SERVICE MANUAL
Plasma Color Television
42WP56P
FILE NO. 030-200507
Published in Japan, Sep. 2005 (YC)
TOSHIBA CORPORATION, 2005

- 2 -
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS .................................................................................................................................... 3
SERVICE MODE .................................................................................................................................................................. 5
LOCATION OF CONTROLS ............................................................................................................................................... 10
LAYOUT OF MAJOR BOARDS .......................................................................................................................................... 12
MECHANICAL DISASSEMBLY .......................................................................................................................................... 13
EXPLODED VIEW .............................................................................................................................................................. 15
PACKING DISASSEMBLY ................................................................................................................................................. 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ................................................................................................. 18
PC BOARDS TOP & BOTTOM VIEW ................................................................................................................................ 23
CIRCUIT BLOCK DIAGRAM .............................................................................................................................................. 37
SPECIFICATIONS ............................................................................................................................................................. 38
APPENDIX:
SCHEMATIC DIAGRAM

- 3 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE SAFETY PRECAUTIONS
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPULUG
The " indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
" or nearby illustrations or text.
The example shown to the left indicates the danger of "electrical shock".
The indicates a forbidden action.
The actual meaning of this caution is indicated inside the or nearby illustrations or text.
The example shown to the left indicates that disassembly is forbidden.
The
- indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
- or nearby illustrations or text.
The example shown to the left indicates that the power plug must be disconnected.

- 4 -
WARNING
KEEP CHILDREN
AWAY
UNPULUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is pos-
sible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same character-
istics.
Use only the specified parts when the mark is included in a circuit diagram or parts list.
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage. Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and recon-
nect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch. Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous

- 5 -
Test signal selection : abutton (on Remote)
Selection of the adjustment items : Channel s/t(on TV or Remote)
Change of the data value : Volume ;+/– (on TV or Remote)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory : CALL + Channel button on TV (s)
Reset the count of operating protect
circuit to “00”: CALL + Channel button on TV (t)
“RCUT” selection : 1 button
“GCUT” selection : 2 button
“BCUT” selection : 3 button
“SCNT” selection : 4 button
“COLP” selection : 5 button
“TNTC” selection : 6 button
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
Automatic A/D Adjustment(PC, Component) : 7 button
Self diagnostic display ON/OFF : 9 button
CAUTION : Never try to perform initialization unless you have changed the memory IC.
SERVICE MODE
1. ENTERING SERVICE MODE
1) Press button once on 2) Press button again and 3) While pressing the button,
Remote Control. keep pressing. press MENU button on TV set.
(Service mode display)
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
Service mode Adjustment mode
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
Press
Press
or Sound Mute

- 6 -
Signals Picture
• Red raster
• Green raster
• Blue raster
• All Black
• All White
R
All BlackAll White
BSignal off G
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ;+/– button will change the value of data in the range from 00H to FFH. The variable range
depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■INITIALIZATION OF MEMORY DATA
After replacing EEPROM IC, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL sbutton on the TV.The initialization of EEPROM IC
has been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto tune” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless EEPROM IC has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of abutton on the Remote Control changes the built-in test patterns on screen as described below
in SERVICE MODE.

- 7 -
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s is executed properly.
2) During diagnosis, the following displays are shown.
1Firmware :
Version information of microprocessor
In case of file name : WP56_EU and Version : 0100 indicates[WP56_EU_0100].
2Time : Total hour of turn the TV on. (Unit : H)
3Power :Operation number of protecting circuit ----"000" is normal.
When indication is other than "000", overcurrent apt to flow, and circuit parts may possibly be damaged.
4Bus line : --"OK" is normal
"SCL-GND"(Red indication) : SCL-GND short circuit
"SDA-GND"(Red indication) : SDA-GND short circuit
"SCL-SDA"(Red indication) : SCL-SDA short circuit
5Bus cont : --- "OK" is normal.
NG is abnormal(Red indication), when type name of semiconductor indicates.
6Block
UV : TV reception mode
V1 : VIDEO 1 input mode ( 1)
V2 : VIDEO 2 input mode ( 2)
V3 : VIDEO 3 input mode ( 3)
78 digit : CD number
8Model name (7 digit)
000
000000
42WP56P
42WP56P
WP56_EU_0100
WP56_EU_0100
1
2
3
4
5
6
78

