Toslon TF740 User manual

1
Preface
As Yachting Electronic Co., Ltd is continuously improving this product, we retain the
right to make changes to the product at any time which may not be reected in this
version of the manual. Please contact your dealer if you require any further assistance.
It is the owner’s sole responsibility to install and use the instrument and transducers in a
manner that will not cause accidents, personal injury or property damage. The user of
this product is solely responsible for observing safe boating practices.
Sonar Performance
The accuracy of the sonar depth display can be aected by many factors, including the
type and location of the transducer and water conditions.
The choice, location, and installation of transducers are critical to the performance of
the system as intended. If in doubt, consult your local dealer.
To reduce the risk of misusing or misinterpreting this unit, you must read and under-
stand all aspects of this Installation and Operation Manual. We also recommend that
you practice all operations using the built-in simulator before using this unit on the
water.
Global Positioning System:
The Global Positioning System (GPS) is operated by the US Government which is solely
responsible for its operation, accuracy and maintenance. The GPS is subject to changes
which could aect the accuracy and performance of all GPS equipment anywhere in
the world, including this instrument.
Warnning: disassembly and repair of this electronic unit should only be performed
by authorized service personnel. Any modication of the serial number or attempt to
repair the original equipment or accessories by authorized individuals will void the
warranty.
We may nd it necessary to change or end our policies, regulations and special
oers at any time. We reserve the right to do so without notice. All features and
specications subject to change without notice.

2
Contents
Overview
Check the Content
Installation
Transducer Installation
GPS Receiver Instrallation
Antenna Installation
Connection
Powering
Using Instruction
Some warnnings
What’s on the display
Key Function
Quickly Operation
Start Using
Set HOME position
Save a waypoint
Go to target waypoint
Import KML
Go back
Menu Opertion
Basic
Sensivity
Surface Clarify
Fish ID. Sens
Background
Color Adjust
Color Style
Advanced Mode
Sonar
Depth Range
2
5
6
7
7
10
12
13
15
17
17
18
19
20
22
22
22
23
24
25
26
26
26
26
26
27
27
27
27
28
28

3
Sonar Gain
Load New Color
Overlap Data
Depth Oset
Temp. Oset
Shallow Alarm
GPS SETTINGS
GPS Filter
Distance Unit
Speed Unit
Time Zone
24-Hour Time
Sample Step
Arrive Alarm
Calibrate compass of display
Calibrate compass of boat
Autopilot
Wirling Test
Boat Type
Channels Reverse
Channel 1 Speed
Channel 2 Speed
Steering Sens.
System
Simulator
Backlight
Key Tone
Language
Baud Rage
Battery Alarm
Boat Vtg. Alarm
Default Settings
System Info.
Radio Bind
28
28
28
28
29
29
30
30
30
30
30
30
31
31
31
32
33
33
33
34
34
34
34
35
35
35
35
35
35
36
36
36
36
36

4
Update R-Boxes.
Quick Qperation
Quick Marker
Waypoint
Route
Go back
Set Home Pos.
Go to Home
Stop Autopilot
Clear Map
Import KML
Overlap Data
Specications
Warranty
Unit Care
FAQ (Frequenly Asked Questions)
36
38
38
39
40
41
41
41
41
41
41
42
43
44
45
46

5
Overview
TF740 is an ALL-IN-ONE Autopilot navigation and sonar system,
which was specially designed for all kinds of bait boats.
Push-Go Key (shortcut)
Pick Up Waypoint form Map
KML Import to Dene Lake Boundary
Two Propellers Boat Support
Propeller & Rudder Boat Support
Steering Sensitivity Adjustable
Built-in Lithium battery Charger
Hardware Gain Adjustable
Color Route to Indicate Depth (2D Map)
Advanced radio system (FHSS/DSSS)
What’s the advantage of TF740?
The TF740 was specially designed for bait boats. It was combined with wireless
Sonar, High Position accuracy GPS and Autopilot.
The advanced sonar features show you actual bottom condition and ish. The
autopilot function can automatically guide the boat to saved waypoint precisely,
which make it possible to use the boat under bad condition, such as night, heavy
fog, etc.

