J RB564 76872820 RESISTOR, CHIP, 1/16W 82 OHM J

R6604 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RB565 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R6605 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RB574 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R6606 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RB81 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

R664 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RC01 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R665 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RC01 76011223 RESISTOR, CHIP, 1/20W 22K OHM J

R670 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RC02 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R671 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J RC02 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R672 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J RC03 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R673 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J RC03 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R678 76871229 RESISTOR, CHIP, 1/8W 2.2 OHM J RC04 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R679 76871229 RESISTOR, CHIP, 1/8W 2.2 OHM J RC04 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R680 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RC05 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R681 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RC05 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R683 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RC06 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R684 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RC06 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R685 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RC07 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R686 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RC07 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R687 76871102 RESISTOR, CHIP, 1/8W 1K OHM J RC08 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R688 76871102 RESISTOR, CHIP, 1/8W 1K OHM J RC08 76011220 RESISTOR, CHIP, 1/20W 22 OHM J

R689 76871102 RESISTOR, CHIP, 1/8W 1K OHM J RC09 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R690 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RC09 76011270 RESISTOR, CHIP, 1/20W 27 OHM J

R691 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RC10 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R692 76011223 RESISTOR, CHIP, 1/20W 22K OHM J RC10 76011270 RESISTOR, CHIP, 1/20W 27 OHM J

R693 76871102 RESISTOR, CHIP, 1/8W 1K OHM J RC11 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

R694 76871102 RESISTOR, CHIP, 1/8W 1K OHM J RC11 76011334 RESISTOR, CHIP, 1/20W 330K OHM J

- 5 -

Location

No.

Location

No.

Parts No. Description Parts No. Description

RC12 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RE66 76367222 RESISTOR, CARBON FILM, 1/6W 2.2K OHM G

RC12 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RE70 76366184 RESISTOR, CARBON FILM, 1/6W 18OK OHM J

RC13 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RE73 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J

RC13 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RE74 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J

RC14 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RE85 76552222 RESISTOR, OXIDE METAL FILM, 1/2W 2.2K OHM J

RC14 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RE86 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J

RC15 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RH04 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

RC16 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RH05 76000445 RESISTOR, CHIP JUMPER, 1608TYPE

RC17 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RH06 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RC18 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RR01 76871750 RESISTOR, CHIP, 1/8W 75 OHM J

RC19 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RR02 76871750 RESISTOR, CHIP, 1/8W 75 OHM J

RC20 76000824 RESISTOR, CHIP JUMPER, 2125TYPE RR03 76871750 RESISTOR, CHIP, 1/8W 75 OHM J

RC21 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RR04 76011330 RESISTOR, CHIP, 1/20W 33 OHM J

RC22 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RR05 76011330 RESISTOR, CHIP, 1/20W 33 OHM J

RC23 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RR06 76011330 RESISTOR, CHIP, 1/20W 33 OHM J

RC24 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS16 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

RC25 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS17 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

RC26 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS18 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

RC27 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS19 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

RC28 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS20 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

RC32 76011331 RESISTOR, CHIP, 1/20W 330 OHM J RS25 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RC33 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS26 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RC34 76011331 RESISTOR, CHIP, 1/20W 330 OHM J RS27 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J

RC35 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS28 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J

RC36 76011331 RESISTOR, CHIP, 1/20W 330 OHM J RS29 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

RC37 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS30 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

RC38 76011331 RESISTOR, CHIP, 1/20W 330 OHM J RS31 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

RC39 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS32 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

RC40 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RS33 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

RC40 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RS34 76011473 RESISTOR, CHIP, 1/20W 47K OHM J

RC41 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RS35 76011104 RESISTOR, CHIP, 1/20W 100K OHM J

RC41 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS36 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC49 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS37 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC50 76011123 RESISTOR, CHIP, 1/20W 12K OHM J RS40 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC51 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS41 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC52 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS42 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC53 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS43 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC54 76011220 RESISTOR, CHIP, 1/20W 22 OHM J RS44 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC55 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS45 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC61 76011564 RESISTOR, CHIP, 1/20W 560K OHM J RS46 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RC62 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RS47 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE01 76366153 RESISTOR, CARBON FILM, 1/6W 15K OHM J RS48 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE02 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS49 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE03 76366153 RESISTOR, CARBON FILM, 1/6W 15K OHM J RS50 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE04 76366222 RESISTOR, CARBON FILM, 1/6W 2.2K OHM J RS500 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

