FILE NO. 033-200318

57WH36P

SERVICE MANUAL

COLOUR TELEVISION

C03P Chassis

Dec., 2003

– SUMMARY –

57WH36P is the same as 42WH36P except for the MECHANICAL DISASSEMBLY and the

parts tabled on back of this sheet.

Use this service manual together with the original service manual of 42WH36P, 51WH36P (File

No. 030-200313).

MECHANICAL DISASSEMBLY(57WH36P)

1 Speaker Grille Removal 2 Control Panel Removal 3 Front Mask Removal

4 Shield Plate, Lens Removal 5 Mirror Removal 6 Back Board Removal

K101

K102

K103

4 screws

K601

4 screws

A160 (CASTER)

A424

A258

A411

A201

A223

A225

K501

K502

4 screws

10 screws

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

– 1 –

Location Parts No. Description Block

No.

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY

PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.

CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com-

ponents which have special characteristics important for safety and should be replaced only with types identical to

those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical

with originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE . Do not

degrade the safety of the receiver through improper servicing.

NOTICE:

•The part number must be used when ordering parts, in order to assist in processing, be sure to include the

Model number and Description.

•The PC board assembly with * mark is no longer available after the end of the production.

ABBREVIATIONS:

Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic

Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film

OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor

(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)

CHASSIS AND CABINET REPLACEMENT PARTS LIST

Models : 57WH36P

CAPACITORS

C101 24796479 ELECTROLYTIC, 35V 4.7UF M

C102 24793221 ELECTROLYTIC, 10V 220UF M

C103 24109102 CERAMIC CHIP, 50V B 1000PF K

C104 24797100 ELECTROLYTIC, 50V 10UF M

C106 24109103 CERAMIC CHIP, 50V B 0.01UF K

C107 24109103 CERAMIC CHIP, 50V B 0.01UF K

C109 24109103 CERAMIC CHIP, 50V B 0.01UF K

C121 24794101 ELECTROLYTIC, 16V 100UF M

C122 24109103 CERAMIC CHIP, 50V B 0.01UF K

C123 24591224 PLASTIC FILM, 50V 0.22UF J

C205 24797229 ELECTROLYTIC, 50V 2.2UF M

C206 24794100 ELECTROLYTIC, 16V 10UF M

C271 24797229 ELECTROLYTIC, 50V 2.2UF M

C301 24503053 PLASTIC FILM, 63V 1UF J

C302 24669010 ELECTROLYTIC, 50V 1UF M 3A

C303 24503053 PLASTIC FILM, 63V 1UF J

C306 24109102 CERAMIC CHIP, 50V B 1000PF K

C308 24109123 CERAMIC CHIP CK73B 50V 12000PF K

C309 24105102 CERAMIC CHIP, 25V CH 1000PF J

C310 24503049 PLASTIC FILM, 63V 0.47UF J

C311 24109103 CERAMIC CHIP, 50V B 0.01UF K

C312 24109332 CERAMIC CHIP, 50V B 3300PF K

C314 24092730 CERAMIC CHIP, 16V B 0.1UF K

C315 24073042 ELECTROLYTIC, 16V 1000UF M 3A

C316 24073042 ELECTROLYTIC, 16V 1000UF M 3A

C317 24669101 ELECTROLYTIC, 50V 100UF M 3A

C320 24073090 ELECTROLYTIC, 50V 100UF M 3A

C321 24073090 ELECTROLYTIC, 50V 100UF M 3A

C323 24109473 CERAMIC CHIP, 25V B 0.047UF K

C324 24073090 ELECTROLYTIC, 50V 100UF M 3A

C325 24503045 PLASTIC FILM, 63V 0.22UF J

C327 24092753 CERAMIC CHIP, 10V B 0.22UF K

C328 24082260 PLASTIC FILM, 100V 4700PF J

C330 24085946 ELECTROLYTIC, NONPOLAR,

16V 10UF M 3A

C332 24073091 ELECTROLYTIC, 50V 220UF M 3A

C333 24693473 PLASTIC FILM, 100V 0.047UF J

C334 24109471 CERAMIC CHIP, 50V B 470PF K

C338 24666330 ELECTROLYTIC, 16V 33UF M 3A

C340 24073036 ELECTROLYTIC, 16V 33UF M 3A

C350 24073057 ELECTROLYTIC, 25V 1000UF M 3A

C362 24109153 CERAMIC CHIP, 50V B 0.015UF K

C370 24073082 ELECTROLYTIC, 50V 2.2UF M 3A

C371 24092730 CERAMIC CHIP, 16V B 0.1UF K

C401 24214332 CERAMIC DISC, 500V B 3300PF K

C402 24214391 CERAMIC DISC, 500V B 390PF K

C403 24073050 ELECTROLYTIC, 25V 22UF M 3A

C405 24503042 PLASTIC FILM, 63V 0.12UF J

C412 24503192 PLASTIC FILM, 400V 0.15UF J

C415 24092478 CERAMIC DISC, 2KV B 470PF K

C416 24676220 ELECTROLYTIC, 100V 22UF M 3A

C417 24503141 PLASTIC FILM, 250V 1.5UF K

C419 24109331 CERAMIC CHIP, 50V B 330PF K

C423 24503142 PLASTIC FILM, 400V 0.27UF J

C425 24503142 PLASTIC FILM, 400V 0.27UF J

C426 24211222 CERAMIC DISC, 2KV B 2200PFK

C432 24567333 PLASTIC FILM, 50V 33000PF J

C440 24503059 PLASTIC FILM, 1800VH 1000PF H

C443 24503099 PLASTIC FILM, 1800VH 4700PF H

C444 24503099 PLASTIC FILM, 1800VH 4700PF H

C445 24828473 PLASTIC FILM, 200V 0.047UF J

C446 24073120

ELECTRPLYTIC, 250V 33UF, 250YXF33M

C448 24073118 ELECTROLYTIC, 160V 33UF M

C449 24214221 CERAMIC DISC, 500V B 220PF K

C460 24073120

ELECTRPLYTIC, 250V 33UF, 250YXF33M

C463 24092730 CERAMIC CHIP, 16V B 0.1UF K

C464 24503343 PLASTIC FILM, 100V 3.3UF K

C467 24820392 PLASTIC FILM, 630V 3900PF J

C468 24820103 PLASTIC FILM, 630V 0.01UF J

C470 24503343 PLASTIC FILM, 100V 3.3UF K

C481 24109103 CERAMIC CHIP, 50V B 0.01UF K

C482 24109822 CERAMIC CHIP, 50V B 8200PF K

C501 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C502 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C503 24794470 ELECTROLYTIC, 16V 47UF M

C504 24109103 CERAMIC CHIP, 50V B 0.01UF K

C505 24794470 ELECTROLYTIC, 16V 47UF M

C506 24109103 CERAMIC CHIP, 50V B 0.01UF K

C507 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C508 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C509 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C511 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C512 24100104 CERAMIC CHIP, 25V F 0.1UF Z

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–2 –

C513 24109103 CERAMIC CHIP, 50V B 0.01UF K

C514 24794470 ELECTROLYTIC, 16V 47UF M

C516 24105110 CERAMIC CHIP, 50V CH 11PF J

C517 24206478 ELECTROLYTIC, 50V 0.47UF M 7L 3A

C519 24797479 ELECTROLYTIC, 50V 4.7UF M

C520 24503047 PLASTIC FILM, 63V 0.33UF J

C521 24092733 CERAMIC CHIP, 50V B 0.022UF K

C522 24109103 CERAMIC CHIP, 50V B 0.01UF K

C523 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C524 24109103 CERAMIC CHIP, 50V B 0.01UF K

C525 24503041 PLASTIC FILM , 63V 0.1UF J

C526 24109103 CERAMIC CHIP, 50V B 0.01UF K

C527 24797229 ELECTROLYTIC, 50V 2.2UF M

C530 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A

C531 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C532 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C533 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C534 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C536 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C537 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C538 24763221 ELECTROLYTIC, 16V 220UF M

C540 24109103 CERAMIC CHIP, 50V B 0.01UF K

C541 24109103 CERAMIC CHIP, 50V B 0.01UF K

C542 24109103 CERAMIC CHIP, 50V B 0.01UF K

C544 24109103 CERAMIC CHIP, 50V B 0.01UF K

C545 24109103 CERAMIC CHIP, 50V B 0.01UF K

C547 24109103 CERAMIC CHIP, 50V B 0.01UF K

C548 24763101 ELECTROLYTIC, 16V 100UF M

C549 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C550 24109103 CERAMIC CHIP, 50V B 0.01UF K

C551 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C552 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C553 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C563 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A

C564 24797229 ELECTROLYTIC, 50V 2.2UF M

C565 24797478 ELECTROLYTIC, 50V 0.47UF M

C575 24092538 CERAMIC CHIP, 10V F 1UF Z

C580 24794470 ELECTROLYTIC, 16V 47UF M

C581 24794470 ELECTROLYTIC, 16V 47UF M

C582 24794470 ELECTROLYTIC, 16V 47UF M

C583 24794470 ELECTROLYTIC, 16V 47UF M

C584 24794101 ELECTROLYTIC, 16V 100UF M

C585 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C586 24794470 ELECTROLYTIC, 16V 47UF M

C587 24794470 ELECTROLYTIC, 16V 47UF M

C601 24669010 ELECTROLYTIC, 50V 1UF M 3A

C602 24669010 ELECTROLYTIC, 50V 1UF M 3A

C603 24591102 PLASTIC FILM, 50V 1000PF J

C604 24591102 PLASTIC FILM, 50V 1000PF J

C605 24669100 ELECTROLYTIC, 50V 10UF M 3A

C606 24669100 ELECTROLYTIC, 50V 10UF M 3A

C607 24667470 ELECTROLYTIC, 25V 47UF M 3A

C608 24667470 ELECTROLYTIC, 25V 47UF M 3A

C609 24668101 ELECTROLYTIC, 35V 100UF M 3A

C610 24669479 ELECTROLYTIC, 50V 4.7UF M 3A

C612 24669102 ELECTROLYTIC, 50V 1000UF M 3A

C613 24503042 PLASTIC FILM, 63V 0.12UF J

C614 24503042 PLASTIC FILM, 63V 0.12UF J

C615 24669102 ELECTROLYTIC, 50V 1000UF M 3A

C616 24669102 ELECTROLYTIC, 50V 1000UF M 3A

C617 24669220 ELECTROLYTIC, 50V 22UF M 3A

C618 24797478 ELECTROLYTIC, 50V 0.47UF M

C619 24794471 ELECTROLYTIC, 16V 470UF M

C621 24797220 ELECTROLYTIC, 50V 22UF M

C622 24591103 PLASTIC FILM, 50V 0.01UF J

C626 24797478 ELECTROLYTIC, 50V 0.47UF M

C627 24797220 ELECTROLYTIC, 50V 22UF M

C628 24797100 ELECTROLYTIC, 50V 10UF M

C629 24591124 PLASTIC FILM, 50V 0.12UF J

C631 24797479 ELECTROLYTIC, 50V 4.7UF M

C633 24795221 ELECTROLYTIC, 25V 220UF M

C634 24797221 ELECTROLYTIC, 50V 220UF M

C636 24797100 ELECTROLYTIC, 50V 10UF M

C660 24765101 ELECTROLYITC, 35V 100UF M

C704 24232103 CERAMIC DISC, 50V F 0.01UF Z

C705 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A

C707 24797470 ELECTROLYTIC, 50V 47UF M

C712 24797470 ELECTROLYTIC, 50V 47UF M

C713 24790470 ELECTROLYTIC, 160V 47UF M

C715 24214472 CERAMIC DISC, 500V B 4700PF K

C717 24214472 CERAMIC DISC, 500V B 4700PF K

C718 24666470 ELECTORLYTIC, 16V 47UF M 3A

C719 24435560 CERAMIC DISC, 500V SL 56PF J

C720 24790100 ELECTROLYTIC, 160V 10UF M

C721 24666470 ELECTORLYTIC, 16V 47UF M 3A

C722 24436820 CERAMIC DISC, 50V SL 82PF J

C726 24212102 CERAMIC DISC, 50V B 1000PF K

C760 24797470 ELECTROLYTIC, 50V 47UF M

C761 24212102 CERAMIC DISC, 50V B 1000PF K

C762 24797470 ELECTROLYTIC, 50V 47UF M

C765 24214472 CERAMIC DISC, 500V B 4700PF K

C766 24214472 CERAMIC DISC, 500V B 4700PF K

C767 24790470 ELECTROLYTIC, 160V 47UF M

C768 24666470 ELECTORLYTIC, 16V 47UF M 3A

C769 24666470 ELECTORLYTIC, 16V 47UF M 3A

C770 24435560 CERAMIC DISC, 500V SL 56PF J

C771 24790100 ELECTROLYTIC, 160V 10UF M

C781 24212102 CERAMIC DISC, 50V B 1000PF K

C782 24797100 ELECTROLYTIC, 50V 10UF M

C784 24214472 CERAMIC DISC, 500V B 4700PF K

C786 24214472 CERAMIC DISC, 500V B 4700PF K

C787 24790470 ELECTROLYTIC, 160V 47UF M

C788 24666470 ELECTORLYTIC, 16V 47UF M 3A

C789 24666470 ELECTORLYTIC, 16V 47UF M 3A

C790 24435560 CERAMIC DISC, 500V SL 56PF J

C791 24790100 ELECTROLYTIC, 160V 10UF M

C792 24232103 CERAMIC DISC, 50V F 0.01UF Z

C813 24667101 ELECTROLYTIC, 25V 100UF M 3A

C890 24669100 ELECTROLYTIC, 50V 10UF M 3A

C892 24669220 ELECTROLYTIC, 50V 22UF M 3A

C893 24669100 ELECTROLYTIC, 50V 10UF M 3A

C894 24669220 ELECTROLYTIC, 50V 22UF M 3A

C895 24669100 ELECTROLYTIC, 50V 10UF M 3A

C896 24669220 ELECTROLYTIC, 50V 22UF M 3A

C901 24211102 CERAMIC DISC, 2KV B 1000PF K

C902 24794100 ELECTROLYTIC, 16V 10UF M

C903 24232103 CERAMIC DISC, 50V F 0.01UF Z

C904 24436471 CERAMIC DISC, 50V SL 470PF J

C906 24679330 ELECTROLYTIC, 250V 33UF M 3A

C907 24214101 CERAMIC DISC, 500V B 100PF K

C911 24211102 CERAMIC DISC, 2KV B 1000PF K

C912 24794100 ELECTROLYTIC, 16V 10UF M

C913 24232103 CERAMIC DISC, 50V F 0.01UF Z

C914 24436471 CERAMIC DISC, 50V SL 470PF J

C915 24679330 ELECTROLYTIC, 250V 33UF M 3A

C917 24214101 CERAMIC DISC, 500V B 100PF K

C921 24211102 CERAMIC DISC, 2KV B 1000PF K

C922 24794100 ELECTROLYTIC, 16V 10UF M

C923 24436471 CERAMIC DISC, 50V SL 470PF J

C924 24232103 CERAMIC DISC, 50V F 0.01UF Z

C925 24679330 ELECTROLYTIC, 250V 33UF M 3A

C926 24214101 CERAMIC DISC, 500V B 100PF K

C961 24794100 ELECTROLYTIC, 16V 10UF M

C962 24794100 ELECTROLYTIC, 16V 10UF M

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–3 –

C2110 24794470 ELECTROLYTIC, 16V 47UF M

C2111 24092730 CERAMIC CHIP, 16V B 0.1UF K

C2112 24092730 CERAMIC CHIP, 16V B 0.1UF K

C2113 24092730 CERAMIC CHIP, 16V B 0.1UF K

C4401 24763221 ELECTROLYTIC, 16V 220UF M

C4402 24109103 CERAMIC CHIP, 50V B 0.01UF K

C4403 24797010 ELECTROLYTIC, 50V 1UF M

C4404 24109103 CERAMIC CHIP, 50V B 0.01UF K

C4405 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C4406 24109103 CERAMIC CHIP, 50V B 0.01UF K

