TouchTunes PowerPack 725 Quick start guide

1 of 14
Contents
About This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Recommended Tools and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking and Checking Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PowerPack 725 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Speaker Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contacting TouchTunes Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
About This Document
This document is intended for:
•Operators of TouchTunes digital jukeboxes.
•TouchTunes Field Service, Customer Support, and Sales personnel.
It explains how to install the TouchTunes PowerPack 725 Powered Subwoofer. Installing the PowerPack 725
Powered Subwoofer involves special safety considerations. It is therefore strongly recommended that you review
this guide thoroughly before you begin.
Installation Notes
TouchTunes PowerPack 725 Powered Subwoofer
(TouchTunes p/n 700723-001)
October 2012
900715-001 Rev. 00

2 of 14
Important Safety Information
•Read all safety instructions before installing this product.
•Keep all instructions for future reference.
•Heed all warnings.
•Follow all instructions.
CAUTION: The PowerPack 725 Powered Subwoofer bass box is heavy and represents a serious safety
hazard if its mounting system should fail. Therefore, installation should only be performed by an
experienced installer or licensed contractor that is familiar with standard rigging, mounting, and hanging
practices, as recognized by a licensed engineer or governmental agency in your area.
CAUTION: Do not install PowerPack 725 components near any heat sources, such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
CAUTION: Do not defeat the safety purposes of the grounding-type plug. A grounding-type plug has two
blades and a third grounding prong. The wider blade or the third grounding prong are provided for your
safety. If the provided plug does not fit in your outlet, consult an electrician for replacement of the obsolete
outlet.
CAUTION: Unplug this apparatus when unused for long periods of time.
Do not use this apparatus near water or moisture—Do not use this product near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, near a swimming pool, or anywhere else that water or
moisture are present.
Clean only with a dry cloth—and as directed in this document. Unplug this product from the wall outlet
before cleaning.
Do not block any ventilation openings. Install in accordance with these instructions—To ensure
reliable operation of the product and to protect it from overheating, put the product in a position and
location that will not interfere with its proper ventilation. For example, do not place the product on a bed,
sofa, or similar surface that may block the ventilation openings. Do not put it in a built-in system, such as a
bookcase or a cabinet that may keep air from flowing through it ventilation openings.
Do not let objects or liquids enter the product—as they may touch dangerous voltage points or short-
out parts that could result in a fire or electric shock.
Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Use only attachments and accessories specified by TouchTunes.
Refer all services to qualified service personnel. Service is required when the apparatus has been
damaged in any way: such as power-supply cord or plug is damaged; liquid has been spilled or objects
have fallen into the apparatus; the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
To disconnect this apparatus you must unplug it from the wall outlet, therefore ensure during installation
that the plug will be accessible after installation to facilitate disconnecting it from the wall outlet or
equivalent.

3 of 14
Note: Unauthorized modification of the PowerPack 725 Powered Subwoofer could void the user's authority to
operate this equipment.
Note: The PowerPack 725 Powered Subwoofer was specifically designed for use with the DA950-U amplifier. The
older DA-415 amplifier should not be used as a replacement, as it was not designed for use inside the PowerPack
725.
Recommended Tools and Equipment
The following list shows tools that you may require to install the PowerPack 725 Powered Subwoofer. Ensure that
you have all tools before beginning installation.
•Philips #2 screwdriver
•Small flat-head screwdriver
•Cable clips and cable ties.
•Pre-wired Cat-5 network cable (or cable, crimp tool and RJ-45 connectors) to connect the jukebox
computer to the amplifier.
•Flashlight, to facilitate installation in low-light situations.
Unpacking and Checking Components
The PowerPack 725 Powered Subwoofer ships in a single box. After unpacking, if it appears to be damaged in any
way, do not attempt to use or install it. Notify TouchTunes or your local distributor immediately.
Verify that you have received the following components:
Dimensions and Weight
Bass Box
To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, integral
convenience receptacles.
PowerPack 725 Powered Subwoofer (p/n 700723-001)
1 Bass box, (p/n 700723-001) including:
1 DA950-U digital audio amplifier
1 AC Power Cord
2 Euroblock connectors, pre-installed onto DA950-U amplifier
1 Cat-5 patch cable, 50 ft.
1 This document (p/n 900715-001)
Height Width Depth Weight
Crated 23” 30” 16” 80 lbs.
Uncrated 19.7” 26.6” 12.8” 75 lbs.

