Toshiba KK-1600 User manual

STAPLER
KK-1600
File No.31100019

General Precautions for Installation/Servicing/Maintenance for the KK-1600
The installation and service should be done by a qualified service technician.
1. When installing the KK-1600 to the Plain Paper Copier, be sure to follow the instructions described in
the “Unpacking/Set-Up Procedure for the KK-1600” booklet which comes with each unit of the
KK-1600.
2. The KK-1600 should be installed by an authorized/qualified person.
3. Before starting installation, servicing or maintenance work, be sure to turn off and unplug the copier
first.
4. When servcing or maintaining the KK-1600, be careful about the rotating or operation sections such
as gear, pulleys, sprockets, cams, belts, etc.
5. When parts are disassembled, reassembly is basically the reverse of disassembly unless otherwise
noted in this manual or other related materials. Be careful not to reassemble small parts such as
screws, washers, pins, E-rings, toothed washers to the wrong places.
6. Basically, the machine should not be operated with any parts removed or disassembled.
7. Delicate parts for preventing safety hazard problems (such as breakers, thermofuses, fuses, door
switches, sensors, etc.if any) should be handled/installed/adjusted correctly.
8. Use suitable measuring instruments and tools.
9. During servicing or maintenance work, be sure to check the serial No. plate and other cautionary
labels (if any) to see if they are clean and firmly fixed.If not, take appropriate actions.
10. The PC board must be stored in an anti-electrostatic bag and handled carefully using a wristband,
because the ICs on it may be damaged due to static electricity.Before using the wrist band, pull out
the power cord plug of the copier and make sure that there is no uninsulated charged objects in the
vicinity.
11. For the recovery and disposal of used KK-1600, consumable parts and packing materials, it is rec-
ommended that the relevant local regulations/rules should be followed.
12. After completing installation, servicing and maintenance of the KK-1600, return the KK-1600 to its
original state, and check operation.
Copyright 2000
TOSHIBA TEC CORPORATION

October 2000 © TOSHIBA TEC 1 KK-1600 CONTENTS
CONTENTS
1. SPECIFICATIONS ...................................................................................................... 1-1
2. OUTLINE .................................................................................................................... 2-1
2.1 Names ofVarious Components ......................................................................................... 2-1
2.2 Layout of Electrical Parts.................................................................................................. 2-2
2.3 Harness Connection Diagram............................................................................................ 2-4
2.4 Board Assembly ............................................................................................................... 2-5
3. OPERATIONAL DESCRIPTION................................................................................ 3-1
3.1 General Description .......................................................................................................... 3-1
3.2 Block Diagram .................................................................................................................. 3-1
3.3 Detection of Abnormal Status ........................................................................................... 3-2
3.4 FlowChart ........................................................................................................................ 3-3
4. MECHANICAL DESCRIPTION.................................................................................. 4-1
4.1 MechanismDrawing.......................................................................................................... 4-1
4.2 Staple Operation ............................................................................................................... 4-1
5. CIRCUIT DESCRIPTION ........................................................................................... 5-1
5.1 PWA Block Diagram ......................................................................................................... 5-1
5.2 Functional Description ...................................................................................................... 5-1
5.3 Signal Description ............................................................................................................. 5-2
5.4 Timing Charts ................................................................................................................... 5-3
6. DISASSEMBLY AND REPLACEMENT..................................................................... 6-1

October 2000 © TOSHIBA TEC 1 - 1 KK-1600 SPECIFICATIONS
1. SPECIFICATIONS
Type of stapling : Flat clinch method
No. of sheets stapled : 52g/m2paper, 2 sheets to 80g/m2paper, 50 sheets
52g/m2paper, 2 sheets to 80g/m2paper, 48 sheets + 200g/m2, 2 sheets
Paper thickness : Max.5.5 mm
Staple capacity : 5000 staples
Dimensions : 257 (W) x 423 (D) x 173 (H) mm
Weight : Approx.3.4 kg
Power supply : 100V - 240V (Supplied from copier)

October 2000 © TOSHIBA TEC 2 - 1 KK-1600 OUTLINE
2. OUTLINE
2.1 Names ofVarious Components
STP 02-01-01
STP 02-01-02
STP power code
STP staple unit
STP staple cartridge
STP base
STP power lamp