C4410 24109471 CERAMIC CHIP, 50V B 470PF K

C4412 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C4420 24073039 ELECTROLYTIC, 16V 220UF M 3A

C4421 24591103 PLASTIC FILM, 50V 0.01UF J

C4422 24669010 ELECTROLYTIC, 50V 1UF M 3A

C4423 24109103 CERAMIC CHIP, 50V B 0.01UF K

C4425 24085958 ELEC. NONPOLAR, 50V 1UF M

C4430 24794101 ELECTROLYTIC, 16V 100UF M

C4451 24073038 ELECTROLYTIC, 16V 100UF M 3A

C4465 24100104 CERAMIC CHIP, 25V F 0.1UF Z

C4671 24820472 PLASTIC FILM, 630V 4700PF J

C5020 24109103 CERAMIC CHIP, 50V B 0.01UF K

C5030 24763101 ELECTROLYTIC, 16V 100UF M

C5080 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A

C5090 24763101 ELECTROLYTIC, 16V 100UF M

C7701 24567334 PLASTIC FILM, 50V 0.33UF J

C7704 24073053 ELECTROLYTIC, 25V 100UF M 3A

C7705 24073053 ELECTROLYTIC, 25V 100UF M 3A

C7706 24567334 PLASTIC FILM, 50V 0.33UF J

C7721 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7722 24105331 CERAMIC CHIP, 50V CH 330PF J

C7724 24073090 ELECTROLYTIC, 50V 100UF M 3A

C7725 24073090 ELECTROLYTIC, 50V 100UF M 3A

C7726 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7727 24105331 CERAMIC CHIP, 50V CH 330PF J

C7729 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7730 24105331 CERAMIC CHIP, 50V CH 330PF J

C7732 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7733 24105331 CERAMIC CHIP, 50V CH 330PF J

C7735 24073090 ELECTROLYTIC, 50V 100UF M 3A

C7736 24073090 ELECTROLYTIC, 50V 100UF M 3A

C7737 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7738 24105331 CERAMIC CHIP, 50V CH 330PF J

C7740 24105102 CERAMIC CHIP, 25V CH 1000PF J

C7741 24105331 CERAMIC CHIP, 50V CH 330PF J

C7761 24666470 ELECTORLYTIC, 16V 47UF M 3A

C7762 24666470 ELECTORLYTIC, 16V 47UF M 3A

C7765 24667220 ELECTROLYTIC, 25V 22UF M 3A

C7766 24667221 ELECTROLYTIC, 25V 220UF M 3A

C7769 24109103 CERAMIC CHIP, 50V B 0.01UF K

C7774 24092730 CERAMIC CHIP, 16V B 0.1UF K

C7775 24092730 CERAMIC CHIP, 16V B 0.1UF K

C7776 24092730 CERAMIC CHIP, 16V B 0.1UF K

C7777 24092730 CERAMIC CHIP, 16V B 0.1UF K

C7779 24105331 CERAMIC CHIP, 50V CH 330PF J

C7780 24436471 CERAMIC DISC, 50V SL 470PF J

C7783 24436471 CERAMIC DISC, 50V SL 470PF J

C7784 24667220 ELECTROLYTIC, 25V 22UF M 3A

C7785 24503041 PLASTIC FILM , 63V 0.1UF J

C7786 24503041 PLASTIC FILM , 63V 0.1UF J

C7788 24353101 CERAMIC DISC, 50V CH 100PF J

C7789 24591472 PLASTIC FILM, 50V 4700PF J

C7791 24073056 ELECTROLYTIC, 25V 470UF M 3A

C7792 24591472 PLASTIC FILM, 50V 4700PF J

C7793 24567104 PLASTIC FILM, 50V 0.1UF J

C7794 24567104 PLASTIC FILM, 50V 0.1UF J

C7795 24591332 PLASTIC FILM, 50V 3300PF J

C7796 24073091 ELECTROLYTIC, 50V 220UF M 3A

C7797 24073094 ELECTROLYTIC, 50V 1000UF M 3A

C7798 24073091 ELECTROLYTIC, 50V 220UF M 3A

C7810 24105471 CERAMIC CHIP, 50V CH 470PF J

C7811 24105561 CERAMIC CHIP, 50V CH 560PF J

C7815 24591103 PLASTIC FILM, 50V 0.01UF J

C7817 24591102 PLASTIC FILM, 50V 1000PF J

C7818 24591102 PLASTIC FILM, 50V 1000PF J

C7819 24591102 PLASTIC FILM, 50V 1000PF J

C7820 24591102 PLASTIC FILM, 50V 1000PF J

C7821 24669010 ELECTROLYTIC, 50V 1UF M 3A

C7822 24503053 PLASTIC FILM, 63V 1UF J

CA03 24105180 CERAMIC CHIP, 50V CH 18PF J

CA04 24105180 CERAMIC CHIP, 50V CH 18PF J

CA13 24105101 CERAMIC CHIP, 50V CH 100PF J

CA14 24105101 CERAMIC CHIP, 50V CH 100PF J

CA15 24793470 ELECTROLYTIC CE04G 10V 47UF M

CA42 24794101 ELECTROLYTIC, 16V 100UF M

CA43 24109103 CERAMIC CHIP, 50V B 0.01UF K

CA44 24109103 CERAMIC CHIP, 50V B 0.01UF K

CA45 24109103 CERAMIC CHIP, 50V B 0.01UF K

CA68 24794100 ELECTROLYTIC, 16V 10UF M

CA69 24100103 CERAMIC CHIP, 50V F 0.01UF Z

CA71 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CA80 24794470 ELECTROLYTIC, 16V 47UF M

CA81 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CA83 24092538 CERAMIC CHIP, 10V F 1UF Z

CA84 24092538 CERAMIC CHIP, 10V F 1UF Z

CB01 24794470 ELECTROLYTIC, 16V 47UF M

CB04 24092538 CERAMIC CHIP, 10V F 1UF Z

CB05 24109222 CERAMIC CHIP, 50V B 2200PF K

CB06 24105561 CERAMIC CHIP, 50V CH 560PF J

CB07 24109332 CERAMIC CHIP, 50V B 3300PF K

CB40 24092538 CERAMIC CHIP, 10V F 1UF Z

CB41 24109222 CERAMIC CHIP, 50V B 2200PF K

CB42 24105561 CERAMIC CHIP, 50V CH 560PF J

CB43 24109332 CERAMIC CHIP, 50V B 3300PF K

CB90 24100103 CERAMIC CHIP, 50V F 0.01UF Z

CC04 24105220 CERAMIC CHIP, 50V CH 22PF J

CC21 24109102 CERAMIC CHIP, 50V B 1000PF K

CC24 24109103 CERAMIC CHIP, 50V B 0.01UF K

CC25 24109103 CERAMIC CHIP, 50V B 0.01UF K

CC31 24109102 CERAMIC CHIP, 50V B 1000PF K

CC47 24212332 CERAMIC DISC, 50V B 3300PF K

CC48 24212332 CERAMIC DISC, 50V B 3300PF K

CC51 24232103 CERAMIC DISC, 50V F 0.01UF Z

CC52 24232103 CERAMIC DISC, 50V F 0.01UF Z

CC60 24109223 CERAMIC CHIP, 25V B 0.022UF K

CC61 24109223 CERAMIC CHIP, 25V B 0.022UF K

CC62 24109102 CERAMIC CHIP, 50V B 1000PF K

CC63 24109102 CERAMIC CHIP, 50V B 1000PF K

CC64 24109102 CERAMIC CHIP, 50V B 1000PF K

CC65 24109102 CERAMIC CHIP, 50V B 1000PF K

CC66 24109102 CERAMIC CHIP, 50V B 1000PF K

CC67 24109102 CERAMIC CHIP, 50V B 1000PF K

CC68 24109223 CERAMIC CHIP, 25V B 0.022UF K

CC69 24109102 CERAMIC CHIP, 50V B 1000PF K

CC70 24109102 CERAMIC CHIP, 50V B 1000PF K

CC71 24109223 CERAMIC CHIP, 25V B 0.022UF K

CC72 24109102 CERAMIC CHIP, 50V B 1000PF K

CC73 24109102 CERAMIC CHIP, 50V B 1000PF K

CC74 24109102 CERAMIC CHIP, 50V B 1000PF K

CC75 24109102 CERAMIC CHIP, 50V B 1000PF K

CC77 24109102 CERAMIC CHIP, 50V B 1000PF K

CC78 24109102 CERAMIC CHIP, 50V B 1000PF K

CC91 24109103 CERAMIC CHIP, 50V B 0.01UF K

CC92 24109103 CERAMIC CHIP, 50V B 0.01UF K

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–4 –

CF01 24203101 ELECTROLYTIC, 16V 100UF M 7L 3A

CF02 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF03 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF04 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF05 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF06 24201101 ELECTROLYTIC, 6.3V 100UF M 7L 3A

CF08 24092538 CERAMIC CHIP, 10V F 1UF Z

CF09 24109102 CERAMIC CHIP, 50V B 1000PF K

CF10 24092538 CERAMIC CHIP, 10V F 1UF Z

CF11 24109102 CERAMIC CHIP, 50V B 1000PF K

CF12 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF13 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF14 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF15 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF16 24201101 ELECTROLYTIC, 6.3V 100UF M 7L 3A

CF17 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF18 24092538 CERAMIC CHIP, 10V F 1UF Z

CF19 24109102 CERAMIC CHIP, 50V B 1000PF K

CF20 24105220 CERAMIC CHIP, 50V CH 22PF J

CF21 24105220 CERAMIC CHIP, 50V CH 22PF J

CF22 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF23 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF24 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF25 24092538 CERAMIC CHIP, 10V F 1UF Z

CF26 24109102 CERAMIC CHIP, 50V B 1000PF K

CF27 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF28 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF29 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF30 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF31 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF32 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A

CF33 24105330 CERAMIC CHIP, 50V CH 33PF J

CF34 24092538 CERAMIC CHIP, 10V F 1UF Z

CF38 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A

CF39 24109103 CERAMIC CHIP, 50V B 0.01UF K

CF40 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF41 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF42 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF43 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF44 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF45 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF46 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF47 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF48 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF49 24000445 CHIP JUMPER, 1608TYPE

CF50 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A

CF51 24109102 CERAMIC CHIP, 50V B 1000PF K

CF52 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CF55 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CG01 24503056 PLASTIC FILM, AC275V 0.1UF M

CG05 24092553 CERAMIC DISC, AC250V B 470PF K

CG06 24073101

ELECTROLYTIC CE04Q 400V 47UF M 3A

CG07 24503049 PLASTIC FILM, 63V 0.47UF J

CG08 24214471 CERAMIC DISC, 500V B 470PF K

CG10 24667331 ELECTROLYTIC, 25V 330UF M 3A

CG11 24667470 ELECTROLYTIC, 25V 47UF M 3A

CG12 24212681

CAPACIT0R, CERAMIC DISC, 50V B 680PF K

CG13 24092333 CERAMIC DISC, 2KV 100PF K

CG20 24676470 ELECTROLYTIC, 100V 47UF M 3A

CG27 24666222 ELECTROLYTIC, 16V 2200UF M 3A

CG34 24666101 ELECTROLYTIC, 16V 100UF M 3A

CG35 24665470 ELECTROLYTIC, 10V 47UF M 3A

CG62 24214471 CERAMIC DISC, 500V B 470PF K

CG65 24214471 CERAMIC DISC, 500V B 470PF K

CR01 24794470 ELECTROLYTIC, 16V 47UF M

CR02 24109103 CERAMIC CHIP, 50V B 0.01UF K

CR03 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR04 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR05 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR06 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR07 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR08 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR09 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR12 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR13 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CR14 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CS01 24797229 ELECTROLYTIC, 50V 2.2UF M