- 8 -
9. VERSION CHECK MODE
1) Press “9” button twice on Remote Control during display of adjustment menu in the service mode. The version of main
MPU will begin to check.
2) During Version Check, the following displays are shown.
1MAIN MPU :
Version information of microprocessor
In case of file name : WP56_EU, Version 0100 for Code Program Version
and (E16) for OSD Version indicates [WP56_EU_0100(E16)]
2EEPROM :
Version information of EEPROM : Display 1 byte data.
3SUB MPU :
Version information of SUB MPU : Display 1 byte data.
4OPTION :
Option information : Display six numbers of 1 byte data.
5HDMI ID :
HDMI ID information : Display 4 byte data.
6CD number : Display 8 digit number
7Model name : Display 7 digit number
8Panel Vender information display
The following Panel Vender and screen size are displayed.
WP56_EU_0100 (E16)
2E
42WP56P LG−42
1
2
3
4
5
6
78
Example : LG-42 indicates that Vender is LG and Screen Size is 42 inch.
Panel Panel Vender Screen Size(Inch)
LCD LPL -23
SHP -26
CMO -27
-32
-37
-42
PDP LG -42

- 9 -
10. STATUS CHECK MODE
1) Press “9” button thrice on Remote Control during display of adjustment menu in the service mode. The status of this model
will begin to check.
2) During Status Check, the following displays are shown.
1MAIN :
Main source information :
Display RF position number (0 - 99) on the main screen, or Input Source (EXT1/2/3/HDMI etc.)
2MAIN FORMAT :
Display Video and PC format information
3MAIN PLL :
Main PLL information : Display five numbers of 1 byte data.
4SCREEN SIZE :
Display the screen size as follows.
5OTHER STATUS :
Other status information : Display three numbers of 2 byte data.
Super live
Cinema
Subtitle
14:9
Wide
4:3
EXT1
1080i-50
C6 38 54 CE 08
0000 0000 0000
1
2
4
5
3

- 10 -
LOCATION OF CONTROLS
ef
Standby
RED – Power On
GREEN – On-timer set
INPUT 3
(EXT 3)
media recorder
decoder*
SCART 1 (EXT 1)
SCART 2 (EXT 2)
BRACKET HOLES

SAT
IN/OUT
MEDIA REC.
TV
MAINS LEAD
SUPPLIED
CONNECTING EXTERNAL EQUIPMENT
CONTROLS AND INPUT CONNECTIONS

- 11 -
Remote control
To mute the sound
Text control buttons
To exit Menus
Bass Boost
Stereo/Bilingual reception
To bring up on-screen information and
for the text initial/index function
To select input from external sources
To access sub-pages when in text mode
To select mode
On-screen Menus
Selectable picture preferences Widescreen viewing
Number buttons
To return to the previous programme
For On/Standby mode
To display text services
When using a TOSHIBA VCR or DVD:
press
m
to PAUSE
press
w
to EJECT
press
l
q
to SKIP-REWIND
press
s
l
to SKIP-FORWARD
press
r
to PLAY
press
p
to STOP
press
q
to REWIND
press
s
to FAST FORWARD
To change programme positions and
text pages
To alter the volume
When using menus the arrows move the
cursor on the screen up, down, left or
right. OK to confirm your selection
When in TV mode:
8/9
Time display
When in text mode:
r
To reveal concealed text
q
To hold a wanted page
s
To enlarge text display size
8/9
To select a page whilst viewing a
normal picture

- 12 -
LAYOUT OF MAJOR BOARDS
U003D
RMT LED BOARD
U003A
TN/AV BOARD
U001
SIGNAL BOARD
U003B
FRONT AV BOARD
U002
LOWB BOARD
U003C
KEY BOARD