RE05 76366392 RESISTOR, CARBON FILM, 1/6W 3.9K OHM J RS501 76011153 RESISTOR, CHIP, 1/2OW 15K OHM J

RE06 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS504 76011153 RESISTOR, CHIP, 1/2OW 15K OHM J

RE07 76366392 RESISTOR, CARBON FILM, 1/6W 3.9K OHM J RS505 76011103 RESISTOR, CHIP, 1/20W 10K OHM J

RE08 76366472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM J RS51 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE09 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS516 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE10 76367180 RESISTOR, CARBON FILM, 1/6W 18 OHM G RS517 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE11 76367222 RESISTOR, CARBON FILM, 1/6W 2.2K OHM G RS52 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE12 76366472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM J RS53 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE13 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J RS54 76011682 RESISTOR, CHIP, 1/20W 6.8K OHM J

RE15 76366182 RESISTOR, CARBON FILM, 1/6W 1.8K OHM J RS55 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE16 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS56 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE17 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J RS58 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE18 76366153 RESISTOR, CARBON FILM, 1/6W 15K OHM J RS59 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE19 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS60 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE26 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J RS61 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE27 76552102 RESISTOR, OXIDE METAL FILM, 1/2W 1K OHM J RS64 76011682 RESISTOR, CHIP, 1/20W 6.8K OHM J

RE28 76552332 RESISTOR, OXIDE METAL FILM, 1/2W 3.3K OHM J RS65 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J

RE29 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J RS66 76011100 RESISTOR, CHIP, 1/20W 10 OHM J

RE30 76366154 RESISTOR, CARBON FILM, 1/6W 150K OHM J RS67 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE33 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J RS68 76011101 RESISTOR, CHIP, 1/20W 100 OHM J

RE34 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J RS78 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

RE60 76000142 RESISTOR, METAL FILM, 1/4W 240 OHM F RS81 76011102 RESISTOR, CHIP, 1/20W 1K OHM J

RE61 76000360 RESISTOR, METAL FILM, 1/4W 1.2K OHM F RS82 76011682 RESISTOR, CHIP, 1/20W 6.8K OHM J

RE63 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J RS85 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

RE65 76367620 RESISTOR, CARBON FILM 1/6W 62 G RS86 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J

- 6 -

Location

No.

Location

No.

Parts No. Description Parts No. Description

RS87 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LE62 23248387 COIL, CHOKE 9X11H 22MMHK 2.5A TLN3499AA

RS88 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LE62 23248432 COIL, CHOKE, TLN3499AH

RV121 76872750 RESISTOR, CHIP, 1/16W 75 OHM J LE70 23248387 COIL, CHOKE 9X11H 22MMHK 2.5A TLN3499AA

RV122 76872750 RESISTOR, CHIP, 1/16W 75 OHM J LE70 23248432 COIL, CHOKE, TLN3499AH

RV123 76872750 RESISTOR, CHIP, 1/16W 75 OHM J LE71 23248386 COIL, CHOKE, TLN3481AA

RV129 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LE71 23248417 COIL, CHOKE, TLN3481AH

RV287 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV247 23246662 COIL, CHIP, TRF4100CN

RV288 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV29 23246654 COIL, CHIP, TRF4220CG

RV289 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV31 23246662 COIL, CHIP, TRF4100CN

RV290 76000445 RESISTOR, CHIP JUMPER, 1608TYPE L105 23277002 FERRITE CORE, ACM3225-102-2PT100

RV291 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV120 23277002 FERRITE CORE, ACM3225-102-2PT100

RV292 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV121 23277002 FERRITE CORE, ACM3225-102-2PT100

RV30 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J LV122 23277002 FERRITE CORE, ACM3225-102-2PT100