CS02 24797229 ELECTROLYTIC, 50V 2.2UF M

CS03 24797229 ELECTROLYTIC, 50V 2.2UF M

CS04 24797229 ELECTROLYTIC, 50V 2.2UF M

CS05 24797229 ELECTROLYTIC, 50V 2.2UF M

CS06 24797229 ELECTROLYTIC, 50V 2.2UF M

CS07 24797229 ELECTROLYTIC, 50V 2.2UF M

CS08 24797229 ELECTROLYTIC, 50V 2.2UF M

CS09 24797229 ELECTROLYTIC, 50V 2.2UF M

CS10 24797229 ELECTROLYTIC, 50V 2.2UF M

CS11 24794100 ELECTROLYTIC, 16V 10UF M

CS12 24794100 ELECTROLYTIC, 16V 10UF M

CS13 24794100 ELECTROLYTIC, 16V 10UF M

CS14 24794100 ELECTROLYTIC, 16V 10UF M

CS18 24794100 ELECTROLYTIC, 16V 10UF M

CS19 24794100 ELECTROLYTIC, 16V 10UF M

CS20 24797478 ELECTROLYTIC, 50V 0.47UF M

CS24 24797229 ELECTROLYTIC, 50V 2.2UF M

CS25 24797229 ELECTROLYTIC, 50V 2.2UF M

CS26 24794100 ELECTROLYTIC, 16V 10UF M

CS27 24797479 ELECTROLYTIC, 50V 4.7UF M

CS28 24797479 ELECTROLYTIC, 50V 4.7UF M

CS29 24797479 ELECTROLYTIC, 50V 4.7UF M

CS30 24797479 ELECTROLYTIC, 50V 4.7UF M

CS31 24797479 ELECTROLYTIC, 50V 4.7UF M

CS32 24797479 ELECTROLYTIC, 50V 4.7UF M

CS33 24795470 ELECTROLYTIC, 25V 47UF M

CV02 24092538 CERAMIC CHIP, 10V F 1UF Z

CV03 24092538 CERAMIC CHIP, 10V F 1UF Z

CV04 24092538 CERAMIC CHIP, 10V F 1UF Z

CV06 24092538 CERAMIC CHIP, 10V F 1UF Z

CV07 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV08 24203101 ELECTROLYTIC, 16V 100UF M 7L 3A

CV09 24092538 CERAMIC CHIP, 10V F 1UF Z

CV10 24794100 ELECTROLYTIC, 16V 10UF M

CV12 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV13 24794100 ELECTROLYTIC, 16V 10UF M

CV14 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV15 24092743 CERAMIC CHIP, 10V F 0.47UF Z

CV23 24203101 ELECTROLYTIC, 16V 100UF M 7L 3A

CV24 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV25 24794470 ELECTROLYTIC, 16V 47UF M

CV28 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV35 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV36 24092743 CERAMIC CHIP, 10V F 0.47UF Z

CV39 24794101 ELECTROLYTIC, 16V 100UF M

CV40 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV42 24092538 CERAMIC CHIP, 10V F 1UF Z

CV44 24092743 CERAMIC CHIP, 10V F 0.47UF Z

CV47 24232103 CERAMIC DISC, 50V F 0.01UF Z

CV65 24203101 ELECTROLYTIC, 16V 100UF M 7L 3A

CV66 24203101 ELECTROLYTIC, 16V 100UF M 7L 3A

CV70 24794100 ELECTROLYTIC, 16V 10UF M

CV71 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CV72 24092538 CERAMIC CHIP, 10V F 1UF Z

CV73 24092538 CERAMIC CHIP, 10V F 1UF Z

CV74 24092538 CERAMIC CHIP, 10V F 1UF Z

CV75 24092538 CERAMIC CHIP, 10V F 1UF Z

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–5 –

CV76 24092538 CERAMIC CHIP, 10V F 1UF Z

CV77 24092538 CERAMIC CHIP, 10V F 1UF Z

CY01 24762471 ELECTROLYTIC, 10V 470UF M

CZ01 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CZ02 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ03 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ04 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ05 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ06 24105102 CERAMIC CHIP, 25V CH 1000PF J

CZ07 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ38 24100104 CERAMIC CHIP, 25V F 0.1UF Z

CZ46 24109103 CERAMIC CHIP, 50V B 0.01UF K

CZ47 24109103 CERAMIC CHIP, 50V B 0.01UF K

RESISTORS

R101 24383153 OXIDE METAL FILM, 2W 15K OHM J

R241 24367473 CARBON FILM, 1/6W 47K OHM G

R242 24367153 CARBON FILM, 1/6W 15K OHM G

R243 24367123 CARBON FILM, 1/6W 12K OHM G

R244 24366823 CARBON FILM, 1/6W 82K OHM J

R245 24011104 CHIP, METAL FILM, 1/20W 100K OHM J U901

R245 24366123 CARBON FILM, 1/6W 12K OHM J U904

R246 24366103 CARBON FILM, 1/6W 10K OHM J

R247 24366102 CARBON FILM, 1/6W 1K OHM J

R271 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R272 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

R273 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R274 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R275 24011683 CHIP, METAL FILM, 1/20W 68K OHM J

R276 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R302 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R305 24322828 OXIDE METAL FILM, 1W 0.82 OHM J

R306 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R307 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R308 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R309 24366101 CARBON FILM, 1/6W 100 OHM J

R311 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R312 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R313 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R314 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

R315 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

R317 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

R318 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

R319 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

R321 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R325 24366472 CARBON FILM, 1/6W 4.7K OHM J

R330 24000633 METAL FILM, 1/4W 10K OHM F

R331 24000633 METAL FILM, 1/4W 10K OHM F

R334 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R335 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R336 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R337 24321129 OXIDE METAL FILM, 1/2W 1.2 OHM J

R338 24011183 CHIP, METAL FILM, 1/20W 18K OHM J

R341 24011273 CHIP, METAL FILM, 1/20W 27K OHM J

R343 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R344 24382151 OXIDE METAL FILM, 1W 150 OHM J

R345 24011100 CHIP, METAL FILM, 1/20W 10 OHM J

R346 24382391 OXIDE METAL FILM, 1W 390 OHM J

R348 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R349 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R350 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R355 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R360 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R362 24011683 CHIP, METAL FILM, 1/20W 68K OHM J

R363 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R365 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R370 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R371 24011823 CHIP, METAL FILM, 1/20W 82K OHM J

R372 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R373 24011823 CHIP, METAL FILM, 1/20W 82K OHM J

R374 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R375 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R377 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R379 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R381 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R382 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R383 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

R384 24011683 CHIP, METAL FILM, 1/20W 68K OHM J

R385 24011272 CHIP, 1/20W 2.7K OHM J

R390 24382561 OXIDE METAL FILM, 1W 560 OHM J

R391 24382561 OXIDE METAL FILM, 1W 560 OHM J

R392 24382561 OXIDE METAL FILM, 1W 560 OHM J

R403 24382101 OXIDE METAL FILM, 1W 100 OHM J

R404 24366272 CARBON FILM, 1/6W 2.7K OHM J

R405 24366101 CARBON FILM, 1/6W 100 OHM J

R406 24383102 OXIDE METAL FILM, 2W 1K OHM J

R407 24381100 OXIDE METAL FILM, 1/2W 10 OHM J

R409 24555220 OXIDE METAL FILM, 3W 22 OHM J

R410 24555220 OXIDE METAL FILM, 3W 22 OHM J

R411 24323229 OXIDE METAL FILM, 2W 2.2 OHM J

R412 24383153 OXIDE METAL FILM, 2W 15K OHM J

R413 24366101 CARBON FILM, 1/6W 100 OHM J

R414 24019259 FUSIBLE, 1/4W 27 OHM G

R415 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R416 24383101 OXIDE METAL FILM, 2W 100 OHM J

R417 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R418 24382104 OXIDE METAL FILM, 1W 100K OHM J

R419 24942102 CARBON COMPOSITION, 1/2W 1K OHM J

R420 24366103 CARBON FILM, 1/6W 10K OHM J

R421 24366223 CARBON FILM, 1/6W 22K OHM J

R422 24366223 CARBON FILM, 1/6W 22K OHM J

R423 24942102 CARBON COMPOSITION, 1/2W 1K OHM J

R424 24376104 CARBON FILM, 1/2W 10OK OHM J

R425 24376104 CARBON FILM, 1/2W 10OK OHM J

R431 24383102 OXIDE METAL FILM, 2W 1K OHM J

R432 24376274 CARBON FILM, 1/2W 270K OHM J

R433 24376274 CARBON FILM, 1/2W 270K OHM J

R434 24376274 CARBON FILM, 1/2W 270K OHM J

R435 24366472 CARBON FILM, 1/6W 4.7K OHM J

R436 24366473 CARBON FILM, 1/6W 47K OHM J

R437 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R438 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R439 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R441 24533331 FUSIBLE, 2W 330 OHM J

R443 24988011 METAL FILM, 1/2W 1 OHM J

R444 24322398 OXIDE METAL FILM, 1W 0.39 OHM J

R446 24366103 CARBON FILM, 1/6W 10K OHM J

R447 24382473 OXIDE METAL FILM, 1W 47K OHM J

R448 24366822 CARBON FILM, 1/6W 8.2K OHM J

R449 24366152 CARBON FILM, 1/6W 1.5K OHM J

R466 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R467 24366563 CARBON FILM, 1/6W 56K OHM J

R469 24366101 CARBON FILM, 1/6W 100 OHM J

R470 24366224 CARBON FILM, 1/6W 220K OHM J

R477 24998471 CHIP, 1/16W 470 OHM

R481 24366103 CARBON FILM, 1/6W 10K OHM J

R482 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R490 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R491 24011272 CHIP, 1/20W 2.7K OHM J

R492 24366101 CARBON FILM, 1/6W 100 OHM J

R501 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

R502 24011272 CHIP, 1/20W 2.7K OHM J

R504 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R505 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–6 –

R506 24011273 CHIP, METAL FILM, 1/20W 27K OHM J

R507 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

R508 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

R509 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R511 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R512 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R513 24011103 CHIP, METAL FILM, 1/20W 10K OHM J U901

R513 24366101 CARBON FILM, 1/6W 100 OHM J U904

R514 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R515 24011102 CHIP, METAL FILM, 1/20W 1K OHM J U901

R515 24366103 CARBON FILM, 1/6W 10K OHM J U904

R516 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R517 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R519 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R520 24366681 CARBON FILM, 1/6W 680 OHM J

R533 24000445 CHIP JUMPER, 1608TYPE

R537 24000445 CHIP JUMPER, 1608TYPE

R539 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R541 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

R552 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R554 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R555 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R561 24552181 OXIDE METAL FILM, 1/2W 180 OHM J

R569 24011823 CHIP, METAL FILM, 1/20W 82K OHM J

R571 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R572 24872152 CHIP, METAL FILM, 1/16W 1.5K OHM J

R573 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R574 24872152 CHIP, METAL FILM, 1/16W 1.5K OHM J

R575 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R576 24872152 CHIP, METAL FILM, 1/16W 1.5K OHM J

R601 24011122 CHIP, METAL FILM, 1/20W 1.2K OHM J

R602 24011122 CHIP, METAL FILM, 1/20W 1.2K OHM J

R603 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

R604 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

R605 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

R606 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

R607 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R608 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R609 24366339 CARBON FILM, 1/6W 3.3 OHM J

R610 24366339 CARBON FILM, 1/6W 3.3 OHM J

R611 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R612 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R613 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R614 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R615 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R616 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R617 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R618 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R619 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

R620 24553681 METAL OXIDE FILM, B 1W 680. J

R621 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R622 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

R623 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R624 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R628 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R629 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R630 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

R631 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R632 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R633 24011822 CHIP, METAL FILM, 1/20W 8.2K OHM J

R634 24011822 CHIP, METAL FILM, 1/20W 8.2K OHM J

R635 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R636 24872822 CHIP, METAL FILM, 1/16W 8.2K OHM J

R637 24872822 CHIP, METAL FILM, 1/16W 8.2K OHM J

R641 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R642 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R643 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R644 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R645 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R646 24872822 CHIP, METAL FILM, 1/16W 8.2K OHM J

R647 24872822 CHIP, METAL FILM, 1/16W 8.2K OHM J

R648 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

R660 24552471 OXIDE METAL FILM, 1/2W 470 OHM J

R688 24552391 OXIDE METAL FILM, 1/2W 390 OHM J

R690 24552391 OXIDE METAL FILM, 1/2W 390 OHM J

R702 24552221 OXIDE METAL FILM, 1/2W 220 OHM J

R709 24366563 CARBON FILM, 1/6W 56K OHM J

R713 24366273 CARBON FILM, 1/6W 27K OHM J

R715 24366333 CARBON FILM, 1/6W 33K OHM J

R716 24366273 CARBON FILM, 1/6W 27K OHM J

R717 24366333 CARBON FILM, 1/6W 33K OHM J

R718 24366101 CARBON FILM, 1/6W 100 OHM J

R719 24366100 CARBON FILM, 1/6W 10 OHM J

R720 24366102 CARBON FILM, 1/6W 1K OHM J

R722 24552471 OXIDE METAL FILM, 1/2W 470 OHM J

R723 24366101 CARBON FILM, 1/6W 100 OHM J

R724 24366151 CARBON FILM, 1/6W 150 OHM J

R725 24366152 CARBON FILM, 1/6W 1.5K OHM J

R730 24552100 OXIDE METAL FILM, 1/2W 10 OHM J

R731 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R732 24366470 CARBON FILM, 1/6W 47 OHM J

R733 24366683 CARBON FILM, 1/6W 68K OHM J

R734 24366470 CARBON FILM, 1/6W 47 OHM J

R735 24366683 CARBON FILM, 1/6W 68K OHM J

R736 24553330 OXIDE METAL FILM, 1W 33 OHM J

R737 24366751 CARBON FILM, 1/6W 750 OHM J

R738 24366102 CARBON FILM, 1/6W 1K OHM J

R739 24366751 CARBON FILM, 1/6W 750 OHM J

R740 24553330 OXIDE METAL FILM, 1W 33 OHM J

R741 24322229 OXIDE METAL FILM, 1W 2.2 OHM J

R742 24321229 OXIDE METAL FILM, 1/2W 2.2 OHM J

R743 24554221 OXIDE METAL FILM, 2W 220 OHM J

R744 24366122 CARBON FILM, 1/6W 1.2K OHM J

R745 24366122 CARBON FILM, 1/6W 1.2K OHM J

R761 24366273 CARBON FILM, 1/6W 27K OHM J

R762 24366563 CARBON FILM, 1/6W 56K OHM J

R763 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R764 24366470 CARBON FILM, 1/6W 47 OHM J