4 of 14
Specifications
Sub-woofer
•Amplified sub-woofer
•Sealed-enclosure design for clean and crisp sound
•2 low-frequency woofers, 10in., 250 W each
Amplifier
•Class-D Architecture
•Dynamic range of 117dB
•Over-current protection
•Thermal protection shutdow
•Mute input
•Turn-on and turn-off pop suppression
•High speed switching power supply
•Total harmonic distortion ≤0.002% (1W)
•Signal-to-noise ratio ≥100dB (A-weighted)
•One balanced input supporting daisy-chaining
•3-Channel mode: One stereo output (midrange and high frequencies) and one bass output (low frequency)
•AC line voltage and frequency configurations: 100 to 120V AC
•Subwoofer: 475W at 4 ohms
•Satellites: 125W per channel at 4 ohms (minimum recommended impedance)
•Satellites: 65W per channel at 8 ohms

5 of 14
PowerPack 725 Components
The PowerPack 725 Powered Subwoofer has been specifically designed for use with TouchTunes jukeboxes. This
speaker system features a bass box module with a built-in DA950-U 3-channel digital audio amplifier. The
PowerPack 725 Powered Subwoofer can be mounted to the wall using a UL-listed VESA wall-mounting bracket,
properly rated for supporting at least 75lbs and properly secured.
The PowerPack 725 Powered Subwoofer components are shown below.
PowerPack 725 Powered Subwoofer Components
PowerPack 725 Powered Subwoofer
Category 5 cable
AC Power Cord
(50 ft.)
with integrated DA950-U amplifier

6 of 14
General Operating Instructions
Power ON/OFF
The PowerPack 725 Powered Subwoofer does not have a power switch. The TouchTunes jukebox turns the PowerPack
725 Powered Subwoofer on and off.
Tone controls and DSP Equalization
Bass and treble adjustments are made using the sound mixer controls in the TouchTunes jukebox.
Note: When first setting up the PowerPack 725 Powered Subwoofer at a location, set the jukebox’s tone controls to flat,
initially, and turn off the software EQ option (“DSP EQ” on JCB-based jukeboxes or “Bass Boost” on Virtuo SmartJukes) to
test with a “vanilla” signal. You can then adjust the tone controls or activate the software EQ option as required.
TouchTunes strongly recommends that you listen to a variety of different music selections and genres, at the lowest and
highest volumes you intend to permit for use at your locations, before finalizing these settings.
Remote volume control
The volume control for the PowerPack 725 Powered Subwoofer is located in the sound mixer screen on the TouchTunes
jukebox‚ and on the RF remote control included with the jukebox. Do not attempt to wire an in-line volume control into the
category 5 cable.
Speaker Placement
Optimum performance of your PowerPack 725 Powered Subwoofer is determined by placement of the system
components. Follow the general guidelines below to ensure the best possible performance from your system.
Bass Box Placement
The PowerPack 725 bass box can be placed with one side against a wall. Either side is acceptable, all that is required is to
route the cables to come out on the appropriate side. Avoid placing the bass box’s port openings directly against a
reflecting surface. For best results place the side with the port openings at least six inches from the wall. Make sure the port
openings are not covered in any way and are at least three inches away from objects.
Bass Box Placement
6 inches
(minimum)

7 of 14
TIP:As a rule of thumb for placing bass reflecting speakers, the distance between the bass port and the reflecting
surface should be approximately equal to the size of the bass port itself.
For best results, do not position the bass port more than 12 inches away from the reflecting surfaces.
Using greater distances will result in diminished bass response.
Satellite Speaker Placement
Follow the recommendations that came with the satellites you will be using. Here are some general considerations
to keep in mind when positioning and installing satellites:
•Satellite speakers work best when located in corners.
•Keep a satellite speaker within 25 feet of any listener.
•Do not position satellite speakers more than 25 feet away from the bass box.
•Mount satellite speakers between 6 feet and 12 feet high.
•Define the listening area and aim the satellite speakers towards the center of the listening area.
•Always maintain a minimum of 4 feet between satellite speakers.
•In 4-satellite configurations, to maximize stereo coverage, if the two satellite speakers for one channel
are to be placed less than 20 feet apart, they should both be placed on one side of the listening area
(in left-left, right-right order). If the two satellite speakers for one channel are to be placed more than 20
feet apart, they should both be alternated with the opposite channel satellites (in left-right, left-right
order).
•Do not aim satellite speakers directly into a corner.
•When placing satellite speakers near the intersection of two walls and a ceiling, use unequal distance
spacing from vertical and horizontal surfaces. Example: 2 feet from the ceiling and 1 foot from adjacent
wall.
•For stereo installations, satellites must be within 25 feet of each other.
Installation
Wall-mounting the Bass Box
The PowerPack 725 Powered Subwoofer is designed to be wall-mounted using a VESA-standard wall-mount
bracket of the same kind used for wall-mounting flat-screen HDTVs, which must be UL-rated to support at least 75
pounds.
Note: It is the installer’s responsibility to choose a position, mounting method, and fasteners consistent with local
building codes and regulations.
DA950-U Amplifier Connector Panel
The DA950-U amplifier installed in the PowerPack 725 Powered Subwoofer’s bass box is shown in the figure
below.
CAUTION: The PowerPack 725 bass box is heavy and represents a serious safety hazard if its mounting
system should fail. Installation of the mounting system should only be performed by an experienced
installer or licensed contractor who is familiar with standard rigging, mounting and hanging practices as
recognized by a licensed engineer or government agency in your area.