RV306 76011473 RESISTOR, CHIP, 1/20W 47K OHM J LV246 23277002 FERRITE CORE, ACM3225-102-2PT100

RV31 76011391 RESISTOR, CHIP, 1/20W 390 OHM J LV248 23277002 FERRITE CORE, ACM3225-102-2PT100

RV32 76011331 RESISTOR, CHIP, 1/20W 330 OHM J LV249 23277002 FERRITE CORE, ACM3225-102-2PT100

RV330 76871750 RESISTOR, CHIP, 1/8W 75 OHM J LV28 23277002 FERRITE CORE, ACM3225-102-2PT100

RV331 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LV284 23277002 FERRITE CORE, ACM3225-102-2PT100

RV332 76011101 RESISTOR, CHIP, 1/20W 100 OHM J ZA01 23103778 FERRITE CORE, TFE1008

RV340 76871750 RESISTOR, CHIP, 1/8W 75 OHM J ZA01 23103778 FERRITE CORE, TFE1008

RV35 76871750 RESISTOR, CHIP, 1/8W 75 OHM J ZA02 23103839 FERRITE CORE, TFE1012

RV36 76871750 RESISTOR, CHIP, 1/8W 75 OHM J ZA02 23103839 FERRITE CORE, TFE1012

RV370 76871750 RESISTOR, CHIP, 1/8W 75 OHM J ZA03 23103840 FERRITE CORE, TFE1013

RV376 76000445 RESISTOR, CHIP JUMPER, 1608TYPE ZA03 23103840 FERRITE CORE, TFE1013

RV377 76000445 RESISTOR, CHIP JUMPER, 1608TYPE ZA11 23103778 FERRITE CORE, TFE1008

RV40 76871750 RESISTOR, CHIP, 1/8W 75 OHM J ZA12 23103839 FERRITE CORE, TFE1012

RV41 76000445 RESISTOR, CHIP JUMPER, 1608TYPE L102 23103828 INDUCTOR, BEAD, TEM2121M

RV414 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L103 23103828 INDUCTOR, BEAD, TEM2121M

RV415 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L151 23103828 INDUCTOR, BEAD, TEM2121M

RV416 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L152 23103828 INDUCTOR, BEAD, TEM2121M

RV42 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LB19 23103828 INDUCTOR, BEAD, TEM2121M

RV43 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LC01 23103828 INDUCTOR, BEAD, TEM2121M

RV44 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LC02 23103828 INDUCTOR, BEAD, TEM2121M

RV45 76011750 RESISTOR, CHIP, 1/20W 75 OHM J LC03 23103828 INDUCTOR, BEAD, TEM2121M

RV46 76011750 RESISTOR, CHIP, 1/20W 75 OHM J LC04 23103828 INDUCTOR, BEAD, TEM2121M

RV50 76011123 RESISTOR, CHIP, 1/20W 12K OHM J LC02 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

RV51 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LC05 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

RV52 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LC06 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

RV64 76011123 RESISTOR, CHIP, 1/20W 12K OHM J

RV76 76011750 RESISTOR, CHIP, 1/20W 75 OHM J SEMICONDUCTORS

RV78 76011123 RESISTOR, CHIP, 1/20W 12K OHM J D607 23357802 DIODE, ZENER, MA8330-M

ZC01 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D670 23362140 DIODE, KDS160-RTK

ZC02 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D671 23362140 DIODE, KDS160-RTK

ZC03 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D674 23362140 DIODE, KDS160-RTK

ZC04 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D675 23362140 DIODE, KDS160-RTK

ZC05 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D676 23362140 DIODE, KDS160-RTK

ZC06 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D678 23362140 DIODE, KDS160-RTK

ZC07 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D679 23362140 DIODE, KDS160-RTK

ZC08 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 D681 23362140 DIODE, KDS160-RTK

ZC09 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB01 23358606 DIODE, LED RED, SLR-56VC3FPQ

ZC10 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB04 23358605 DIODE, LED GREEN, SLR-56MC3FPQR

ZC11 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB20 23357406 DIODE, ZENER, UDZS5.6B

ZC12 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB22 23357703 DIODE, 1SS355

ZC13 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB23 23357703 DIODE, 1SS355

ZC16 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB501 23357505 DIODE, VRM=80V IF=100MA SMINI2 MA2J11100L