KK-1600 OUTLINE 2 - 2 October 2000 © TOSHIBA TEC
2.2 Layout of Electrical Parts
STP 02-02-01
STP 02-02-02
STP AC adapter
STP1
STP LED PWA
M1 SW2
SW1
SEN1
SEN2
STP2

October 2000 © TOSHIBA TEC 2 - 3 KK-1600 OUTLINE
Symbols and functions of various devices
Name
STPCOV-SW
STP cover open switch
EMPTY-SW
STP staple empty switch
PSET-SEN
STP paper set sensor
HP-SEN
STP home position sensor
STP motor
STP CONT PWA
STP sensor PWA
STP LED PWA
Function
Detects the open/close state of the cover during
staple replacement, etc.
Detects the presence or absence of staples.
Detects the loading of the paper to be stapled.
Detects the home position of the drive section.
Drive the stapler.
PWA which controls the stapler.
PWA which relays the sensor signals and motor
drive signals.
PWA on which the power lamp (LED) is installed.
Symbol
SW1
SW2
SEN1
SEN2
M1
STP1
STP2
LED

KK-1600 OUTLINE 2 - 4 October 2000 © TOSHIBA TEC
2.3 Harness Connection Diagram
STP 02-03-01
1
2
1
2
1
2
3
4
5
6
7
1
2
3
4
5
6
7
AC
adapter
STP cover open switch
STP motor
STP staple
empty switch
STP home
position sensor
STP paper set sensor
STP LED PWA
Staple unit
STP
CONT
PWA
STP
sensor
PWA
GND
24V
24V
COVER
GND
CN1
H.P
5V
GND
Empty
CW
CCW
5V
GND
GND
LED
Set
J1
J2
J3
1
2
3
J4
1
2
J5
1
2
CN3
1
2
CN2
M
AC IN

October 2000 © TOSHIBA TEC 2 - 5 KK-1600 OUTLINE
2.4 Board Assembly
STPL CONTROLLER
4G1–1231
4H10109
02
MADE IN JAPAN
JP16
D9
C11 2
J5
1
FU1
J1
D8
2
1
3
JP11 JP12
8
JP14
JP10
Q1
1
J4
3117
JP2
JP1
JP5
D5
D7
D4
Q7
Q5
S
Q6
S
Q4
S
DG
DSG
DG
G
JP6
W
J3
JP15
C6
C16
C19
C9
0
R16R14
D6
C8
1
2J2
IO
G
Q3
JP13
C4
Q2
1
D2
C3
9D3
D10
JP17
C5
JP9 JP8
D1
C1
JP7
JP3
JP4
11
2
STP 02-04-01

October 2000 © TOSHIBA TEC 3 - 1 KK-1600 OPERATIONAL DESCRIPTION
3. OPERATIONAL DESCRIPTION
3.1 General Description
Upon detecting the loading of paper, the STP operates the motor for staple operation. The AC input
supplied from the copier is converted to a DC voltage (24V) through the AC adapter in the STP and used as
a power supply for the STP.
3.2 Block Diagram
The STP consists of the AC adapter, STP CONT PWA, sensors, power indicator LED, staple unit, etc. The
staple unit consists of the STP motor, STP Sensor PWA for relaying the sensor signals, mechanical drive
section, etc.
STP 03-02-01
M STP motor
Staple unit
AC
adapter
STP
CONT
PWA
STP
sensor
PWA
+24V
J1
J2
STP cover open switch
STP paper set sensor
STP LED PCB
STP staple empty switch
STP home position sensor
J4J5J3

KK-1600 OPERATIONAL DESCRIPTION 3 - 2 October 2000 © TOSHIBA TEC
3.3 Detection of Abnormal Status
• Cover Open/Close Detection
The STP cover open switch turns OFF when the cover is opened. Since the switch is connected to the
power supply, the power supply to the STP is cut when the switch turns OFF. For this reason, all the
operation is disabled while the cover is open. When the STP cover is closed, the delivery of the power
supply is resumed to light the STP power lamp and enable stapling.
• Staple Empty Detection
Upon detecting a staple empty state, the STP staple empty switch resets the motor drive circuit so that
the motor does not operate even if the STP paper set sensor detects the presence of paper. This error
state is reset when staples are supplied causing the STP paper set sensor to detect the presence of
staples.