R765 24552100 OXIDE METAL FILM, 1/2W 10 OHM J

R766 24366470 CARBON FILM, 1/6W 47 OHM J

R767 24552221 OXIDE METAL FILM, 1/2W 220 OHM J

R768 24366751 CARBON FILM, 1/6W 750 OHM J

R769 24366122 CARBON FILM, 1/6W 1.2K OHM J

R770 24553330 OXIDE METAL FILM, 1W 33 OHM J

R771 24322229 OXIDE METAL FILM, 1W 2.2 OHM J

R772 24366683 CARBON FILM, 1/6W 68K OHM J

R773 24366683 CARBON FILM, 1/6W 68K OHM J

R774 24366751 CARBON FILM, 1/6W 750 OHM J

R775 24366122 CARBON FILM, 1/6W 1.2K OHM J

R776 24553330 OXIDE METAL FILM, 1W 33 OHM J

R777 24321229 OXIDE METAL FILM, 1/2W 2.2 OHM J

R778 24366102 CARBON FILM, 1/6W 1K OHM J

R779 24554221 OXIDE METAL FILM, 2W 220 OHM J

R781 24366273 CARBON FILM, 1/6W 27K OHM J

R782 24366563 CARBON FILM, 1/6W 56K OHM J

R783 24552221 OXIDE METAL FILM, 1/2W 220 OHM J

R784 24552100 OXIDE METAL FILM, 1/2W 10 OHM J

R785 24366470 CARBON FILM, 1/6W 47 OHM J

R786 24366751 CARBON FILM, 1/6W 750 OHM J

R787 24366122 CARBON FILM, 1/6W 1.2K OHM J

R788 24366683 CARBON FILM, 1/6W 68K OHM J

R789 24366683 CARBON FILM, 1/6W 68K OHM J

R790 24366751 CARBON FILM, 1/6W 750 OHM J

R791 24366122 CARBON FILM, 1/6W 1.2K OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–7 –

R792 24366102 CARBON FILM, 1/6W 1K OHM J

R793 24321229 OXIDE METAL FILM, 1/2W 2.2 OHM J

R794 24553330 OXIDE METAL FILM, 1W 33 OHM J

R795 24322229 OXIDE METAL FILM, 1W 2.2 OHM J

R796 24554221 OXIDE METAL FILM, 2W 220 OHM J

R797 24366470 CARBON FILM, 1/6W 47 OHM J

R798 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R799 24553330 OXIDE METAL FILM, 1W 33 OHM J

R901 24366101 CARBON FILM, 1/6W 100 OHM J

R903 24942102 CARBON COMPOSITION, 1/2W 1K OHM J

R905 24366470 CARBON FILM, 1/6W 47 OHM J

R906 24366331 CARBON FILM, 1/6W 330 OHM J

R908 24366470 CARBON FILM, 1/6W 47 OHM J

R909 24366390 CARBON FILM, 1/6W 39 OHM J

R911 24366101 CARBON FILM, 1/6W 100 OHM J

R913 24942102 CARBON COMPOSITION, 1/2W 1K OHM J

R915 24366330 CARBON FILM, 1/6W 33 OHM J

R916 24366331 CARBON FILM, 1/6W 330 OHM J

R918 24366470 CARBON FILM, 1/6W 47 OHM J

R919 24366390 CARBON FILM, 1/6W 39 OHM J

R920 24366153 CARBON FILM, 1/6W 15K OHM J

R921 24366101 CARBON FILM, 1/6W 100 OHM J

R923 24942102 CARBON COMPOSITION, 1/2W 1K OHM J

R925 24366470 CARBON FILM, 1/6W 47 OHM J

R926 24366331 CARBON FILM, 1/6W 330 OHM J

R928 24366470 CARBON FILM, 1/6W 47 OHM J

R929 24366390 CARBON FILM, 1/6W 39 OHM J

R930 24366153 CARBON FILM, 1/6W 15K OHM J

R931 24383153 OXIDE METAL FILM, 2W 15K OHM J

R932 24383153 OXIDE METAL FILM, 2W 15K OHM J

R933 24000874 USE 1W 439J

R934 24321228 OXIDE METAL FILM, 1/2W 0.22 OHM J

R936 24383153 OXIDE METAL FILM, 2W 15K OHM J

R937 24383153 OXIDE METAL FILM, 2W 15K OHM J

R938 24366150 CARBON FILM, 1/6W 15 OHM J

R941 24383153 OXIDE METAL FILM, 2W 15K OHM J

R942 24383153 OXIDE METAL FILM, 2W 15K OHM J

R943 24383153 OXIDE METAL FILM, 2W 15K OHM J

R944 24383153 OXIDE METAL FILM, 2W 15K OHM J

R945 24366150 CARBON FILM, 1/6W 15 OHM J

R948 24366153 CARBON FILM, 1/6W 15K OHM J

R949 24366153 CARBON FILM, 1/6W 15K OHM J

R951 24383153 OXIDE METAL FILM, 2W 15K OHM J

R952 24383153 OXIDE METAL FILM, 2W 15K OHM J

R953 24383153 OXIDE METAL FILM, 2W 15K OHM J

R954 24383153 OXIDE METAL FILM, 2W 15K OHM J

R959 24366150 CARBON FILM, 1/6W 15 OHM J

R961 24366152 CARBON FILM, 1/6W 1.5K OHM J

R962 24366471 CARBON FILM, 1/6W 470 OHM J

R964 24366332 CARBON FILM, 1/6W 3.3K OHM J

R965 24366471 CARBON FILM, 1/6W 470 OHM J

R966 24366331 CARBON FILM, 1/6W 330 OHM J

R967 24366681 CARBON FILM, 1/6W 680 OHM J

R987 24366470 CARBON FILM, 1/6W 47 OHM J

R991 24366153 CARBON FILM, 1/6W 15K OHM J

R992 24366153 CARBON FILM, 1/6W 15K OHM J

R2020 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R2022 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R2060 24366221 CARBON FILM, 1/6W 220 OHM J

R2105 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R2106 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R2107 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R2149 24871681 CHIP, 1/8W 680 OHM J

R2150 24871681 CHIP, 1/8W 680 OHM J

R2151 24871681 CHIP, 1/8W 680 OHM J

R2155 24871102 CHIP, METAL FILM, 1/8W 1K OHM J

R2156 24871102 CHIP, METAL FILM, 1/8W 1K OHM J

R2157 24871102 CHIP, METAL FILM, 1/8W 1K OHM J

R2158 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R2159 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R4151 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

R4152 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R4153 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R4401 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R4402 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

R4403 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

R4404 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

R4405 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R4406 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R4407 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

R4408 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R4409 24871152 CHIP, METAL FILM, 1/8W 1.5K OHM J

R4411 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R4412 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R4414 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R4420 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

R4421 24011330 CHIP, 1/20W 33 OHM J

R4422 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R4423 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

R4427 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

R4428 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

R4430 24381150 OXIDE METAL FILM, 1/2W 15 OHM J

R4431 24366102 CARBON FILM, 1/6W 1K OHM J

R4444 24383102 OXIDE METAL FILM, 2W 1K OHM J

R4451 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R4452 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R4454 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R4455 24011272 CHIP, 1/20W 2.7K OHM J

R4466 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R4467 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R4831 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

R5020 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R5030 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7701 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

R7707 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7708 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7710 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7711 24339189 METAL FILM, 2W 1R8 J

R7712 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7713 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7715 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7716 24339189 METAL FILM, 2W 1R8 J

R7717 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7718 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7720 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7721 24339189 METAL FILM, 2W 1R8 J

R7722 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7723 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7725 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7726 24339189 METAL FILM, 2W 1R8 J

R7727 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7728 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7730 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7731 24339189 METAL FILM, 2W 1R8 J

R7732 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7733 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7735 24384121 OXIDE METAL FILM, 3W 120 OHM J

R7736 24339189 METAL FILM, 2W 1R8 J

R7742 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R7743 24323338 OXIDE METAL FILM, 2W 0.33 OHM J

R7744 24323338 OXIDE METAL FILM, 2W 0.33 OHM J

R7745 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7746 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7747 24011221 CHIP, METAL FILM, 1/20W 220 OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–8 –

R7748 24011221 CHIP, METAL FILM, 1/20W 220 OHM J

R7749 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R7750 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R7751 24011822 CHIP, METAL FILM, 1/20W 8.2K OHM J

R7752 24011822 CHIP, METAL FILM, 1/20W 8.2K OHM J

R7753 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7754 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R7755 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R7756 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R7757 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

R7758 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

R7759 24011272 CHIP, 1/20W 2.7K OHM J

R7760 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R7761 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7762 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R7766 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

R7767 24011153 CHIP, METAL FILM, 1/2OW 15K OHM J

R7775 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

R7776 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R7777 24011474 CHIP, METAL FILM, 1/20W 470K OHM J

R7778 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7779 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

R7786 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7788 24366221 CARBON FILM, 1/6W 220 OHM J

R7793 24011182 CHIP, METAL FILM, 1/20W 1.8K OHM J

R7799 24011684 CHIP, METAL FILM, 1/20W 680K OHM J

R7836 24366472 CARBON FILM, 1/6W 4.7K OHM J

R7837 24366100 CARBON FILM, 1/6W 10 OHM J

R7841 24366101 CARBON FILM, 1/6W 100 OHM J

R7842 24366472 CARBON FILM, 1/6W 4.7K OHM J

R7843 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R7844 24366472 CARBON FILM, 1/6W 4.7K OHM J

R7845 24552331 OXIDE METAL FILM, 1/2W 330 OHM J

R7846 24366103 CARBON FILM, 1/6W 10K OHM J

R7847 24366103 CARBON FILM, 1/6W 10K OHM J

R7848 24366222 CARBON FILM, 1/6W 2.2K OHM J

R7861 24366472 CARBON FILM, 1/6W 4.7K OHM J

R7862 24366222 CARBON FILM, 1/6W 2.2K OHM J

R7864 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7868 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

R7872 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R7880 24011221 CHIP, METAL FILM, 1/20W 220 OHM J

R7881 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7882 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R7883 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

R7890 24011561 CHIP, METAL FILM, 1/20W 560 OHM J

R7891 24011561 CHIP, METAL FILM, 1/20W 560 OHM J

R7904 24000203 METAL FILM, 1/4W 27K OHM F

R7905 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

R7906 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

R7907 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

R7908 24366222 CARBON FILM, 1/6W 2.2K OHM J

R7909 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

R7910 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

R7911 24011561 CHIP, METAL FILM, 1/20W 560 OHM J

R7912 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

R7913 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

R7914 24381182 OXIDE METAL FILM, 1/2W 1.8K OHM J

R7921 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7922 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R7923 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

R9501 24366470 CARBON FILM, 1/6W 47 OHM J

R9503 24366681 CARBON FILM, 1/6W 680 OHM J

R9607 24366470 CARBON FILM, 1/6W 47 OHM J

R9608 24366681 CARBON FILM, 1/6W 680 OHM J

RA02 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA03 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA04 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA05 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA06 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA07 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RA08 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RA09 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA10 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA11 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA12 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA13 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

RA14 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

RA15 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

RA19 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA20 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA21 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA22 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA24 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA26 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA27 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA29 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RA30 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RA31 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA32 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA33 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA35 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA36 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA37 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA41 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA42 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA43 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

RA44 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

RA45 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA50 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA53 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA60 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA61 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA63 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA64 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RA69 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA70 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA71 24366683 CARBON FILM, 1/6W 68K OHM J

RA72 24366223 CARBON FILM, 1/6W 22K OHM J

RA73 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J U901

RA73 24366103 CARBON FILM, 1/6W 10K OHM J U906A

RA74 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA75 24011103 CHIP, METAL FILM, 1/20W 10K OHM J U901

RA75 24366103 CARBON FILM, 1/6W 10K OHM J U906A

RA76 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

RA77 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA78 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

RA79 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

RA80 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

RA82 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA83 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA84 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA85 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA86 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA87 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA88 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

RA89 24011272 CHIP, 1/20W 2.7K OHM J

RA90 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA91 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

RA92 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA93 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA94 24011470 CHIP, METAL FILM, 1/20W 47 OHM J

RA95 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RA96 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

– 9 –

RA97 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RA98 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RA99 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RA100 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RA101 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RA103 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RB01 24366271 CARBON FILM, 1/6W 270 OHM J

RB02 24366471 CARBON FILM, 1/6W 470 OHM J

RB04 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

RB05 24011105 CHIP, METAL FILM, 1/20W 1M OHM J

RB06 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

RB07 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RB08 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RB09 24011103 CHIP, METAL FILM, 1/20W 10K OHM J U901

RB09 24366470 CARBON FILM, 1/6W 47 OHM J U906C

RB10 24011101 CHIP, METAL FILM, 1/20W 100 OHM J U901

RB10 24366101 CARBON FILM, 1/6W 100 OHM J U906A

RB11 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J U901

RB11 24366103 CARBON FILM, 1/6W 10K OHM J U906A

RB12 24366471 CARBON FILM, 1/6W 470 OHM J

RB32 24011105 CHIP, METAL FILM, 1/20W 1M OHM J

RB33 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

RB34 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RB35 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RB46 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RB49 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

RB81 24011122 CHIP, METAL FILM, 1/20W 1.2K OHM J

RB82 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

RB83 24011123 CHIP, METAL FILM, 1/20W 12K OHM J

RB90 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RB91 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RB92 24011181 CHIP, METAL FILM, 1/20W 180 OHM J

RB93 24011181 CHIP, METAL FILM, 1/20W 180 OHM J

RB94 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RB95 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RB96 24011273 CHIP, METAL FILM, 1/20W 27K OHM J

RB97 24011273 CHIP, METAL FILM, 1/20W 27K OHM J

RB98 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RC01 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC02 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC03 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC04 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC05 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC06 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC07 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC08 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RC09 24000445 CHIP JUMPER, 1608TYPE