- 13 -
PP4×8 SBN ×6
PP6×35+SW+W
SBN ×4
BITTB 4×12 SBN ×14
PP3×8 SBN
PP4×8 SBN ×9
BITTB 4×12
SBN ×7
A401
A410
A403
A206
A206
MECHANICAL DISASSEMBLY
1. Remove the stand (foot) and back cover.
2. Remove the boards (LOWB,TN/AV, FRONT AV, KEY) and piece key ass'y.
BITTB 3×12
ECO ×2
BITTB 3×8 ECO ×2
PP4×8 ECO
PP3×8 SBN
PP3×8 ECO ×8
PP4×8 SBN ×2
PP4×12 SBN ×2
BITTB 3×12 SBN ×4
PP3×8 ECO
×2
PP3×8 ECO ×6
H001
U800
U003C
U003A
U003B
A221
A220

- 14 -
PP3×8 ECO ×4
PP3×8 ECO ×6
U001
U002
W662
W661
BITTB 3×8 SBN
×6
BITTB 3×12
ECO ×2
BITTB 3×8 SBN
×6
U003D
3. Remove the boards (SIGNAL, RMT LED) and speaker.
4. Remove the display.
BITTB 4×12 ECO ×4
BITTB 4×12 ECO ×19
B001
A201

- 15 -
EXPLODED VIEWS
1. Chassis Block
PP4×8 SBN ×6
PP6×35+SW+W
SBN ×4
BITTB 4×12 SBN ×14
PP3×8 SBN
PP4×8 SBN ×9
BITTB 4×12
SBN ×7 A401
W662
A403
A410
W661
BITTB 3×8 SBN ×6
BITTB 3×12
ECO ×2
BITTB 3×8 SBN ×6
U003D
A206
A206

- 16 -
BITTB 3×12
ECO ×2
PP3×8 ECO ×4
BITTB 3×8 ECO ×2
PP4×8 ECO
PP3×8 SBN
PP3×8 ECO ×8
PP4×8 SBN ×2
PP4×12 SBN ×2
PP3×8 ECO ×6
BITTB 3×12 SBN ×4
PP3×8 ECO ×2
BITTB 4×12 ECO ×4
BITTB 4×12 ECO ×19
PP3×8 ECO ×6
H001
B001
U800
U001
A221
U003C
U003A
U003B
A201
U002
A220
2. Main Block