6
Check the content
3
1
2
15
15
14
14
45
12
12
13
13
11
11
10
10
6
7
89
1.Display
2. SonarBox-740w
3. Autopilot CCU740
4. XGPS 740
5. Transducer
6.Rubber for transducer
7. SonarBox extending cable
8. Power cable
9. Servo cable
10. Antenna for boat
11.Antenna for display
12. Bracket of GPS receiver
13. Screws (4pcs)
14. Valco
15. Antenna extending cable

7
Transducer Installation
1) for XBOAT730
Installation
Transducer
Mounting Instruction Transducer Knob
Rubber
Screw down the 2 screws to
loose the battery support
1
take the knob and fake
transducer down
3
screw tight the knob
5installation was nished
6
hold the transducer(with
rubber) through the boat
4
loose the knob of xed fake
transducer by hand
2

8
2) for general bait boats ( like Carp Madness, Viper, etc)
For these bait boats, there is no transducer groove on the bottom housing. So, you
need to drill a hole on the boat bottom to x the transducer.
3) for bait boats of Carplounge/Waverunner/Vegaboat/Carp, etc
For these bait boats, there is a transducer groove on the boat bottom. So, you only need
to simply match the transducer to the boat with a rubber.
Transducer
Knob
Rubber
Transducer
Mounting Instruction
1) Choose a proper position
2) Drille a hole (14mm) on the
selected position.
3) Assemble the transducer
and rubber.
4) Hold the assembled
transduer and rubber through
the housing. Then use the knob
to screw tighten the transducer
from the inner housing.
5) The nished installation.
1
2
3 4 5
keep the sharp end the same
direction with head of
boat

9
4) for Anatec catamaran bait boat
For the boat, you only need simply match the transducer to the boat with the rubber
Transducer
Mounting Instruction
1) Take o the transducer
cover from the boat.
2) Assemble the transducer
and rubber.
3) Hold the assembled
transduer through the groove.
4) Use the knob to screw
tighten the transducer from
the inner housing.
5) The nished installation
1
2
3 4 5
keep the sharp end the same
direction with head of
boat
Transducer
Knob
Rubber

10
1) for XBOAT730
GPS receiver Installation
Transducer
GPS receiver Screws
GPS bracket
Take the GPS lid down from
XBoat
1
Slid the GPS receiver to the
GPS lid
3Hold the assembled GPS receiver
and lid going through the boat
4
Fix the GPS bracket on the
GPS lid
2

11
Note: when begin installing the GPS receiver, some key points should be noted:
1) The antenna for transmitter should be at least 30cm away from any other antennas.
2) The GPS receiver should be mounted where is far away from any magnet things,
such as icro, nickel, etc. Which may cause interference of compass.
3) The icon of arrow on the GPS receiver should be oriented in the same direction
with the heading direction of boat.
4) After the installation, please check the compass. If you nd the compass does not
show proper direction, please calibrate the compass by manual operation. For the
details, please refer to page 31 (Calibrate Compass of Boat).
1
2
3
4
2) for general bait boats ( like Anatec, Vegaboat, etc)
Find a proper location on the boat, then x the GPS bracket on the boat. And nally
install the GPS receiver on the bracket.

12
Following is the instruction to install the antenna on boat:
1) Choose an proper installation position.
2) Drill an hole (5mm diameter) on the selected position.
3) Screw down the wisher and nut from the antenna extended cable.
4) Hold the DC cable through the hole from inner housing, then put the
wisher and the nut.
5) Screw tighted the nut by an wrench.
6) Finally, screw the antenna on the boat.
Screwing the antenna to the boat will be ok.
for display
for transmitter
for display
2) for general bait boats ( like Anatec, Vegaboat, etc)
1) for xboat730
Install antenna for transmitter
In the package, you can nd 2 antennas. one is for
transmitter, another is for display.
d
ed
c
ab
le
Antenna Installation
Knob
Install Antenna
on boat
Instruction
1
antenna extended cable antenna for transmitter
23
45 6