RC10 24000445 CHIP JUMPER, 1608TYPE

RC60 24366681 CARBON FILM, 1/6W 680 OHM J

RC61 24366681 CARBON FILM, 1/6W 680 OHM J

RF01 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF02 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF03 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF04 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF05 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RF06 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RF07 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF08 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RF09 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RF10 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF11 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF12 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RF13 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RF14 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RF15 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RF16 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RF17 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RF18 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF19 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RF20 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RF21 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF22 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF23 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF24 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF25 24000445 CHIP JUMPER, 1608TYPE

RF26 24011331 CHIP, METAL FILM, 1/20W 330 OHM J

RF27 24105121 CERAMIC CHIP, 50V CH 120PF J

RF28 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF29 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF30 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF31 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF32 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF33 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF34 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF35 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF36 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RF37 24011330 CHIP, 1/20W 33 OHM J

RF38 24011330 CHIP, 1/20W 33 OHM J

RF39 24011330 CHIP, 1/20W 33 OHM J

RF40 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

RF42 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

RF43 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

RF44 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J

RF45 24000445 CHIP JUMPER, 1608TYPE

RF46 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

RF48 24000445 CHIP JUMPER, 1608TYPE

RF51 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF57 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF58 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RF63 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

RF64 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

RF65 24011224 CHIP, METAL FILM, 1/20W 220K OHM J

RF66 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J

RF68 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF69 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF70 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF71 24000445 CHIP JUMPER, 1608TYPE

RF78 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RF79 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF80 24019398 CHIP BLOCK, 1/16W P-8 33 OHM J

RF81 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF82 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF84 24000445 CHIP JUMPER, 1608TYPE

RF93 24000445 CHIP JUMPER, 1608TYPE

RF94 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF95 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RF97 24011330 CHIP, 1/20W 33 OHM J

RF98 24011330 CHIP, 1/20W 33 OHM J

RF99 24011330 CHIP, 1/20W 33 OHM J

RF100 24011330 CHIP, 1/20W 33 OHM J

RF101 24011330 CHIP, 1/20W 33 OHM J

RF102 24011330 CHIP, 1/20W 33 OHM J

RF103 24011330 CHIP, 1/20W 33 OHM J

RF104 24011330 CHIP, 1/20W 33 OHM J

RF105 24011330 CHIP, 1/20W 33 OHM J

RF106 24011330 CHIP, 1/20W 33 OHM J

RF107 24011330 CHIP, 1/20W 33 OHM J

RF108 24011330 CHIP, 1/20W 33 OHM J

RF109 24011330 CHIP, 1/20W 33 OHM J

RF110 24011330 CHIP, 1/20W 33 OHM J

RF111 24011330 CHIP, 1/20W 33 OHM J

RF112 24011330 CHIP, 1/20W 33 OHM J

RF147 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RF148 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–10 –

RG03 24007494 CERAMIC-COVER 1.4W 100. K

RG04 24376154 CARBON FILM, 1/2W 150K OHM J

RG05 24310829 OXIDE METAL FILM, 1/2W 8.2 OHM J

RG11 24366471 CARBON FILM, 1/6W 470 OHM J

RG12 24310279 METAL FILM, 1/2W 2.7 OHM J

RG17 24366103 CARBON FILM, 1/6W 10K OHM J

RG18 24366472 CARBON FILM, 1/6W 4.7K OHM J

RG19 24366103 CARBON FILM, 1/6W 10K OHM J

RG20 24366331 CARBON FILM, 1/6W 330 OHM J

RG21 24310829 OXIDE METAL FILM, 1/2W 8.2 OHM J

RG22 24323229 OXIDE METAL FILM, 2W 2.2 OHM J

RG23 24321228 OXIDE METAL FILM, 1/2W 0.22 OHM J

RG26 24366229 CARBON FILM, 1/6W 2.2 OHM J

RG75 24381182 OXIDE METAL FILM, 1/2W 1.8K OHM J

RR01 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RR02 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RR03 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RR04 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RR05 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RR06 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RR07 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RR08 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RR09 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

RR10 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RR11 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RR12 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

RR13 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RR14 24011392 CHIP, METAL FILM, 1/20W 3.9K OHM J

RR15 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

RR16 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RR17 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS01 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS02 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS03 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS04 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS05 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS06 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS07 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS08 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS09 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS10 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS11 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS12 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS13 24011271 CHIP, METAL FILM, 1/20W 270 OHM J

RS14 24011271 CHIP, METAL FILM, 1/20W 270 OHM J

RS15 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RS16 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RS17 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS18 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS19 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS20 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS21 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RS22 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RS23 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS24 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS25 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS26 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS27 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS28 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS29 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RS30 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RS31 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS32 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS33 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS34 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS37 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS38 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS49 24011271 CHIP, METAL FILM, 1/20W 270 OHM J

RS50 24011271 CHIP, METAL FILM, 1/20W 270 OHM J

RS51 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RS52 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RS53 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS54 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS55 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RS56 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RS58 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS59 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RS61 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS63 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS65 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

RS66 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS67 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS68 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS69 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS70 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RS71 24011393 CHIP, METAL FILM, 1/20W 39K OHM J

RS72 24011393 CHIP, METAL FILM, 1/20W 39K OHM J

RS73 24011563 CHIP, METAL FILM, 1/20W 56K OHM J

RS74 24011563 CHIP, METAL FILM, 1/20W 56K OHM J

RS75 24011223 CHIP, METAL FILM, 1/20W 22K OHM J

RS76 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RS77 24011104 CHIP, METAL FILM, 1/20W 100K OHM J

RV04 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV05 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RV07 24367103 CARBON FILM, 1/6W 10K OHM G

RV08 24367103 CARBON FILM, 1/6W 10K OHM G

RV09 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV10 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV16 24011333 CHIP, METAL FILM, 1/20W 33K OHM J

RV17 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RV18 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV19 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RV20 24367103 CARBON FILM, 1/6W 10K OHM G

RV21 24367392 CARBON FILM, 1/6W 3.9K OHM G

RV23 24552101 OXIDE METAL FILM, 1/2W 100 OHM J

RV25 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV26 24872471 CHIP, METAL FILM, 1/16W 470 OHM J

RV27 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV28 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RV29 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J

RV30 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV31 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV32 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV33 24367392 CARBON FILM, 1/6W 3.9K OHM G

RV34 24367392 CARBON FILM, 1/6W 3.9K OHM G

RV35 24872151 CHIP, 1/16W 150 OHM J

RV36 24872151 CHIP, 1/16W 150 OHM J

RV37 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV38 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV39 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV41 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV42 24011391 CHIP, METAL FILM, 1/20W 390 OHM J

RV43 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RV44 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV45 24366683 CARBON FILM, 1/6W 68K OHM J

RV46 24366750 CARBON FILM, 1/6W 75 OHM J

RV47 24366750 CARBON FILM, 1/6W 75 OHM J

RV48 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RV51 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RV52 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RV53 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RV60 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J

RV61 24552101 OXIDE METAL FILM, 1/2W 100 OHM J

RV62 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–11 –

RV63 24872471 CHIP, METAL FILM, 1/16W 470 OHM J

RV64 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV65 24552101 OXIDE METAL FILM, 1/2W 100 OHM J

RV66 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV67 24872471 CHIP, METAL FILM, 1/16W 470 OHM J

RV68 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RV81 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV85 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV86 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV87 24872750 CHIP, METAL FILM, 1/16W 75 OHM J

RV88 24872151 CHIP, 1/16W 150 OHM J

RV89 24872151 CHIP, 1/16W 150 OHM J

RV94 24011750 CHIP, METAL FILM, 1/20W 75 OHM J

RV95 24011750 CHIP, METAL FILM, 1/20W 75 OHM J

RV96 24011750 CHIP, METAL FILM, 1/20W 75 OHM J

RV281 24367102 CARBON FILM, 1/6W 1K OHM G

RV331 24367102 CARBON FILM, 1/6W 1K OHM G

RV341 24367102 CARBON FILM, 1/6W 1K OHM G

RZ02 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RZ03 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RZ04 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

RZ06 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RZ08 24011102 CHIP, METAL FILM, 1/20W 1K OHM J

RZ09 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RZ11 24011101 CHIP, METAL FILM, 1/20W 100 OHM J

RZ17 24011103 CHIP, METAL FILM, 1/20W 10K OHM J

RZ18 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RZ19 24011473 CHIP, METAL FILM, 1/20W 47K OHM J

RZ20 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J

RZ21 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RZ22 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J