- 17 -
PACKING DISASSEMBLY
A701B
A701A
A702B
A702B
A702A
A702A
A705
A705
Y110
Y101
Y130
Y170
Y174

- 18 -
Location Parts No. Description
No.
Location Parts No. Description
No.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “SERVICE SAFETY PRECAUTIONS” ON PAGE 3 OF
THIS MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in
the original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the SERVICE SAFETY PRECAUTIONS. Do not degrade
the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with ∗ mark is no longer available after the end of the production.
CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 42WP56P
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CAPACITORS
C101 76109103 CERAMIC CHIP, 50V B 0.01UF K
C102 76073019 ELECTROLYTIC, 10V 470UF M 3A
C103 76109102 CERAMIC CHIP, 50V B 1000PF K
C104 76619143 ELECTROLYTIC CHIP, 50V 4.7UF M
C105 76073019 ELECTROLYTIC, 10V 470UF M 3A
C117 76109103 CERAMIC CHIP, 50V B 0.01UF K
C118 76109103 CERAMIC CHIP, 50V B 0.01UF K
C162 76105101 CERAMIC CHIP, 50V CH 100PF J
C164 76100103 CERAMIC CHIP, 50V F 0.01UF Z
C190 76092730 CERAMIC CHIP, 16V B 0.1UF K
C501 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C502 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C503 76619046 ELECTROLYTIC CHIP, 16V 470UF
C504 76109103 CERAMIC CHIP, 50V B 0.01UF K
C505 76619046 ELECTROLYTIC CHIP, 16V 470UF
C506 76109103 CERAMIC CHIP, 50V B 0.01UF K
C514 76665221 ELECTROLYTIC, 10V 220UF M 3A
C516 76105110 CERAMIC CHIP, 50V CH 11PF J
C517 76092785 CERAMIC CHIP, 10V B 0.47UF K
C519 76619048 ELECTROLYTIC CHIP, 25V 4.7UF M
C521 76092733 CERAMIC CHIP, 50V B 0.022UF K
C524 76109103 CERAMIC CHIP, 50V B 0.01UF K
C526 76109103 CERAMIC CHIP, 50V B 0.01UF K
C527 76619071 ELECTROLYTIC CHIP, 50V 2.2UF
C529 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C530 76619157 ELECTROLYTIC CHIP, 16V 100UF
C605 76109102 CERAMIC CHIP, 50V B 1000PF K
C606 76109102 CERAMIC CHIP, 50V B 1000PF K
C612 76664102 ELECTROLYTIC, 6.3V 1000UF M 3A
C631 76619102 ELECTROLYTIC CHIP, 16V 47UF M
C632 76092731 CERAMIC CHIP, 16V B 1UF K
C651 76092463 CERAMIC CHIP, 16V B 0.22UF K
C652 76092463 CERAMIC CHIP, 16V B 0.22UF K
C653 76092538 CERAMIC CHIP, 10V F 1UF Z
C662 76109102 CERAMIC CHIP, 50V B 1000PF K
C663 76619100 ELECTROLYTIC CHIP, 16V 10UF M
C665 76669339 ELECTROLYTIC, 50V 3.3UF M
C666 76669339 ELECTROLYTIC, 50V 3.3UF M
C668 76073086 ELECTROLYTIC, 50V 10UF M 3A
C671 76669479 ELECTROLYTIC, 50V 4.7UF M
C674 76669479 ELECTROLYTIC, 50V 4.7UF M
C677 76109681 CERAMIC CHIP, 50V B 680PF K
C678 76109681 CERAMIC CHIP, 50V B 680PF K
C680 76668102 ELECTROLYTIC, 35V 1000UF M 3A
C681 76668102 ELECTROLYTIC, 35V 1000UF M 3A
C682 76668102 ELECTROLYTIC, 35V 1000UF M 3A
C690 76815103 CERAMIC CHIP, 50V B 0.01UF K
C694 76285104 CERAMIC CHIP, 50V B 0.1UF K
C696 76285104 CERAMIC CHIP, 50V B 0.1UF K
C1801 76285104 CERAMIC CHIP, 50V B 0.1UF K
C1802 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1803 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1804 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1805 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1806 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1807 76109103 CERAMIC CHIP, 50V B 0.01UF K
C1808 76109103 CERAMIC CHIP, 50V B 0.01UF K
C6605 76766100 ELECTROLYTIC, 50V 10UF M
CB01 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB02 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB05 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB38 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CC11 76109102 CERAMIC CHIP, 50V B 1000PF K
CC12 76109102 CERAMIC CHIP, 50V B 1000PF K
CC31 76109102 CERAMIC CHIP, 50V B 1000PF K
CC40 76109102 CERAMIC CHIP, 50V B 1000PF K
CC41 76109102 CERAMIC CHIP, 50V B 1000PF K
CC60 76109102 CERAMIC CHIP, 50V B 1000PF K
CC61 76109102 CERAMIC CHIP, 50V B 1000PF K
CC62 76109102 CERAMIC CHIP, 50V B 1000PF K
CC63 76109102 CERAMIC CHIP, 50V B 1000PF K
CC64 76109102 CERAMIC CHIP, 50V B 1000PF K
CC65 76109102 CERAMIC CHIP, 50V B 1000PF K
CC66 76109102 CERAMIC CHIP, 50V B 1000PF K
CC67 76109102 CERAMIC CHIP, 50V B 1000PF K
CC74 76109102 CERAMIC CHIP, 50V B 1000PF K
CC75 76109102 CERAMIC CHIP, 50V B 1000PF K
CE03 76539104 PLASTIC FILM, 50V 0.1UF J
CE05 76073090 ELECTROLYTIC, 50V 100UF M 3A
CE10 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE11 76539474 PLASTIC FILM, 50V 0.47UF J
CE12 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE60 76073186 ELECTROLYTIC, 35V 470UF M
CE61 76617028 ELECTROLYTIC, 16V 1200UF M
CE62 76073020 ELECTROLYTIC, 10V 1000UF M 3A