8 of 14
Note: The DA950-U amplifier provides RJ45 input and output connectors to enable daisy-chaining of components.
R L R L
+ - + - + - + - + - + -
R L
1
3
8
7
5
4
10
9
2
6
DA950-U Amplifier
1. Power connector: Connect the supplied power cord here. The DA950-U will automatically turn on when the power
cord is plugged into a wall outlet (AC 120V /60Hz MAX 1000W). There is no power switch.
2. Power / Settings Lights:
•Bass Boost: Lights up when bass boost is on. Should always be on while this amplifier is in use inside the
PowerPack 725.
•3-CH Mode: Lights up when 3-channel mode is on. Should always be on while this amplifier is in use inside the
PowerPack 725.
•Power Amp #1: Lights up when power amp #1 is on
•Power Amp #2: Lights up when power amp #2 is on
3. Protection mode indicators, channels #1 and #2: lights up when a channel has gone into over-current protection
mode or thermal protection mode.
4. Balanced audio input/output connectors (unused in this configuration)
5. Balanced audio input/output connectors: Two RJ45 connectors are provided to connect the DA950-U to a jukebox
and/or other audio equipment via standard category 5 cable. Wired in parallel. One should be used as input, and the
other can then be used as a "thru" connection.
You can purchase pre-wired cable, or you can wire your own cable as follows:
RJ45 Cable Wiring
6. Satellite speaker outputs: The two connectors, wired in parallel. Provides two channels (stereo) of output, making it
easy to wire up to two speakers per channel for a total of four speakers. 125W / 4 ohms per channel.
CAUTION: Do not connect the AC power cord to a wall outlet until all audio
connections have been completed.
1
2
3
4
5
6
7
8
white + orange
orange
white + green
blue
white + blue
green
white + brown
brown
white + orange
orange
white + green
blue
white + blue
green
white + brown
brown
1
2
3
4
5
6
7
8
Near
End
Color Color
Far
End
Straight-through category 5 cable wiring RJ45 connector

9 of 14
7. Speaker outputs (unused in this configuration)
8. Bass channel audio output connector: Provides audio out at 475W / 4 ohms for the subwoofers inside the
PowerPack 725.
9. Bass Boost: Activates bass boost when pushed in. Must be left permanently on while this amplifier is used by
the PowerPack 725.
10. Channel Mode: 3-channel mode when pushed in, 4-channel mode otherwise. Must be kept permanently set to
3-channel mode while this amplifier is used by the PowerPack 725.
Making Connections
Your PowerPack 725 Powered Subwoofer is shipped without external satellite speakers and is designed for you to
use your own satellites. Two 4-terminal Euroblock connectors are included to connect your satellites to the
jukebox’s amplifier. These Euroblock connectors are preinstalled on the DA950-U amplifier.
This section explains how to make connections between the jukebox computer, EQ box, PowerPack 725 3-channel
amplifier, external satellite speakers, and bass box.
1. Remove the grille from the amplifier side of the bass box by unfastening the eight (8) screws, and put the grille
aside
Routing channel
(on both sides
of bass box)
.
Removing Grille to Expose the Amplifier
Note: Pass all cables through the cable routing channel of the bass box.
2. Unlock and open your jukebox. Decide which Zone output you wish to use with the PowerPack 725.

10 of 14
3. Connect the category 5 cable with RJ45 connectors from the chosen Zone output on the jukebox computer to the input
connector on the amplifier inside the PowerPack 725.
JCB
R L R L
+-+- +-+- + - + -
R L
DA950-U Amplifier
(Inside PowerPack 725)
MJS
- OR -
Virtuo I/O Board
Connecting the Jukebox Computer to the Amplifier
4. Prepare the satellite speaker cables by stripping the ends of their connector wires, exposing approximately 1/4” of wire.
5. Locate the supplied four-slot Euroblock connector for the satellite speakers.
6. Loosen the screws along the top of the connector using a flat-head screwdriver, if necessary.
Overhead view
Euroblock terminals