RZ26 24011471 CHIP, METAL FILM, 1/20W 470 OHM J

RZ29 24011681 CHIP, METAL FILM, 1/20W 680 OHM J

COILS & TRANFORMERS

L101 23248296 COIL, CHOKE

L102 23103828 INDUCTOR, BEAD, TEM2121M

L103 23103828 INDUCTOR, BEAD, TEM2121M

L302 23248073 COIL, CHOKE, TLN3299D

L303 23248073 COIL, CHOKE, TLN3299D

L304 23103145 FERRITE CHOKE, TEM2011AA

L310 23289846 COIL, PEAKING, TRF4101AT

L401 23289560 COIL, PEAKING, TRF4560AF

L402 23248345 COIL, CHOKE EI24 120MMH TLN3534AH

L403 23103145 FERRITE CHOKE, TEM2011AA

L406 23248191 COIL, CHOKE, TLN3351AD

L407 23103248 FERRITR CHOKE, TEM2014AA

L408 23103248 FERRITR CHOKE, TEM2014AA

L441 23233056 COIL, LINEARITY TLN2222AG

L462 23231372 DEFLECTION YOKE, TDY707QD

L463 23231372 DEFLECTION YOKE, TDY707QD

L464 23231372 DEFLECTION YOKE, TDY707QD

L472 23102441 MAGNET, CONVERGENCE, MAG1094

L473 23102499 MAGNET, CPM29.1VM MAG-1119

L474 23102441 MAGNET, CONVERGENCE, MAG1094

L501 23289470 COIL, PEAKING, TRF4470AF

L503 23289470 COIL, PEAKING, TRF4470AF

L504 23238714 COIL, PEAKING, TRF4100AJ

L505 23289840 COIL, PEAKING, TRF4100AT

L510 23103852 COIL, FILTER, TEM2028AH

L511 23103852 COIL, FILTER, TEM2028AH

L513 23103845 COIL, TEM2030AY

L514 23103845 COIL, TEM2030AY

L515 23103845 COIL, TEM2030AY

L516 23103845 COIL, TEM2030AY

L531 23103845 COIL, TEM2030AY

L535 23289840 COIL, PEAKING, TRF4100AT

L538 23280022 COIL, PEAKING, TRF4101AZ

L701 23289840 COIL, PEAKING, TRF4100AT

L702 23261974 COIL, FERRITE BEAD, HC5-035

L704 23103145 FERRITE CHOKE, TEM2011AA

L705 23103145 FERRITE CHOKE, TEM2011AA

L764 23103894 FILTER, FERRITE BEAD, TEM2011AW

L765 23103894 FILTER, FERRITE BEAD, TEM2011AW

L766 23261974 COIL, FERRITE BEAD, HC5-035

L769 23237975 COIL, PEAKING, TRF4101AC

L780 23237975 COIL, PEAKING, TRF4101AC

L781 23103145 FERRITE CHOKE, TEM2011AA

L782 23103145 FERRITE CHOKE, TEM2011AA

L783 23261974 COIL, FERRITE BEAD, HC5-035

L901 23237975 COIL, PEAKING, TRF4101AC

L902 23238714 COIL, PEAKING, TRF4100AJ

L903 23289845 COIL, PEAKING, TRF4680AT

L911 23289840 COIL, PEAKING, TRF4100AT

L912 23289845 COIL, PEAKING, TRF4680AT

L913 23238714 COIL, PEAKING, TRF4100AJ

L922 23289845 COIL, PEAKING, TRF4680AT

L923 23238714 COIL, PEAKING, TRF4100AJ

L961 23289840 COIL, PEAKING, TRF4100AT

L4401 23289101 COIL, PEAKING, TRF4101AF

L4420 23289470 COIL, PEAKING, TRF4470AF

L4441 23248326 COIL, CHOKE, TLN3530AH

L7701 23103145 FERRITE CHOKE, TEM2011AA

L7702 23103145 FERRITE CHOKE, TEM2011AA

L7703 23103145 FERRITE CHOKE, TEM2011AA

L7704 23103145 FERRITE CHOKE, TEM2011AA

L7705 23103145 FERRITE CHOKE, TEM2011AA

L7706 23103145 FERRITE CHOKE, TEM2011AA

L7708 23103145 FERRITE CHOKE, TEM2011AA

L7709 23103145 FERRITE CHOKE, TEM2011AA

L7710 23248320 COIL, CHOKE 15X23H 100MMH 2.5A

TLN3441AH

L7711 23248320 COIL, CHOKE 15X23H 100MMH 2.5A

TLN3441AH

L7712 23248031 COIL, CHOKE, TLN3274D

L7713 23248031 COIL, CHOKE, TLN3274D

LA01 23289840 COIL, PEAKING, TRF4100AT

LC01 23103828 INDUCTOR, BEAD, TEM2121M

LC02 23103828 INDUCTOR, BEAD, TEM2121M

LC03 23103828 INDUCTOR, BEAD, TEM2121M

LC04 23103828 INDUCTOR, BEAD, TEM2121M

LC05 23103828 INDUCTOR, BEAD, TEM2121M

LC06 23103828 INDUCTOR, BEAD, TEM2121M

LC07 23238562 COIL, PEAKING, TRF4109AJ

LC08 23238562 COIL, PEAKING, TRF4109AJ

LC09 23103828 INDUCTOR, BEAD, TEM2121M

LC10 23103828 INDUCTOR, BEAD, TEM2121M

LC11 23103845 COIL, TEM2030AY U901

LC11 23103852 COIL, FILTER, TEM2028AH U906B

LC12 23103845 COIL, TEM2030AY U901

LC12 23238562 COIL, PEAKING, TRF4109AJ U906B

LC13 23103828 INDUCTOR, BEAD, TEM2121M

LC15 23103828 INDUCTOR, BEAD, TEM2121M

LC16 23103828 INDUCTOR, BEAD, TEM2121M

LC17 23103828 INDUCTOR, BEAD, TEM2121M

LC18 23103828 INDUCTOR, BEAD, TEM2121M

LC21 23103828 INDUCTOR, BEAD, TEM2121M

LF01 23103827 INDUCTOR, BEAD, TEM2120M

LF02 23103827 INDUCTOR, BEAD, TEM2120M

LF03 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

LF04 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

LF07 23103828 INDUCTOR, BEAD, TEM2121M

LF08 23103828 INDUCTOR, BEAD, TEM2121M

LF10 23289100 COIL, PEAKING, TRF4100AF

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–12 –

LF11 23103827 INDUCTOR, BEAD, TEM2120M

LF20 23103827 INDUCTOR, BEAD, TEM2120M

LF21 23103827 INDUCTOR, BEAD, TEM2120M

LF31 23103828 INDUCTOR, BEAD, TEM2121M

LF32 23103828 INDUCTOR, BEAD, TEM2121M

LF42 23103828 INDUCTOR, BEAD, TEM2121M

LF43 23103828 INDUCTOR, BEAD, TEM2121M

LF45 23103828 INDUCTOR, BEAD, TEM2121M

LF46 23103828 INDUCTOR, BEAD, TEM2121M

LF47 23103828 INDUCTOR, BEAD, TEM2121M

LF48 23103828 INDUCTOR, BEAD, TEM2121M

LF49 23103828 INDUCTOR, BEAD, TEM2121M

LF57 23103828 INDUCTOR, BEAD, TEM2121M

LF60 23103828 INDUCTOR, BEAD, TEM2121M

LF62 23103887 INDUCTOR, CHIP BEAD, TEM2130AM

LF63 23103828 INDUCTOR, BEAD, TEM2121M

LG03 23103880 COIL, CHOKE, TEM2011Y

LG08 23103880 COIL, CHOKE, TEM2011Y

LG09 23103880 COIL, CHOKE, TEM2011Y

LG10 23103880 COIL, CHOKE, TEM2011Y

LG11 23103880 COIL, CHOKE, TEM2011Y

LG24 23280016 COIL, PEAKING, TRF4100AZ

LG25 23289840 COIL, PEAKING, TRF4100AT

LR01 23289840 COIL, PEAKING, TRF4100AT

LV09 23289840 COIL, PEAKING, TRF4100AT

LV10 23289840 COIL, PEAKING, TRF4100AT

LV42 23289840 COIL, PEAKING, TRF4100AT

LV43 23289840 COIL, PEAKING, TRF4100AT

LV46 23103852 COIL, FILTER, TEM2028AH

LZ01 23289840 COIL, PEAKING, TRF4100AT

LZ02 23289840 COIL, PEAKING, TRF4100AT

LZ03 23289840 COIL, PEAKING, TRF4100AT

LZ04 23103827 INDUCTOR, BEAD, TEM2120M

LZ05 23103852 COIL, FILTER, TEM2028AH

T400 23224386 TRANSFORMER, FOCUS, TLN2220AH

T401 23224371

TRANSFORMER, HORIZ DRIVE, TLN1080AH

T461 23236812

TRANSFORMER, FLY-BACK TFB3093AD

T461A 23192961 ANODE CAP ASSY, TCC5605AU

TG01 23217466

TRANSFORMER, CONVERTER TPW3449AM

TG02 23211661 COIL, LINE FILTER, TRF3192

SEMICONDUCTORS

Q201 23314794 TRANSISTOR, 2PC1815Y

Q241 23114756 TRANSISTOR, 2SC2482

Q271 23114499 TRANSISTOR, RN1404

Q272 23114499 TRANSISTOR, RN1404

Q273 23114493 TRANSISTOR, RN2404

Q274 23314993 TRANSISTOR, 2SC4081 Q

Q301 23319787 IC, LA7833S

Q301B 23035308 SCREW, 3X8MM, TAPPING

Q302 23000711 IC, TA1317AN

Q305 23314994 TRANSISTOR, 2SA1576A106

Q306 70119059 IC, OP AMP, TA75902P(J)

Q370 23314993 TRANSISTOR, 2SC4081 Q

Q371 23314994 TRANSISTOR, 2SA1576A106

Q372 23205014 TRANSISTOR, 2SC4667-O

Q381 23205014 TRANSISTOR, 2SC4667-O

Q382 23205014 TRANSISTOR, 2SC4667-O

Q400 23205079 TRANSISTOR, 2SC4686A

Q402 23205166 TRANSISTOR, FET, 2SK2962

Q404 23205149 TRANSISTOR, 2SC5859(FA)

Q404B 23850638 INSULATOR, TRANSISTOR, AC263

Q404D 72471082 SCREW, 3X10MM

Q405 23114425 TRANSISTOR, 2SA1015-Y(TE

Q406 23114433 TRANSISTOR, 2SC1815-Y

Q410 23114433 TRANSISTOR, 2SC1815-Y

Q411 23314993 TRANSISTOR, 2SC4081 Q

Q420 23114756 TRANSISTOR, 2SC2482

Q425 23205031 TRANSISTOR, FET, 2SK2920

Q428 23314993 TRANSISTOR, 2SC4081 Q

Q501 23009178 IC, TB1274AF(J,FP)

Q504 23314994 TRANSISTOR, 2SA1576A106

Q505 23314994 TRANSISTOR, 2SA1576A106

Q506 23314794 TRANSISTOR, 2PC1815Y

Q507 23114501 TRANSISTOR, RN1402

Q510 23009369 IC, TA1360AFG

Q530 23905590 IC, M52055FP

Q535 23314993 TRANSISTOR, 2SC4081 Q

Q537 23314994 TRANSISTOR, 2SA1576A106

Q538 23314994 TRANSISTOR, 2SA1576A106

Q539 23314994 TRANSISTOR, 2SA1576A106

Q601 23009485 IC, TA8258H(GR)

Q601B 23035308 SCREW, 3X8MM, TAPPING

Q611 70114396 TRANSISTOR, 2SC3326B

Q612 70114396 TRANSISTOR, 2SC3326B

Q613 23314993 TRANSISTOR, 2SC4081 Q

Q614 23114499 TRANSISTOR, RN1404

Q615 23314994 TRANSISTOR, 2SA1576A106

Q616 23314994 TRANSISTOR, 2SA1576A106

Q617 23906596 IC, BA4558

Q618 23314993 TRANSISTOR, 2SC4081 Q

Q619 23314993 TRANSISTOR, 2SC4081 Q

Q624 70114396 TRANSISTOR, 2SC3326B

Q625 23114493 TRANSISTOR, RN2404

Q626 23314993 TRANSISTOR, 2SC4081 Q

Q627 23114493 TRANSISTOR, RN2404

Q706 23114433 TRANSISTOR, 2SC1815-Y

Q707 23114437 TRANSISTOR, 2SC752GTM-Y

Q709 23114433 TRANSISTOR, 2SC1815-Y

Q710 23114425 TRANSISTOR, 2SA1015-Y(TE

Q711 23205075 TRANSISTOR, 2SA1930

Q711B 23035308 SCREW, 3X8MM, TAPPING

Q712 23205076 TRANSISTOR, 2SC5171

Q712B 23035308 SCREW, 3X8MM, TAPPING

Q719 23114433 TRANSISTOR, 2SC1815-Y

Q720 23114433 TRANSISTOR, 2SC1815-Y

Q740 23314993 TRANSISTOR, 2SC4081 Q

Q751 23135040 IC, CONVERGENCE OUT STK394-250

Q752 23135040 IC, CONVERGENCE OUT STK394-250

Q760 23114425 TRANSISTOR, 2SA1015-Y(TE

Q761 23205075 TRANSISTOR, 2SA1930

Q761B 23035308 SCREW, 3X8MM, TAPPING

Q769 23114433 TRANSISTOR, 2SC1815-Y

Q771 23205076 TRANSISTOR, 2SC5171

Q771B 23035308 SCREW, 3X8MM, TAPPING

Q772 23319666 IC, TC74HC123AP(NEW)

Q776 23114433 TRANSISTOR, 2SC1815-Y

Q777 23114425 TRANSISTOR, 2SA1015-Y(TE

Q778 23114433 TRANSISTOR, 2SC1815-Y

Q779 23114433 TRANSISTOR, 2SC1815-Y U904

Q779 23114433 TRANSISTOR, 2SC1815-Y U901E

Q780 23114425 TRANSISTOR, 2SA1015-Y(TE

Q781 23114433 TRANSISTOR, 2SC1815-Y U904

Q781 23114433 TRANSISTOR, 2SC1815-Y U901F

Q782 23319894 IC, NJM79M05FA U904

Q782 23114425 TRANSISTOR, 2SA1015-Y(TE U901F

Q783 23205037 TRANSISTOR, 2SJ512 U904

Q783 23114433 TRANSISTOR, 2SC1815-Y U901F

Q783B 23035308 SCREW, 3X8MM, TAPPING

Q784 23904268 IC, PQ05RR1 U904

Q784 23205075 TRANSISTOR, 2SA1930 U901F

Q784B 23035308 SCREW, 3X8MM, TAPPING U904

Q784B 23035308 SCREW, 3X8MM, TAPPING U901F

Q785 23205076 TRANSISTOR, 2SC5171

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–13 –

Q785B 23035308 SCREW, 3X8MM, TAPPING

Q788 23314993 TRANSISTOR, 2SC4081 Q

Q792 23319666 IC, TC74HC123AP(NEW)

Q793 23205031 TRANSISTOR, FET, 2SK2920

Q796 23314993 TRANSISTOR, 2SC4081 Q

Q890 23009549 IC, REGULATOR +9V 3% NJM2396F09D

Q890B 23035308 SCREW, 3X8MM, TAPPING

Q891 23009546 IC, REGULATOR +5V 3% NJM2396F05D

Q891B 23035308 SCREW, 3X8MM, TAPPING

Q892 23009546 IC, REGULATOR +5V 3% NJM2396F05D

Q892B 23035308 SCREW, 3X8MM, TAPPING

Q901 23314971 TRANSISTOR, 2SC5360(FA)

Q901B 23035308 SCREW, 3X8MM, TAPPING

Q902 23114433 TRANSISTOR, 2SC1815-Y

Q911 23314971 TRANSISTOR, 2SC5360(FA)

Q911B 23035308 SCREW, 3X8MM, TAPPING

Q912 23114433 TRANSISTOR, 2SC1815-Y

Q913 23114425 TRANSISTOR, 2SA1015-Y(TE

Q921 23314971 TRANSISTOR, 2SC5360(FA)

Q921B 23035308 SCREW, 3X8MM, TAPPING

Q922 23114433 TRANSISTOR, 2SC1815-Y

Q961 23114433 TRANSISTOR, 2SC1815-Y

Q962 23114425 TRANSISTOR, 2SA1015-Y(TE

Q973 23114425 TRANSISTOR, 2SA1015-Y(TE

Q2104 23314791 TRANSISTOR, 2PA1015Y

Q2105 23314791 TRANSISTOR, 2PA1015Y

Q2106 23314791 TRANSISTOR, 2PA1015Y

Q2107 23314994 TRANSISTOR, 2SA1576A106

Q2108 23314994 TRANSISTOR, 2SA1576A106

Q2109 23314994 TRANSISTOR, 2SA1576A106

Q4420 23000370 IC, TA1318N

Q4430 23114733 TRANSISTOR, 2SC2655-Y

Q4451 23205068 TRANSISTOR, 2SC5343S-Y

Q4452 23114458 TRANSISTOR, RN1206

Q4453 23114458 TRANSISTOR, RN1206

Q4454 23114458 TRANSISTOR, RN1206

Q4465 23314994 TRANSISTOR, 2SA1576A106

Q7761 23314994 TRANSISTOR, 2SA1576A106

Q7762 23314993 TRANSISTOR, 2SC4081 Q

Q7763 23314993 TRANSISTOR, 2SC4081 Q

Q7764 23314994 TRANSISTOR, 2SA1576A106

Q7765 23314994 TRANSISTOR, 2SA1576A106

Q7766 23314993 TRANSISTOR, 2SC4081 Q

QA01 23009445

IC, 8BIT MCU 120K 64PIN CXP750010-310S

QA02 23009332 IC, AT24C256-2.7

QA05 23906367 IC, PST9146NL

QA13 23205112 TRANSISTOR, 2SA1980UF-Y(

QA82 23000592

IC, 2IN-1OUTSW 6DBAMP CLP MM1504XN

QA83 23114499 TRANSISTOR, RN1404

QA84 23205014 TRANSISTOR, 2SC4667-O

QA85 23314994 TRANSISTOR, 2SA1576A106

QB01 23314791 TRANSISTOR, 2PA1015Y

QB04 23314994 TRANSISTOR, 2SA1576A106

QB05 23314993 TRANSISTOR, 2SC4081 Q

QB06 23314994 TRANSISTOR, 2SA1576A106

QB42 23314994 TRANSISTOR, 2SA1576A106

QB43 23314993 TRANSISTOR, 2SC4081 Q

QB81 70114396 TRANSISTOR, 2SC3326B

QB82 70114396 TRANSISTOR, 2SC3326B

QB83 23314994 TRANSISTOR, 2SA1576A106

QB92 23314993 TRANSISTOR, 2SC4081 Q

QB93 23314994 TRANSISTOR, 2SA1576A106

QB94 23314994 TRANSISTOR, 2SA1576A106

QB95 23314994 TRANSISTOR, 2SA1576A106

QB96 23314994 TRANSISTOR, 2SA1576A106

QF01 23009431 IC, SDA6001 B12

QF02 23906770 IC, BA033FP

QF03 23000904

IC, REGULATOR +2.5V TO252-3 BA25BC0FP

QF04 23009595 IC, IC42S16400-7TT/R

QF05 23009114 IC, BD4746G

QF06 23314993 TRANSISTOR, 2SC4081 Q

QF07 70114402 TRANSISTOR, 2SC3437-Y

QF08 23314993 TRANSISTOR, 2SC4081 Q

QF09 23205014 TRANSISTOR, 2SC4667-O

QF10 23314558 TRANSISTOR, 2SA1610, Y34

QF11 23314558 TRANSISTOR, 2SA1610, Y34

QF12 23314558 TRANSISTOR, 2SA1610, Y34

QF13 23009275 IC, ROM 256KX16BIT FLASH ROM

MX29LV400BTC-70

QF14 23009811 IC, ROM 512KX16BIT FLASH WR7

MX29LV800TMC-90WR7

QF15 23314994 TRANSISTOR, 2SA1576A106

QF16 23314993 TRANSISTOR, 2SC4081 Q

QF20 23009635 IC, 4K BIT CMOS EEPROM

AT24C04AN-10SI-2.7

QF21 23114501 TRANSISTOR, RN1402

QF24 23205099 TRANSISTOR, FET VDSS=60V RK7002

QF25 23205099 TRANSISTOR, FET VDSS=60V RK7002

QF27 23314993 TRANSISTOR, 2SC4081 Q

QG01 23135014 IC, HYBRID VDSS=650V STR-G5551

QG01B 23035308 SCREW, 3X8MM, TAPPING

QG36 23314141 TRANSISTOR, 2SC3852

QG36B 23035308 SCREW, 3X8MM, TAPPING

QG37 23314791 TRANSISTOR, 2PA1015Y

QG38 23314794 TRANSISTOR, 2PC1815Y

QR02 23906666 IC, TA1287F(EL)