- 19 -
Location Parts No. Description
No.
Location Parts No. Description
No.
CE63 76539104 PLASTIC FILM, 50V 0.1UF J
CE64 76539104 PLASTIC FILM, 50V 0.1UF J
CE65 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE66 76539474 PLASTIC FILM, 50V 0.47UF J
CE67 76666470 ELECTORLYTIC, 16V 47UF M 3A
CE85 76666470 ELECTORLYTIC, 16V 47UF M 3A
CT01 76092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT04 76105151 CERAMIC CHIP, 50V CH 150PF J
CT05 76092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT06 76092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT07 76092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT08 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CT09 76109103 CERAMIC CHIP, 50V B 0.01UF K
CV02 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV03 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV13 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV17 76092731 CERAMIC CHIP, 16V B 1UF K
CV19 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV20 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV21 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV22 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV23 76619042 ELECTROLYTIC CHIP, 16V 22UF M 3A
CV24 76092731 CERAMIC CHIP, 16V B 1UF K
CV25 76092731 CERAMIC CHIP, 16V B 1UF K
CV26 76619042 ELECTROLYTIC CHIP, 16V 22UF M 3A
CV27 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV28 76619042 ELECTROLYTIC CHIP, 16V 22UF M 3A
CV51 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV52 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV54 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV55 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CV56 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV57 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV58 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV59 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV60 76619157 ELECTROLYTIC CHIP, 16V 100UF
CV62 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV63 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV91 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CV121 76109103 CERAMIC CHIP, 50V B 0.01UF K
CV122 76105101 CERAMIC CHIP, 50V CH 100PF J
CY650 76109103 CERAMIC CHIP, 50V B 0.01UF K
RESISTORS
R103 76011101 CHIP, 1/20W 100 OHM J
R104 76011103 CHIP, 1/20W 10K OHM J
R105 76011273 CHIP, 1/20W 27K OHM J
R107 76000445 CHIP JUMPER, 1608TYPE
R108 76000445 CHIP JUMPER, 1608TYPE
R114 76000445 CHIP JUMPER, 1608TYPE
R167 76011101 CHIP, 1/20W 100 OHM J
R169 76000445 CHIP JUMPER, 1608TYPE
R170 76011682 CHIP, 1/20W 6.8K OHM J
R501 76011682 CHIP, 1/20W 6.8K OHM J
R502 76011272 CHIP, 1/20W 2.7K OHM J
R504 76011101 CHIP, 1/20W 100 OHM J
R505 76011101 CHIP, 1/20W 100 OHM J
R506 76011273 CHIP, 1/20W 27K OHM J
R507 76011392 CHIP, 1/20W 3.9K OHM J
R508 76011682 CHIP, 1/20W 6.8K OHM J