11 of 14
7. Wire the ends of the satellite speaker wires to the Euroblock connector and ensure correct polarity (it is
standard to use red for positive and black for negative.) Using a flat-head screwdriver, tighten the screws to
secure the speaker cables to the connector.
8. If it was not already done, connect the PowerPack 725 subwoofer to the DA950-U by pressing its connector
into the bass channel audio output connector (6) on the amplifier.
9. Optional: Connect the DA950-U to other audio equipment (for example, another PowerPack 725 Powered
Subwoofer) using a standard category 5 cable with RJ45 connectors. See “Daisy-Chaining PowerPack 725
Powered Subwoofers” on page 11.
10. Power up the unit by connecting the power cord between a properly grounded wall outlet (AC 120V /60Hz MAX
1000W) and the power connector on the amplifier.
Daisy-Chaining PowerPack 725 Powered Subwoofers
The PowerPack 725 Powered Subwoofer provides daisy-chaining capability, enabling you to connect additional
PowerPack 725 systems to achieve increased sound coverage for large areas.
The following figure illustrates how to daisy-chain multiple PowerPack 725 Powered Subwoofers.
Daisy-Chaining PowerPack 725 Powered Subwoofers
Caution: Review your speaker circuit, and ensure that the resulting impedance is in the range
between 4 and 8 ohms. Values outside this range will result in either poor performance, or the
amplifier’s over-current and/or thermal protection to activate, preventing audio output.
from Jukebox
to another amplifier

12 of 14
Up to 10 PowerPack 725 Powered Subwoofers can be daisy-chained for a single zone in this manner.
Note: Best results are achieved by using only PowerPack 725 Powered Subwoofers—whose EQ curve has been tailored
specifically for that system—in a daisy-chained configuration.
Although other types of amplifiers can be used, the resulting sound quality may be unpredictable. In addition, the use of
other amplifiers will require using a Line-Out DI box (not included), which may be ordered from TouchTunes (p/n 700168-
002).
Care and Cleaning
To clean your speakers, dust them with a clean, dry cloth or vacuum cleaner attachment. Never use abrasives, solvent-
based cleaners, or harsh detergents.
If you wish to use a cleaner, apply onto the cleaning cloth, not directly onto the product. Test a small area first, as some
cleaning products may damage some of the surfaces.
Do not use cleaning agents on the drive units.
Warranty Information
TouchTunes warrants this product to be free from defects in materials and workmanship (subject to the terms set forth
below) for a period of 1 year from the date of purchase. During the warranty period, TouchTunes will repair or replace (at
TouchTunes’ option) this product or any defective parts.
To obtain warranty service, please call TouchTunes for instructions. (See “Contacting TouchTunes Support” .) You will
require a Return Authorization (RA), and you will need to ship this product in either its original packaging or packaging
affording an equal degree of protection.
•Before a purchaser ships a product back to TouchTunes™, the purchaser must obtain a valid RA number.
Boxes received without an authorized RA Number shall be shipped back.
•Authorized RA Numbers shall expire 30 days after they are issued.
•Only the TouchTunes product and quantity specified on the original RA request can be returned with the RA
Number issued.
•If returning additional products to TouchTunes™, a new RA Number shall be required.
•If TouchTunes receives a shipment containing products not authorized for return on that RA Number, we shall
return them as is.
This warranty is invalid if:
•The factory-applied serial number has been altered or removed from this product, or
•This product was not purchased from TouchTunes or an authorized distributor.
This warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, acts of God, accident,
commercial use or modification of, or to any part of, the product. This warranty does not cover damage due to improper
operation, maintenance or installation, or attempted repair by anyone other than TouchTunes. Any unauthorized repairs will
void this warranty.

13 of 14
Copyright © 2012 TouchTunes Interactive Networks
TouchTunes Interactive Networks, Inc.
400 Sainte Croix Avenue, Suite 200 E
Montreal, Quebec,
Canada, H4N 3L4
TouchTunes Interactive Networks, Inc.
3455 Salt Creek Lane, Suite 100
Arlington Heights, IL 60005
USA
Technical Support
847-353-1954
www.touchtunes.com
Contacting TouchTunes Support
If you need help with or have questions about this document, contact TouchTunes by:
•Using the email links on the Contacts page on the TouchTunes Dashboard at
https://operator.touchtunes.com.
•Calling TouchTunes 24/7 Service Hotline at 847-353-1954.
To help us assist you more effectively with problem reports, the following information may be required when
contacting TouchTunes Support:
•Jukebox ID
•Jukebox model (e.g., Virtuo, Allegro MX-1, Ovation II).
•The serial number of any component you believe to be defective.
•The date/time of the problem.
•Actions performed immediately before the problem occurred.
•Any additional comments.
If you require assistance with this or any other TouchTunes product, please call or email technical support. We
value your comments.

14 of 14