ZC18 76019479 RESISTOR, CHIP BLOCK, 1/32W 22 OHM J, P-8 DB502 23357765 DIODE, ZENER, MA8100-M

ZC19 76019404 RESISTOR, CHIP BLOCK, 1/16W 10K OHM J, P-8 DB503 23357765 DIODE, ZENER, MA8100-M

ZC21 76019404 RESISTOR, CHIP BLOCK, 1/16W 10K OHM J, P-8 DB504 23357505 DIODE, VRM=80V IF=100MA SMINI2 MA2J11100L

ZC22 76019404 RESISTOR, CHIP BLOCK, 1/16W 10K OHM J, P-8 DC01 23362231 DIODE, NNCD6.8MG-T1

ZC23 76019404 RESISTOR, CHIP BLOCK, 1/16W 10K OHM J, P-8 DC02 23362231 DIODE, NNCD6.8MG-T1

DC03 23362231 DIODE, NNCD6.8MG-T1

COILS & TRANSFORMERS DC04 23362231 DIODE, NNCD6.8MG-T1

L101 23248398 COIL, CHOKE, TLN3278D DC05 23362194 DIODE, HIGH SPEED SWITCHING 1SS193(TE85L,F)

LE10 23289980 COIL, PEAKING, TRF4220AZ DE01 23357706 DIODE, AK04

LE30 23248387 COIL, CHOKE 9X11H 22MMHK 2.5A TLN3499AA DE02 23357706 DIODE, AK04

LE30 23248432 COIL, CHOKE, TLN3499AH DE03 23357823 DIODE, ZENER, MTZJ3.6A

LE31 23248386 COIL, CHOKE, TLN3481AA DE03 23357681 DIODE, ZENER, RD3.6ESA B1

LE31 23248417 COIL, CHOKE, TLN3481AH DE04 23357821 DIODE, ZENER, MTZJ3.3A

LE60 23248456 COIL, CHOKE, TLN3540AH DE04 23357683 DIODE, ZENER, RD3.3ESA B1

LE61 23289980 COIL, PEAKING, TRF4220AZ DE05 23357499 DIODE, ERB12-01

- 7 -

Location

No.

Location

No.

Parts No. Description Parts No. Description

DE06 23357922 DIODE, 1SS120-7-E Q673 23205443 TRANSISTOR, 2SA1162-Y(F)

DE06 23357697 DIODE, 1SS133 QB04 23205463 TRANSISTOR, 2SC2712-Y(TE85L,F)

DE07 23357821 DIODE, ZENER, MTZJ3.3A QB07 23205463 TRANSISTOR, 2SC2712-Y(TE85L,F)

DE07 23357683 DIODE, ZENER, RD3.3ESA B1 QB502 23205307 TRANSISTOR, 2SA562TM-Y(F)

DE08 23357499 DIODE, ERB12-01 QB503 23205506 TRANSISTOR, 2SC4081 Q

DE09 23357922 DIODE, 1SS120-7-E QB503 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)

DE09 23357697 DIODE, 1SS133 QB504 23205506 TRANSISTOR, 2SC4081 Q

DE10 23357922 DIODE, 1SS120-7-E QB504 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)

DE10 23357697 DIODE, 1SS133 QB505 23205506 TRANSISTOR, 2SC4081 Q

DE31 23357922 DIODE, 1SS120-7-E QB505 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)

DE31 23357697 DIODE, 1SS133 QB508 23205307 TRANSISTOR, 2SA562TM-Y(F)

DE32 23357829 DIODE, ZENER, MTZJ4.3C QC03 23205578 TRANSISTOR, RTQ035P02 RTQ035P02

DE32 23357675 DIODE, ZENER, RD4.3ESA B3 QC04 23205578 TRANSISTOR, RTQ035P02 RTQ035P02

DE60 23357810 DIODE, FMB-G14L QC05 23205578 TRANSISTOR, RTQ035P02 RTQ035P02

DE61 23357922 DIODE, 1SS120-7-E QC06 23205578 TRANSISTOR, RTQ035P02 RTQ035P02

DE61 23357697 DIODE, 1SS133 QE01 23205313 TRANSISTOR, 2SC1815-Y(F)

DE62 23357845 DIODE, ZENER, MTZJ7.5B QE01 23205376 TRANSISTOR, 2SC5343-Y(BULK)