13
Connection
After all the installatiion are nished, please make the connection as following ture.
Sonar Box
Autopilot CCU
Power
(DC 12V)
Signal port
to servo / ESC of boat
to remote receiver to Sonar Box-740W
to antenna

14
Connection of CCU-Autopilot
connected to
SonarBox-740w
Port B is connected to
Reciver of the remote
Port A is connected to Speed
Contorller(ESC) or Servo
The following gures instruct how to connect the Autopilot CCU740 with your bait boat.
The system could control most 2 engineers or 1 engine (with rudder) boat with proper
settings.
Xboat mode ESC of Right Motor ESC of Left Motor
2 Engines ESC of Right Motor ESC of Left Motor
1 Engine ESC Servo
channel-3 channel-1
channel of right Motor channel of left Motor
channel of ESC channel of servo
Port A
Transmitter connection & function
Port B

15
Recomended voltage
Absolute Maximum voltage
For display
9-15V
16.0V
For transmitter
6-12V
14.8V
There are 2 ways to power the TF740 display
1) Use a inner 3S lithium (12.6v) battery pack as shown in the picture.
2) Use a outer lithium battery
Note:
3S Lithium battery is optional (users can buy it from local dealer)
DC15V /1A wall-charger support (optional)
The device work while battery-charging support
indicator LED of working
3S lithium battery pack
1) charging port
2) outer battery connection
indicator LED of working
Powering

16
Battery Type
12V Lead-acid
8*AA NiMH
8*AA Alkaline
2S Lithium
3S Lithium
4S Lithium
Voltage
10.8v~14.8V
7.8V~10.6V
7.5V~12.8V
5.6~8.4V
8.4~12.6V
11.2V~16.8V
Permission
12V
lead-acid
8AA
NiMH
8AA
Alkaline
2S
Lithium
3S
Lithium
4S
Lithium
Note: overvoltage may burn the elements in the device!
From bellow shows the voltage range of the most popular batteries in the market:

17
Using instruction
Special Notications
Before you start using the device, there is something you should know:
1) please do not put the display on ground
during the operation, which could cause a
short R/C distance.
The proper way is using an tripod to
support the display, and keep it at least
1.2m above the ground.
2) Please turn on the SonarBox and X-Pilot
CCU rst, then turn on the display. Otherwise
the display will indicate an error message as
following:
3) Please start using the device only when the Satellite Number reach more than 7,
which means the GPS signal is strong enough.
Note: the most satellite number
TF740 can reach is 12.
Radio module......Fail
Sonar module......Fail
GPS module......Fail
Compass module......Ok
Autopilot module......Fail
System check
Satellite Number

18
What’s on the display
Depth
readout
Water temp
Voltage of
bait boat
SD Card in
Strength of
Radio signal
Distance
to Home
Time
Speed
of boat
Voltage of
display
Depth range
at bottom
Fish symbol
Structure
Indicator of
Boat heading
direction
Number of satellite
Distance to Target
Autopilot mode
Remote mode
Surface
clutter
Route of boat
Note: on the route, dierent
color means the depth
changing of the water while
the boat is running.

19
MENU Open Menu settings( Basic, Sonar, and GPS SETTINGS, AUTOPILOT, SYSTEM).
PUSH-GO Used to quickly enter into waypoint or go home by one-button pusing.
KEYPAD Selects items on menus; increase & decrease a value of option.
POWER Turns unit on/o. Also be use to quit a menu setting.
PAGE
ENTER
ZOUT /ZIN Used to zoom out GPS route on the screen.
Used to switch between main menus or some sub menus.
Finalizes menu selections; conrm a setting.
ENTER key is also used to quickly enter into GPS Operation menu.
MENU
ZOUT/ZIN KEYPAD
PAGE
POWER PUSH-GO ENTER
Key Function
