Touchstone 40001 User manual

Model # 40001
CITADEL Pyramid Heater

WARNING
This product can expose you to chemicals
including carbon monoxide which is known to the
State of California to cause birth defects or other
reproductive harm. For more information go to
www.P65Warnings.ca.gov.
All screws come preinstalled in related parts.

3

(Top: 32 in Side: 26 in)
4

5

Not Provided
M5X8
screws
20 3
3
21 Reflector Studs
+
Wing Nut
6

1.Attach wheels (10) to bottom plate (1) . 2.Locate the propane cylinder bracket (11) and
attach it on the bottom plate with 3 bolts and nuts
provided with the bracket.Use the M8x45 screw to
secure the propane cylinder.
3.Connect and fix the 4 lower support (6) to the
bottom plate(1) and middle plate (3) with
screws (19).
4.Connect 4 upper supports (5) to the lower
supports (6) with screw (19), then fix the
damper with screws (19).
Hardware Used: 4x Bolts and Nuts
(pre-assembled)
Hardware Used: 20x Screws
Hardware Used: 3x Bolts and Nuts
(pre-assembled to Brackets)
Hardware Used: 12x Screws
Opening on Base is opposite
side of wheels. Note location
of door guides on bases
7

5.Unscrew the red igniter button on the control
box and insert the AA battery (17) with the
POSITIVE end facing upward.Then attach the
control box (2) underneath the middle plate (3)
with screws (19).
6.Carefully put the glass tube (7) up through the center
of the hole in the upper plate (4).Make sure the rubber
ring (18) is attached on the lower end of the glass tube.
Now place the glass tube through the hole on the middle
plate (3). Check to ensure the glass tube covers the center
hole of the middle plate.
Hardware Used: 1x AA Battery
4x Screws
Hardware Used: 1x Rubber Ring
(Not Included)
Opening on Base is opposite
side of wheels. Note location
of door guides on bases
8

7. Attach the bolts onto the damper (4),and put 3pcs
washer onto the bolts,then put the reflector (8)
onto the bolts,put 3pcs washer through the bolts
and fix with screws
8.Attach the protection guards (9) to the upper frame by
inserting the hooks at the top of the guards into the holes
on the supports. Repeat at the bottom of the supports.
Secure the protection guards to the top of the supports
with the fixing brackets(12) and screw in place.
9.Fix the sides panels (13) with the screws (19).
Note:Do not cover the side where the control knob is.
Hardware Used: 3x Studs
3x Wing Nuts Hardware Used: 4x Screws
Hardware Used: 12x Screws
Remember to remove
protective film from reflector.
9

10.Screw the handle (15) on the front panel (14) - attach the panel
by inserting its two hooks into the holes on the bottom plate.Hook
the chain (16) to the hole in the control box,then close the panel
to the middle plate - the panel is attached by the magnets.
Tips:the chain can hole the panel while operating the control.
10

OFF
PILOT
LO
HI
HI
LO
OFF
3. Check for the pilot flame through the glass tube. If the pilot does not light, press and
turn the
your LPG cylinder when the heater is not in use.
11

12

AA battery is missing or dead Replace AA battery
13