DE62 23357632 DIODE, ZENER, RD7.5ESA B2 QE02 23205313 TRANSISTOR, 2SC1815-Y(F)

DE71 23357922 DIODE, 1SS120-7-E QE02 23205376 TRANSISTOR, 2SC5343-Y(BULK)

DE71 23357697 DIODE, 1SS133 QE03 23205315 TRANSISTOR, RN1206(F)

DE72 23357829 DIODE, ZENER, MTZJ4.3C QE04 23205313 TRANSISTOR, 2SC1815-Y(F)

DE72 23357675 DIODE, ZENER, RD4.3ESA B3 QE04 23205376 TRANSISTOR, 2SC5343-Y(BULK)

DE74 23357922 DIODE, 1SS120-7-E QE11 23205315 TRANSISTOR, RN1206(F)

DE74 23357697 DIODE, 1SS133 QE25 23205340 TRANSISTOR, 2SA1020-Y(F)

DE85 23357861 DIODE, ZENER, MTZJ11A QE26 23205313 TRANSISTOR, 2SC1815-Y(F)

DE85 23357624 DIODE, ZENER, RD11ESA B1 QE26 23205376 TRANSISTOR, 2SC5343-Y(BULK)

DE86 23357922 DIODE, 1SS120-7-E QE61 23205315 TRANSISTOR, RN1206(F)

DE86 23357697 DIODE, 1SS133 QE66 23205315 TRANSISTOR, RN1206(F)

DE99 23357840 DIODE, ZENER, MTZJ6.2B QE71 23205324 TRANSISTOR, RN2004(F)

DR01 23357765 DIODE, ZENER, MA8100-M QE85 23205339 TRANSISTOR, 2SC2655-Y(F)

DR02 23357765 DIODE, ZENER, MA8100-M QS03 23205302 TRANSISTOR, 2SC3326-B(F)

DR03 23357765 DIODE, ZENER, MA8100-M QS04 23205302 TRANSISTOR, 2SC3326-B(F)

DV120 23357751 DIODE, ZENER, MA8068-M QS05 23205325 TRANSISTOR, RN2404(F)

IC414 23085936 IC, BU4245G-TR QS08 23205506 TRANSISTOR, 2SC4081 Q

IC710 75001217 IC, TC7SH04FU, INVERTER QS08 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)

IC909 75001247 IC, TC7SH32FU(TE85LF) QS08 23205392 TRANSISTOR, 2SC5343UF-Y(BULK)

Q670 23085826 IC, 2CH POWER IC HZIP-12P TA8246AHQ(5) QS08 23205347 TRANSISTOR, KTC4075Y/P

Q670 23085039 IC, TA8246AHQ QS09 23205506 TRANSISTOR, 2SC4081 Q

QB501 23085951 IC, BLASTER IC S3C80F9BKZ-SO77 QS09 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)

QB516 23009976 IC, BH33FB1WG-TR QS09 23205392 TRANSISTOR, 2SC5343UF-Y(BULK)

QB80 23085600 IC, PST9129 QS09 23205347 TRANSISTOR, KTC4075Y/P

QC01 23085879 IC, USB2224-NU-05 USB2224-NU-05 QS10 23205302 TRANSISTOR, 2SC3326-B(F)

QC02 23085121 IC, TC7SH04FU(TE85L,F) QS11 23205302 TRANSISTOR, 2SC3326-B(F)

QC07 23085774 IC, REG PQ033EZ01ZPH PQ033EZ01ZPH QS19 23205506 TRANSISTOR, 2SC4081 Q

QE10 23135077 IC, SI-3090CA QV18 23205330 TRANSISTOR, RN1403(F)

QE30 23135084 IC, MPD6S011S QV21 23205507 TRANSISTOR, 2SA1576A Q

QE60 23085381 IC, SI-8050SS QV22 23205329 TRANSISTOR, RN1404(F)

QE65 23135076 IC, SI-3050C QV23 23205329 TRANSISTOR, RN1404(F)

QE70 23135084 IC, MPD6S011S QV283 23205329 TRANSISTOR, RN1404(F)

QH01 23085253 IC, SN74CB3Q3306APWR LC03 23103271 FILTER, EMI 2012 201OHM 0.35A TEM2033AD

QS01 23009916 IC, MM1631AJBE LC04 23103271 FILTER, EMI 2012 201OHM 0.35A TEM2033AD

QS102 23085576 IC, OP AMP, BA4558F LV200 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