QR03 23314993 TRANSISTOR, 2SC4081 Q

QR04 23314993 TRANSISTOR, 2SC4081 Q

QR05 23314993 TRANSISTOR, 2SC4081 Q

QR06 23314993 TRANSISTOR, 2SC4081 Q

QR07 23114501 TRANSISTOR, RN1402

QS01 70114396 TRANSISTOR, 2SC3326B

QS02 70114396 TRANSISTOR, 2SC3326B

QS03 23314993 TRANSISTOR, 2SC4081 Q

QS04 23314993 TRANSISTOR, 2SC4081 Q

QS05 70114396 TRANSISTOR, 2SC3326B

QS06 70114396 TRANSISTOR, 2SC3326B

QS07 70114396 TRANSISTOR, 2SC3326B

QS08 70114396 TRANSISTOR, 2SC3326B

QS09 23114493 TRANSISTOR, RN2404

QS14 70114396 TRANSISTOR, 2SC3326B

QS15 70129558 IC, MM1231XF

QS16 23314993 TRANSISTOR, 2SC4081 Q

QV01 23906887 IC, CXA2069Q

QV02 23314993 TRANSISTOR, 2SC4081 Q

QV03 23314993 TRANSISTOR, 2SC4081 Q

QV04 23314993 TRANSISTOR, 2SC4081 Q

QV06 23314994 TRANSISTOR, 2SA1576A106

QV09 23314794 TRANSISTOR, 2PC1815Y

QV12 23314794 TRANSISTOR, 2PC1815Y

QV14 23314794 TRANSISTOR, 2PC1815Y

QV15 23314993 TRANSISTOR, 2SC4081 Q

QV16 70128711 IC, SW 2IN 1OUT 3CIRCUIT ALLCLP

BA7603F

QV17 23318981 IC, MC14053BF

QV21 23314994 TRANSISTOR, 2SA1576A106

QV22 23314993 TRANSISTOR, 2SC4081 Q

QZ01 23009303 IC, CMOS MULTI COMB SOP16

TDA9181T/N1,118

QZ03 23314994 TRANSISTOR, 2SA1576A106

QZ04 23314994 TRANSISTOR, 2SA1576A106

QZ05 23314994 TRANSISTOR, 2SA1576A106

QZ06 23314994 TRANSISTOR, 2SA1576A106

QZ09 23314993 TRANSISTOR, 2SC4081 Q

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–14 –

QZ10 23314994 TRANSISTOR, 2SA1576A106

QZ12 23314993 TRANSISTOR, 2SC4081 Q

D101 23316755 DIODE, ZENER, MTZJ33C

D216 23316688 DIODE, ZENER, MTZJ9.1C

D218 23316688 DIODE, ZENER, MTZJ9.1C

D220 23316688 DIODE, ZENER, MTZJ9.1C

D272 23118041 DIODE, MA111

D301 23357165 DIODE, ZENER, UDZS7.5B

D302 23357366 DIODE, FR105-B5

D304 23316794 DIODE, SC570A

D305 23118822 DIODE, ERB12-02

D306 23118822 DIODE, ERB12-02

D307 23118522 DIODE, ZENER, RD7.5ES-B3

D350 23357366 DIODE, FR105-B5

D370 23316231 DIODE, 1SS355

D401 23118056 DIODE, AG01

D402 23357366 DIODE, FR105-B5

D404 23316254 DIODE, ERC06-15

D406 23115910 DIODE, S5295G

D411 23316731 DIODE, ZENER, MTZJ18B

D412 23118707 DIODE, RP-1H

D413 23118707 DIODE, RP-1H

D414 23357366 DIODE, FR105-B5

D415 23357366 DIODE, FR105-B5

D418 23316755 DIODE, ZENER, MTZJ33C

D419 23316231 DIODE, 1SS355

D421 23357366 DIODE, FR105-B5

D425 23357366 DIODE, FR105-B5

D426 23118499 DIODE, ZENER, RD18ESA B2

D461 23224366 DIODE, FMQ-3GU

D461B 23035308 SCREW, 3X8MM, TAPPING

D502 23118041 DIODE, MA111

D505 23115599 DIODE, 1N4148

D506 23316673 DIODE, ZENER, MTZJ5.6C

D511 23357037 DIODE, ZENER, UDZS5.6B

D514 23357037 DIODE, ZENER, UDZS5.6B

D515 23357037 DIODE, ZENER, UDZS5.6B

D520 23118641 DIODE, ZENER, RD2.0ESA B2

D601 23316231 DIODE, 1SS355

D602 23316231 DIODE, 1SS355

D603 23316231 DIODE, 1SS355

D604 23316231 DIODE, 1SS355

D605 23316231 DIODE, 1SS355

D606 23316231 DIODE, 1SS355

D607 23316231 DIODE, 1SS355

D608 23316231 DIODE, 1SS355

D609 23316231 DIODE, 1SS355

D610 23316231 DIODE, 1SS355

D611 23316231 DIODE, 1SS355

D612 23316231 DIODE, 1SS355

D613 23316231 DIODE, 1SS355

D614 23316231 DIODE, 1SS355

D628 23316739 DIODE, ZENER, MTZJ22C

D660 23316719 DIODE, ZENER, MTZJ12B

D704 23115599 DIODE, 1N4148

D705 23115599 DIODE, 1N4148

D715 23115599 DIODE, 1N4148

D721 23115599 DIODE, 1N4148

D761 23115599 DIODE, 1N4148

D762 23115599 DIODE, 1N4148

D763 23115599 DIODE, 1N4148

D764 23115599 DIODE, 1N4148

D781 23115599 DIODE, 1N4148

D782 23115599 DIODE, 1N4148

D783 23115599 DIODE, 1N4148

D784 23115599 DIODE, 1N4148

D890 23357365 DIODE, 1N4004A-B5

D891 23357365 DIODE, 1N4004A-B5

D892 23357365 DIODE, 1N4004A-B5

D896 23357365 DIODE, 1N4004A-B5

D901 23115599 DIODE, 1N4148

D902 23115599 DIODE, 1N4148

D911 23115599 DIODE, 1N4148

D912 23115599 DIODE, 1N4148

D921 23115599 DIODE, 1N4148

D922 23115599 DIODE, 1N4148

D931 23115599 DIODE, 1N4148

D932 23115599 DIODE, 1N4148

D933 23115599 DIODE, 1N4148

D934 23115599 DIODE, 1N4148

D936 23115337 DIODE, 1S1834

D941 23115599 DIODE, 1N4148

D942 23115599 DIODE, 1N4148

D943 23115599 DIODE, 1N4148

D945 23115337 DIODE, 1S1834

D946 23115599 DIODE, 1N4148

D963 23115599 DIODE, 1N4148

D964 23115599 DIODE, 1N4148

D965 23115599 DIODE, 1N4148

D966 23115599 DIODE, 1N4148

D967 23115337 DIODE, 1S1834

D4401 23316231 DIODE, 1SS355

D4402 23316231 DIODE, 1SS355

D4430 23115532 DIODE, ERB12-01

D4431 23316715 DIODE, ZENER, MTZJ11A

D4451 23115532 DIODE, ERB12-01

D4452 23357170 DIODE, ZENER, UDZS8.2B

D4453 23316231 DIODE, 1SS355

D7703 23316231 DIODE, 1SS355

D7705 23316231 DIODE, 1SS355

D7706 23316231 DIODE, 1SS355

D7707 23316231 DIODE, 1SS355

D7708 23316231 DIODE, 1SS355

D7717 23316675 DIODE, ZENER, MTZJ6.2B

D7718 23316675 DIODE, ZENER, MTZJ6.2B

D7729 23316738 DIODE, ZENER, MTZJ22B

D7730 23316675 DIODE, ZENER, MTZJ6.2B

D7731 23316675 DIODE, ZENER, MTZJ6.2B

D7733 23316731 DIODE, ZENER, MTZJ18B

D7734 23316731 DIODE, ZENER, MTZJ18B

D7735 23115532 DIODE, ERB12-01

D776 23118859 DIODE, 1SS133

D7761 23316684 DIODE, ZENER, MTZJ8.2B

D7762 23316684 DIODE, ZENER, MTZJ8.2B

D7763 23316231 DIODE, 1SS355

D7764 23316231 DIODE, 1SS355

D7766 23316231 DIODE, 1SS355

D7806 23316231 DIODE, 1SS355

D7808 23316714 DIODE, RL2Z

D7809 23316231 DIODE, 1SS355

D7810 23316402 DIODE, RL4Z

D7811 23316231 DIODE, 1SS355

DA02 23316231 DIODE, 1SS355

DA03 23316231 DIODE, 1SS355

DA42 23316673 DIODE, ZENER, MTZJ5.6C

DA50 23316673 DIODE, ZENER, MTZJ5.6C

DB01 23358564 DIODE, LED, SLR-56VC3FPQ

DB02 23358563 DIODE, LED, SLR-56MC3FPQR

DG02 23316711 DIODE, S1WBA60

DG03 23357366 DIODE, FR105-B5

DG10 23357366 DIODE, FR105-B5

DG11 23316746 DIODE, ZENER, MTZJ27B

DG12 23316672 DIODE, ZENER, MTZJ5.6B

DG13 23316746 DIODE, ZENER, MTZJ27B

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–15 –

DG21 23118057 DIODE, AG01A

DG25 23118052 DIODE, RU4Z LF-L1

DG27 23316673 DIODE, ZENER, MTZJ5.6C

DR01 23316231 DIODE, 1SS355

DR02 23316231 DIODE, 1SS355

DR03 23316231 DIODE, 1SS355

DR04 23316231 DIODE, 1SS355

DR05 23316231 DIODE, 1SS355

DR12 23357172 DIODE, ZENER, UDZS10B

DR13 23357172 DIODE, ZENER, UDZS10B

DR14 23357172 DIODE, ZENER, UDZS10B

DR70 23357037 DIODE, ZENER, UDZS5.6B

DR71 23357037 DIODE, ZENER, UDZS5.6B

DS01 23357172 DIODE, ZENER, UDZS10B

DS02 23357172 DIODE, ZENER, UDZS10B

DS03 23357172 DIODE, ZENER, UDZS10B

DS04 23357172 DIODE, ZENER, UDZS10B

DS11 23118041 DIODE, MA111

DS13 23316231 DIODE, 1SS355

DS14 23316231 DIODE, 1SS355

DV02 23357172 DIODE, ZENER, UDZS10B

DV04 23357172 DIODE, ZENER, UDZS10B

DV05 23357172 DIODE, ZENER, UDZS10B

DV06 23357172 DIODE, ZENER, UDZS10B

DV07 23357172 DIODE, ZENER, UDZS10B

DV08 23357172 DIODE, ZENER, UDZS10B

DV09 23357172 DIODE, ZENER, UDZS10B

DV11 23357172 DIODE, ZENER, UDZS10B

DV12 23357172 DIODE, ZENER, UDZS10B

DV14 23357171 DIODE, ZENER, UDZSTE-17 9.1B

DV15 23357172 DIODE, ZENER, UDZS10B

DV16 23357037 DIODE, ZENER, UDZS5.6B

DV17 23357037 DIODE, ZENER, UDZS5.6B

DV18 23357037 DIODE, ZENER, UDZS5.6B

DV19 23357037 DIODE, ZENER, UDZS5.6B

DV20 23357037 DIODE, ZENER, UDZS5.6B

DV21 23357037 DIODE, ZENER, UDZS5.6B

DV22 23357172 DIODE, ZENER, UDZS10B

MISCELLANEOUS

B109 23037312 SCREW

B224 23035412 SCREW

B230 23037312 SCREW

B231 23845856 WIRE CLAMP, POF COAT) L=70MM

B233 23035412 SCREW

B236 23037312 SCREW

B237 23037312 SCREW

B238 23035412 SCREW

BB21A 23713013 CONNECTOR, SOCKET, B-B 16P 1.5

BB21B 23713014 CONNECTOR, BRIDGE PLUG 16P 1.5

BB22A 23713013 CONNECTOR, SOCKET, B-B 16P 1.5

BB22B 23713014 CONNECTOR, BRIDGE PLUG 16P 1.5

BB23A 23713013 CONNECTOR, SOCKET, B-B 16P 1.5

BB23B 23713014 CONNECTOR, BRIDGE PLUG 16P 1.5

BB24A 23903022 CONNECTOR, BASE B-B 8P 2.5 JST

BB24B 23903022 CONNECTOR, BASE B-B 8P 2.5 JST

BB24C 23368627 CONNECTOR, BRIDGE B-B 8P 2.5JST

08TM-2.5FJ-E

BB80B 23713014 CONNECTOR, BRIDGE PLUG 16P 1.5

BB82B 23713014 CONNECTOR, BRIDGE PLUG 16P 1.5

BB83A 23903022 CONNECTOR, BASE B-B 8P 2.5 JST

BB83B 23903022 CONNECTOR, BASE B-B 8P 2.5 JST

BB83C 23368627 CONNECTOR, BRIDGE B-B 8P 2.5JST

08TM-2.5FJ-E

BB85B 23903022 CONNECTOR, BASE B-B 8P 2.5 JST

BB85C 23368627 CONNECTOR, BRIDGE B-B 8P 2.5JST

08TM-2.5FJ-E

E921 23964147 COOLANT, COOLANT

E929 23969684 TAPE, GLASS-CLOTH, W/ADHESIVE

W=90 T=0.18

E951 23964147 COOLANT, COOLANT

E959 23969684 TAPE, GLASS-CLOTH, W/ADHESIVE

W=90 T=0.18

E981 23964147 COOLANT, COOLANT

E989 23969684 TAPE, GLASS-CLOTH, W/ADHESIVE

W=90 T=0.18

GA01 23103828 INDUCTOR, BEAD, TEM2121M

GA02 23103828 INDUCTOR, BEAD, TEM2121M

GA06 23103828 INDUCTOR, BEAD, TEM2121M

GA07 23103828 INDUCTOR, BEAD, TEM2121M

GA08 23103828 INDUCTOR, BEAD, TEM2121M

GA10 23103828 INDUCTOR, BEAD, TEM2121M

GA21 23103828 INDUCTOR, BEAD, TEM2121M

GA22 23103828 INDUCTOR, BEAD, TEM2121M