October 2000 © TOSHIBA TEC 3 - 3 KK-1600 OPERATIONAL DESCRIPTION
STP cover open
switch
Copier power ON
STP power lamp OFF
STP power lamp ON
Open
Close
STP staple
empty switch
OK?
OK
Load paper into STP.
(STP paper set sensor ON)
STP motor operates
to start stapling.
Stampling stopped
Supply staples
NG
STP 03-04-01
3.4 Flow Chart

October 2000 © TOSHIBA TEC 4 - 1 KK-1600 MECHANICAL DESCRIPTION
4. MECHANICAL DESCRIPTION
4.1 Mechanism Drawing
4.2 Staple Operation
The staple operation of the STP is performed only by the rotation of the STP motor through the combination
of the gears and cams.
The loading of paper is detected when the paper detection lever is pushed. When paper is loaded into the
stapler, the paper detection lever is pushed causing the STP paper set sensor to detect the presence of
paper.
When the presence of paper is detected, if staples are available, the STP motor is operated to drive the
gears and cams to perform staple operation. If no staples are available, the STP does not operate until
staples are supplied. When one time of staple operation is finished, the STP returns to its original state
and stands by until the next presence of paper is detected.
Staples are loaded in the cartridge and its capacity is about 5,000 staples. When the cartridge is supplied
with staples or a new cartridge is installed, perform staple operation without staples (7 to 8 times) to feed
staples to a position where stapling is possible.
STP 04-01-01
STP paper set sensor
Paper set

October 2000 © TOSHIBA TEC 5 - 1 KK-1600 CIRCUIT DESCRIPTION
5. CIRCUIT DESCRIPTION
5.1 PWA Block Diagram
5.2 Functional Description
The STP operates the stapler through the STP controller PWA. When the power of the copier is turned on,
a power supply is also delivered to the STP to enable stapling. When paper is loaded into the stapler, the
STP paper set sensor detects the presence of paper (changing from“High” to“Low”), and 200 ms later the
CW signal turns ON (changing from “Low”to “High”) to operate the STP motor forward. When the motor
operates, the gears and cams of the stapler operate for stapling. When the STP home position sensor
detects the home position of the stapler (changing from “High”to“Low”) after the CW signal is activated, the
CW signal turns OFF.
If the STP home position sensor remains at “High” level (a failure to return to the home position) for some
reason even if a fixed time (approx.900 ms) has elapsed after the CW signal turns ON, the CW signal turns
OFF and 100 ms later the CCW signal is turned ON (changing from “Low” to “High”) to operate the STP
motor reversely. In practice, however, if the STP has locked up mechanically, an overload occurs so that
the fuse installed on the STP CONT PWA will blow or the protective circuit of the AC adapter will function
to cut the delivery of the power supply (shutdown).
If the stapler is not at the home position when the power is turned on (“High” level), about 60 ms later the
CCW signal is turned ON (changing from “Low”to“High”) to operate the motor reversely allowing the stapler
to return to the home position.
STP 05-01-01
24V
J2 J5J4J3
FU1
STP cover open
switch
STP AC adapter
STP LED PWA
STP sensor PWA
STP paper set
sensor
5V
5V
24V
5V
GND
GND
GND
1
2
1
21
2
3
1
5V 3
2
GND 1
GND
CW
PAPER_SENS
STPL_H/P
HOOK_SW
CCW
4
3
2
5
6
7
J1
Q3
switching
regulator
Motor
controll
circuit
Motor drive
circuit
Motor drive
circuit

KK-1600 CIRCUIT DESCRIPTION 5 - 2 October 2000 © TOSHIBA TEC
5.3 Signal Description
The STP cover open switch detects the open or close state of the cover. A microswitch is used for the
switch. A power supply is delivered to the stapler when the cover is closed, and cut off when open.
The STP paper set sensor detects the loading of paper. A photo sensor is used for the switch. The signal
goes LOW when the paper to be stapled is loaded.
The STP home position sensor detects the home position of the stapler. A photo sensor is used for the
sensor. It is mounted on the STP sensor PWA and detects the home position every stapling.
The STP staple empty switch detects the presence or absence of staples. A microswitch is used for the
sensor. When staples have run out or no cartridge is mounted, the signal is detected at “Low”level.
Signal Name
STPCOV
STPPSET
STPHP
STPEMP
Part Name
STP cover open
switch
STP paper set
sensor
STP home
position sensor
STP staple
empty switch
Functional Description
Detects the open/close
state of the cover during
staple replacement, etc.
Detects the loading of the
paper to be stapled.
Detects the home position
of the drive section.
Detects the presence or
absence of staples.
Status
Open: Power off
Low: Paper loaded
Low: Home position
Low: No staples
Note
Microswitch
Photo sensor
Photo sensor
Microswitch