R512 76011101 CHIP, 1/20W 100 OHM J
R514 76011102 CHIP, 1/20W 1K OHM J
R650 76011102 CHIP, 1/20W 1K OHM J
R651 76011473 CHIP, 1/20W 47K OHM J
R652 76011103 CHIP, 1/20W 10K OHM J
R653 76011223 CHIP, 1/20W 22K OHM J
R654 76011103 CHIP, 1/20W 10K OHM J
R655 76011222 CHIP, 1/20W 2.2K OHM J
R660 76011473 CHIP, 1/20W 47K OHM J
R662 76011103 CHIP, 1/20W 10K OHM J
R663 76011473 CHIP, 1/20W 47K OHM J
R664 76011104 CHIP, 1/20W 100K OHM J
R667 76011104 CHIP, 1/20W 100K OHM J
R670 76011472 CHIP, 1/20W 4.7K OHM J
R671 76011182 CHIP, 1/20W 1.8K OHM J
R672 76011472 CHIP, 1/20W 4.7K OHM J
R673 76011182 CHIP, 1/20W 1.8K OHM J
R675 76011102 CHIP, 1/20W 1K OHM J
R676 76011473 CHIP, 1/20W 47K OHM J
R677 76011473 CHIP, 1/20W 47K OHM J
R684 76871229 CHIP, 1/8W 2.2 OHM J
R685 76871229 CHIP, 1/8W 2.2 OHM J
R687 76871102 CHIP, 1/8W 1K OHM J
R688 76871102 CHIP, 1/8W 1K OHM J
R689 76871102 CHIP, 1/8W 1K OHM J
R690 76871102 CHIP, 1/8W 1K OHM J
R691 76871102 CHIP, 1/8W 1K OHM J
R692 76871102 CHIP, 1/8W 1K OHM J
R697 76000576 CHIP JUMPER, 3216TYPE
R4100 76011102 CHIP, 1/20W 1K OHM J
R4101 76011681 CHIP, 1/20W 680 OHM J
R4102 76011471 CHIP, 1/20W 470 OHM J
R4103 76011102 CHIP, 1/20W 1K OHM J
R4104 76011152 CHIP, 1/20W 1.5K OHM J
R4105 76011102 CHIP, 1/20W 1K OHM J
R4106 76011681 CHIP, 1/20W 680 OHM J
R4107 76011471 CHIP, 1/20W 470 OHM J
R4108 76011102 CHIP, 1/20W 1K OHM J
R4109 76011152 CHIP, 1/20W 1.5K OHM J
R4120 76000445 CHIP JUMPER, 1608TYPE
R4122 76000445 CHIP JUMPER, 1608TYPE
R6603 76011223 CHIP, 1/20W 22K OHM J
R6605 76011103 CHIP, 1/20W 10K OHM J
R6606 76011104 CHIP, 1/20W 100K OHM J
R6610 76011102 CHIP, 1/20W 1K OHM J
R6611 76011102 CHIP, 1/20W 1K OHM J
R6612 76011104 CHIP, 1/20W 100K OHM J
R6613 76011104 CHIP, 1/20W 100K OHM J
R6614 76011103 CHIP, 1/20W 10K OHM J
R6615 76011102 CHIP, 1/20W 1K OHM J
R6616 76011104 CHIP, 1/20W 100K OHM J
R6617 76011104 CHIP, 1/20W 100K OHM J
R6631 76011473 CHIP, 1/20W 47K OHM J
R6632 76011473 CHIP, 1/20W 47K OHM J
R6634 76011102 CHIP, 1/20W 1K OHM J
RA71 76011683 CHIP, 1/20W 68K OHM J
RA72 76011223 CHIP, 1/20W 22K OHM J
RA73 76011103 CHIP, 1/20W 10K OHM J
RA74 76000445 CHIP JUMPER, 1608TYPE
RA77 76011103 CHIP, 1/20W 10K OHM J
RA78 76000445 CHIP JUMPER, 1608TYPE
RA79 76000445 CHIP JUMPER, 1608TYPE
RB08 76011470 CHIP, 1/20W 47 OHM J
RB09 76011470 CHIP, 1/20W 47 OHM J
RB10 76011331 CHIP, 1/20W 330 OHM J
RB15 76011471 CHIP, 1/20W 470 OHM J
RB24 76000445 CHIP JUMPER, 1608TYPE
RC01 76011101 CHIP, 1/20W 100 OHM J
RC02 76011101 CHIP, 1/20W 100 OHM J
RC03 76011101 CHIP, 1/20W 100 OHM J
RC04 76011101 CHIP, 1/20W 100 OHM J
RC11 76011101 CHIP, 1/20W 100 OHM J
RC12 76011101 CHIP, 1/20W 100 OHM J
RC40 76011101 CHIP, 1/20W 100 OHM J
RC41 76011101 CHIP, 1/20W 100 OHM J
RE04 76366222 CARBON FILM, 1/6W 2.2K OHM J
RE06 76366473 CARBON FILM, 1/6W 47K OHM J
RE10 76367180 CARBON FILM, 1/6W 18 OHM G