QV16 23085806 IC, 3 IN 1 OUT 75OHM DRIVER MM1228XFBE LV201 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

QV20 23085393 IC, MM1502XN LV202 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

QV282 23085352 IC, M52055FP LV203 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

Q101 23205506 TRANSISTOR, 2SC4081 Q LV204 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

Q101 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F) LV205 23103272 FILTER, EMI 2012 361OHM 0.22A TEM2034AD

Q161 23205506 TRANSISTOR, 2SC4081 Q XB501 23153504 CERAMIC RESONATOR, 8.00MHZ 25OHM

Q161 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F) B001A 23405526 OPTICAL FILTER, PDP42V T47 SSC PM00QZ001

Q4100 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) P881 23023131 INLET, NOISE FILTER, GL-2080FVP-L

Q4101 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F)

Q4102 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) MISCELLANEOUS

Q4103 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) FE20 23144373 FUSE, RADIAL LEAD SUB-MINIATUR 250V 630MA

Q660 23205506 TRANSISTOR, 2SC4081 Q P662 23023302 EARPHONE JACK

Q661 23205506 TRANSISTOR, 2SC4081 Q PB501 23023327 EARPHONE JACK

Q663 23205506 TRANSISTOR, 2SC4081 Q PB502 23023327 EARPHONE JACK

Q664 23205506 TRANSISTOR, 2SC4081 Q PB503 23023327 EARPHONE JACK

Q665 23205325 TRANSISTOR, RN2404(F) P661 23023302 EARPHONE JACK

Q671 23205302 TRANSISTOR, 2SC3326-B(F) MJ22 23389359 CABLE, FFC 0.5 50P L70 GOLD

Q672 23205302 TRANSISTOR, 2SC3326-B(F) MJ60 23389359 CABLE, FFC 0.5 50P L70 GOLD

- 8 -

Location

No.

Location

No.

Parts No. Description Parts No. Description

MZ01 23368940 CABLE, LVDS 550MM PDP2 PICTURE TUBE

H003A 23368943 CABLE, PH0NO 350MM JLC YAF11-1194N B001 23301662 DISPLAY, J-MD42HM8BSNJ JMD42HM8BSNJ

H003B 23368943 CABLE, PH0NO 350MM JLC YAF11-1194N B001 23301673 DISPLAY, MD-42HM8BTNJ MD-42HM8BTNJ

PJ21A 23713934 CONNECTOR, 2MM 3P S WHT, B3B-PH-K-S(LF) U100 23301674 DISPLAY, TY-DB42H8T TY-DB42H8T

PC01 23713622 CONNECTOR, 2MM 5P SMD B5B-PH-SM4-TBT

PJ930 23713574 CONNECTOR, 7P TOP TYPE, BM07B-SRSS-TBT(LF)

CCESSORIES

PJ41 23713943 CONNECTOR, CONNECT B11B-PH-K-S(LF) Y109 23945015 BAG, POLYETHYLENE COVER 250X400

PJ41A 23713943 CONNECTOR, CONNECT B11B-PH-K-S(LF) Y174 23845510 BAND

PJ41B 23713943 CONNECTOR, CONNECT B11B-PH-K-S(LF) Y101 23566767 OWNERS MANUAL, ENGLISH/FRENCH 42HPX95 E/F

PJ41C 23713943 CONNECTOR, CONNECT B11B-PH-K-S(LF) Y101 23566767 OWNERS MANUAL, ENGLISH/FRENCH 42HPX95 E/F

PV25A 23713944 CONNECTOR, CONNECT B12B-PH-K-S(LF) P819 23713754 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4

PV25B 23713944 CONNECTOR, CONNECT B12B-PH-K-S(LF) P820 23713754 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4

P602A 23713938 CONNECTOR, CONNECT B5B-PH-K-S(LF) P601 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4