October 2000 © TOSHIBA TEC 5 - 3 KK-1600 CIRCUIT DESCRIPTION
5.4 Timing Charts
• Staple operation
• Staple operation (When staples have run out during operation)
STP paper set sensor
STP staple empty switch
STP home position sensor
CW
CCW
L
H
L
H
L
H
L
H
L
H
200ms 858ms
L
H
L
H
L
H
L
H
L
H
200ms 200ms
STP paper set sensor
STP staple empty switch
STP home position sensor
CW
CCW
No staples

KK-1600 CIRCUIT DESCRIPTION 5 - 4 October 2000 © TOSHIBA TEC
• Reverse operation (When the motor has locked up)
• Reverse operation (When the stapler is not at the home position at power on time)
STP paper set sensor
STP staple empty switch
STP home position sensor
CW
CCW
200ms 900ms
L
H
L
H
L
H
L
H
L
H
100ms
STP paper set sensor
STP staple empty switch
STP home position sensor
CW
CCW
L
H
L
H
L
H
L
H
L
H
L
H
60ms
POWER ON

October 2000 © TOSHIBA TEC 6 - 1 KK-1600 DISASSEMBLY AND REPLACEMENT
6. DISASSEMBLY AND REPLACEMENT
[A] STP cover/STP staple cartridge
1. Pull STP cover to release one hook and open
STP cover.
Fig. 6-1
2. Release 2 hooks and detach STP cover.
Fig. 6-2
[B] STP bottom cover F
1. Removeone screwanddetach connector cover.
Fig. 6-4
STP cover
Hook STP cover
Connector cover
Screw
314-1
314-2
315
3. Release 2 hooks and remove STP staple car-
tridge.
Fig. 6-3 321-1
STP staple cartridge

KK-1600 DISASSEMBLY AND REPLACEMENT 6 - 2 October 2000 © TOSHIBA TEC
4. Release the power cable from the hook of the
manual pocket.
Fig. 6-6
5. Remove 2screws, release2 hooks, andremove
stapler.
Fig. 6-7
6. Remove one screw and detach STP bottom
cover F.
Fig. 6-8
Manual pocket
Power cable
Hook
Stapler
Screw
STP bottom cover F
Screw
316-2
317
318
2. Remove 2 screws and remove connector plate.
3. Release 2 hooks and detach connector.
Fig. 6-5
Connector plate Screw
Hook
316-1

October 2000 © TOSHIBA TEC 6 - 3 KK-1600 DISASSEMBLY AND REPLACEMENT
[C] STP bottom cover R
1. Remove stapler.(See Fig.6-4 to 6-7)
2. Remove 4screws and detachSTP bottomcover
R.
Fig. 6-9
[D] STP staple cover
1. Detach STP cover.(See Fig.6-1 and 6-2)
2. Remove STP staple cartridge.(See Fig.6-3)
3. Remove stapler.(See Fig.6-4 to 6-7)
4. Detach STP bottom cover R. (See Fig. 6-9)
5. Remove one screw, release 5 hooks, and de-
tach STP staple cover.
Fig. 6-10
[E] STP cover open switch
1. Detach STP cover.(See Fig.6-1 and 6-2)
2. Remove STP staple cartridge.(See Fig.6-3)
3. Remove stapler.(See Fig.6-4 to 6-7)
4. Detach STP bottom cover.(See Fig.6-9)
5. Detach STP staple cover.(See Fig.6-10)
6. Detach one connector from STP controller PWA
(J2) and release 3 clamps.
Screw
Screw
STP bottom cover R
STP staple cover
Hook
Hook
319
321-2
Fig. 6-11 321-3
7. Removeone screwandremoveSTPcover open
switch.
Fig. 6-12
321-4
Screw
Clamp
Connector
Clamp
Screw
STP cover open switch