- 20 -
Location Parts No. Description
No.
Location Parts No. Description
No.
RE11 76367222 CARBON FILM, 1/6W 2.2K OHM G
RE12 76366472 CARBON FILM, 1/6W 4.7K OHM J
RE13 76366102 CARBON FILM, 1/6W 1K OHM J
RE15 76366182 CARBON FILM, 1/6W 1.8K OHM J
RE16 76366473 CARBON FILM, 1/6W 47K OHM J
RE17 76366103 CARBON FILM, 1/6W 10K OHM J
RE18 76366153 CARBON FILM, 1/6W 15K OHM J
RE19 76366473 CARBON FILM, 1/6W 47K OHM J
RE60 76000142 METAL FILM, 1/4W 240 OHM F
RE61 76000360 METAL FILM, 1/4W 1.2K OHM F
RE63 76366102 CARBON FILM, 1/6W 1K OHM J
RE65 76367620 CARBON FILM 1/6W 62 G
RE66 76367222 CARBON FILM, 1/6W 2.2K OHM G
RE85 76552222 OXIDE METAL FILM, 1/2W 2.2K OHM J
RE86 76366103 CARBON FILM, 1/6W 10K OHM J
RR01 76871750 CHIP, 1/8W 75 OHM J
RR02 76871750 CHIP, 1/8W 75 OHM J
RR03 76871750 CHIP, 1/8W 75 OHM J
RR04 76011330 CHIP, 1/20W 33 OHM J
RR05 76011330 CHIP, 1/20W 33 OHM J
RR06 76011330 CHIP, 1/20W 33 OHM J
RS23 76011104 CHIP, 1/20W 100K OHM J
RS24 76011104 CHIP, 1/20W 100K OHM J
RS25 76011104 CHIP, 1/20W 100K OHM J
RS26 76011104 CHIP, 1/20W 100K OHM J
RT01 76011101 CHIP, 1/20W 100 OHM J
RT02 76011273 CHIP, 1/20W 27K OHM J
RT03 76011683 CHIP, 1/20W 68K OHM J
RT04 76011102 CHIP, 1/20W 1K OHM J
RT05 76011101 CHIP, 1/20W 100 OHM J
RT06 76011391 CHIP, 1/20W 390 OHM J
RT07 76011821 CHIP, 1/20W 820 OHM J
RT08 76011151 CHIP, 1/20W 150 OHM J
RT09 76011471 CHIP, 1/20W 470 OHM J
RT10 76011101 CHIP, 1/20W 100 OHM J
RT11 76011471 CHIP, 1/20W 470 OHM J
RT12 76011102 CHIP, 1/20W 1K OHM J
RV02 76872750 CHIP, 1/16W 75 OHM J
RV03 76872151 CHIP, 1/16W 150 OHM J
RV04 76872151 CHIP, 1/16W 150 OHM J
RV05 76872750 CHIP, 1/16W 75 OHM J
RV06 76872750 CHIP, 1/16W 75 OHM J
RV07 76872750 CHIP, 1/16W 75 OHM J
RV13 76872750 CHIP, 1/16W 75 OHM J
RV21 76872750 CHIP, 1/16W 75 OHM J
RV28 76872750 CHIP, 1/16W 75 OHM J
RV30 76872750 CHIP, 1/16W 75 OHM J
RV31 76872750 CHIP, 1/16W 75 OHM J
RV32 76872680 CHIP, 1/16W 68 OHM J
RV51 76011101 CHIP, 1/20W 100 OHM J
RV52 76871181 CHIP, 1/8W 180 OHM J
RV54 76011473 CHIP, 1/20W 47K OHM J
RV55 76011473 CHIP, 1/20W 47K OHM J
RV56 76011473 CHIP, 1/20W 47K OHM J
RV57 76011101 CHIP, 1/20W 100 OHM J
RV58 76871181 CHIP, 1/8W 180 OHM J
RV59 76011473 CHIP, 1/20W 47K OHM J
RV71 76011470 CHIP, 1/20W 47 OHM J
RV72 76011470 CHIP, 1/20W 47 OHM J
RV73 76011470 CHIP, 1/20W 47 OHM J
RV74 76011470 CHIP, 1/20W 47 OHM J
RV76 76011473 CHIP, 1/20W 47K OHM J
RV78 76011101 CHIP, 1/20W 100 OHM J
RV79 76871181 CHIP, 1/8W 180 OHM J
RV80 76011473 CHIP, 1/20W 47K OHM J
RV81 76011473 CHIP, 1/20W 47K OHM J
RV82 76871181 CHIP, 1/8W 180 OHM J
RV84 76011101 CHIP, 1/20W 100 OHM J
RV85 76011473 CHIP, 1/20W 47K OHM J