P602B 23713938 CONNECTOR, CONNECT B5B-PH-K-S(LF) PJ63A 23713756 PLUG, 5P 2.5MM G, B5B-EH-F1-TV4

PJ42 23713940 CONNECTOR, CONNECT B8B-PH-K-S(LF) P804B 23713757 PLUG, 6P 2.5MM G, B6B-EH-F1-TV4

PJ62 23713910 CONNECTOR, CONNECTOR B5P-VH(LF) P804A 23713757 PLUG, 6P 2.5MM G, B6B-EH-F1-TV4

PJ62A 23713910 CONNECTOR, CONNECTOR B5P-VH(LF) P809A 23713762 PLUG, NP 2.5MM G, B11B-EH-F1A

PJ22 23757180 CONNECTOR, FH12-50S-0.5SV(55) FH12-50S-0.5SV(55) P803B 23713763 PLUG, NP 2.5MM G, B12B-EH-F1A

PJ60 23757180 CONNECTOR, FH12-50S-0.5SV(55) FH12-50S-0.5SV(55) P803A 23713763 PLUG, NP 2.5MM G, B12B-EH-F1A

PJ22A 23757176 CONNECTOR, IRS 9637S-50Y902 GLD 9637S-50Y902 P807A 23713763 PLUG, NP 2.5MM G, B12B-EH-F1A

PJ60A 23757176 CONNECTOR, IRS 9637S-50Y902 GLD 9637S-50Y902 P801 23372249 POWER CORD, UL/CSA 2M

XC01 23153589 CRYSTAL RESONATOR, XTAL 12MHZ K902 23306627 REMOCON HAND UNIT, CT-90233

PV01 23023311 JACK, PIN 2S6P, LAP5030-0111GC K903 23306644 REMOCON IR, IR BLASTER G-LINK VTR CONT.32HL95

PV02 23023315 JACK, PIN 7P SMK LAP5030-0203F KB01 23009710 REMOCON RECEIVER, GP1UE281RK

PV03 23023313 JACK, PIN 5P, LAP5030-0201G PC02 23903251 SOCKET, CFH050-C7-1180

PV03 23023315 JACK, PIN 7P SMK LAP5030-0203F PC02A 23903257 SOCKET, CFHEJT-90-0000 CFHEJT-90-0000

PV05 23023318 JACK, PIN 5P, LAP50300206GC PC03 23903250 SOCKET, CLE9042-0101F

PV60 23365275 JACK, PHONO 3P V-L-R, YKC21 PV90 23713710 SOCKET, D-SUB 15P, KRD-8622

PV61 23023300 JACK, Y/C YKF51-5560

UF01 23125931 MOTOR, DCFAN 12V 80MM 350 D08A-12PM15B CABINATE PARTS

UF01 23125931 MOTOR, DCFAN 12V 80MM 350 D08A-12PM15B E871B 23960136 ADHESIVE, SILICONE, TSE3843-W

UF03 23125942 MOTOR, DCFAN12V60MMPOD D06R-12TS1002BC2 E871B 23960136 ADHESIVE, SILICONE, TSE3843-W

UF02 23125929 MOTOR, FAN, FBL08A12L A703 23945216 BAG, LAMIFILM BAG 42HP84 42HP84:S1304D121

UF02 23125929 MOTOR, FAN, FBL08A12L A701B 23015181 CARTON, BOTTOM CASE 42HP95 42HP95;S1305D117

H003C 23747055 NUT, F-CONNECTOR 2H BS A701A 23015199 CARTON, CASE 42HPX95 42HPX95;S1305D125

H003 23344525 SWITCH, 2I3O BUNPAI US DIG RSU143 B240 23015336 CARTON, CASE CHASSIS 42HP95 42HP95;S1305D210

SA01 23344507 SWITCH, PUSH, SKHHLMA010 A401 23533556 COVER, BACK COVER ASSY 42WP56C;A055118E

SA02 23344507 SWITCH, PUSH, SKHHLMA010 A401 23533556 COVER, BACK COVER ASSY 42WP56C;A055118E

SA03 23344507 SWITCH, PUSH, SKHHLMA010 A410 23533616 COVER, CABLE COVER PROPER 42HP95;A055093E

SA04 23344507 SWITCH, PUSH, SKHHLMA010 A201 23533642 COVER, FRONT BEZEL ASSY 42HPX95;A055092E

SA05 23344507 SWITCH, PUSH, SKHHLMA010 A403 23436887 FOOT, STAND ASSY 42HP95;S1305E304

SA06 23344507 SWITCH, PUSH, SKHHLMA010 PP02 23528292 HOLDER, ABMM-A-D, (NO SERVICE)