GC01 24000445 CHIP JUMPER, 1608TYPE

GC02 24000445 CHIP JUMPER, 1608TYPE

GC03 24000445 CHIP JUMPER, 1608TYPE

GC04 24000445 CHIP JUMPER, 1608TYPE

GC20 24000445 CHIP JUMPER, 1608TYPE

GJ07 24000445 CHIP JUMPER, 1608TYPE

GJ12 24000445 CHIP JUMPER, 1608TYPE

GJ44 24000445 CHIP JUMPER, 1608TYPE

GJ46 24000445 CHIP JUMPER, 1608TYPE

GJ47 24000445 CHIP JUMPER, 1608TYPE

GJ48 24000445 CHIP JUMPER, 1608TYPE

GJ49 24000445 CHIP JUMPER, 1608TYPE

GJ50 24000445 CHIP JUMPER, 1608TYPE

GJ105 24000445 CHIP JUMPER, 1608TYPE

GL01 23103859 FILTER, FERRITE CHOKE, TEM2011

GL02 23103859 FILTER, FERRITE CHOKE, TEM2011

GJ601 24000445 CHIP JUMPER, 1608TYPE

GJ603 24000445 CHIP JUMPER, 1608TYPE

GJ604 24000445 CHIP JUMPER, 1608TYPE

GJ701 24000445 CHIP JUMPER, 1608TYPE

GJ702 24000445 CHIP JUMPER, 1608TYPE

GJ703 24000445 CHIP JUMPER, 1608TYPE

GJ704 24000445 CHIP JUMPER, 1608TYPE

GJ710 24000445 CHIP JUMPER, 1608TYPE

GR05 24000445 CHIP JUMPER, 1608TYPE

GR07 24000445 CHIP JUMPER, 1608TYPE

GR401 24000445 CHIP JUMPER, 1608TYPE

GR501 24000445 CHIP JUMPER, 1608TYPE

GR502 24000445 CHIP JUMPER, 1608TYPE

GR503 24000445 CHIP JUMPER, 1608TYPE

GV03 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV04 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV06 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV08 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV09 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV35 24011101 CHIP, METAL FILM, 1/20W 100 OH

GV42 24011331 CHIP, METAL FILM, 1/20W 330 OH

H002 23148745 MODULE, NICAM/IGR A-PRO MPSN11C

JP237 24000445 CHIP JUMPER, 1608TYPE

KB01 23000852 IC, REMOTE PHOTO RECEIVER,

PIC-37043TE2

P605A 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

P605B 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

P661 23365444 EARPONE JACK, D3.5 HOSIDEN

P708 23902655 CONNECTOR, B-B 15P

P708A 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

– 16 –

P708B 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

P709 23902655 CONNECTOR, B-B 15P

P709A 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

P709B 23368580 CONNECTOR, PLUG 6P,

2.5MM G JST-EH B6B-EH-F1-TV4

P801 23372151 POWER CORD, AC250V3A L/FUSE13A

GB13F1 FUSE13A(UK)

P801 23372052 POWER CORD, 250V2.5A

P915A 23367072 CONNECTOR, PLUG,

NP 2.5MM G JST-EH, B12B-EH-F1A

P915B 23367072 CONNECTOR, PLUG,

NP 2.5MM G JST-EH, B12B-EH-F1A

P916A 23367071 CONNECTOR, PLUG,

NP 2.5MM G JST-EH, B11B-EH-F1A

P916B 23367071 CONNECTOR, PLUG,

NP 2.5MM G JST-EH, B11B-EH-F1A

PB12B 23368584 CONNECTOR, PLUG,

3P2.5MM W EH-JST S3B-EH

PF01 23903176 SOCKET, 60P TKD, 136901160W4

PH01 23165461

TERMINAL, DOUBLE ISA07-SA ISA07-SA

PH02 23165460 TERMINAL, SINGLE ISA01-A

S801 23344482 SWITCH, ESB92S NAE ESB92S28B

SA01 23145226 SWITCH, 1C1P, PUSH

SA02 23145226 SWITCH, 1C1P, PUSH

SA03 23145226 SWITCH, 1C1P, PUSH

SA04 23145226 SWITCH, 1C1P, PUSH

SA06 23145226 SWITCH, 1C1P, PUSH

V901A 23903148

SOCKET, ISH-44S-E ICE #5 ISH-44S-E #5

V902A 23903148

SOCKET, ISH-44S-E ICE #5 ISH-44S-E #5

V903A 23903148

SOCKET, ISH-44S-E ICE #5 ISH-44S-E #5

W661 23351183 SPEAKER, SPK1424AM,

160X160 8-OHM 20W

W662 23351183 SPEAKER, SPK1424AM,

160X160 8-OHM 20W

X501 23153438 CRYSTAL, 16.200 25PPM 25OHM

X4402 23153721 CERAMIC RESONATOR, 503KHZ

X4420 23153721 CERAMIC RESONATOR, 503KHZ

XA03 23153394 CRYSTAL

XF01 23153552 CRYSTAL RESONATOR, 6MHZ 50PPM

CRYSTAL

Z401 23140203 SPARK GAP, 2.0-3.0KV C-010,

AG20PC152F-L3N

Z410 23110841 FOCUS PACK, TPA6030

Z410A 23505177 CABLE, FOCUS

Z450 24083014

COMPOSITE PARTS,CR-BLOCK TPA5011AH

Z711 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z716 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z721 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z726 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z731 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z736 23144540 PROTECTOR, 491SERIES, 125V 2.5A

Z800 23103839 FERRITE CORE, TFE1012

Z802 23103839 FERRITE CORE, TFE1012

Z803 23103839 FERRITE CORE, TFE1012

ZC01Z 23148062 MODULE, D-CONVER MDCE11-S42W

MDCE11-S42W

ZG01 23144450 PROTECTOR, PRF2000, 125V, 2.0A

ZY01 23148026 MODULE, SCAN CONVERTER, MDFS11

PC BOARD ASSEMBLIES

∗U104 23761774 PC BOARD ASSY, TEXT 42WH36P PU

PD1670A

∗U901A 23788452 PC BOARD ASSY, CRT-R 42WH36 PU

PD1102A1

∗U901B 23788453 PC BOARD ASSY, CRT-G 42WH36 PU

PD1102A2

∗U901C 23788454 PC BOARD ASSY, CRT-B 42WH36 PU

PD1102A3

∗U901D 23788455 PC BOARD ASSY, SVM-G 42WH36 PU

PD1102A4

∗U901E 23788456 PC BOARD ASSY, SVM-R 42WH36 PU

PD1102A5

∗U901F 23788457 PC BOARD ASSY, SVM-B 42WH36 PU

PD1102A6

∗U902 23761090 PC BOARD ASSY, SIGNAL PU PD1098E

∗U903 23708765 PC BOARD ASSY, POWER PU PD0768B

∗U904 23788448

PC BOARD ASSY, DEFCONV PU PD1099A

∗U905 23788451 PC BOARD ASSY, EPGPOWER 42WH36

PU PD1101

∗U906A 23788749 PC BOARD ASSY, FRONT-CON 51WH3

PU PD1261A1

∗U906B 23788750 PC BOARD ASSY, FRONT-IN 51WH36

PU PD1261A2

∗U906C 23788751 PC BOARD ASSY, REM 51WH36P

PU PD1261A3

PICTURE TUBE

V911R 23587085 SERVICE KIT, SERVICE KIT CRT-R

57WH36P

V912B 23587086 SERVICE KIT, SERVICE KIT CRT-B

57WH36P

V913G 23587038 SERVICE KIT, SERVICE KIT CRT-G

51WH36P

TUNER

H001 23321398 TUNER, TADF4-003A, EURO IF ALPS

ACCESSORIES

Y101A 23565918 OWNER’S MANUAL, ENGLISH O/M ENG

42WH36P

Y101E 23565919 OWNERS MANUAL, EURO, 42WH36P

K902 23306434 REMOCON HAND UNIT IR,

CTVPAL CT-90100

CABINET PARTS

A001 23072700

OTHER BLOCK, WOOD CABINET 57WH36P

A004 23530761 BACK COVER ASSY, 57HX83 57HX83

A125 23560038 LABEL, ATTENTION SERVICE 48PJ6DB

A160 23437802 CASTER, CASTOR ASSEMBLY DIP35

3787DB;CASTOR ASSY

A201 23530782 COVER, BEZEL 57H83 57H83

A213 23428217 DOOR, DOOR 51WH36P 51WH36P

A215 23929911

PIECE, SNAP-IN GEAR DAMPER CONNON

A223 23445739 BUTTON, POWER BUTTON 51WH36P

A225 23450681 PANEL, CONTROL PANEL 51WH36P

51WH36P

A258 23527315 GRILLE, SPEAKER GRILLE 57WH36P

57WH36P

A260 23929899 PIECE, POLE BOTTOM LEFT 57H83

A262 23929900 PIECE, POLE BOTTOM RIGHT 57H83

A268 23532421 COVER, FRONT PANEL(COVER)

51WH36P;B035208E

A424 23411914

CABINET, VENTED BACK BOARD 51WH36P

A505 72471068 SCREW, 4X12

A508 23035412 SCREW

A529 23037312 SCREW

A543 72471068 SCREW, 4X12

A547 23035010 SCREW, PBI 4X16

A701 23067417 CARTON, TOP 57WH36P 57WH36P

A702 23946626

PACKING, BOTTOM 57WH36P 57WH36P

A703 23946625 PACKING, TOP 57WH36P 57WH36P

SPECIFIC INFORMATIONS

Location Parts No. Description Block

No.

Location Parts No. Description Block

No.

–17 –

A726 23974753 POLYPROPYLENE BAND, 3327DB

A727 23974753 POLYPROPYLENE BAND, 3327DB

K501 23311013 SCREEN, 57KNH LENTICULAR SHEET

SCREEN57KNHL

K502 23311014 SCREEN, 57KN FRESNEL SHEET

SCREEN57KN-F

K601 23405089 MIRROR, MIRROR 57W 57WH18P

TOSHIBA CORPORATION

1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN

Table of contents

Other Toshiba TV manuals

Toshiba

Toshiba 50HM67 - 50" Rear Projection TV User manual

Toshiba

Toshiba 32HFX72 User manual

Toshiba

Toshiba 32Z17B User manual

Toshiba

Toshiba CV32F68 User manual

Toshiba

Toshiba 32XV635D User manual

Toshiba

Toshiba CN32G90 User manual

Toshiba

Toshiba 43UA3A Series User manual

Toshiba

Toshiba 62HM85 User manual

Toshiba

Toshiba MW27FN1/R User manual

Toshiba

Toshiba 17HLV85 User manual

Toshiba

Toshiba 13A20 User manual

Toshiba

Toshiba 50L5200U User manual

Toshiba

Toshiba 32W153xDx User manual

Toshiba

Toshiba 36AF12 User manual

Toshiba

Toshiba CF35E50 User manual

Toshiba

Toshiba 2857 DB User manual

Toshiba

Toshiba 20AS24 User manual

Toshiba

Toshiba 43VJ22P User manual

Toshiba

Toshiba Regza XV55 Series User manual

Toshiba

Toshiba 50L711U18 User manual

Toshiba

Toshiba 20A44 User manual

Toshiba

Toshiba 40S3653DB User manual

Toshiba

Toshiba 21CSZ2R1 User manual

Toshiba

Toshiba 27AF46C User manual

Popular TV manuals by other brands

Sony

Sony XBR-100Z9D reference guide

Grundig

Grundig T 55-830 text manual

Zenith

Zenith A50M84WOM Operating guide and warranty

Panasonic

Panasonic TX-25XDP3 operating instructions

Philips

Philips TPM16.1L Service manual

Sony

Sony M91 operating instructions

Sony

Sony TRINITRON KV-PG14P70 Service manual

Philips

Philips 55HFL2879T/12 user manual

LG RT-29FA65VE Service manual

Grundig

Grundig CUC 2121 M Service manual

Sharp

Sharp LC-20B2UA Service manual

Philips

Philips 32RF52S Quick use and setup guide

Apex Digital

Apex Digital AT2408S, AT2708S instruction manual

Sony

Sony Bravia KD-75X80K reference guide

Panasonic

Panasonic TX-21GV1 Service manual

Samsung

Samsung QE55S95BATXXN E-manual

Philips

Philips 29PT9113 - annexe 1 user manual

Panasonic

Panasonic TX-P54Z11E operating instructions

Toshiba 57WH36P User manual

Popular TV manuals by other brands