RV90 76366750 CARBON FILM, 1/6W 75 OHM J
RV90A 23965241 TAPE, CC #12 10MM L30M
RV91 76366750 CARBON FILM, 1/6W 75 OHM J
RV92 76011103 CHIP, 1/20W 10K OHM J
RV93 76011392 CHIP, 1/20W 3.9K OHM J
RV94 76011103 CHIP, 1/20W 10K OHM J
RV95 76011392 CHIP, 1/20W 3.9K OHM J
RV121 76872750 CHIP, 1/16W 75 OHM J
RV129 76011101 CHIP, 1/20W 100 OHM J
RV251 76011101 CHIP, 1/20W 100 OHM J
RV252 76011102 CHIP, 1/20W 1K OHM J
RV253 76011392 CHIP, 1/20W 3.9K OHM J
RV254 76011432 CHIP, 1/20W 4.3K OHM J
RV255 76011102 CHIP, 1/20W 1K OHM J
RV256 76011152 CHIP, 1/20W 1.5K OHM J
RV257 76011102 CHIP, 1/20W 1K OHM J
RV258 76011101 CHIP, 1/20W 100 OHM J
RV259 76011222 CHIP, 1/20W 2.2K OHM J
RV260 76011101 CHIP, 1/20W 100 OHM J
COIL & TRANSFORMERS
L101 23248398 COIL, CHOKE, TLN3278D
L102 23103828 INDUCTOR, BEAD, TEM2121M
L103 23103828 INDUCTOR, BEAD, TEM2121M
L104 23103828 INDUCTOR, BEAD, TEM2121M
L105 23277002 FERRITE CORE,ACM3225-102-2PT100
L190 23103828 INDUCTOR, BEAD, TEM2121M
L505 23289022 COIL, PEAKING, TRF4100AT
LC01 23103828 INDUCTOR, BEAD, TEM2121M
LC02 23103828 INDUCTOR, BEAD, TEM2121M
LC03 23103828 INDUCTOR, BEAD, TEM2121M
LC04 23103828 INDUCTOR, BEAD, TEM2121M
LC05 23103828 INDUCTOR, BEAD, TEM2121M
LC06 23103828 INDUCTOR, BEAD, TEM2121M
LC21 23103828 INDUCTOR, BEAD, TEM2121M
LC22 23103828 INDUCTOR, BEAD, TEM2121M
LC23 23103828 INDUCTOR, BEAD, TEM2121M
LC24 23103828 INDUCTOR, BEAD, TEM2121M
LC27 23103828 INDUCTOR, BEAD, TEM2121M
LC28 23103828 INDUCTOR, BEAD, TEM2121M
LC29 23103828 INDUCTOR, BEAD, TEM2121M
LC30 23103828 INDUCTOR, BEAD, TEM2121M
LC31 23103238 INDUCTOR, BEAD, TEM2142AD
LC32 23103238 INDUCTOR, BEAD, TEM2142AD
LC33 23103238 INDUCTOR, BEAD, TEM2142AD
LE10 23289980 COIL, PEAKING, TRF4220AZ
LE60 23248456 COIL, CHOKE, TLN3540AH
LE61 23289980 COIL, PEAKING, TRF4220AZ
LE62 23248432 COIL, CHOKE, TLN3499AH
LT01 23289028 COIL, PEAKING, TRF4101AT
LV17 23277002 FERRITECORE, ACM3225-102-2PT100
LV21 23277002 FERRITECORE, ACM3225-102-2PT100
LV22 23277002 FERRITECORE, ACM3225-102-2PT100
LV23 23277002 FERRITECORE, ACM3225-102-2PT100
LV24 23277002 FERRITECORE, ACM3225-102-2PT100
LV25 23277002 FERRITECORE, ACM3225-102-2PT100
LV26 23277002 FERRITECORE, ACM3225-102-2PT100
LV27 23277002 FERRITECORE, ACM3225-102-2PT100
LV28 23277002 FERRITECORE, ACM3225-102-2PT100
LV29 23277002 FERRITECORE, ACM3225-102-2PT100
LV30 23277002 FERRITECORE, ACM3225-102-2PT100
LV31 23277002 FERRITECORE, ACM3225-102-2PT100
LV32 23277002 FERRITECORE, ACM3225-102-2PT100
LV33 23277002 FERRITECORE, ACM3225-102-2PT100
LV120 23277002 FERRITECORE, ACM3225-102-2PT100
LV121 23277002 FERRITECORE, ACM3225-102-2PT100
LV122 23277002 FERRITECORE, ACM3225-102-2PT100