SA07 23344507 SWITCH, PUSH, SKHHLMA010 Y170 23845800 HOLDER, WIRE, NYLON66 D6.8

SA08 23344507 SWITCH, PUSH, SKHHLMA010 PP03 23845859 HOLDER, WIRE, PVC-C0AT, L=70MM

N100 23969797 TAPE PP03 23845859 HOLDER, WIRE, PVC-C0AT, L=70MM

N100 23969797 TAPE A206 23469406 INSULATOR, INSULATOR 42WP56C:D055102E

E900A 23965241 TAPE, CC #12 10MM L30M A407 23950113 LABEL, SERIAL NUMBER, TTX3

E901A 23965241 TAPE, CC #12 10MM L30M A702B 23580048 PACKING, BOTTOM PACKING 42HP95 42HP95;S1305D119

PP01 23974994 BAND, KESSOKU A705 23518043 PACKING, JOINT, 32Z5P

PP01A 23974994 BAND, KESSOKU A702A 23580047 PACKING, TOP PACKING 42HP95 42HP95:S1305D118

PP01B 23974994 BAND, KESSOKU B205 23940528 PIECE, AV COVER ASSEMBLY 42HPX95;S1305E537

PP05 23974994 BAND, KESSOKU B205 23940528 PIECE, AV COVER ASSEMBLY 42HPX95;S1305E537

A221 23940494 PIECE, PIECE CONTROL ASSY 42HP95;C055083E

TUNER A220 23940495 PIECE, PIECE FRONT AV ASSY 42HP95;C055084E

H001 23321536 TUNER, TIF US HOR IIC PH 864M ENG36A36GF Q670B 23717240 SCREW

QE10B 23717240 SCREW

PC BOARD ASSEMBLIES QE60B 23717240 SCREW

U104 75001606 PC BOARD ASSY, PD2142A1 MULTI CARD B222 23717306 SCREW WITH WASHER

U803 75001599 PC BOARD ASSY, PD2202B1 LOWB A231 23717214 SCREW, BITTB3X12SBN

U105A 75001682 PC BOARD ASSY, PD2220C1 TN/AV-AOUT B214 23717214 SCREW, BITTB3X12SBN

U105B 75001683 PC BOARD ASSY, PD2220C2 FRONT-AV B214A 23717214 SCREW, BITTB3X12SBN

U105C 75001684 PC BOARD ASSY, PD2220C3 LED-RMT B214B 23717214 SCREW, BITTB3X12SBN

U105D 75001685 PC BOARD ASSY, PD2220C4 KEY-SW A235A 23738074 SCREW, PP 5X16 SW+W SBN

U101 75001680 PC BOARD ASSY, PD2222C1 SIGNAL B213 23717219 SCREW, PP3X8+SW+W SBN

U103 75001408 PC BOARD ASSY, PD2232A1 D-TUNER A237 23717250 SCREW, PP4X12+SW+W SBN 42HP84;S2681X011

U102 75001681 PC BOARD ASSY, PD2266E1 SEIN FPD WITH LAN B221 23717225 SCREW, PP4X20+SW+W SBN

U103 75001699 PC BOARD ASSY, PD2301A1 D-TUNER A235 23717177 SCREW, PP5X12+SW+W SBN 32L400V;S2681X011

U800 23122503 P0WER UNIT, POWER BLOCK MODULE 1H277W A423 23717217 SCREW, PP6X35+SW+W SBN 42HP84;S2681X011

A230 23717192 SCREW, SCREW, AV BOARD 62HM84;S1304F038

A230 23717443 SCREW, SCREW, AV BOARD ECO 62HM84;S1304F038

- 9 -

Location

No.

Location

Parts No. Description Parts No. Description

W661 23351322 SPEAKER, SPK1470BO, 6X12+6X12+TW

W662 23351322 SPEAKER, SPK1470BO, 6X12+6X12+TW

PP22 23748085 WASHER, WASHER 10X4.2XT=0.3 32WL55C:D985220E

- 10 -

Location

No.

Location

No.
